Kodak ESP - Manuel utilisateur

Networking Setup Guide

Guide de conﬁguration réseau

Guía de configuración de red

Guia de configuração de rede

All-in-One Printers • Imprimantes tout-en-un

Impresoras multifunción • Impressoras Multifuncionais

2www.kodak.com/go/aiosupport

Setting Up a Wireless (Wi-Fi) Connection

Before you connect, you need:

•awirelessrouter.

• to determine whether your wireless router supports Wi-Fi Protected Setup (WPS).

NOTE: If you have specific questions about your router, see your router manufacturer’s documentation.

Connecting to a non-WPS wireless router

Record your network information in the spaces below, using the correct uppercase and lowercase letters.

Network Name (SSID): ____________________________________________________

Security String (case-sensitive): ____________________________________________

NOTE: If you already set up your printer, you need to press Home, then press to select Network

Settings, then WiFi Setup Wizard. Press OK after each selection.

1. Press to select Wireless, then press OK.

2. Press to select your network, then press OK.

If you don’t see your network in the list, or if you want to change your network, select Rescan for

Wireless Networks, then press OK.

If the name of your network is not listed, make sure your wireless router is turned on and within

range. If the name of your network is still not listed, go to www.kodak.com/go/inkjetnetworking.

3. If your network requires a password, use the LCD keyboard to enter your Security String. The

Security String is case-sensitive.

On the control panel (both types of keyboards), press , , or to select the letters and

numbers, using the correct uppercase and lowercase letters. Press OK after each character. When

you are done, select DONE, then press OK.

www.kodak.com/go/inkjetnetworking 3

Networking Setup Guide for KODAK All-in-One Printers

There are two types of keyboards. Follow the instructions for your keyboard.

4. When the confirmation message appears, press OK.

When the printer is successfully connected, the Wi-Fi status light is on.

If you are unable to connect your printer, go to www.kodak.com/go/inkjetnetworking.

5. Install the KODAK All-in-One Printer Software on your computer. Follow the on-screen instructions

to complete your setup.

NOTE: If you installed the software before connecting to your network, select Start > Programs >

Kodak > Kodak Printer Network Setup Utility and follow the on-screen instructions.

Connecting to a WPS wireless router

NOTE: If you already set up your printer, you need to press Home, then press to select Network

Settings, then WiFi Setup Wizard. Press OK after each selection.

1. Press to select Wireless, then press OK.

•To change from uppercase to

lowercase, select abc/123,

then press OK.

• To change from lowercase to

uppercase, select ABC/123,

then press OK.

•To enter punctuation or

symbols, select !@#, then press

OK.

Use the arrow

keys to select the

letters, numbers,

and symbols.

Press OK after

each selection.

Setting Up a Wireless (Wi-Fi) Connection

4www.kodak.com/go/aiosupport

2. With WPS Connect selected, press OK.

3. Select one of these two methods of connecting:

IMPORTANT: Before you press OK on the printer, make sure you know where the router's button is, or where

to enter the generated PIN.

4. When the confirmation message appears, press OK.

When the printer is successfully connected, the Wi-Fi status light should be on.

If you are unable to connect your printer, go to www.kodak.com/go/inkjetnetworking.

5. Install the KODAK All-in-One Printer Software on your computer. Follow the on-screen instructions to

complete your setup.

NOTE: If you installed the software before connecting to your network, select Start > Programs >

Kodak > Kodak Printer Network Setup Utility and follow the on-screen instructions.

Pressing a Button Entering a PIN

a. With Push Button Configuration selected, press OK.

b. Press or select the WPS button for your wireless router.

NOTE: You will have two minutes to press or select the

WPS button. It may be a button on the device or a

virtual button in the device’s software.

a. Press to select Generate WPS

PIN, then press OK.

b. In your wireless router’s software,

locate the PIN screen.

c. Enter the PIN you received from the

LCD into the PIN screen.

www.kodak.com/go/aiosupport 5

Setting Up an Ethernet Connection

Before you connect, you need to:

• Have a functional Ethernet network that includes a router, switch, or hub with an Ethernet port.

• Have a Category 5 (or higher) Ethernet cable.

• Temporarily disable your firewall until the printer is successfully installed and communicating.

Connecting to an Ethernet network

1. Connect the Ethernet cable into the Ethernet port on the back of the printer.

2. Connect the other end of the Ethernet cable into an available Ethernet port

on your router, switch, or hub.

3. Install the KODAK All-in-One Printer Software on your computer. Follow the

on-screen instructions to complete your setup.

Eastman Kodak Company

Rochester, NY 14650

Kodak is a trademark of Eastman Kodak Company.

Specifications subject to change without notice.

P/N 1K5951

July 2010

Printed in China

1K7343
