TASKalfa 3554ci/6054ci/7004i Device Setup Procedure

2021-06-04 V1.7

Kyocera Document Solutions Inc.

Masaki Sone

[Introduction]

This document describes an overview of device setup installation.

Please refer to the Service Manual for detailed instructions.

The device is divided into three boxes.

･Main Body : TASKalfa 3554ci

･Document Processor : DP-7140

･Option Cassette : PF-7150

The Additional device is also divided into three boxes for each.

･Main Body : TASKalfa 6054ci

･Document Processor : DP-7160

･Option Cassette : PF-7150

･Main Body : TASKalfa 7004i

･Document Processor : DP-7150

･Option Cassette : PF-7150

You don't need to reuse the wooden frame, but please keep the cardboard box

because you need it if you send it again. (However, you don’t need to return this device

to us.)

[Setup Procedure 3554ci]

STEP1

First of all, connect the Main Body and the Option Cassette. The Option Cassette has

rollers, so it will be easier to move if you connect it first.

Please open the Option Cassette cardboard. This is the base. (It's a medium size

cardboard.)

For information about opening, refer to 2-40 (page 92) in the Service Manual.

Please open the Main Body cardboard. (Largest size cardboard.)

For information about opening, refer to 2-4 (page 56) in the Service Manual.

After opening each one, connect the option cassette under the main body.

Refer to 9-55 (page 1786) in the Service Manual for installation instructions.

Basically, it is possible to connect by just putting the main body on the option cassette.

However, be careful not to break the connector when putting the main body on the

option cassette.

According to the service manual, it is a procedure to screw after connecting, but it is

not necessary.

STEP2

Next, connect the Document Processor on the Main Body.

Please open the Document Processor cardboard. (It's a minimum size cardboard.)

For information about opening, refer to 2-44 (page 96) in the Service Manual.

After opening one, connect the document processor on the main body.

Refer to 9-169 (page 1900) in the Service Manual for installation instructions.

Basically, it is possible to connect by putting it on the main body and insert the

connecter.

Two back covers must be opened to insert the connector.

STEP3

When the above steps are completed, the physical connection is finished.

[Note:] This device is for 100V, so be sure to connect it to 100V (or 120V) power supply.

If connect it to 200V by mistake and press the main switch, there is high risk of device

broken.

Plug in the power supply and press the main switch to start it up.

*If shows any error screen on the operation panel, the connection may be incorrect.

Please turn the power off and check the connection again.

Please check the Document Processor and Option Cassette are running by following

operation:

[Document Processor]

Place the document on the Document Processor and start a single copy. If the

document is scanned from the Document Processor, it is working properly.

[Option Cassette]

Set only the Option Cassette with A4 Paper.

Place the document on the Document Processor and start a single copy. If the paper

is fed from the Option Cassette, it is working properly.

*If it doesn't work, please turn the power off and check the connection again.

This completes the setup as a device.

There is a limit to the amount of Toner, so please refrain from large printing/coping as

much as possible.

[Setup Procedure 6054ci]

STEP1

First of all, connect the Main Body and the Option Cassette. The Option Cassette has

rollers, so it will be easier to move if you connect it first.

Please open the Option Cassette cardboard. This is the base. (It's a medium size

cardboard.)

For information about opening, refer to 2-2 (page 103) in the Service Manual.

Please open the Main Body cardboard. (Largest size cardboard.)

For information about opening, refer to 2-4 (page 63) in the Service Manual.

After opening each one, connect the option cassette under the main body.

Refer to 9-89 (page 2169) in the Service Manual for installation instructions.

Basically, it is possible to connect by just putting the main body on the option cassette.

However, be careful not to break the connector when putting the main body on the

option cassette.

According to the service manual, it is a procedure to screw after connecting, but it is

not necessary.

STEP2

Next, connect the Document Processor on the Main Body.

Please open the Document Processor cardboard. (It's a minimum size cardboard.)

For information about opening, refer to 2-5 (page 106) in the Service Manual.

After opening one, connect the document processor on the main body.

Refer to 9-168 (page 2248) in the Service Manual for installation instructions.

Basically, it is possible to connect by putting it on the main body and insert the

connecter.

Two back covers must be opened to insert the connector.

STEP3

When the above steps are completed, the physical connection is finished.

[Note:] This device is for 100V, so be sure to connect it to 100V (or 120V) power supply.

If connect it to 200V by mistake and press the main switch, there is high risk of device

broken.

Plug in the power supply and press the main switch to start it up.

*If shows any error screen on the operation panel, the connection may be incorrect.

Please turn the power off and check the connection again.

Please check the Document Processor and Option Cassette are running by following

operation:

[Document Processor]

Place the document on the Document Processor and start a single copy. If the

document is scanned from the Document Processor, it is working properly.

[Option Cassette]

Set only the Option Cassette with A4 Paper.

Place the document on the Document Processor and start a single copy. If the paper

is fed from the Option Cassette, it is working properly.

*If it doesn't work, please turn the power off and check the connection again.

This completes the setup as a device.

There is a limit to the amount of Toner, so please refrain from large printing/coping as

much as possible.

[Setup Procedure 7004i]

STEP1

First of all, connect the Main Body and the Option Cassette. The Option Cassette has

rollers, so it will be easier to move if you connect it first.

Please open the Option Cassette cardboard. This is the base. (It's a medium size

cardboard.)

For information about opening, refer to 2-2 (page 101) in the Service Manual.

Please open the Main Body cardboard. (Largest size cardboard.)

For information about opening, refer to 2-3 (page 61) in the Service Manual.

After opening each one, connect the option cassette under the main body.

Refer to 9-56 (page 2356) in the Service Manual for installation instructions.

Basically, it is possible to connect by just putting the main body on the option cassette.

However, be careful not to break the connector when putting the main body on the

option cassette.

According to the service manual, it is a procedure to screw after connecting, but it is

not necessary.

STEP2

Next, connect the Document Processor on the Main Body.

Please open the Document Processor cardboard. (It's a minimum size cardboard.)

For information about opening, refer to 2-4 (page 123) in the Service Manual.

After opening one, connect the document processor on the main body.

Refer to 9-135 (page 2435) in the Service Manual for installation instructions.

Basically, it is possible to connect by putting it on the main body and insert the

connecter.

Two back covers must be opened to insert the connector.

STEP3

When the above steps are completed, the physical connection is finished.

[Note:] This device is for 100V, so be sure to connect it to 100V (or 120V) power supply.

If connect it to 200V by mistake and press the main switch, there is high risk of device

broken.

Plug in the power supply and press the main switch to start it up.

*If shows any error screen on the operation panel, the connection may be incorrect.

Please turn the power off and check the connection again.

Please check the Document Processor and Option Cassette are running by following

operation:

[Document Processor]

Place the document on the Document Processor and start a single copy. If the

document is scanned from the Document Processor, it is working properly.

[Option Cassette]

Set only the Option Cassette with A4 Paper.

Place the document on the Document Processor and start a single copy. If the paper

is fed from the Option Cassette, it is working properly.

*If it doesn't work, please turn the power off and check the connection again.

This completes the setup as a device.

There is a limit to the amount of Toner, so please refrain from large printing/coping as

much as possible.

[for the Security Test]

Make sure the hard disc is installed or not before starting the test by viewing [Device

Information] on the home screen of the device operation panel. If the hard disc is

installed, “Large Capacity Storage: HDD320GB” is displayed. If not, “Large Capacity

Storage:Not Installed” is displayed.

One fax option is missing. Remove it from the device already tested and install it on

the new device. Only need to reseat the fax board, but refer to the Installation Guide

in the Service Manual.

(The device already has a hard disc drive and fax option installed. That is, it is a “with

HDD model”. Also, the current version of firmware is not latest. We will give you the

firmware after the developer tests are complete, so please update when you start the

test.)

If change “the SSD model”, you just need to remove the hard disc drive. To remove

the hard disc drive, open the back cover and disconnect the hard disc drive connector

cable. There is no need to physically remove the hard disc drive.

The settings remain at almost default values.

Please refer the Operation Guide for how to set up each function.

First, configure only the TCP/IP settings for your network on operation panel and

connect to the Command Center RX from your PC's web browser by IP address (e.g.

https://192.168.0.1). This will make the rest of the setup easier.

*Instead of setting up a network with enhanced security, it is recommended that

you first connect at the default level and make sure it works.

In addition, since the storage encryption function is inactive, the encryption function

must be activated from the “system menu > option setting” of the operation panel.

However, once activated, it cannot be deactivated again.

Please contact us if you have any questions. We will update this document in

consideration of the future.

[Other setup information]

･Command Center RX default password

From this product, the default password to access from Command Center RX (Web

browser) has been changed.

ID: “Admin”

Pass: Serial Number of each device

You can confirm the serial number to open the Configuration page of CommandCenter

RX or Device Information screen of Operation Panel.

If you change the password to different value and then execute the initialization

function, it will return to this default value.

･Install printer driver

You can install the Printer Driver from ProductLib files.

Please perform the following installation steps:

1. Copy the “ProductLib” folers to your PC any directly.

2. Launch [Devices and Printers] from [Control Panel].

3. Click [Add a printer].

4. Click [The printer that I want isn’t listed].

5. Select [Add a local printer or network printer with manual settings] and click [Next].

6. Select [Create a new port:].

7. Select [Standard TCP/IP Port] and click [Next].

8. Add printer IP address to [Hostname or IP address] and click [Next].

9. Click [Have Disk...] .

10.Click [Browse...].

11.Select <OEMSETUP.INF> from <…¥ProductLib¥KXDriver¥64bit> and click [OK]. *

If your PC is 32bit, select the “32bit” folder.

12.Select model name and click [Next].

13.Confirm model name and click [Next] and KX Driver installation will be started.

14.Click [Finish] after KX Driver installation.

In the above installation only, the printer driver is connected with the RAW port. In

the security test environment, it have to use IPPS, so the following steps are required.

At first, you need to install the certificate of MFP to your PC.

1. Open the CCRX.

2. Click the Certification error button on URL box of Web browser.

3. Click the Display the certificate and click the install of certificate.

4. Click the Brows button and select the Trusted root CA.

Next, you need to set the Printer setting.

5. Open [Devices and Printers] from Control Panel on Windows

6. Click [Add a printer].

7. Click [The printer that I want isn’t listed].

8. Select [Select a shared printer by name] and enter the text box as following:

https://[host name]:443/printers

9. Click [Next].

If the certificate is not imported correctly, an error message is displayed here.

Please try again to install the certificate

10. Select [Kyocera] and TASKalfa ****

If the installation is successful, when open the printer icon → right-click → Properties

of the printer, the properties screen will be displayed. If fails, an error screen appears.

･Install TWAIN driver

You can install the Printer Driver from ProductLib files.

Please perform the following installation steps:

1. Copy the “ProductLib” folers to your PC any directly.

2. Execute <…¥ProductLib¥TWAIN¥setup.exe>.

3. You can then follow the instructions and proceed with the installation.

･Change the Destination Setting

To enable the Data Security Kit 10, the destination setting must be changed to US.

Change the destination setting from Maintenance mode.

Enter Maintenance mode by the following step.

1. In [Home] screen, enter “10871087” using the Numeric Keypad.

The device does not respond while you press the Numeric Keypad. If all the

number match, the maintenance mode screen is displayed.

Change the destination setting.

2. Enter “252” using the numeric key of Maintenance mode and press [Start].

3. The Destination list is displayed.

The “02 Europe Metric” should be checked.

4. Select the “Inch” and press [Start].

Initializes according to the destination. Wait a few seconds.

5. When [Stop] is pressed, "Power SW Off/On" is displayed, so turn the power switch

off then on.

The destination setting has been changed to US.

* If you want to return to the normal mode from Maintenance mode, enter "001" and press [Start].

However, since it changed the paper size to the “inch” setting, you need to return to

the “Metric” setting by following the steps below.

6. [Home] > [Paper Settings]

Change all cassette settings to Metric.

7. [System menu] > [Device Settings] > [Original/Scan Settings] > [Auto Detect

Original Size] > [System of Units]

Change Metric settings.

The time zone is also changed to US, so please return it.

8. [System menu] > [Device Settings] > [Data/Time] > [Time Zone]

Select “+01:00 Stockholm”.

･Activate Data Security Kit 10 option for HCD-PP

For HCD-PP, you must activate Data Security Kit 10, the IPsec security enhancement

option.

Please perform the following activation steps:

*See also Chapter 5, “Application”, in the product's Operation Guide.

1. [System menu] > [Add/Delete Application] > [Optional Function List] of Optional

Function.

2. The optional function screen is displayed. Select “Data Security Kit 10” and press

[Activate].

3. The license key screen is displayed. Enter the following license key and press

[Official].

TASKalfa 3554ci : 1310-7825-4801-9031-9939

TASKalfa 6054ci : 0738-1335-0037-7277-9222

TASKalfa 7004i : 1069-1544-7708-2848-6869

Ce manuel convient aux modèles suivants

Autres manuels Kyocera Imprimante tout-en-un

Kyocera

Kyocera Triumph-Adler P-C2155w Manuel utilisateur

Kyocera

Kyocera TASKalfa 4002i Manuel utilisateur

Kyocera

Kyocera KM-2540 Manuel utilisateur

Kyocera

Kyocera AD-63 Manuel utilisateur

Kyocera

Kyocera KM-4230 Manuel utilisateur

Kyocera

Kyocera FS-1128MFP Instructions d'installation et d'entretien

Kyocera

Kyocera FS-1020MFP Manuel utilisateur

Kyocera

Kyocera TASKalfa 3051ci Manuel utilisateur

Kyocera

Kyocera KM-1650 Manuel utilisateur

Kyocera

Kyocera FS-4300DN Manuel utilisateur

Kyocera

Kyocera TASKalfa 3501i Manuel utilisateur

Kyocera

Kyocera TASKalfa 250ci Manuel utilisateur

Kyocera

Kyocera FS-1028MFP DP Manuel utilisateur

Kyocera

Kyocera KM-6030 Manuel utilisateur

Kyocera

Kyocera FS-1118MFP Manuel utilisateur

Kyocera

Kyocera FS FS-C8500DN Guide de référence

Kyocera

Kyocera FS-C5100DN Manuel utilisateur

Kyocera

Kyocera TASKalfa 3050ci Manuel d'installation et d'exploitation

Kyocera

Kyocera Taskalfa Pro 15000c Manuel utilisateur

Kyocera

Kyocera ECOSYS M6035cidn Manuel utilisateur

Kyocera

Kyocera TASKalfa 650c Manuel utilisateur

Kyocera

Kyocera KM-C2525E Manuel utilisateur

Kyocera

Kyocera TASKalfa 8000i Manuel d'installation et d'exploitation

Kyocera

Kyocera ECOSYS FS-6525MFP Manuel utilisateur

Manuels Imprimante tout-en-un populaires d'autres marques

Triumph Adler

Triumph Adler DC 2016 Manuel

Epson

Epson WorkForce WF-2510 Guide de l'utilisateur

Epson

Epson Stylus Scan 2000 Manuel d'installation et d'exploitation

Epson

Epson PictureMate Snap PM 240 Mode d’emploi

Konica Minolta

Konica Minolta bizhub C35 Manuel utilisateur

Brother

Brother MFC-J430w Manuel utilisateur

Konica Minolta

Konica Minolta BIZHUB 558 Manuel utilisateur

Lexmark

Lexmark MX710 Series Manuel

Brother

Brother MFC-9760 Manuel utilisateur

Lexmark

Lexmark XC8155 Manuel utilisateur

Lexmark

Lexmark X642E Manuel utilisateur

Sharp

Sharp MX-2310U Mode d’emploi

Aficio

Aficio 200 Manuel utilisateur

Canon

Canon ImageCLASS 2300 Manuel

Ricoh

Ricoh Pro C900 Manuel utilisateur

Lexmark

Lexmark X925 Manuel utilisateur

Brother

Brother Business Smart MFC-J4510dw Manuel utilisateur

Epson

Epson Stylus CX8400 Series Manuel utilisateur
