Krabat Pilot
User Manual
2
Safety
All Krabat products are CE marked according to MDR 2017/745 and 93/42 / EØF, Class 1 of 14 June
1993 - Medical Device Directive. This certifies that it meets all relevant European safety
requirements. This manual is approved according to these standards. The shelf life of the product
corresponds to a lifespan of about 5 years under normal use. After about 5 years the product should
be renovated by Krabat AS or an approved partner to extend the product’s service life. All service
must be performed by Krabat or an authorized partner.
Products with electrical components must be submitted to Krabat for a technical review / overhaul
before it is sent out to use again.
The CE-label is to be removed if the product is modified, or non-original parts are used!
Adjustments not described in Krabat user manuals shall only be carried out by Krabat, or by
personnel approved by Krabat.
Krabat products are not toys! Improper use may cause damage to both user and/ or the product.
Warranty
Krabat provide a guarantee of 2 years for all products. This guarantee is aimed at defects in
workmanship or materials. The guarantee may be reduced or waive if service or daily maintenance
are not observed. It is the customer’s responsibility to ensure that maintenance is carried out.
The warranty does not cover accidental damage, including damage caused by improper use or lack of
maintenance. The warranty does not cover normal wear or wear parts.
The warranty is void if non-original parts are used, or if the product is repaired or modified by
personnel not approved by Krabat.
3
The information in this manual was correct at the time of publication. The information can
be changed by the manufacturer without notice, therefore go to www.krabat.no for
updated instructions for use and updated technical information about the product at all
times.
Revision history:
Revision:
Date:
Author:
Notes:
1.0
10.10.2016
A.L. Sørensen
Etablished
2.0
03.05.2021
A.Simensen
Lagt til revisjonstabell og advarsler
4
Krabat Pilot
General....................................................................................... s. 05
Main components.............................................................. s. 07
Use................................................................................................. s. 08
Individual adjustments….............................................. s. 08
Optional equipment........................................................ s. 09
Maintenance......................................................................... s. 10
Technical data………………………………………………..………………..s. 11
Warnings and definitions........................................... s. 12
Warranty.................................................................................. s. 15
5
01 –General
Krabat Pilot is an innovative and different transfer aid for the younges users. Traditional
crawlingaids gives minimal active help to the child to lift the hips, but so does Krabat Pilot.
When the child is helped to lift the hips, it is easier to get the knees under the child and this
makes it easier to move. The lifting movement that Krabat Pilot gives is dynamic, and
changes all the time when the child moves. By using the crawling and positioning
equipment Co-Pilot, the child gets the friction needed against the ground and adjustable
elastics that can alternate leg movement, correct the child back in 4-foot standing and
prevent hip abduction.
Krabat Pilot requires individual testing and customization.
6
Krabat Pilot is an aid for positioning in 4-
footer, pre-stages for crawling and
transfer. The pilot provides a starting
position that stimulates play and
participation by the child coming up
from the floor. Weight bearing on the
hip and shoulder joints is very important
for the child's motor development.
It is beneficial to start with Krabat Pilot
early while the child is motivated to
work with 4-foot standing and crawling.
The aid provides a dynamic lift of the
child's hips, which can be changed
according to the child's weight and
activity level. The height can also be
changed so that Krabat Pilot is suitable
for children of different sizes, where the
main group is between 1 and 5 years
old.
Krabat Pilot has stepless height adjustment and adjustable length of the board. The strength of the
gas spring that adjusts the lift on the hips can be easily adapted to the individual user. The optimal
configuration for each child with the correct height, length of the board and strength of the gas
spring that lifts the hips is determined by a test.
It is easy to take the child in and out of the aid. The child is also not restrained (other than with a
strap under the buttocks), and can move relatively freely. This is important both for well-being and
for the crab movement.
Krabat Pilot is designed so that there is a minimal risk of fingers getting caught under the wheels
during use. The surface facing the child is soft and easy to keep clean.
Krabat Pilot has a modern and thoughtful design, and is compact and easy to take with you.
Movement
7
02 –Main components –Krabat Pilot
Krabat Pilot with manuel height adjustment has the main components:
01 Adjustable cradle to place the child safely in during use.
02 Lower main structure that controls the direction of the crab aid
03 Adjustable seat strap that keeps the child in the correct position
04 Directional wheels
05 Height adjustment
06 Mount for Krabat Co-Pilot (optional)
01
03
02
04
05
06
8
03 –Use
Good and correct friction on the knees is important for crawling. Krabat Co-Pilot are knee pads
specially developed to provide good friction against surfaces such as parquet and floor coverings
when the child uses Krabat Pilot.
Krabat Co-Pilot is delivered with elastic that is attached between the child and the aid, and / or
between the child's knees. The result of this solution is that the child can get help of himself to move
his knees forward during crawling. The elastic reduces hip abduction and leads the child back to the
crab position in case of spasm.
04 –Adjustment
Adjustment of height
Stepless adjustment, lowest possibility
Stepless adjustment, highest possibility
Krabat Co-Pilot
Backstrap
Butterfly harness
9
05 –Accessories
There are some accessories available, eg Co-pilot, new pillows, vests and straps.
See www.krabat.com for an updated list of accessories.
Most of the accessories are delivered with their own user and installation instructions.
If you need accessories or other custom equipment for Krabat Pilot, contact a Krabat representative
or a Krabat-approved therapist for installation and adjustment.
Adjusting of the cradle
Adjusting of the gas spring
Gas spring in position with most lift
Gas spring in position with medium lift
Gas spring in position with less lift
10
06 - Maintenance
All metal and plastic parts can be cleaned with mild soapy water. The cot is covered with foam
material, and can be cleaned with either a cloth and soapy water or machine washed at 40 degrees.
If necessary, new ones can be bought, which are easily replaced and can be done on your own.
This is a personal product, individually tailored according to the medical requirements and
requirements of each user. No regular maintenance is required.
Wash product components if necessary. Follow regular hygiene advice and keep the product clean at
all times.
The pillows are attached to the product with Velcro. Advice on removing stains can be found at
www.krabat.no.
Ball bearings and other moving parts are maintenance-free and should not be lubricated.
To avoid damage, no part of the product should be repaired or maintained while in use.
NOTE: If any part breaks, breaks, or is obviously damaged, stop using the product and contact
authorized personnel for service or appropriate corrective action.
07 - Individual adjustment
If the product needs to be adjusted for any reason, please contact a physiotherapist or occupational
therapist. Adjustments to the unit must be made by qualified personnel or Krabat AS.
Under no circumstances may the user make changes to the product.
