Konica Minolta PagePro 1300W Guide de configuration

PagePro 1300W

GeneralInformation

Guide

1760486-001A

4136-7744-01A

Locate your Printer...



On a surface capable of supporting the printer, consumables, and media.



A surface can be tested for levelness with a standard round pencil.

If the pencil rolls, the surface is not level. Clear the area of any

obstruction or items such as cables that might prevent the printer

from sitting directly on the flat, level surface.



If the printer is located in a cold room that is rapidly heated, or if the printer

is moved from a cold place to a warm, humid place, condensation may

occur within the printer, degrading print quality. If this occurs, allow the

printer to adapt to the environment for about one hour before use.



If using a humidifier or water vaporizer in the room with the printer, use

only purified or distilled water. Impurities in the water may be released into

the air, where they can accumulate inside the printer and cause degraded

printer output.

Component Weight

Printer 15.45 lb (7 kg)

Printer with consumables (such as

toner cartridge and drum cartridge) 17.20 lb (7.8 kg)

With these characteristics... But away from...

On a hard, flat, stable, level (±1° or

less slant at any point around the

machine).

Direct sunlight. Heating and cooling

sources, extreme temperature or

humidity changes, wind, and dust.

Open flamesor items that can easily

burn.

Close to an easily accessible

grounded power supply (on an

exclusively dedicated power outlet)

that meets printer specifications.

Near your computer. At the length

6.5 ft. (2 m) or less for an IEEE 1284

bidirectional parallel connection.

A connection to the same electrical

circuit as high-current machines.

Noise-generating equipment, such

as a copier or air conditioner, and

strong magnetic or electromagnetic

fields, such as a refrigerator.

With enough space to allow

adequate ventilation and easy

servicing.

Water, water pipes, liquid (drink)

containers, and corrosive chemicals

or vapors, such as ammonia.

With an ambient temperature range

of 50°–95° F (10°–35° C) and

relative humidity range of 15%–85%

(noncondensating).

Small, loose metal parts, such as

paper clips and staples.

At an altitude of 0–10,170 ft.

(0–3,100 m). Excessive vibration.

CAUTION

Obstructing the ventilation grilles could present a fire hazard.

WARNING!

For products installed outside North America, do not connect the

groundwire to gas or water pipes or grounding for telephones.

Safety Information

Laser Safety

This is a page printer which operates by means of a laser. There is no possi-

bility of danger from the laser, provided the printer is operated according to

the instructions in this manual.

Since radiation emitted by the laser is completely confined within protective

housing and external covers, the laser beam cannot escape from the

machine during any phase of user operation.

Internal Laser Radiation

Maximum average radiation power: 36.903 µW at the laser aperture of the

print head unit.

Wavelength: 770-800 nm.

This product employs a Class 3b Laser Diode that emits an invisible laser

beam. The Laser Diode and the Scanning Polygon Mirror are incorporated in

the print head unit.

The print head unit is NOT A FIELD SERVICE ITEM. Therefore, the print

head unit should not be opened under any circumstances.

Laser aperture of the print

head unit.

Laser Safety Label

CAUTION

Use of controls, adjustments, or performance of procedures other than those

specified in this manual may result in hazardous radiation exposure.

This is a semiconductor laser. The maximum power of the laser diode is 15

mW and the wavelength is 770-800 nm. A laser safety label is attached to the

back of the printer.

For United States Users-CDRH Regulation

This printer is certified as a Class 1 Laser product under the Radiation Perfor-

mance Standard according to the Food, Drug and Cosmetic Act of 1990.

Compliance is mandatory for laser products marketed in the United States,

and is reported to the Center for Devices and Radiological Health (CDRH) of

the U.S. Food and Drug Administration (FDA) of the Department of Health

and Human Services (DHHS). This means that the product does not produce

hazardous laser radiation.

The label shown above indicates compliance with the CDRH regulations and

must be attached to laser products marketed in the United States.

For European Users-CE Marking (Declaration of

Conformity)

This product complies with the following EU directives: 89/336/EEC, 73/23/

EEC, and 93/68/EEC directives. This declaration is valid for the area of the

European Union (EU) only.

This device must be used with a shielded parallel interface cable and

shielded USB interface cable. The use of non-shielded cables is likely to

result in interference with radio communications, and is prohibited under 89/

336/EEC rules.

Ozone Release

During printer operation, a small quantity of ozone is released. This amount is

not large enough to harm anyone adversely. However, be sure the room

where the printer is being used has adequate ventilation, especially if you are

printing a high volume of materials or if the printer is being used continuously

over a long period.

Support Information

Wherever inthe world you have installed your printer,the top three sources of

support are the same.

1. Your Vendor

In many cases, your local vendor may be best equipped to help you. Your

vendor may have specially trained technicians available to answer questions

and has the equipment to analyze your situation.

2. Your Application Vendor

Often, “printing” problems have more to do with the application being used

than with the printer itself. In this case, the application manufacturer is the

best source of help.

3. Information on the web

KONICA MINOLTA provides extensive information on the web. Here you will

find general information about the KONICA MINOLTA products and technical

support information aiding you in using your product in the best possible man-

ner. To access your local website, please refer to www.minolta-qms.com and

select your country.

Technical Support

When you need support by telephone, fax, or e-mail, please gather the fol-

lowing information. Have it ready to tell a technician if you call or include it in

your fax or e-mail, so our technicians can help you more quickly.



The printer model and serial number



Your phone and fax number, e-mail address, shipping address



A description of the problem



The type of host computer you’re using



The type and version of operating system you’re using



The interface you’re using and protocol (for example, TCP/IP for

network)



The application and version you’re using



The emulation (for example, PostScript, PCL, or GDI) of the file

you’re trying to print (listed on the Config page)



A Configuration Page or Startup Page

KONICA MINOLTA Contacts

Worldwide Contact Information

The Americas

Internet www.minolta-qms.com

Support via

Internet www.minolta-qms.com/support,

then click on Answer Base

Service via

Internet www.minolta-qms.com/service

Q-Shop www.q-shop.com

Order products, accessories, and consumables directly

from Konica Minolta Printing Solutions USA Inc.

Font & Form

Center www.minolta-qms.com/products/font center/index.html

Address One Magnum Pass

Mobile, Alabama 36618

Information via

Telephone 1 (800) 523-2696 (toll-free US)

Information on KONICA MINOLTA products, supplies,

and accessories, and on the authorized

KONICA MINOLTA reseller or service provider nearest

you

Where to Buy &

Authorized

Service Provider

via Internet

www.minolta-qms.com/buy.html

US and Canada only Find resellers and authorized ser-

vice providers near you

Technical Support and Service Requests

Support via

E-mail www.minolta-qms.com/support/supportmail/index.html

Telephone 1 (877) 778-2687 (toll-free US, Canada, Mexico)

7:00 am–7:00 pm Central Time (closed national holidays)

Also use this number for information about service, installa-

tion, maintenance pricing, on-site service and depot repair,

and service provider uninstall and repack

Fax,

Latin America 1 (251) 639-3347

Mexico Service

Mexico City

Rest of Mexico 52-70-5900 (Hardware only)

01-800-0032500 (Hardware only)

Spare Parts Ordering and Information

Lusk &

Associates 1 (866) 767-7278

www.lusknet.com

National Parts

Depot 1 (800) 524-8338 (Option 1)

www.nationalparts.com

Font & Form Center

Telephone 1 (251) 634-4FONT

General Contacts

Telephone

Latin America

Canada

1 (251) 633-4300

1 (905) 206-0848

Fax

Canada

Latin America

1 (251) 633-4866

1 (905) 206-0903

1 (251) 639-3347

E-mail info@minolta-qms.com

Internet

US/Canada

Latin America www.minolta-qms.com/usa.html

www.minolta-qms.com/Latin_America

Europe, Middle East and Africa

Asia-Pacific

Address Edisonbaan 14-E

3430BL Nieuwegein

PO Box 1491

The Netherlands

Telephone Please contact your local vendor, or visit

euro.minolta-qms.com and select your country to find local

support information.

E-mail helpdesk@minolta-qms.nl

Internet euro.minolta-qms.com

Australia

Address 44 Hampden Road

Artarmon NSW 2064

PO Box 364

Artarmon NSW 1570

Telephone

Fax +61 2 9884 9966

+61 2 9884 9977

Technical Sup-

port Helpline 1800 456 999 (toll free Australia)

E-mail technical@minolta-qms.com.au

People’s Republic of China

Address Unit 3008, Di Wang Commercial Centre

Shun Hing Square

5002 Shen Nan Dong Road

Shenzhen, 518008

Telephone

Fax +86 755 8213 9688

+86 755 2588 1166

Technical Sup-

port Helpline +86 800 830 3434 (toll free PR China)

Hong Kong

Address 12/F, 1063 King’s Road

Quarry Bay

Hong Kong

Telephone

Fax +852 2997 7787

+852 2997 7784

Japan

Technical Sup-

port Helpline 001 800 7746 8377 (toll free Hong Kong)

Malaysia

Address 1, Jalan 13/6

46200 Petaling Jaya

Selangor

Telephone

Fax +6 03 7957 2611

+6 03 7957 4124

Technical Sup-

port Helpline 1800 7746 8377 (toll free Malaysia)

Singapore

Address Balmoral Plaza

271 Upper Bukit Timah Road #03-06

Singapore, 259708

Telephone

Fax +65 6735 8466

+65 6735 8477

Technical Sup-

port Helpline 1800 735 4498 (toll free Singapore)

Address Sumitomofudousan Shiba Bldg. 11 4F

1-5-9, Shiba, Minato-ku

Tokyo, 105-0014 Japan

Telephone

Fax 03-5439-2705

03-5439-2713

E-mail support@minolta-qms.co.jp

Autres manuels pour PagePro 1300W

Table des matières

Autres manuels Konica Minolta Imprimante

Konica Minolta

Konica Minolta bizhub C550 Series Manuel utilisateur

Konica Minolta

Konica Minolta bizhub C3120i Manuel utilisateur

Konica Minolta

Konica Minolta PagePro 1250E Manuel utilisateur

Konica Minolta

Konica Minolta Magicolor 4650 Manuel utilisateur

Konica Minolta

Konica Minolta magicolor 2430 DL Manuel utilisateur

Konica Minolta

Konica Minolta AccurioPrint 2100 Manuel utilisateur

Konica Minolta

Konica Minolta PagePro 1400W Manuel utilisateur

Konica Minolta

Konica Minolta Magicolor 2550 Manuel utilisateur

Konica Minolta

Konica Minolta A0DX011 Manuel utilisateur

Konica Minolta

Konica Minolta PagePro 1250W. Manuel utilisateur

Konica Minolta

Konica Minolta bizhub PRESS C70hc Manuel utilisateur

Konica Minolta

Konica Minolta Magicolor 5450 Manuel utilisateur

Konica Minolta

Konica Minolta magicolor 1650EN Instructions originales

Konica Minolta

Konica Minolta bizhub 3301P Manuel utilisateur

Konica Minolta

Konica Minolta Magicolor 2300W Manuel utilisateur

Konica Minolta

Konica Minolta bizhub C658 Manuel utilisateur

Konica Minolta

Konica Minolta bizhub C550 Series Manuel utilisateur

Konica Minolta

Konica Minolta magicolor 5670EN Manuel utilisateur

Konica Minolta

Konica Minolta magicolor 7450 II Manuel utilisateur

Konica Minolta

Konica Minolta BIZHUB C353P Manuel utilisateur

Konica Minolta

Konica Minolta magicolor 1690MF Manuel utilisateur

Konica Minolta

Konica Minolta Magicolor 4650EN Manuel utilisateur

Konica Minolta

Konica Minolta Magicolor 5570 Manuel utilisateur

Konica Minolta

Konica Minolta bizhub 40P/40PX Instructions originales

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
