Installation and User's Guide

Freestanding Cast Iron Bath





1066115-X2-A

English page 1-4



K-11195X

Important Information

IMPORTANT NOTICE TO INSTALLERS!: Please leave these instructions for the consumer. They contain

important information.

CAUTION: Risk of personal injury. Cast iron baths are extremely heavy. Wear appropriate safety

equipment when installing these products.

CAUTION: Risk of product or property damage. Do not support the bath by the rim.

Thank You for Choosing Kohler Company

Tools and Materials

Thank you for choosing Kohler. Kohler craftsmanship oers you a rare combination of proven performance

and graceful sophistication that will satisfy you for years to come. The dependability and beauty of your Kohler

product will surpass your highest expectations. We’re very proud of our products here at Kohler and we know

you will be too.

Please take a few minutes to review this manual before you start installation. If you encounter any installation

or performance problems, please don’t hesitate to contact us. Our phone numbers and website are listed on

back cover.

All information in this manual is based upon the latest product information available at the time of publication.

At Kohler, we constantly strive to improve the quality of our products. We reserve the right to make changes in

product characteristics, packaging or availability at any time without notice.

Thank you for choosing Kohler Company.

Before You Begin

¨Observe all local plumbing and building codes.

¨Before moving the bath, carefully plan the installation area. This bath is heavy and will not easily t through

doorways.

¨To ensure a successful installation, the oor must be level.

¨Provide adequate oor support.

¨Floor support under bath must provide for a minimum of 270 kg/square meter loading.

¨Ensure that the drain location corresponds to the bath outlet.

¨The illustrations shown may not represent your actual product. The installation instructions still apply.

¨Uncrate and inspect bath for damage. Leave all materials in the crate during construction to prevent damage.

Plus:

• Conventional woodworking tools and materials

• Drop cloth

1066115-X2-A 2 Kohler Co.

Kohler Co. 3 1066115-X2-A

CAUTION: Risk of property and product damage. Ensure a watertight seal on the bath drain connections.

CAUTION: Risk of personal injury. Cast iron baths are extremely heavy. Obtain sucient help to carefully

lift or move the bath.

Prepare the Site

Install Plumbing

Install Drain

¨Old Bath Removal (if necessary)

¨Apply the nished ooring material prior to installing the bath.

¨Ensure the nished oor is level before proceeding with the bath installation.

Suboor Preparation

• Check the ooring under the bath, and make repairs as needed. Make sure the suboor is level.

Plumbing Preparation

•Position the plumbing according to rough-in dimensions. Cap the supplies and check for leaks.

¨When the bath is securely positioned, connect the drain to the trap. See g. A, B, C.

¨Install the faucet and ings. Open the hot and cold water valves, and check the supply connections for leaks.

¨Run water into the bath, and check the drain connections for leaks.

¨Install the drain on the bath according to the drain manufactuer’s instructions.

¨Use at least four people to carefully place the bath at the desired place.

Fig. A Fig. B

Connect Here

Fig. C

Connect Here Connect Here

Silicone Filler

Kohler Co. 3 1066115-X2-A

Install the Adjusting Bath Legs

NOTICE: All housekeeping and maintenance employees must be trained in the proper cleaning of Kohler

bathtubs. Post a copy of this notice in a readily-visible location.

¨Do not allow the feet or drain hole to scrape the oor

during installation, or you could damage the enamel.

¨All baths are equipped with adjustable legs for proper

level and height on all oors. The adjustment is 10 mm

compared to dimension cited on price list. Do not seal legs

to the oor.

¨Check for level along the top of the side of the bath and

across the drain end.

WARNING: Risk of personal injury. Wear personal

protective equipment and obtain sucient help

to carefully lift or move the bath. Cast iron baths

are extremely heavy. If the cast iron bath is not lifted

properly, personal injury may occur.

Bolt

M10 x 45

Adjusting Bath Legs

Bolt

M12 x 50

Bath

Clean-up After Installation

Important Consumer Information

When cleaning up after installation, do not use abrasive cleansers as they may scratch and dull the surface.

Use warm water and liquid, non-abrasive detergent to clean the surface.

Stubborn stains, paint, or tar can be removed with turpentine or paint thinner. Do not allow cleaners containing

petroleum distillates to remain in contact with the bath surface for long periods of time. Plaster can be removed

by scraping with wood edge. Do not use metal scrapers, wire brushes, or other metal tools. One of the powder

type detergents may be used on a damp cloth to provide mild abrasive action to the residual plaster.

The Safeguard slip resistant surface on this bathtub meets or exceeds the requirements of ASME/ANSI for

A112.19.1M slip resistance.

DANGER: Risk of product damage. Improper maintenance or cleansers may permanently remove the slip

resistant surface on Kohler bathtubs.

¨Do not use steel wool, wire brushes, metal scrapers or abrasive sponge pads to clean a Kohler bathtub.

¨Do not use bung machines on the slip resistant surface.

¨Do not use high alkaline or strong acid cleansers.

¨Do not use abrasive cleansers.

¨Use only non-abrasive cleansers and a soft nylon brush to clean the slip resistant surface.

¨When using commercial cleansers, use cleansers with a pH of between three and eight.

¨Follow cleanser manufacturer instructions very carefully.

1066115-X2-A 4 Kohler Co.









 

  

  

 

  



   



  



 



เพิ�มเติม

• เครื�องมือที�ใช้สําหรับงานไม้

• ผ้าสะอาด



¨ 

¨   



¨ 

¨ 

¨ 

¨ 

¨ 



¨  

   



Kohler Co. 5 1066115-X2-A

   



   









¨ 

¨ 

¨ 



• 



• 

¨ 

¨ 

¨ 

¨ 

¨ 

ภาพ ก. ภาพ ข.

ภาพ ค.

ขันข้อต่อที�นี�

ยาซิลิโคน

1066115-X2-A 6 Kohler Co.

  









¨ 



¨    

  

 

¨ 



  



¨ 

¨ 

¨ 

¨ 

¨ 

¨ 

¨ 

 



 

 



โบลท์

M10 x 45

โบลท์

M12 x 50

อ่างอาบนํ�า

ขาอ่างอาบนํ�า

สามารถปรับระดับได้

  



 





Kohler Co. 7 1066115-X2-A



 



E-mail: [email protected]

KOHLER (THAILAND) PUBLIC COMPANY LIMITED

16th FL. Jasmine City Bldg., 2 Soi Sukhumvit 23, Sukhumvit Road, Wattana, Bangkok 10110 Thailand

Call Center Tel. +(66) 2204 6222 Fax. +(66) 2204 6224

1066115-X2-A
