Kramer VM-4HDT Manuel utilisateur

USER MANUAL

MODEL:

VM-4HDT

1:4 HDMI to HDBT DA

P/N: 2900-300486 Rev 1 www.kramerAV.com

VM-4HDT – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 3

2.3 Recycling Kramer Products 3

3Overview 4

3.1 About HDBaseT™ Technology 5

3.2 Using Twisted Pair Cable for HDBT 5

3.3 Defining the VM-4HDT 1:4 HDMI to HDBT DA 6

4Connecting the VM-4HDT 7

5Operating the VM-4HDT 9

5.1 IR and RS-232 Signal Routing 9

5.2 Acquiring an EDID 13

6Default EDID 14

7Technical Specifications 16

7.1 Default Communication Parameters 16

8Protocol 3000 17

8.1 Kramer Protocol 3000 Syntax 17

8.2 Kramer Protocol 3000 Commands 20

8.3 Kramer Protocol 3000 –Detailed Commands 20

Figures

Figure 1: VM-4HDT 1:4 HDMI to HDBT DA 6

Figure 2: Connecting the VM-4HDT 1:4 HDMI to HDBT DA 8

Figure 3: VM-4HDT DIP-Switches 9

Figure 4: VM-4HDT DIP-Switches Setup 10

Figure 5: IR/RS-232 Routing Example 12

VM-4HDT - Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:

Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and

GROUP 14: Collaboration.

Congratulations on purchasing your Kramer VM-4HDT 1:4 HDMI to HDBT DA,

which is ideal for the following typical applications:

Boardrooms and meeting rooms

Presentation and multimedia applications

Broadcast

Rental and staging

VM-4HDT - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to http://www.kramerav.com/downloads/VM-4HDT to check for up-to-

date user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighbouring electrical appliances that may adversely

influence signal quality

Position your Kramer VM-4HDT away from moisture, excessive sunlight and

dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

VM-4HDT - Getting Started

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the Kramer Electronics input power wall

adapter that is provided with the unit

Warning:

Disconnect the power and unplug the unit from the wall

before installing

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country

go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

VM-4HDT - Overview

3 Overview

The Kramer MegaTOOLS®VM-4HDT is a high-quality 1:4 HDMI to HDBT DA that

takes one HDMI input, equalizes and reclocks the signal and distributes it to four

identical HDBT outputs. The VM-4HDT distributes signals having resolutions up to

4Kx2K and including WUXGA and 1080p.

In particular, the VM-4HDT features:

A maximum data rate of 10.2Gbps (3.4Gbps per graphic channel)

HDMI support for 3D, Deep Color, x.v.Color™, Lip Sync, HDMI

Uncompressed Audio Channels, Dolby TrueHD, DTS-HD, CEC (only for OUT

HDCP compliance (note that sources that support HDCP will output HDCP

protected content)

Kramer Equalization & re-Klocking™ Technology that rebuilds the digital

signal integrity to travel longer distances

I-EDIDPro™ Kramer Intelligent EDID Processing™, an intelligent EDID

handling and processing algorithm that ensures Plug and Play operation for

HDMI systems

A default EDID for fast and efficient connection of the unit

The default EDID feature lets you connect the VM-4HDT without having to connect a

display to the output

Support for EDID Designer via the USB port

3D pass-through

A 5V DC power source

A MegaTOOLS®sized enclosure. two devices can be mounted in a 1U rack

space using the optional RK-T2B adapter

The VM-4HDT supports a range of up to 70m (230ft) at 2K resolutions and 40m

(130ft) at 4K resolutions (on shielded BC-HDKat6a cable).

VM-4HDT - Overview

3.1 About HDBaseT™ Technology

HDBaseT™ is an advanced all-in-one connectivity technology (supported by the

HDBaseT Alliance). It is particularly suitable in the ProAV –and also the home –

environment as a digital networking alternative, where it enables you to replace

numerous cables and connectors by a single LAN cable used to transmit, for

example, uncompressed full high-definition video, audio, IR, as well as various

control signals.

The products described in this user manual are HDBaseT certified.

3.2 Using Twisted Pair Cable for HDBT

Kramer engineers have developed special twisted pair cables to best match our

digital twisted pair products; BC−HDKat6a (CAT 6 23 AWG cable) significantly

outperforms regular CAT 5 / CAT 6 cables.

We strongly recommend that you use shielded twisted pair cable.

VM-4HDT - Overview

3.3 Defining the VM-4HDT 1:4 HDMI to HDBT DA

Figure 1 defines the VM-4HDT.

Figure 1: VM-4HDT 1:4 HDMI to HDBT DA

Feature

Function

PROGRAM Mini USB

Connector

Use to send RS-232 Commands (see Section 8.3).

Connect to a PC to perform firmware upgrades (via K-

Upload) and work with the EDID Designer.

K-Upload and EDID Designer can be downloaded from

our Web site at:

http://www.kramerav.com/manual/EDID Designer

EDID SETUP Button

Press to capture the input EDID or select the default EDID

(see Section 5)

IN LED

Lights when an active input signal is detected

LINK LEDs

Lights when a link is established with the receiver

(from 1 to 4)

OUTPUT LEDs

Lights when an active output acceptor is detected

(from 1 to 4)

ON LED

Lights when the unit receives power

INPUT HDMI

Connector

Connects to the HDMI source

HDBT OUT

Connectors

Connect to an HDBT acceptor (from 1 to 4), for example

TP-580R

IR 3.5mm Mini Jack

Connect to the remote IR sensor/emitter

RS-232 CONTROL 3-

pin Terminal Block

Connect to the serial controller to send RS-232 data to

remote receiver

SETUP 8-way

DIP-switch

Used to set the IR and RS-232 commands behavior, (see

Section 5.1.1)

SETUP 4-way

DIP-switch

For future use

5V DC Connector

Connects to the 5V DC power supply
