Kramer VP-16X18AK/110V Manuel utilisateur

Kramer Electronics, Ltd.

USER MANUAL

Model:

VP-16x18AK

16 x 18 PC UXGA/Audio Router

Contents

1Introduction 1

2Getting Started 1

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 2

2.3 Recycling Kramer Products 3

2.4 Quick Start 3

3Overview 5

3.1 Shielded Twisted Pair and Unshielded Twisted Pair 6

4Defining the VP-16x18AK 16 x 18 PC UXGA/Audio Router 7

4.1 Using the IR Transmitter 11

5Installing the VP-16x18AK in a Rack 12

6Connecting and Configuring the VP-16x18AK 13

6.1 Connecting the VP-16x18AK 13

6.2 Connecting the Audio Outputs to Balanced/Unbalanced Acceptors 14

6.3 Connecting to the VP-16x18AK via RS-232 15

6.4 Connecting to the VP-16x18AK via RS-485 15

6.5 Connecting to the VP-16x18AK via the Ethernet Port 16

6.5.1 Connecting Directly to the Ethernet Port 16

6.5.2 Connecting via a Network Hub, Switch, or Router 18

6.5.3 Configuring the Ethernet Port on the VP-16x18AK Using K-Upload 18

6.6 Setting the RS-485 Termination and Machine Number DIP-switches 18

7Operating the VP-16x18AK Locally via the Front Panel Buttons 20

7.1 The Status Display 20

7.2 Switching Inputs to Outputs 20

7.3 The At Once and Confirm Modes 21

7.3.1 Toggling between At Once and Confirm Modes 21

7.3.2 Confirming a Switching Action 21

7.4 Setting the Audio Gain for Inputs and Outputs 22

7.5 Audio Output Bass and Treble Level Setting 22

7.6 Setting the Audio-Follow-Video or Breakaway Option 23

7.6.1 Setting the Audio-Follow-Video Option 23

7.6.2 Setting the Breakaway Option 23

7.7 Storing and Recalling Setup Configurations 23

7.7.1 Storing a Setup Configuration 24

7.7.2 Recalling a Setup Configuration 24

7.8 Locking and Unlocking the Front Panel Buttons 24

8Operating the VP-16x18AK Remotely 25

8.1 Operating the VP-16x18AK via RS-232 25

9Operating the VP-16x18AK Remotely Using a Web Browser 27

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Contents

9.1 Connecting to the VP-16x18AK via your Browser 27

9.2 The Main Switching Matrix Page 29

9.2.1 Switching an Input to an Output 30

9.2.2 Setting the AFV Mode 30

9.2.3 Operating in the Offline Mode 31

9.2.4 Storing and Recalling Setups 32

9.2.5 Locking the Front Panel Buttons 34

9.3 Audio Input Gain Control Page 34

9.4 The Configuration Page 35

10 Firmware Upgrade Using K-Upload 36

11 Technical Specifications 37

12 Default Communication Parameters 38

13 Factory Default EDID 38

14 Table of ASCII Codes for Serial Communication (Protocol 3000) 40

15 Table of Hex Codes for Serial Communication (Protocol 2000) 41

16 Kramer Protocol 43

16.1 Switching Protocols 43

16.1.1 Switching Protocols via the Front Panel Buttons 43

16.1.2 Switching Protocols via Protocol Commands 43

16.2 Kramer Protocol 3000 43

16.2.1 Protocol 3000 Syntax 44

16.2.2 Command Parts Details 44

16.3 Kramer Protocol 2000 51

Figures

Figure 1: VP-16x18AK 16 x 18 PC UXGA/Audio Router Front Panel 7

Figure 2: VP-16x18AK 16 x 18 PC UXGA/Audio Router Rear Panel 9

Figure 3: Connecting the VP-16x18AK 16 x 18 PC UXGA/Audio Router 14

Figure 4: Connecting to a Balanced Acceptor 14

Figure 5: Connecting to an Unbalanced Acceptor 15

Figure 6: Local Area Connection Properties Window 17

Figure 7: Internet Protocol (TCP/IP) Properties Window 17

Figure 8: VP-16x18AK DIP-switches 18

Figure 9: Control Configuration via RS-232 26

Figure 10: Java Test Page Success Message 27

Figure 11: Entering the IP Address in the Address Bar 27

Figure 12: The Loading Page 28

Figure 13: First Time Security Warning 28

Figure 14: Main Switching Matrix Page 29

Figure 15: Selecting a Switching Point on the Matrix 30

Figure 16: Switching an Input to an Output 30

Figure 17: AFV Mode Warning 31

Figure 18: AFV Mode Audio Channels Switched 31

Contents

iii

Figure 19: Switching Audio in the Offline Mode 32

Figure 20: Exiting Offline Warning 32

Figure 21: Selecting Preset 07 33

Figure 22: Selecting Preset 03 33

Figure 23: Recalling a Preset in Offline Mode 34

Figure 24: Audio Gain Control Page 34

Figure 25: Selecting Audio Input Gain for Channel 2 35

Figure 26: Configuration Page 35

Tables

Table 1: VP-16x18AK 16 x 18 PC UXGA/Audio Router Front Panel Features 8

Table 2: VP-16x18AK 16 x 18 PC UXGA/Audio Router Rear Panel Features 10

Table 3: DIP-switch Settings 18

Table 4: Machine Number DIP-switch Settings 19

Table 5: Technical Specifications of the VP-16x18AK 37

Table 6: Communication Parameters 38

Table 7: VP-16x18AK Video Signal Codes for Protocol 3000 40

Table 8: VP-16x18AK Audio Signal Codes for Protocol 3000 40

Table 9: VP-16x18AK Audio Input Gain Codes 40

Table 10: VP-16x18AK Audio Output Gain Codes 41

Table 11: VP-16x18AK Hex Codes for Switching Video Channels via RS-232/RS-485 41

Table 12: VP-16x18AK Hex Codes for Switching Audio Channels via RS-232/RS-485 41

Table 13: VP-16x18AK Hex Codes for Increasing/Decreasing the Audio Input Gain 41

Table 14: VP-16x18AK Hex Codes for Setting the Audio Input Gain 42

Table 15: VP-16x18AK Hex Codes for Increasing/Decreasing the Output Gain 42

Table 16: VP-16x18AK Hex Codes for Setting the Audio Output Gain 42

Table 17: Instruction Codes for Protocol 3000 45

Table 18: Protocol Definitions 51

Table 19: Instruction Codes for Protocol 2000 52

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront video, audio, presentation, and broadcasting

professionals on a daily basis. In recent years, we have redesigned and

upgraded most of our line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly

defined by function: GROUP 1: Distribution Amplifiers; GROUP 2:

Switchers and Routers; GROUP 3: Control Systems; GROUP 4:

Format/Standards Converters; GROUP 5: Range Extenders and Repeaters;

GROUP 6: Specialty AV Products; GROUP 7: Scan Converters and

Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room

Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:

Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio;

and GROUP 14: Collaboration.

Congratulations on purchasing your VP-16x18AK, 16 x 18 PC

UXGA/Audio Router which is ideal for the following typical applications:

Professional display systems requiring a true 16x18 computer

graphics and audio matrix operation

Multimedia and presentation source and acceptor selection

The package includes the following items:

VP-16x18AK, 16 x 18 PC UXGA/Audio Router

Kramer RC-IR3Infrared Remote Control transmitter (including the

required battery and a separate user manual

)

Power cord

, rack “ears”and this user manual1

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to www.kramerav.com/downloads/VP-16x18AK to check for

up-to-date user manuals, application programs, and to check if

firmware upgrades are available (where appropriate).

Available from www.kramerav.com

We recommend that you use only the power cord that is supplied with this machine

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration

in signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighbouring electrical appliances that may

adversely influence signal quality

Position your VP-16x18AK away from moisture, excessive sunlight and

dust

This equipment is to be used only inside a building. It may

only be connected to other equipment that is installed inside

a building.

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside

the unit

Warning:

Use only the power cord that is supplied with

the unit

Warning:

Do not open the unit. High voltages can

cause electrical shock! Servicing by qualified

personnel only

Warning:

Disconnect the power and unplug the unit

from the wall before installing

Warning:

In case of static electricity discharge, the

device may freeze and require restarting. The

product then returns to normal operation in

its pre-freeze state

Getting Started

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive

2002/96/EC aims to reduce the amount of WEEE sent for disposal to

landfill or incineration by requiring it to be collected and recycled. To

comply with the WEEE Directive, Kramer Electronics has made

arrangements with the European Advanced Recycling Network (EARN)

and will cover any costs of treatment, recycling and recovery of waste

Kramer Electronics branded equipment on arrival at the EARN facility. For

details of Kramer’s recycling arrangements in your particular country go to

our recycling pages at http://www.kramerav.com/support/recycling/.

2.4 Quick Start

This quick start chart summarizes the basic setup and operation steps.

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

Overview

3 Overview

The VP-16x18AK is a high performance, 16x18 computer graphics video

matrix router for high resolution video and stereo audio signals. The

VP-16x18AK is HDTV compatible and lets you simultaneously route any

or all of the 16 inputs to any or all of the 18 outputs.

In particular, the VP-16x18AK, 16 x 18 PC UXGA/Audio Router features:

Kramer’s innovative integrated sync processing; Kr-isp®technology

provides a sharp, stable image by restoring the signal waveform even

when the sync level is too low

A video bandwidth of over 300MHz that ensures transparent

performance even for the most critical applications

12 preset memory locations for quick access to common routing

configurations and audio gain status for each output

Automatic detection of inputs with live connections (the respective

input button lights green)

A delayed switching mode (ranging from 0 to 3.5sec

) for clean

transitions when switching between non-genlocked sources

DC-coupled video inputs and outputs

Audio-follow-video and breakaway options

16 VGA (up to UXGA) video inputs on 15-pin HD connectors

16 unbalanced, stereo audio inputs on 3.5mm mini jacks

16 VGA (up to UXGA) video outputs on 15-pin HD connectors

16 balanced stereo audio outputs on 5-pin, removable terminal block

connectors

Two Twisted Pair outputs on RJ-45 connectors

Audio level control buttons for adjusting the volume of each input

and output

Bass and treble control for each output

The ability to place multiple switching actions in a queue and then to

activate them simultaneously with a one touch button

The ability to lock the front panel buttons to prevent tampering with

settings

Support for DDC (Display Data Channel) communication between

input 1 and output 1 high-density 15-pin HD connectors on pins 12

and 15

Default EDID values programmed on each input

In ½ second increments

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

You can operate the VP-16x18AK using the front panel buttons, or

remotely via:

RS-485, RS-232 serial or Ethernet TCP/UDP commands (using

Kramer 2000 and 3000 protocols) transmitted by a touch screen

system, PC or other serial/Ethernet controller

The Kramer Infrared Remote Control transmitter or Infrared remote

extension cable transmitter (optional)

Your Web browser using Ethernet communication over a LAN

The VP-16x18AK is dependable, rugged and fits into three vertical spaces

(3U) of a standard 19” professional rack.

3.1 Shielded Twisted Pair and Unshielded Twisted Pair

We recommend that you use Shielded Twisted Pair (STP) cable, and stress

that the compliance to electromagnetic interference was tested using STP

cable. There are different levels of STP cable available, and we advise you

to use the best quality STP cable that you can afford. Our non-skew-free

cable, Kramer BC-STP is intended for analog signals where skewing is not

an issue.

In cases where there is skewing, our Unshielded Twisted Pair (UTP) skew-

free cable, Kramer BC-XTP, may be advantageous, and UTP cable might

also be preferable for long range applications. In any event when using UTP

cable, it is advisable to ensure that the cable is installed far away from

electric cables, motors and so on, which are prone to create electrical

interference.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Kramer Commutateur matriciel

Kramer

Kramer Sierra Video 6448V5Sxl Manuel utilisateur

Kramer

Kramer VS-606xl Manuel utilisateur

Kramer

Kramer VS-3232A Manuel utilisateur

Kramer

Kramer Sierra Video 1608V3S Manuel utilisateur

Kramer

Kramer 1608HDS Manuel utilisateur

Kramer

Kramer VS-88H2A Manuel utilisateur

Kramer

Kramer Sierra Video 1616V3S Manuel utilisateur

Kramer

Kramer Sierra Pro XL 1608V5 Manuel utilisateur

Kramer

Kramer 3232DEE Manuel utilisateur

Kramer

Kramer XL 1616V4S Manuel utilisateur

Kramer

Kramer VP-32x1 Manuel utilisateur

Kramer

Kramer VS-44UHD Manuel utilisateur

Kramer

Kramer VS-169TP Manuel utilisateur

Kramer

Kramer XL 3232V Manuel utilisateur

Kramer

Kramer VS-1616D Manuel utilisateur

Kramer

Kramer Sierra Video 4832V5Sxl Manuel utilisateur

Kramer

Kramer VS-48H Manuel utilisateur

Kramer

Kramer XL 1616V2S Manuel utilisateur

Kramer

Kramer Sierra Pro XL 1608V3S Manuel utilisateur

Kramer

Kramer VP-8x4 Manuel utilisateur

Kramer

Kramer XL 1616V Manuel utilisateur

Kramer

Kramer VS-88HC Manuel utilisateur

Kramer

Kramer VP-1608 Manuel utilisateur

Kramer

Kramer VP-12x8 Manuel utilisateur

Manuels Commutateur matriciel populaires d'autres marques

Broadcast Tools

Broadcast Tools SS 8.2 Manuel utilisateur

Altimium

Altimium MATF32 Manuel utilisateur

ALFAtron

ALFAtron ALF-MUK44N Manuel utilisateur

Monoprice

Monoprice Blackbird 15377 Manuel utilisateur

PTN

PTN FMX12 Manuel utilisateur

CYP

CYP nT15GX01 Manuel utilisateur

TESmart

TESmart HMA0402A40 Manuel utilisateur

Octava

Octava HD4XSTPMX Manuel utilisateur

Intelix

Intelix FLX-88 Mode d'emploi

Roland

Roland XS-1HD Manuel utilisateur

Atlona

Atlona AT-HDMI-22M Manuel utilisateur

Link

Link HD8X8 Manuel utilisateur

AMX

AMX AVS-OP-2020-117 Instructions et recettes

Lindy

Lindy 38042 Manuel utilisateur

Extron electronics

Extron electronics MTPX Plus Series Manuel utilisateur

Key Digital

Key Digital Champion KD-16x16CS Manuel utilisateur

Shinybow USA

Shinybow USA SB-8811 Manuel utilisateur

Optimus

Optimus Compact Manuel utilisateur
