USER MANUAL
Dear Customer,
We sincerely appreciate your purchase of KYK alkaline water Ionizer
medical substance producer and we hope your health and happiness.
Before operating the product, you must read the user manual carefully.
You can know not only how to use but also the strong points of the product
with a manual, use the strong points well to select custom water for various
purposes and use it effectively, and, moreover, optimize the performance
and life of the product.
All employees of our company promise to think in customer’s shoes at all
times and be dedicated to the benefits, health, and happiness of the
customer.
Thank you.
Thank you for Being our Customer
!
President
Sincerely
Special Features
Parts and Features
Control Panel
Caution before Installation of the Product
Installation Instructions
How to instal-Separation cool and hot water type
How to install - Under sink water supply
system/General model type
How to install and the check list
How to Use
Filters Replacement
How to Replace Filters
Water Guide
Caution in use of raw water and maintenance of the Product
Notices for safety
Product Specifications
Warranty Registration
Table of Contents
4
5
6
7
8
10
11
13
14
16
17
19
20
21
22
23
Note: The design and specifications of this product may be
improved at any time.
4
Special Features
Shimmering aluminum front panel with color display
Patented platinum titanium electrodes for improved electrolysis
Newly-developed ceramic valve (model: RP3)
A. make RP3 to work without a booster pump under low water flow
B. regulate water flow without water pressure regulator under
high water flow
C. increased reliability
SMPS with high performance and efficiency to avoid overheat
Ability to check filters authenticity and capacity (days/liters)
Ability to adjust for the pH of source water
Voice notifications and ON/OFF
Maximized convenience and safety by automatic after-cleaning and
draining from the electrolysis cell and filters
Precise calibration in 200 different levels of electric current to get
exact pH level of water
Various water for different purposes:
A. Drinking for children and adults (Alkali 1,2)
B. Making tea, cooking, washing fruit and vegetables (Alkali 3,4)
C. Washing hands and face (Acid)
D. Taking medicine (Purified)
5
Product Body
Parts and Features
Front
Back
Power
Cord
Fuse Acidic Water
Drain
Source Water
Inlet
Bottom
Front
RE3
Control Buttons Water On / Off Valve
Stainless
Steel Hose
LED
Indicator
Filter Cover
Speaker
Faucet
diverter valve
Hose
Accessories
6x8 90°
elbow connectors
pH test drops
Manual
RP3
6
Control Panel
Clean:
Tap to start on-demand cleaning cycle.
Automatic cleaning runs after every 30 liters to protect the electrolysis plates.
RE3 RP3
Filters Indicators
Weak Alkaline Water
(pH8.5 / pH9.0)
Acidic Water
(Strong / Weak)
Cleaning
Strong Alkaline Water
(pH9.5 / pH10.0)
On/Off / Mode
Weak Alkaline Water
(pH8.5 / pH9.0)
Acidic Water
(Strong / Weak)
Cleaning
Strong Alkaline Water
(pH9.5 / pH10.0)
Purified WaterPurified Water
Mode
Water On/Off Valve
(turn to open or close water)
Working Indicator
LED
7
Caution before Installation of the Product
Install on the stable and flat surface.
Please observe the following before installation.
Place ionizer at least 10 cm away from the walls.
Keep away from moisture, water and direct sunlight. Connect it to COLD water pipe only.
Hot water may damage the Ionizer.
Place drain hose below the Ionizer.
Do not bend or press the hose.
Keep the drain hose length under 1 m.
Cold water pipe
8
Installation Instructions
Installation
Non-hole Valve
Hot Water Releasing Hole
Cold Water Releasing Hole
‘O’ Shape Packing
Water Entrance Control Valve
Hole Valve
‘O’ Shape Packing
‘O’ Shape Packing
‘O’ Shape Packing
All hookup part of pipe arrangement has to be covered by teflon tape for avoiding the leakage and you
control the bounding number of tape for keeping the level of a horizontality and a perpendicularity.
When you decompose and reassemble the product, if you give the over force, it will be possible to leak after
assembling the product because of a pipe arrangement distortion of raw water, a break out of rubber packing
and a breakage.
After locking all raw water of installation area or type switch valve fixed on the
wall for cold and hot water connected with a water service pipe behind a tap as shown
in the figure by using a type screwdriver, check to cut off water completely by
opening a tap.
Separate from the pipe for cold and hot water connected with a tap. (See the top figure)
Warning-When you decompose the product, if a rubber packing attached on the
nipple for preventing the leakage is worn out, you will change that.
unless it will cause a leakage of product.
You wrap a teflon tape for preventing the leakage several times on nipples without
a hole and with a hole and link them.
Water Entrance Control
Valve Elbow
Product Water Entrance Hole
9
But standard of a nipple with a hole differs according to the area and a manufacturer
and if the size is not correct, you will order it separately.- We accept a request in the A/S
center.)
Warning-You wrap the tape for preventing the leakage 4~5 times not to harm on the
connection between nipple and piping and after complete connection, you have to adjust
the direction of a valve not to make a problem on the connection with the product.
You link the switch valve with the nipple with a hole connected in 3) as shown
in the figure.
Warning-You wrap the tape for preventing the leakage proper times not to harm on the
connection between nipple and piping and after complete connection, you have to adjust
the direction of a valve not to make a problem on the connection with the product.
(As shown in the figure, after stopping down the nipple, the switch valve will be horizontal
so you control the amount of leakage tape as the same amount.)
Insert the hose stop down nut at the hose and push the hose in the switch valve at the end.
After that connect the hose stop down nut with switch valve and stop down with proper
strength.
Warning-If you stop down the nut too strong, the water will be possible to leak because
the hose in the hose stop down nut can be torn. Or if you stop down the nut too loose,
the water will leak because the hose is missed from the switch valve.
So you connect the hose safely by giving the proper strength carefully.
How to connect with the product after connecting the hose with a tap pipe
After selecting the proper place for the product, cut the length of hose with some extra to
the product. As shown in the figure, remove a rubber plug in the raw water inlet and put
the hose in the raw water inlet. At this time, you put the hose at the end not to miss from
the product.
Power cord Water drain outlet
Water supply inlet
