A-61555 May 2010 5-1

5 Maintenance

This chapter provides:

• a cleaning frequency chart

• a list of cleaning tools and materials

• a list of supplies, consumables and accessories

• cleaning procedures for the scanner

• replacement procedures for customer-replaceable parts

IMPORTANT: Scanner components marked with a green tab indicate

operator-accessible parts.

Cleaning your scanner and preventative maintenance on a regular

basis is required to ensure the best possible image quality. The

following is a preventative maintenance procedure that is

recommended to prevent costly interruptions during production

scanning. Following this procedure as recommended should take

approximately 5 to 10 minutes.

Some document types generate more paper dust and debris and may

require more frequent cleaning than recommended.

NOTES:

• Some debris from the rubber tires on the feed module and separation

roller is normal. Tire debris does not always mean that the tires are

worn or damaged. After cleaning, inspect the tires for wear and

replace the separation roller or feed module if necessary.

• When cleaning rollers/tires, allow the rollers/tires to dry completely

before scanning.

• Use only the recommended cleaning supplies.

• Do not use canned/compressed air.

• Using unapproved cleaning fluids or solvents may damage the

rubber tires.

5-2 A-61555 May2010

Cleaning frequency

chart A recommended cleaning sequence includes vacuuming the scanner

transport, cleaning the residue from the feed module, separation roller

or drive rollers and cleaning the imaging guides.

Use the chart below as a guide to the order and how frequently you

should clean your scanner.

Cleaning tools and

materials Use only these cleaning tools and materials when performing routine

maintenance on your scanner. Use of any other cleaning materials

could damage your scanner.

•Kodak Digital Science Transport Cleaning Sheets

•Kodak Digital Science Roller Cleaning Pads

• Staticide wipes for Kodak Scanners

• A vacuum cleaner and tools

Procedure Start of

day Middle of

shift Start of new

shift

Vacuum output tray and input

areas (input elevator and

transport)

Clean all rollers x x

Vacuum transport area x x x

Remove and vacuum under

background strips x

Run transport cleaning sheet x x

Clean imaging guides - basic x x x

Clean imaging guides - thorough x x

A-61555 May 2010 5-3

Supplies,

consumables and

accessories

Contact your scanner supplier to order supplies.

NOTE: Items and catalog numbers are subject to change.

Ordering parts The following parts can be ordered from Parts Services.

Supplies/Consumables CAT No.

Kodak Feeder Consumables Kit for i600/i1800 Series

Scanners 108 4755

Kodak Feeder Kit for Ultralightweight Paper for i600/i1800

Series Scanners 896 5279

Kodak Extra-Large Feeder Consumables Kit for i600/i1800

Series Scanners 842 6157

Kodak Extra-Extra-Large Feeder Consumables Kit for i600/

i1800 Series Scanners 134 3680

Kodak Imaging Guide Set / for i600/i1800 Series Scanners 197 6703

Kodak Printer Ink Blotters, Front Side for i1800 Series

Scanners 125 7633

Kodak Printer Ink Blotters, Rear Side for i1800 Series

Scanners 114 1472

Enhanced Printer Black Ink Cartridge for Kodak i800/i1800

Series Scanners 818 3386

Enhanced Printer Red Ink Cartridge for Kodak i800/i1800

Series Scanners 159 6832

Kodak Digital Science Transport Cleaning Sheets (qty 50) 169 0783

High Resolution Printer Maintenance Kit 877 6254

High Resolution Printer Black Ink Cartridge for Kodak i1800

Series Scanners and Kodak Imagelink Microimager 70 822 1376

High Resolution Printer Red Ink Cartridge for Kodak i1800

Series Scanners and Kodak Imagelink Microimager 70 145 6532

Kodak Digital Science Roller Cleaning Pads (qty 24) 853 5981

Staticide Wipes for Kodak Scanners (qty 144) 896 5519

Kodak Calibration Targets (qty 5) 127 1436

Black Background (for i1800/i700/i600 Series Scanners) 801 4755

Accessories CAT No.

Kodak White Background Accessory 894 9000

Kodak Manual Feeder for the i1800 Series Scanners 874 1894

Kodak High Resolution Printer Accessory 815 0237

Parts Part No.

Exit deflector 3E9575

26 in. document extenders (qty 1 per box) 5E4754

30 in. document extenders (qty 1 per box) 9E3216

34 in. document extenders (qty 1 per box) 9E5277

5-4 A-61555 May2010

Cleaning procedures Follow the cleaning procedure below to ensure the best scanner

performance and image quality.

Cleaning the OCP

touchscreen The touchscreen requires very little maintenance. However,

periodically, it is recommended that you use a Staticide wipe to clean

the screen and dry it with a lint free cloth.

Vacuuming the output tray

and input elevator 1. Power down the scanner.

2. Remove the output tray.

3. Thoroughly vacuum the outputtray area and the input elevator area.

A-61555 May 2010 5-5

Cleaning the rollers Cleaning the rollers includes all of the rollers in the transport area, the

separation roller tires and the feed module tires.

1. Pull up on the pod release lever and open the pod.

2. Manually rotate and wipe the rollers with a roller cleaning pad.

IMPORTANT: The roller cleaning pad contains sodium lauryl ether

sulfate and sodium silicate which can cause eye

irritation. Refer to the MSDS for more information.

3. Dry the rollers with a lint-free cloth.

5-6 A-61555 May2010

Cleaning the separation roller tires

4. Pull the separation pad holder forward and remove the separation

roller.

5. Manually rotate and wipe the separation roller tires with a roller

cleaning pad. For best results wipe parallel to the ribs in order to

remove any residue between the ribs.

6. Inspect the tires. If the tires show signs of wear or damage, replace

the separation roller. See “Replacement procedures” later in this

chapter.

7. Reinstall the separation roller by aligning the slots on the separation

roller with the holders.

8. Close the pod.

A-61555 May 2010 5-7

Cleaning the feed module tires

9. Lift up the printer access cover.

10.Push the release lever down (located underneath the printer access

cover) to release and remove the feed module.

5-8 A-61555 May2010

11.Manually rotate and wipe the feed module tires with a roller cleaning

pad. For best results wipe parallel to the ribs in order to remove any

residue between the ribs.

12.Inspect the tires. If the tires show signs of wear or damage, replace

the feed module tires. See “Replacement procedures” later in this

chapter.

13.Reinstall the feed module by aligning the pins and fitting it into

position. Pull up on the release lever to lock it into place. Verify that

the feed module is securely in place and moves freely after you

install it.

14.Close the printer access cover.

Align

these

areas

A-61555 May 2010 5-9

Vacuuming the transport

area 1. Open the pod.

2. Thoroughly vacuum the entire transport area, paying particular

attention to these areas:

Vacuuming under the

background strips 1. Using the green tabs pull off the upper and lower background strips

and set them aside.

2. Vacuum the areas where the background strips are adhered to.

3. Reinstall the upper and lower background strips.

the edges of the transport the reflective tape near the

front of the transport

the reflective tape near the

front of the pod the three multifeed sensors at the base

of the transport and the pod
