KYMCO XCITING 500 Manuel utilisateur

XCITING 500

By KWANG YANG Motor Co., Ltd.

First Edition, Feb 2005

unauthorized use without the written permission of

KWANG YANG Motor Co., Ltd.

is expressly prohibited.

4121-LBA2-S00

XCITING 500

PREFACE

This Service Manual describes the

technical features and servicing

procedures for the KYMCO XCITING

500.

Section 1 contains the precautions for

all operations stated in this manual.

Read them carefully before any

operation is started.

Section 2 is the removal/installation

procedures for the frame covers which are

subject to higher removal/installation

frequency during maintenance and

servicing operations.

Section 3 describes the inspection/

adjustment procedures, safety rules and

service information for each part, starting

from periodic maintenance.

Sections 7 through 13 give instructions

for disassembly, assembly and adjustment

of engine parts. Section 14 through 16 is

the removal/ installation of chassis.

Section 17 through 21 states the testing

and measuring methods of electrical

equipment.

Most sections start with an assembly or

system illustration and troubleshooting

for the section. The subsequent pages give

detailed procedures for the section.

KWANG YANG MOTOR CO., LTD.

OVERSEAS SALES DEPARTMENT

OVERSEAS SERVICE SECTION

TABLE OF CONTENTS

GENERAL INFORMATION 1

FRAME COVERS /EXHAUST MUFFLER 2

INSPECTION/ADJUSTMENT 3

LUBRICATION SYSTEM 4

FUEL SYSTEM/FUEL PUMP/FUEL

TANK/CARBURETOR 5

COOLING SYSTEM 6

ENGINE REMOVAL/INSTALLATION 7

CYLINDER HEAD/VALVES 8

CYLINDER/PISTON 9

DRIVE AND DRIVEN PULLEY 10

FINAL REDUCTION 11

A.C. GENEARTOR/STARTER CLUTCH 12

CRANKCASE/CRANKSHAFT 13

STEERING HANDLEBAR/FRONT

WHEEL/FRONT SHOCK ABSORBER 14

REAR FORK/REAR WHEEL/REAR

SHOCK ABSORBER` 15

BRAKE SYSTEM 16

BATTERY/CHARGING SYSTEM 17

IGNITION SYSTEM 18

ELECTRIC STARTER 19

LIGHTS/METERS/SWITCHES 20

WIRING DIAGRAMS 21

The information and contents included in

this manual may be different from the

motorcycle in case specifications are

changed.

KYMCO reserves the right to make

changes at any time without notice and

without incurring any obligation.

CHASSIS

ELECTRICAL

UIPMENT

ENGINE

1. GENERAL INFORMATION

1-0

XCITING 500

__________________________________________________________________________________

GENERAL INFORMATION

__________________________________________________________________________________

SERIAL NUMBER------------------------------------------------------------ 1-1

SPECIFICATIONS------------------------------------------------------------ 1-2

SERVICE PRECAUTIONS-------------------------------------------------- 1-3

TORQUE VALUES ----------------------------------------------------------- 1-7

SPECIAL TOOLS ------------------------------------------------------------- 1-9

LUBRICATION POINTS ---------------------------------------------------1-10

CABLE& HARNESS ROUTING--------------------------------------------1-12

TROUBLESHOOTING------------------------------------------------------1-22

1. GENERAL INFORMATION

1-1

XCITING 500

SERIAL NUMBER

Location of Engine Serial Numbe

Location of Frame Serial Numbe

1. GENERAL INFORMATION

1-2

XCITING 500

SPECIFICATIONS

ITEM SPECIFICATIONS

Name XCITING 500

Overall length 2250 mm (90 in)

Overall width (mm) 815 mm (33 in)

Overall height (mm) 1450 mm (58 in)

Wheel base (mm) 1570 mm (63 in)

Engine type O.H.C.

Displacement 498.5 cm3 (30.4 cu-in)

Fuel Used 92# nonleaded gasoline

Front wheel 83 kg (183 lbs)

Dry weight Rear wheel 132 kg (290 lbs)

Total 215 kg (473 lbs)

Front wheel 90 kg (198 lbs)

Curb weight Rear wheel 141 kg (310 lbs)

Total 231 kg (508 lbs)

Front wheel 120/70-15

Rear wheel 150/70-14

Ground clearance 150 mm (6 in)

Min. turning radius 2750 mm (110 in)

Starting system Electric starter moto

Type Gasoline, 4-stroke

Cylinder arrangement Single cylinder

Combustion chamber type Semi-sphere

Valve arrangement O.H.C., chain drive

Bore x stroke (mm) 92 x75 mm

(3.7 x3 in)

Compression ratio 10.5:1

Compression pressure 13 kgf/c

²(1300kPa,

185 psi)

Open 2°BTDC

Valve Intake Close 45°ABDC

timin

Open 45°BBDC

Exhaust Close 5°ATDC

Valve clearance Intake 0.1 mm (0.004 in)

(cold) Exhaust 0.1 mm (0.004 in)

Idle speed (rpm) 1400rpm

Lubrication type Forced pressure &

Wet sump

Oil pump type Trochoid

Oil filter type Full-flow filtration

Oil capacity 2.5 L (2.2 lmp qt,

2.65 Us qt)

Final reduction oil

capacity 0.55 L (0.5 lmp qt,

0.58 Us qt)

Cooling Type Liquid cooled

ITEM SPECIFICATIONS

Air cleaner type & No Wet paper type element

Fuel capacity 12.8 L (3.38 lmp gal,

2.82 US gal

Type CVK

Main jet NO. 98

Venturi dia. φ36 mm (φ1.44 in)

Throttle type PISTON

Type Full transistor digital

ignition

Spark plug CR8E

Ignition timing Throttle position senso

Spark plug gap 0.6～0.7mm (0.002～

0.003 in)

Battery Capacity 12V12AH

Clutch Type Dry, centrifugal

automatic

Type Helical gear/spur gear

Operation Automatic centrifugal

Type

Type CVT

Preliminary 2.68 – 1

Final 5.4

FR/RR tire rolling

circumference 1724/1778 mm (69/71 in)

Front 2 kg/cm²(200 Kpa, 28

psi)

Tire pressure

(rider only/60

kg) Rear 2.5 kg/c

²(250 Kpa, 36

psi)

Turning Left 40°

angle Right 40°

Brake s

ste

Rea

Disk brake

type Front Disk brake

Front Telescopic fork

Suspension

type Rear Unit swing

Frame type Back born

Tires

Fuel S

stem

Carbureto

Electrical Equipment

nition S

stem

Power Drive System

Transmis-

sion Gear Reduction

Ratio

Moving Device Damping

Device

Lubrication

stem

Engine

1. GENERAL INFORMATION

1-3

XCITING 500

SERVICE PRECAUTIONS

Make sure to install new gaskets, O-rings,

circlips, cotter pins, etc. when

reassembling.

When tightening bolts or nuts, begin with

larger-diameter to smaller ones at several

times, and tighten to the specified torque

diagonally.

Use genuine parts and lubricants.

When servicing the motorcycle, be sure to

use special tools for removal and

installation.

After disassembly, clean removed parts.

Lubricate sliding surfaces with engine oil

before reassembly.

Apply or add designated greases and

lubricants to the specified lubrication

points.

After reassembly, check all parts for proper

tightening and operation.

When two persons work together, pay

attention to the mutual working safety.

Disconnect the battery negative (-) terminal

before operation.

When using a spanner or other tools, make

sure not to damage the motorcycle surface.

After operation, check all connecting

points, fasteners, and lines for proper

connection and installation.

When connecting the battery, the positive

(+) terminal must be connected first.

After connection, apply grease to the

battery terminals.

Terminal caps shall be installed securely.

1. GENERAL INFORMATION

1-4

XCITING 500

If the fuse is burned out, find the cause and

repair it. Replace it with a new one

according to the specified capacity.

After operation, terminal caps shall be

installed securely.

When taking out the connector, the lock on

the connector shall be released before

operation.

Hold the connector body when connecting

or disconnecting it.

Do not pull the connector wire.

Check if any connector terminal is bending,

protruding or loose.

The connector shall be inserted

completely.

If the double connector has a lock, lock

it at the correct position.

Check if there is any loose wire.

Before connecting a terminal, check for

damaged terminal cover or loose negative

terminal.

Check the double connector cover for

proper coverage and installation.

Insert the terminal completely.

Check the terminal cover for proper

coverage.

Do not make the terminal cover opening

face up.

Secure wire harnesses to the frame with

their respective wire bands at the

designated locations.

Tighten the bands so that only the insulated

surfaces contact the wire harnesses.

Confir

Capacity

1. GENERAL INFORMATION

1-5

XCITING 500

After clamping, check each wire to make

sure it is secure.

Do not squeeze wires against the weld or

its clamp.

After clamping, check each harness to

make sure that it is not interfering with any

moving or sliding parts.

When fixing the wire harnesses, do not

make it contact the parts which will

generate high heat.

Route wire harnesses to avoid sharp edges

or corners. Avoid the projected ends of

bolts and screws.

Route wire harnesses passing through the

side of bolts and screws. Avoid the

projected ends of bolts and screws.

Route harnesses so they are neither

pulled tight nor have excessive slack.

Protect wires and harnesses with electrical

tape or tube if they contact a sharp edge or

corner.

When rubber protecting cover is used to

protect the wire harnesses, it shall be

installed securely.

Do not break the sheath of wire.

If a wire or harness is with a broken sheath,

repair by wrapping it with protective tape

or replace it.

When installing other parts, do not press or

squeeze the wires.

Do not pull

too tight！

o Contac

Do not press or

squeeze the

1. GENERAL INFORMATION

1-6

XCITING 500

After routing, check that the wire harnesses

are not twisted or kinked.

Wire harnesses routed along with

handlebar should not be pulled tight, have

excessive slack or interfere with adjacent

or surrounding parts in all steering

positions.

When a testing device is used, make sure to

understand the operating methods

thoroughly and operate according to the

operating instructions.

Be careful not to drop any parts.

When rust is found on a terminal, remove

the rust with sand paper or equivalent

before connecting.

Symbols:

The following symbols represent the

servicing methods and cautions included in

this service manual.

: Apply engine oil to the

specified points. (Use

designated engine oil for

lubrication.)

: Apply grease for lubrication.

: Transmission Gear Oil (90#)

: Note

Engine Oil

Grease

Gear Oil

＊

Do you understand

the instrument？

Remove Rust！

1. GENERAL INFORMATION

1-7

XCITING 500

TORQUE VALUES

STANDARD TORQUE VALUES

Item Torque

N•m (kgf•m, lbf•ft) Item Torque

N•m (kgf•m, lbf•ft)

5mm bolt and nut

6mm bolt and nut

8mm bolt and nut

10mm bolt and nut

12mm bolt and nut

14mm bolt and nut

5(0.5, 4)

10 (1, 7)

22 (2.2, 16)

35 (3.5, 25)

55 (5.5, 40)

70 (7, 50)

4mm screw

5mm screw

6mm screw, SH bolt

6mm flange bolt and nut

8mm flange bolt and nut

10mm flange bolt and nut

3 (0.3, 2)

4 (0.4, 3)

9 (0.9, 6.5)

12 (1.2, 9)

27 (2.7, 20)

40 (4, 29)

Torque specifications listed below are for important fasteners.

ENGINE

Item Q‘ty Thread dia.

(mm) Torque

N•m (kgf•m, lbf•ft) Remarks

MAINTENANCE:

Engine oil drain plug

Oil strainer screen cap

Oil filter cartridge

Transmission oil drain bolt

Transmission oil filler bolt

Spark plug

Tappet adjust nut

LUBRICATION SYSTEM:

Oil pump screw

Oil cooler bolt

COOLING SYSTEM:

Water pump cover bolt

CYLINDER HEAD:

Breather separator bolt

Cylinder head bolt (1 – 4)

Cylinder head bolt (5 – 13)

Cylinder head cover bolt

Cam chain tensioner bolt

Tensioner pivot bolt

Rocker arm shaft

DRIVE/DRIVEN PULLEY:

Drive face nut

Clutch out nut

25 (2.5, 18)

15 (1.5, 11)

10 (1, 7)

24 (2.4, 18)

12 (1.2, 9)

9 (0.9, 6)

3 (0.3, 2)

35 (3.5, 25)

13 (1.3, 9)

48 (4.8, 35)

23 (2.3, 17)

10 (1, 7)

12 (1.2, 9)

10 (1, 7)

45 (4.5, 32)

135 (13.5, 97)

80 (8, 58)

Apply oil

Autres manuels pour XCITING 500

Table des matières

Autres manuels KYMCO Scooter

KYMCO

KYMCO 50 LIKE 4T Manuel utilisateur

KYMCO

KYMCO Agility 16+ 50 2022 Manuel utilisateur

KYMCO

KYMCO 125 AGILITY CITY - Manuel utilisateur

KYMCO

KYMCO G-DINK 300i Manuel utilisateur

KYMCO

KYMCO Super 9 50 Manuel utilisateur

KYMCO

KYMCO AGILITY 50 - SERVICE Note de version

KYMCO

KYMCO Mini LS Manuel utilisateur

KYMCO

KYMCO 50 AGILITY RS 4T Manuel utilisateur

KYMCO

KYMCO 125 DINK - Manuel utilisateur

KYMCO

KYMCO SPADE 150i Manuel utilisateur

KYMCO

KYMCO Yager 200i Manuel utilisateur

KYMCO

KYMCO YUP 250 Manuel utilisateur

KYMCO

KYMCO FILLY LX 50 Manuel utilisateur

KYMCO

KYMCO DINK 200i Manuel utilisateur

KYMCO

KYMCO PEOPLE S 125 Manuel utilisateur

KYMCO

KYMCO Super 8 ForU Manuel utilisateur

KYMCO

KYMCO 250 PEOPLE S INJECTION Manuel utilisateur

KYMCO

KYMCO Compagno 50i Manuel utilisateur

KYMCO

KYMCO Many 110 EV Series Manuel utilisateur

KYMCO

KYMCO 125 SUPER 8 Manuel utilisateur

KYMCO

KYMCO Scooter Manuel utilisateur

KYMCO

KYMCO 125 GRAND DINK MMC Manuel utilisateur

KYMCO

KYMCO People S 250 Manuel utilisateur

KYMCO

KYMCO 500 XCITING RI ABS Manuel utilisateur

Manuels Scooter populaires d'autres marques

TEKTRO

TEKTRO CHEETAH Manuel utilisateur

Douglas

Douglas Vespa Sprint Guide d'installation

PLAYTIVE

PLAYTIVE AS-2448 Manuel utilisateur

Ebinger

Ebinger DONKEY XL Manuel utilisateur

Flyer

Flyer Mountain Guide de l'utilisateur

BackCountry eBikes

BackCountry eBikes Storm Manuel utilisateur

equipmed

equipmed FreeRoam II Manuel utilisateur

Yoto

Yoto Lion Manuel utilisateur

WESTHILL BIKES

WESTHILL BIKES LINK Manuel utilisateur

BAnff

BAnff eProdigy series Manuel utilisateur

Winther

Winther 475 Manuel utilisateur

Jetson

Jetson JBZL17 Manuel utilisateur

First Choice Mobility

First Choice Mobility Roma Medical Corella S741 Manuel utilisateur

Carrera

Carrera impel Manuel utilisateur

Afikim

Afikim Superlight SL-3 Manuel utilisateur

CareCo

CareCo ZOOM Manuel utilisateur

Douglas

Douglas Vespa G.S. Manuel utilisateur

Gazelle

Gazelle with BOSCH System Manuel utilisateur
