Kramer Electronics, Ltd.

USER MANUAL

Model:

VP-14xl

RS-232 Port Extender

Contents

1Introduction 1

2Getting Started 1

2.1 Quick Start 1

3Overview 3

4Defining the VP-14xl RS-232 Port Extender 4

5Connecting the VP-14xl RS-232 Port Extender 5

6Setting the DIP-switches on the VP-14xl 6

6.1 Setting the RS-485 Bus Termination 6

6.2 Setting the ADDR DIP-switches 7

6.3 Setting the BAUD DIP-switches 7

6.4 Selecting Hardware/Software Mode 7

6.5 Hardware Mode 8

6.6 Software Mode 8

7Technical Specifications 8

8Serial Port Pinouts 9

9Table of Hex Codes for Serial Communication (Protocol 2000) 9

Figures

Figure 1: VP-14xl RS-232 Port Extender Front and Rear Panels 4

Figure 2: Connecting the VP-14xl RS-232 Port Extender 5

Figure 3: VP-14xl DIP-switches 6

Tables

Table 1: VP-14xl RS-232 Port Extender Front and Rear Panel Features 4

Table 2: VP-14xl DIP-switch Functions 6

Table 3: Hardware Mode Reply Source DIP-switch Setting 7

Table 4: Software Mode RS-485 Machine Number DIP-switch Setting 7

Table 5: Serial Port Baud Rate DIP-switch Setting 7

Table 6: Technical Specifications of the VP-14xl RS-232 Port Extender 8

Table 7: 9-Pin D-sub Serial Port Pinouts 9

Table 8: Protocol Command Definition 9

Table 9: Instruction Codes for the VP-14xl 10

Table 10: Sample VP-14xl Control Commands 10

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better! Our 1,000-plus different models

now appear in 11 groups1

Congratulations on purchasing your Kramer Tools™ VP-14xl RS-232 Port

Extender. This product is ideal for:

that are clearly defined by function.

•Converting USB and RS-485 interfaces to RS-232 interfaces

•Monitoring several RS-232 controlled machines via one PC port

•Inter-communication between several serially controlled machines

The package includes the following items:

•VP-14xl RS-232 Port Extender

•Mounting bracket

•Power adapter2

•This user manual

(5V DC output)

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high performance high resolution cables4

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:

Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7: Scan

Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack

Adapters; GROUP 11: Sierra Products

2 As an option, you can purchase the Kramer VA-100P-5 10 Port Universal 5-Volt Power Supply enabling you to supply power to up to

10 Kramer devices that require 5V DC

3 Download up-to-date Kramer user manuals from http://www.kramerelectronics.com

4 The complete list of Kramer cables is available from http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

Overview

3 Overview

The unique VP-14xl RS-232 Port Extender distributes an incoming RS-232,

RS-485 or USB command as transmitted by a touch screen control system,

personal computer or other type of control system, to up to three RS-232 ports.

This lets you control up to three compatible devices with only one serial port or

RS-232 card.

The VP-14xl is specifically designed for use with Kramer switchers and routers,

but can be used with any other equipment which employs RS-232.

In particular, the VP-14xl features:

•One RS-232 input port

•One RS-485 input port

•One USB input port

•Three RS-232 output ports

•Operation in either Hardware or Software mode

•DIP-switches to determine the source of the reply command when the

VP-14xl is in hardware mode

•DIP-switches to determine the machine number when operating in Software

mode and there are multiple VP-14xl units on the RS-485 bus

•DIP-switches to determine the serial port baud rate (see Section 6.3)

In Hardware mode, the:

•VP-14xl routes the reply from the output port defined by the DIP-switches 2,

3 and 4 (see Section 6.2)

•RS-232 data is passed from any input to all outputs

In Software mode, the VP-14xl routes the data and reply based on the Protocol

2000 commands received from the PC or other device connected to any of the

inputs (RS-232, RS-485 or USB), see Section 8.

To achieve the best performance, we recommend:

•Connecting only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise levels

(often associated with low quality cables)

•Avoiding interference from neighboring electrical appliances that may

adversely influence signal quality and positioning your VP-14xl in a location

free from moisture and away from excessive sunlight and dust

Caution: No operator serviceable parts inside the unit

Warning: Use only the Kramer Electronics input power wall

adapter that is provided with the unit

Warning: Disconnect the power and unplug the unit from the wall

before installing

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Defining the VP-14xl RS-232 Port Extender

4 Defining the VP-14xl RS-232 Port Extender

Figure 1 and Table 1 define the front and rear panels of the VP-14xl.

Figure 1: VP-14xl RS-232 Port Extender Front and Rear Panels

Table 1: VP-14xl RS-232 Port Extender Front and Rear Panel Features

# Feature Function

1 RS-232 IN 9-pin D-sub (F) Connector Connect to source computer 1

2 RS-485 IN 3-pin Removable Terminal

Block

Connect to source computer 2. Connect G to the Ground

connection, A to the A connection, and B to the B connection

3 USB IN Connector Connect to source computer 3

4 ADDR DIP-switches 2, 3 and 4 Hardware mode: Determines the reply source

Software mode: Determines the machine number (see

Section 6.2)

5 BAUD DIP-switches 5, 6 and 7 Determines the serial port baud rate (see Section 6.2)

6 ON LED Lights green when the unit is powered on

7 TERM DIP-switch 1 Sets the RS-485 bus termination (see Section 6.1)

8 S/W DIP-switch 8 Selects Software or Hardware mode (see Section 6.4)

RS-232

OUTPUTS

1 9-pin D-sub (M)

Connectors

Connect to destination or switcher 1 (see Section 8)

10 2 Connect to destination or switcher 2

11 3 3-pin Removable

Terminal Block

Connect to destination or switcher 3. Connect TX to RX on the

destination, RX to TX, and G to Ground

12 RESET Button Press to initiate startup sequence

13 5V DC Connector Connect to the power adapter, center pin positive

Connecting the VP-14xl RS-232 Port Extender

5 Connecting the VP-14xl RS-232 Port Extender

Figure 2: Connecting the VP-14xl RS-232 Port Extender

To connect your VP-14xl RS-232 Port Extender, as the example in Figure 2

illustrates1

1. Connect up to three computer sources to the input connectors (for example, 2

PCs and a laptop).

2. Connect up to three units to be controlled to the output connectors (for

example, Kramer switches).

3. If you are using the RS-485 input, set the RS-485 termination (see

Section 6.1).

1 Switch OFF the power on each device before connecting it to your VP-14xl. After powering up your VP-14xl, switch on the power to

each device

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Setting the DIP-switches on the VP-14xl

4. Set the Hardware/Software DIP-switch (see Section 6.4) as follows:

In Hardware mode, set the REPLY DIP-switches to determine the unique

reply output port (see Section 6.2)

In Software mode, set the machine number (see Section 6.2).

5. Set the serial port baud rate (see Section 6.3).

6. Select the appropriate machine number (see Section 6.2).

7. Connect the 5V DC power adapter to the 5V DC socket and to the mains

electricity.

Note: Changing any DIP-switch requires that you either power cycle

the VP-14xl or press the Reset button (see Table 1).

6 Setting the DIP-switches on the VP-14xl

Moving a DIP-switch down turns the switch on, moving it up turns the switch off.

Figure 3: VP-14xl DIP-switches

Table 2: VP-14xl DIP-switch Functions

DIP-switch # Function

1 RS-485 termination

2, 3, 4 In Hardware mode: Sets the reply source

In Software mode: Sets the machine number

5, 6, 7 Sets the serial port baud rate

8 Sets Software/Hardware mode

6.1 Setting the RS-485 Bus Termination

DIP-switch 1 sets the RS-485 bus termination. Only the first and last physical

device on the RS-485 bus must be terminated, all other devices must be un-

terminated.

When the DIP-switch is:

•OFF, the unit is un-terminated (default)

•ON, the unit is terminated

Setting the DIP-switches on the VP-14xl

6.2 Setting the ADDR DIP-switches

DIP-switches 2, 3 and 4 set either the reply source (in Hardware mode Table 3) or

machine number (in Software mode Table 4).

Table 3: Hardware Mode Reply Source DIP-switch Setting

Reply Source DIP-switch

2 3 4

Reply is taken from output 1 (default) ON OFF OFF

Reply is taken from output 2 OFF ON OFF

Reply is taken from output 3 OFF OFF ON

Note: When there is more than one VP-14xl attached to the RS-485 bus only one

unit can have a reply source set, all other units must have DIP-switches 2, 3 and 4

set to OFF.

Table 4: Software Mode RS-485 Machine Number DIP-switch Setting

Machine Number DIP-switch Machine Number DIP-switch

2 3 4 2 3 4

1 OFF OFF OFF 5 OFF OFF ON

2 ON OFF OFF 6 ON OFF ON

3 OFF ON OFF 7 OFF ON ON

4 ON ON OFF 8 ON ON ON

When there is more than one VP-14xl attached to the RS-485 bus each unit must

have a unique machine number.

6.3 Setting the BAUD DIP-switches

DIP-switches 5, 6 and 7 set the serial port baud rate in both Hardware and

Software modes.

Table 5: Serial Port Baud Rate DIP-switch Setting

Baud Rate DIP-switch Baud Rate DIP-switch

5 6 7 5 6 7

1200 OFF OFF OFF 19200 OFF OFF ON

2400 ON OFF OFF 38400 ON OFF ON

4800 OFF ON OFF 57600 OFF ON ON

9600 (default) ON ON OFF 115200 ON ON ON

6.4 Selecting Hardware/Software Mode

DIP-switch 8 sets the operating mode to either Hardware or Software mode.

When the DIP-switch is:

•OFF, the unit is set to Hardware mode (default)

•ON, the unit is set to Software mode

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Technical Specifications

6.5 Hardware Mode

In Hardware mode, the:

•RS-232 data is passed from any input to all outputs

•VP-14xl routes the reply from the output port defined by the DIP-switches 2,

3 and 4 (see Section 6.2). For reliable operation, only one port should be

defined

6.6 Software Mode

In Software mode, the VP-14xl routes the data and reply based on the Protocol

2000 commands received from the PC or other device connected to any of the

inputs (RS-232, RS-485 or USB), see Section 8.

Note: Only one reply port can be opened at a time. It is possible to open multiple

direct ports but only one reply port can be open at a time.

This means that if port1 is currently open and you then open port2, the port 1 is

automatically closed. If you then open port 1 again, port 2 is automatically closed.

In this way it is possible to close all reply ports, as well as all direct ports.

7 Technical Specifications

Table 6 provides the technical specifications for the VP-14xl RS-232 Port

Extender.

Table 6: Technical Specifications1

INPUT:

of the VP-14xl RS-232 Port Extender

1 RS-232 on 9-pin D-sub (F) connector; 1 RS-485 on 3-pin removable

terminal block; 1 USB Type B connector

OUTPUTS: 2 RS-232 on 9-pin D-sub (M) connectors, 1 RS-232 on 3-pin removable

terminal block

RS-232 COMPLIANCE 1200 to 115200; 8 data bits, 1 stop bit, no parity

OPERATING MODES: Hardware and Software

USB COMPLIANCE: 1.1

CONTROLS: DIP-switches

POWER SOURCE: 5V DC, 130mA

OPERATING

TEMPERATURE:

0° to +55°C (32° to 131°F)

STORAGE

TEMPERATURE:

-45° to +72°C (-49° to 162°F)

HUMIDITY: 10% to 90%, RHL non-condensing

DIMENSIONS: 12cm x 6.9cm x 2.4cm (4.7" x 2.7" x 0.96") W, D, H

WEIGHT: 0.3kg. (0.7lbs.) approx.

ACCESSORIES: 5V DC 2A Power supply, mounting bracket

OPTIONS: RK-3T 19" rack adapter

1 Specifications are subject to change without notice

Table des matières

Autres manuels Kramer Extenseur

Kramer

Kramer VM-3DT Manuel utilisateur

Kramer

Kramer EXT3-TR Manuel utilisateur

Kramer

Kramer PT-5R/T Manuel utilisateur

Kramer

Kramer MINICOM EXT-RS232 Manuel utilisateur

Kramer

Kramer TP-600TRxr Manuel utilisateur

Kramer

Kramer FC-46H2 Manuel utilisateur

Kramer

Kramer PT-571 Manuel utilisateur

Kramer

Kramer PT-100 Manuel utilisateur

Kramer

Kramer PT-871/2-KIT Manuel utilisateur

Kramer

Kramer VM-3DT Manuel utilisateur

Kramer

Kramer FC-50 Manuel utilisateur

Kramer

Kramer TP-330FW Manuel utilisateur

Kramer

Kramer DS Vision 3000 Manuel utilisateur

Kramer

Kramer PT-571HDCP Manuel utilisateur

Kramer

Kramer VM-2HDT Manuel utilisateur

Kramer

Kramer VM-2DT Manuel utilisateur

Kramer

Kramer VM-3HDT Manuel utilisateur

Kramer

Kramer WP-2UT/R-KIT Manuel utilisateur

Kramer

Kramer VM-4DT Manuel utilisateur

Kramer

Kramer VM-2HDT Manuel utilisateur

Kramer

Kramer EXT3-XR-TR Manuel utilisateur

Kramer

Kramer TP-400FW Manuel utilisateur

Kramer

Kramer FC-50 Manuel utilisateur

Kramer

Kramer WP-789T Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
