Kramer SPK-W511 Manuel utilisateur

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

SPK-W511

On-Wall Speakers

P/N: 2900-300115 Rev 2

SPK-W511 – Contents i

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Recycling Kramer Products 2

3Overview 3

3.1 Defining the SPK-W511 3

4Installing the SPK-W511 4

4.1 Choosing the Best Location 4

4.2 Installing the Speaker Wires 4

4.3 Installing the Mounting Bracket 5

4.4 Installing the SPK-W511 6

5Technical Specifications 7

Figures

Figure 1: SPK-W511 3

Figure 2: SPK-W511 with Brackets Connected 5

Figure 3: Installing the SPK-W511 6

SPK-W511 - Introduction 1

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Products.

Congratulations on purchasing your Kramer SPK-W511 On-Wall Speakers, which

are ideal for:

•Conference Rooms

•Boardrooms

•Schools and University Classrooms

•Presentation Venues

•Home Theater

2 SPK-W511 - Getting Started

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

Go to http://www.kramerelectronics.com to check for up-to-date

user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

•Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

•Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

•Position your Kramer Speakers away from moisture, excessive sunlight and

dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

2.2 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country

go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

SPK-W511 - Overview 3

3 Overview

The SPK-W511 includes a pair of high performance speakers that can be

mounted on the wall vertically or horizontally, and indoors as well as outdoors. The

mounting brackets are made of painted steel that can be attached to each

speaker, letting you rotate each speaker to the left or right.

The speakers are weather resistant but not waterproof, and can

withstand the humidity in the air. We recommend that you locate

them in an area that is covered and protected from rain.

3.1 Defining the SPK-W511

This section defines the SPK-W511:

Figure 1: SPK-W511

# Feature Function

1 Speaker Grille Do not remove from the speakers

2 Bracket Knob (4) Use two knobs to fasten the bracket to the speaker

3 Speaker Bracket Used for mounting the speaker onto the wall

4 Screw Type

Input Port

Positive (red) Connect to the positive stereo analog audio output

of the receiver

5 Negative (black) Connect to the negative stereo analog audio output

of the receiver

4 SPK-W511 - Installing the SPK-W511

4 Installing the SPK-W511

This section explains how to:

•Choose the best location for your speakers (see Section 4.1)

•Install the speaker wires (see Section 4.2)

•Install the mounting brackets (see Section 4.3)

•Install the SPK-W511 (see Section 4.4)

4.1 Choosing the Best Location

Before installing the speakers:

•Experiment by placing the speakers in different locations before finally

deciding on the most suitable location

•Be sure that the wall type is appropriate for the mounting brackets, that is,

either solid wood, bricks, concrete, hollow building blocks, or wood studs

•Check that the mounting location is free of obstructions, such as electrical

piping, AC ducts or water lines, and so on

4.2 Installing the Speaker Wires

To install the speakers, do the following:

1. Measure the length from each speaker to the receiver, and cut the wires

accordingly, adding some access wire length to let you easily remove the

speakers from the bracket without having to disconnect the input wires.

The distance should measure up to about 4 meters (13 feet)

2. Strip the ends of the wires approximately 3/8 inch.

3. Pass the speaker wires through the round hole in the mounting bracket.

4. Unscrew the negative (black) screw-type connector, insert the wire from the

negative terminal on the receiver, and retighten.

5. Unscrew the positive (red) screw-type connector, insert the wire from the

positive terminal on the receiver, and retighten.

SPK-W511 - Installing the SPK-W511 5

6. Insert the brackets (see Section 4.3)

4.3 Installing the Mounting Bracket

To install the mounting brackets, do the following:

1. Mark the location of the mounting holes on the wall.

2. Screw the mounting screws onto the wall at the location where you want to

mount the speakers.

If the location is backed by wall studs, you can use the wood screws

provided. If the location is backed by a gypsum board, use wall anchors (not

included in the package).

3. Slide a speaker into each mounting bracket.

4. Align the bracket screw holes (upper and lower) to those on the speaker and

screw a knob to each of the holes to secure the speaker to the bracket (see

Figure 2).

Figure 2: SPK-W511 with Brackets Connected

5. You can slightly loosen the knobs on a speaker to adjust its direction.

6 SPK-W511 - Installing the SPK-W511

4.4 Installing the SPK-W511

You can connect the SPK-W511 speakers to an amplifier, for example the Kramer

907xl Power Amplifier/Mixer, as illustrated in Figure 3:

Figure 3: Installing the SPK-W511

SPK-W511 - Technical Specifications 7

5 Technical Specifications

Audio and Power

DESCRIPTION: 2-way on-wall speakers

FREQUENCY RESPONSE: 70Hz to 20kHz@ -10dB

WOOFER: 5.25” (133mm) polypropylene cone

TWEETER: 0.51” (13mm) Mylar

IMPEDANCE: 8Ω

NOMINAL SENSITIVITY: 89dB 1W @1M

DIRECTIVITY FACTOR (Q): 3.3 (2kHz)

DIRECTIVITY INDEX (DI) 5.2dB (2kHz)

POWER CAPACITY: 30W RMS

80W continuous program

CROSSOVER FREQUENCY: WOOFER: Full range

TWEETER: High-pass @ 8kHz

INPUT CONNECTORS: Gold-plated 5-way binding posts

Shipping and Installation

MATERIALS: Frame, grill and brackets steel; cabinet ABS

OPERATING TEMPERATURE: 0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE: -40° to +70°C (-40° to 158°F)

HUMIDITY: 10% to 90%, RHL non-condensing

WEIGHT PER SINGLE SPEAKER: 2kg (4.4lbs) approx.

WEIGHT WITH MOUNTING KIT: 2.4kg (5.3lbs) approx.

SHIPPING WEIGHT (FOR PAIR): 4.8kg (10.6lbs) approx.

DIMENSIONS: 18.5cm x 16.5cm x 24.9cm (7.28” x 6.5” x 9.8”), W, D, H.

DIMENSIONS with mounting

brackets:

18.5cm x 16.7cm x 27cm (7.28” x 6.6” x 10.6”), W, D, H.

INSTALLATION CLEARANCE: Front panel to wall (with mounting bracket): 21cm (8.2”)

Back panel to wall (with mounting bracket): 4.5cm (1.8”)

ACCESSORIES: 2 mounting brackets (including 4 knobs and 4 mounting

screws)

OPTIONS: BCP-2S speaker cable

COLORS: Available in white or black

Specifications are within a 10% tolerance and are subject to change without notice at

http://www.kramerelectronics.com
