Kodak PIXPRO ORBIT360 4KVR360 Manuel utilisateur

Ver. 1.0

User Manual

PIXPRO 360 VR Remote Viewer

(Smart Device Version)

for

KODAK PIXPRO ORBIT360 4K/4KVR360

VR Camera

Before You Start

Declaration of Conformity

Responsible Party: JK Imaging Ltd.

Address: JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA

JK Imaging Europe, 71 Clarendon Road, Watford, WD17 1DS, UK

Company Website: kodakpixpro.com

About this Manual

JK Imaging reserves all rights of this document. No part of this published manual may be reproduced, transmitted,

transcribed, stored in a retrieval system or translated into any language or computer language, in any form, by any means,

without the prior written permission of JK Imaging Ltd.

All trademarks mentioned in this manual are used for identiication purposes only and are properties of their respective

owners.

This manual will instruct you on how to operate the PIXPRO 360 VR Remote Viewer APP. Every eort has been made to

ensure that the contents of this manual are accurate, however JK Imaging reserves the right to modify and make updates

and changes as necessary.

Throughout this manual, the following symbols are used to help you locate information quickly and easily:

Indicates useful information

Indicates pressing and holding in a certain point

Indicates tap a certain point

Matters Needing Attention

Your Smart Device operating system needs to be version iOS 9 or higher, or ANDROID 5.0 or higher. iPad mini1 / iPad 4 /

iPad Air 1 / iPhone 5S and earlier models (using any system versions) will not support this APP.

Do not use in places with high intensity magnetic ields, electrostatic and electric wave interference (for example near a

microwave oven), which may or may not cause failure in the camera receiving proper signals.

Do not use the Wi-Fi or NFC connection or functions on an airplane.

When using the Wi-Fi or NFC connection, the camera and the Smart Device can only be connected one to one. Please

keep the camera within 10 meters (32.8 feet) avoiding signal shielding interference.

When the Smart Device detects its operating system to be out of memory, the APP will not be able to operate normally.

Please check the memory of your Smart Device and make any necessary updates.

We will update the APP from time to time. Some new features will require you to synchronously update the irmware

version of the camera in order to ensure the stability of the system. Please note for these types of prompts on the APP.

Contents

Before You Start............................................................................................................ 1

Contents ....................................................................................................................... 3

Connecting the Camera with your Smart Device ....................................................... 6

Downloading and Installing the APP ..................................................................................................................................... 6

Establishing Connection........................................................................................................................................................ 7

Wi-Fi Connections (iOS and ANDROID Systems) ......................................................................................................... 7

BLUETOOH Connection (ANDROID System) ................................................................................................................ 7

NFC Connection (ANDROID System) ............................................................................................................................ 8

Operation Methods ...................................................................................................... 9

Remote Viewinder................................................................................................................................................................. 9

Remote Viewinder Interface ........................................................................................................................................ 9

Parameter Settings ........................................................................................................................................................ 11

Shooting Mode...................................................................................................................................................... 11

Image Size ............................................................................................................................................................. 13

Movie Size.............................................................................................................................................................. 14

Unfold Mode .......................................................................................................................................................... 15

Camera Modes ...................................................................................................................................................... 16

Function Menu....................................................................................................................................................... 17

Menu ...................................................................................................................................................................... 21

Shooting Settings ........................................................................................................................................... 22

General Settings ............................................................................................................................................ 24

Shooting Methods ......................................................................................................................................................... 28

Shooting ................................................................................................................................................................ 28

Video Recording.................................................................................................................................................... 29

Playback ................................................................................................................................................................................. 30

Switching of the Remote Viewinder Mode and Playback Mode.................................................................................30

Switching Camera and Smart Device Index Playback ................................................................................................. 31

Introduction of Icons in the Playback Mode................................................................................................................. 32

Single Playback ..................................................................................................................................................... 32

Index Playback....................................................................................................................................................... 34

Description of Functions in Playback Mode ................................................................................................................. 35

Gestures in Playback Mode................................................................................................................................... 35

Rotate (Smart Device Single Playback Mode) ............................................................................................... 35

Select One or More File(s) (Camera and Smart Device Index Playback Mode).................................................. 36

Download (Camera Single Playback and Index Playback Mode)................................................................... 39

Editing Video Files (Smart Device Single Playback Mode)............................................................................. 40

Sharing ............................................................................................................................................................. 43

Delete .............................................................................................................................................................. 49

Playing Videos (Camera and Smart Device Single Playback Mode) ................................................................... 50

VR / Global Photos Playback (Camera and Smart Device Single Playback Mode)............................................. 51

VR Cardboard (VR Glasses Playback) ........................................................................................................... 52

Menu (Camera and Smart Device Index Playback Mode).............................................................................. 55

Connecting the Camera with your Smart Device

Downloading and Installing the APP

Please download the APP installation package / (APP Name: PIXPRO 360 VR Remote Viewer ) to your Smart Device

from the path below and install it.

ANDROID System

For ANDROID devices, search and download the “PIXPRO 360 VR Remote Viewer ” APP in Google Play and install it

following the instructions on the interface.

iOS System

For APPLE devices, search and download the “PIXPRO 360 VR Remote Viewer ” APP in the iTunes APP store and

install it following the instructions on the interface.

After successful installation, this icon / will appear on your Smart Device's screen.

https://play.google.com/store/APPs/details?id=com.jkimaging.pixproremoteviewer

https://itunes.APPLE.com/us/APP/pixpro-remote-viewer/id833154167?mt=8

Establishing Connection

Wi-Fi Connections (iOS and ANDROID Systems)

1. Camera: Check the SSID (PIXPROORBIT360_XXXX / PIXPRO4KVR360_KXXXX) and password (default factory

password: 12345678) as indicated on the label inside the battery compartment of the camera. In the

main interface, press the button to switch to Wi-Fi mode.

2. Smart Device: Enable Wi-Fi mode, the Smart Device will automatically search nearby Wi-Fi hotspots. Select the

camera’s SSID (PIXPROORBIT360_XXXX / PIXPRO4KVR360_KXXXX) and input the password.

To optimize Wi-Fi performance, please close other unnecessary programs running on your Smart Device.

BLUETOOH Connection (ANDROID System)

1. Camera: Press the button to turn the camera on. In the main interface, press and hold the button for 2

seconds to enter the BLUETOOH Pairing Interface.

2. Smart Device: Tap the APP icon on your Smart Device to enable Wi-Fi and BLUETOOH functions and enter the

"Select a device to connect" screen; after selecting the SSID of the camera to connect ( PIXPRO-

ORBIT360_XXXX / PIXPRO4KVR360_KXXXX), the BLUETOOH pairing screen appears; tap "PAIR"

and the Wi-Fi will be connected automatically when pairing is successful.

If it is not the irst time connecting to the APP, tap the APP icon on your Smart Device directly. Select the SSID

of the camera to connect (PIXPROORBIT360_XXXX / PIXPRO4KVR360_KXXXX) to enter the connection screen .

If the camera is not turned on, the camera will turn on automatically and enter the shooting mode screen.

When your Smart Device doesn't support BLUETOOH, tapping on the APP icon will enter the prompts screen

and will indicate that the Smart Device doesn't support BLUETOOH function and will ask you to open the APP

after establishing Wi-Fi connection on the setting connection screen of your Smart Device.

When connecting to the camera via BLUETOOH, it is invalid to establish a connection in the BLUETOOH setting

screen of your Smart Device. You can use the APP to make it.

NFC Connection (ANDROID System)

1. Enable NFC mode on your Smart Device.

2.Use your Smart Device to lightly touch the NFC mark on the camera; if the Smart Device has a prompt tone or

vibration, it means the connection is successful.

3.The APP should automatically open on your Smart Device.

The NFC feature will only be available when your Smart Device's screen is unlocked.

When using NFC connection, no matter whether the BLUETOOH function is supported on the Smart Device, only

Wi-Fi connection is established.

If connection fails, tap to try reconnecting.

XXXXXXXXXXXXXXXXXXXX

•XXXXXXXXXXXXXXXXX

•XXXXXXXXXXXX

•XXXXXXXXXXX

•XXXXXXXXXXXXXXXXX

•XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

XXXXXXXXXXXX

Connection Failed

When it is unnecessary to connect your Smart Device to the camera or you are unable to connect your Smart Device

to the camera, tap the icon on the screen of your Smart Device to perform related operations under the Playback

Mode of the Smart Device.

Operation Methods

Remote Viewinder

Remote Viewinder Interface

On the Remote Viewinder Interface, tap the icon to hide information , and tap to restore initial display.

1234567

VR V R

1234567
