Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront video, audio, presentation, and broadcasting
professionals on a daily basis. In recent years, we have redesigned and
upgraded most of our line, making the best even better!
Our 1,000-plus different models now appear in 14 groups that are clearly
defined by function: GROUP 1: Distribution Amplifiers; GROUP 2:
Switchers and Routers; GROUP 3: Control Systems; GROUP 4:
Format/Standards Converters; GROUP 5: Range Extenders and Repeaters;
GROUP 6: Specialty AV Products; GROUP 7: Scan Converters and
Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room
Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:
Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio;
and GROUP 14: Collaboration.
Thank you for purchasing the Kramer DigiTOOLS®FC-331 SD/HD-SDI to
HDMI Converter, which is ideal for:
Home theater, presentation and multimedia applications
Rental and staging
SD/HD-SDI to HDMI Converter for medical equipment
The package includes the following items:
FC-331
Power supply (5V DC input)
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Getting Started
2
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
Review the contents of this user manual
Go to www.kramerav.com/downloads/FC-331 to check for up-to-
date user manuals, application programs, and to check if firmware
upgrades are available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
Use only good quality connection cables (we recommend Kramer
high-performance, high-resolution cables) to avoid interference,
deterioration in signal quality due to poor matching, and elevated
noise levels (often associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight
coils
Avoid interference from neighbouring electrical appliances that may
adversely influence signal quality
Position your FC-331 away from moisture, excessive sunlight and
dust
This equipment is to be used only inside a building. It may
only be connected to other equipment that is installed inside
a building.
Getting Started
3
2.2 Safety Instructions
Caution:
There are no operator serviceable parts inside
the unit
Warning:
Use only the power cord that is supplied with
the unit
Warning:
Do not open the unit. High voltages can
cause electrical shock! Servicing by qualified
personnel only
Warning:
Disconnect the power and unplug the unit
from the wall before installing
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive
2002/96/EC aims to reduce the amount of WEEE sent for disposal to
landfill or incineration by requiring it to be collected and recycled. To
comply with the WEEE Directive, Kramer Electronics has made
arrangements with the European Advanced Recycling Network (EARN)
and will cover any costs of treatment, recycling and recovery of waste
Kramer Electronics branded equipment on arrival at the EARN facility. For
details of Kramer’s recycling arrangements in your particular country go to
our recycling pages at
http://www.kramerelectronics.com/support/recycling/.
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Getting Started
4
2.4 Quick Start
This quick start chart summarizes the basic setup and operation steps.
Overview
5
3 Overview
The FC-331 SD/HD-SDI to HDMI Converter is a high-performance format
converter for SDI (SMPTE 259M), HD-SDI (SMPTE 292M), and 3G
HD-SDI (SMPTE 424M) signals. It converts an SDI (Level A) audio and
video signal to an HDMI output signal with the same resolution and frame
rate
1
.
The FC-331 features:
An SD/HD-SDI/3G HD-SDI input on a BNC connector
An SDI loop on a BNC connector and an HDMI output
HDTV compatibility
Automatic active input LED indicators on the front panel. Green
indicates a standard definition (SDI) input signal and blue indicates a
high-definition (HD-SDI) input signal
5V DC power
Medical equipment compliance
3.1 Accessory to Medical Equipment (IEC 60601-1)
In the modern medical environment remote access is essential, for example,
to transfer clinical data between doctors and to train to medical students.
The FC-331 is certified according to the IEC 60601-1-2, Clause 2.1.3,
Medical Electrical Equipment, Part 1: General Requirements for EMC
standard which is required when accessory devices are used at locations
where medical personnel and patients are present.
The FC-331 constitutes an optional component that can be considered
necessary and suitable as part of medical equipment or for use as part of a
medical system to provide real time simultaneous video feeds to those
present at the local medical environment and at remote locations. In this
environment, the FC-331 can be added to the system ONLY if the
connecting equipment has been evaluated and meets the IEC 60601-1-2
EMC standards. Note, that when attaching accessory devices to a digital or
analog interface, they must comply with the IEC standard for which they
are used: EMC Standard (IEC 60601-1-2), Information Technology
equipment (IEC 60950-1 (2ed)).
1
No scaling is performed
Your FC-331 SD/HD-SDI to HDMI Converter
7
Table 1: FC-331 SD/HD-SDI to HDMI Converter Features
#
Feature
Function
1
SD/HD-SDI IN BNC Connector
Connects to an SD or HD-SDI source
2
SD/HD-SDI LOOP BNC Connector
Connects to an SD or HD-SDI acceptor
3
SDI AUDIO GROUP SELECT
Turn to select the SDI input stereo channel (0 to 7)
4
HDMI OUT Connector
Connects to an HDMI acceptor
5
5V DC
+5V DC connector for powering the unit
6
SD/HD LED
Illuminates green for an SD input signal and blue for an
HD-SDI input signal
7
OUT LED
Illuminates green to indicate that a display is connected
8
ON LED
Illuminates green when receiving power
