Krabat Pilot
User manual
Krabat Pilot
Krabat provide a guarantee of 2 years on all its products. This guarantee is aimed at defects in workmanship
or materials. The guarantee may be reduced or waive if service or daily maintenance are not observed. It is the
customer’s responsibility to ensure that maintenance is carried out.
The warranty does not cover accidental damage, including damage caused by improper use or lack of main-
tenance. The warranty does not cover normal wear or wear parts.
The warranty is void if non-original parts, or if the product is repaired or modified by personel not approved by
Krabat.
All Krabat products are CE marked according to 93/42 / EØF, Class 1 of 14 June 1993 - Medical Device
Directive. This certifies that it meets all relevant European safety requirements. This manual is approved
according to these standards. The shelf life of the product corresponds to a lifespan of about 5 years
under normal use. Then the product should be renovated by Krabat AS or an approved partner to extend
the life. All service must be performed by Krabat or an authorized partner.
Products with electrical components must be submitted to Krabat for a technical review / overhaul
before it is sent out to use again.
The CE-label is to be removed if the product is modified, or non-original parts are used!
Adjustments not described in Krabat user manuals shall only be carried out by Krabat,
or by personel approved by Krabat.
Krabat products are not toys! Improper use may cause damage to both user and/ or
the product.
Warranty
Safety
Pilot
Pilot
Pilot
01.0. General........................................................................... s. 05
02.0. Main components...............................................s. 06
03.0. Use.......................................................................................... s. 07
04.0. Adjustment/adaptation............................. s. 07
05.0. Accessories...................................................................s. 10
06.0. Maintenance..............................................................s. 11
07.0. Warranty......................................................................... s. 12
4 Krabat Pilot
Krabat Pilot is a technical aid that
supports a child on their hands and
knees, which is the pre-stage to
crawling and moving around. The
patented aid assists the child to raise
their pelvis, making it easier to place
their knees under his or her hips. The
use of this aid should be determined
by your local physiotherapist.
Krabat Pilot gives a dynamic assistance to lift the child
pelvis and can be altered as the child is growing or
changing their activity level. The height has infinite
adjustments possibilities and the length of the board
can be adjusted, making it suitable for children of
different sizes between the ages of 1 – 5 years. The
optimal configuration for the end user is decided at an
individual trial. Do not use the aid unless an individual
trial has been carried out. Furthermore, do not let other
children use the aid without an individual trial.
As children grow they change their movement pattern
on a regular basis. It is likely that the child will need
adjustment of the aid. Contact your local physiotherapist
if the product is not optimal or if adjustments are
needed.
General
01
Krabat Pilot 5
04
Krabat Pilot has the following main components:
01 Coat with integrated undercarriage
02 Mechanics
03 Main board with upholstery
04 Gas spring
05 Straps for groin and buttocks
Main components
02.0
03
01
02
05
Fig. 01
Main components
6 Krabat Pilot
Place the child in the prone position on the Krabat Pilot. Adjust the straps according to the child size and movement
pattern. The strap around the buttocks can be adjusted using the plastic buckles on each side. It is important that
this strap is not too tight. The child needs to have a perpendicular angle of the hips without squeezing the thighs
against the product. The aim for the strap around the buttocks is to prevent the child sliding out of the aid. The
child should move freely in the aid. Make sure the child fingers are not trapped under the aid.
Your local physiotherapist will advise the adults how to handle the child using the Krabat Pilot. To facilitate the
child into the correct position it is recommended that the adult stands on their hands and knees close to the
child. Krabat Pilot gives the child the opportunity to exercise in positions which they cannot get into themselves.
Use
03.0
As the child is growing adjustments are needed. Some of the simple adjustments described below can be done
by the carer. If the aid does not function properly or if bigger adjustments are needed, contact your local physio-
therapist. Otherwise, contact Krabat AS or a representative for Krabat AS for these adjustments.
See video for adjustment and adaptations at www.krabat.com
Individual adjustment and adaptations
04.0
Krabat Pilot 7
The height of the board is altered by simply loosening the M5 screw using the accompanying 4 mm Allen key. Put
the board at desired height and tighten the M5 screw securely. The lowest track in the two front rods indicates
maximum height.
The front board can be fixed in two positions. Remove the upholstery on the front board and loosen the 4 M4
screws using the accompanying. Fix the board in desired position according to the premade holes.
The back board can be fixed in three different positions. Simply loosen the 4 M5 screws on each side using the
accompanying 4 mm Allen key. Pull the board out to desired length and tighten.
Adjustment of the board
Adjusting the length of the board
04.1
04.2
The accompanying Allen key is mounted on the
bottom of the aid
Screws for adjustment of the front board
Use the accompanying Allen key on the screw in front
Screws for adjustment of the back board
The front board can be set in to different positions, and the back board in three different positions
8 Krabat Pilot
The strap around buttocks has two plastic buckles which can be detached. Adjust the length by pulling the end
of the strap.
The gas spring can be fixed in three different positions were the upper hole gives the least amount of assistance,
and the bottom hole gives the most amount of assistance. Use the accompanying 4 mm Allen key and fix the
gas spring in desired position.
Strap around buttocks
Adjustment of the gas spring
04.4
04.3
Plastic buckle to attach the strap around buttocks
The accompanying Allen key is mounted on the
bottom of the aid
Adjustment of length
Screw for adjustment of gas spring
Gas spring in position of the most lift Gas spring in position of medium lift Gas spring in position of light lift
Krabat Pilot 9
We recommend the use of Krabat Co-pilot position and crawling system whilst using the Krabat Pilot. These are
pads for the knee, especially designed for crawling. It protects the knees and gives friction on smooth surfaces,
which optimizes the use of Krabat Pilot.
The pads can be worn on top of normal clothing. Each set has got a left and a right pad which is connected to
each other and the Pilot with elastic bands. This will assist the child in bringing the knees forward in alternate
leg movements. Furthermore, it is limiting hip abduction and guides the legs into the crawling position.
The elastic bands attach the knee pads and the Pilot to each other.
Krabat Pilot accessories
Co-Pilot
05.0
05.1
The accompanying Allen key is mounted on the
bottom of the aid
Velcro attachment
Attachment of the Co-Pilot
Krabat Co-Pilot
10 Krabat Pilot
