TP-590RXR Quick Start (P/N: 2900-300860QS REV 2)

P/N:

2900- 300860QS

Rev:

Scan for full manual

TP-590RXR Quick Start Guide

This guide helps you install and use your TP-590RXR for the first time.

Go to www.kramerav.com/downloads/TP-590RXR to download the latest user manual and check if firmware

upgrades are available.

Step 1: Check what’s in the box

TP-590RXR HDMI Line Receiver

4 Rubber feet

1 Bracket set

1 Power supply (12V DC)

1 Quick start guide

Step 2: Get to know your TP-590RXR

Feature

Function

USB 1 –4 Connectors

Connect to the USB peripheral devices, (forexample, USB camera, computer mouse, or

keyboard).

POE STATUS LED

Lights green when poweris received over the TP connection.

LINK LED

Lights green when the HDBT link is valid.

ON LED

Lights green when the device receives power.

Feature

Function

HDBT IN RJ-45 Connector

Connect to the HDBT OUT RJ-45 connector on the HDBT transmitter.

IR 3.5mm Mini Jack Connector

Connect to an external infrared transmitter or sensor.

RS-232 3-pin Terminal Block

Connect to an RS-232 device to be controlled, for example, a projector.

AUDIO OUT 3.5mm Mini Jack

Connector

Connect to the stereo, analog audio acceptor.

HDMI OUT Connector

Connect to the HDMI acceptor.

SETUP 4-way DIP-switch

Set the device behavior (see Step 4).

CONTROL

RS-232 3-pin

Terminal Block

Connect to the serial controller for this device.

ETHERNET

RJ-45 Connector

Connect to the Ethernetcontroller to control this device or to a LAN to pass network traffic.

RESET Switch

Press and hold for 5 seconds to reset the device to factory default settings.

Press and immediately release to power-cycle the device (Reset).

PROG Mini USB Connector

Connect to a PC to perform firmware upgrades.

12V DC Power Connector

Connect to the supplier power adapter ifpower is not supplied from a PoE device via the TP

cable.

Step 3: Install TP-590RXR

Install TP-590RXR using one of the following methods:

•Attach the rubber feet and place the unit on a flat surface.

•Fasten a bracket (included) on each side of the unit and attach it to a flat surface.

For more information go to www.kramerav.com/downloads/TP-590RXR.

•Mount the unit in a rack using an optional RK-T2B rack adapter.

Step 4: Connect the inputs and outputs

Always switch OFF the power on each device before connecting it to your TP-590RXR. For best results, we recommend that you

always use Kramer high-performance cables to connect AV equipment to TP-590RXR.

Setting the DIP Switches

Set the DIP-switches using the table on the right. The ON/OFF

positions are as follows:

•Switch down = ON

•Switch up = OFF

Note: Changes to the DIP-switches only take effect on power-up.

Function

Status

Range

mode

Off—Extended range (provides increased

range at a reduced bandwidth)

On—Normal range (factory default)

Reserved

Off—Factory default

EDID lock

Off—Automatic EDID acquisition (factory

default)

On—Lock (locks the current EDID so that

changes on the output do not result in

changes to the EDID)

Reserved

Off—Factory default

Step 5: Connect the power

Connect the 12V DC power supply to TP-590RXR and plug it into the mains electricity.

Safety Instructions

Caution:

There are no operator serviceable parts inside the unit.

Warning:

Use only the Kramer Electronics power supply that is provided with the unit.

Warning:

Disconnect the power and unplug the unit from the wall before installing.

See www.KramerAV.com for updated safety information.

Step 6: Operate TP-590RXR

Operate TP-590RXR via:

•Remotely, using Protocol 3000

commands via RS-232 or Ethernet

•Embedded web pages via the

Ethernet

•Remotely, using an IR remote

control transmitter

Default Parameters

Parameter

Value

Name

KRAMER_

Model

TP-590RXR

IP Address

192.168.1.39

UDP Port

50000

TCP Port

5000

Network Mask

255.255.0.0

Gateway Address

192.168.0.1

RS-232 Baud Rate

115200

HDCP Mode

Followoutput

Audio Selection Mode

Auto

Video Signal Loss Timeout (no 5V)

0 seconds

Video Signal Loss Timeout (5V present)

10 seconds

Protocol 3000 Commands

Command

Description

Command

Description

Protocol handshaking

Set/get protocol permission

AV-SW-TIMEOUT

Set/get video auto-switch timeout

LOGOUT

Cancel current permission level

BUILD-DATE?

Read device build date

MODEL?

Read device model

CPEDID

Copy EDID data from the output to the input

NAME

Set/get machine (DNS) name

DIR

List files in device

NAME-RST

Reset machine name to factory default

(DNS)

DISPLAY?

Valid / Invalid output

NET-DHCP

Set/get DHCP mode

ETH-PORT

Set/get Ethernet port protocol

NET-GATE

Set/get gateway IP

FACTORY

Resets the device to factory default

NET-IP

Set/get IP address

FS-FREE?

Get file system free space

NET-MAC?

Get MAC address

GEDID

Read EDID data

NET-MASK

Set/get subnet mask

GET

Get file

PASS

Set/get Password

HDCP-MOD

Set/get HDCP mode

PROT-VER?

Get device protocol version

HDCP-STAT?

Get HDCP signal status

RESET

Reset device

HELP

Get command list or help for specific

command

SECUR

Start / Stop Security

LDEDID

Write EDID data to input

SIGNAL?

Get input signal lock status

LDFW

Load new firmware

SN?

Read device serial number

LOAD

Load new firmware

UPGRADE

Perform firmware upgrade

LOCK-EDID?

Get EDID lock status

VERSION?

Read device firmware version

Using the Embedded Web Pages

The TP-590RXR can be operated remotely using the

embedded web pages. Access the web pages from the

control computer using a web browser and an Ethernet

connection.

Before attempting to connect:

•Ensure that your browser is supported.

•Ensure that JavaScript is enabled.

Note: In the event that a Web page does not update

correctly, clear your Web browser’s cache.

Note: Only one instance of the web pages can be open at a

time.

To browse the TP-590RXR web pages:

1. Open your Internet browser.

2. Type the IP number of the device (default =

192.168.1.39) in your browser.

If authentication is enabled, the following window

appears.

3. Enter the valid username and password to access the

web pages.

Following a successful logon, the Default page

appears.

Item

Description

Video Settings

Viewthe current video settings.

Reveal Button

Click to reveal the Page Selection

panel.

4. Click the Reveal button to open the left hand side

page panel.

5. Select the required page from the Page Selection

Panel to configure the device:

Video Settings Page: Modify the video and timeout

parameters.

Device Settings Page:

•View some of the device characteristics (for example,

model and web version)

•Edit IP settings

•Load and save configurations

•Reset the device to factory default settings

EDID Management Page:

•Copy EDID data to either or both of the inputs

•Lock the EDID on each input independently

Note: Do not power up the display before locking the EDID.

Firmware Upgrade Page:

•View the current firmware version

•Upgrade the firmware

Authentication Page: Assign or change logon

authentication details.

About Page: View the Web page version and Kramer

Electronics Ltd company details.
