Installation Instructions

MODELS:

WP-3H2, W-3H2

HDMI Extender

SAFETY WARNING

Disconnect the unit from the power supply before opening and servicing

For the latest information on our products and a list of Kramer distributors, visit our Web site where

updates to this user manual may befound.

We welcome your questions, comments, andfeedback.

www.kramerAV.com

[email protected]m

P/N:

2900-301252

Rev:

The WP-3H2 / W-3H2, HDMI Extender

Thank you for purchasing the Kramer WP-3H2 Wall Plate (US, UK and EU versions) and/or W-3H2

Dual Insert HDMI Extenders. The HDMI Extender is ideal for ProAV, multimedia and home cinema

applications. The device extends the HDMI transmission length by reclocking and regenerating the

HDMI signal before it sends the output to the HDMI display. It extends the HDMI cable distance

between the HDMI player and the HDMI display. By placing WP-3H2 / W-3H2 in the transmission

path, it removes dropout and digital noise (sparkles) in your picture that may result from using long

HDMI cables. In addition, the HDMI Extender:

•Provides a method of transmitting 4K@60Hz (4:4:4) signals at a distance of up to 20m from the

source (10m from the source to the HDMI Extender, and 10m from the HDMI Extender to the

display).

•Maintains an HDMI single link video resolution of up to 4K@60Hz (4:4:4).

•Supports the DDWG standard for HDMI compliant displays.

•Complies with HDCP 1.4 and HDCP 2.2.

•Supports ARC, CEC, deep color, x. v. color™, 7.1 PCM, 4K and 3D as specified in HDMI 2.0.

Feature

Function

INPUT HDMITM Connector

Connects to an HDMI source.

POWER LED

Lights when power powered (via the HDMI source or via an external

power source connected to the 2-pin terminal block connector).

External Power Supply 2-pin Terminal

Block Connector

Optional: Connect to a power supply. Connect GND to GND, +5V to

+5V. (Typically used when the HDMI source is not strong enough to

power the device, or when the device is located far from the source or

when driving sources such asAOCH cables).

Ring Tongue Terminal Grounding Screw

Connect to grounding wire (optional).

OUTPUT HDMITM Connector

Connect to an HDMI acceptor

The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI

Licensing Administrator, Inc.

Connecting the Input and Output

The WP-3H2 / W-3H2 input is connected via a

male-to-male HDMI cable (not provided) to an HDMI

source, such as a 4K UHD Blu-ray player.

The WP-3H2 / W-3H2 output is connected via a

second male-to-male HDMI cable (not provided) to an

HDMI acceptor, such as a 4K UHD projector or

display.

See the Technical Specifications for the maximum

lengths of the input and output HDMI cables.

Installing the WP-3H2 / W-3H2

After connecting the ports, insert the device into the in-wall box and connect the parts as shown in the

illustrations below:

WP-3H2 US-D Version

WP-3H2 EU/UK Version

DECORA® isa registered trademark of Leviton Manufacturing Co., Inc.

DECORA® design frames are included in US-D models.

We recommend that you use any of the following standard 1 Gang in-wall junction boxes:

•US-D: 1 Gang US electrical junction boxes.

•EU: 1 Gang in-wall junction box, with a cut-hole diameter of 86mm and depth that can fit in both

the device and the connected cables (DIN 49073).

•UK: 1 Gang in-wall junction box, 75x75mm (W, H) and depth that can fit in both the device and

the connected cables (BS 4662 or BS EN 60670-1 used with supplied spacers and screws).

W-3H2 Dual Insert

Grounding the HDMI Extender (Optional)

1. Connect the ring tongue terminal to the building grounding

point wire (a green-yellow, AWG#18 (0.82mm2) wire,

crimped with a proper hand-tool is recommended).

2. Insert the M3x6 screw through the toothed lock washers and

the tongue terminal in the order shown above.

3. Insert the M3x6 screw (with the two toothed lock washers

and ring tongue terminal) into the grounding screw hole and

tighten the screw.

Connect the Power (Optional)

Connect the 5V DC power adapter to the HDMI Extender and plug the adapter into the mains.

Safety Instructions

Caution:

There are no operator serviceable parts inside the unit.

Warning:

Disconnect the power and unplug the unit from the wall before installing.

See www.KramerAV.com for updated safety information.

Technical Specifications

Input

HDMI

On an HDMI Connector

Output

HDMI

On an HDMI Connector

Video

Maximum Resolution:

4K@60Hz 4:4:4

Maximum Range:

Resolution

Total

Distance

HDMI Source

to Device

Device to

Display

4K@60 4:4:4

20m (65ft)

10m (33ft)

4K@60 4:2:0 / 4K@30

40m (130ft)

25m (82ft)

15m (49ft)

1080p@60

45m (150ft)

30m (98ft)

15m (49ft)

Compliance

Up to HDCP 2.2

HDMI Support

ARC, CEC, deep color, x. v. color™, 7.1 PCM, 4K and 3D as specified in

HDMI 2.0

Control

Front Panel

Power LED

Power

Consumption

5V DC, 150mA

Source (WP-3H2)

5.2V/4A

Environmental

Conditions

Operating Temperature:

0° to +40°C (32° to 104°F)

Storage Temperature:

-40° to +70°C (-40° to 158°F)

Operating Humidity:

10% to 90%, RHL non-condensing

Enclosure

Net Dimensions

(W, D, H)

US-D: 7cm x 2.4cm x 11.4cm (2.8" x 0.9" x 4.5);

EU: 8cm x 2.4cm x 8cm (3.1" x 0.9" x 3.1);

UK: 8.6cm x 2.4cm x 8.6cm (3.4" x 0.9" x 3.4")

Dual insert: 5cm x 2.8cm x 4.7cm (2" x 1.1" x 1.8")

Shipping Dimensions

(W, D, H)

Wall plate: 23.2cm x 13.6cm x 10cm (9.1" x 5.4" x 3.9") (W, D, H)

Dual Insert: 12.6cm x 8.4cm x 4.1cm (5" x 3.3" x 1.6") (W, D, H)

Net Weight

0.17kg (0.4lbs) approx..

Shipping Weight

0.56kg (1.2lbs) approx.

Accessories

(WP-3H2)

Included

Power adapter and cord

US-D version: 1 white US Frame set and faceplate

European version: 1 EU white frame, 1 UK white frame, 1 EU/UK white

faceplate

Specifications are subject to change without notice at www.kramerav.com
