knöll systems - advanced home products http://www.knollsystems.com/dlp177.htm

1 of 3 1/21/2005 1:15 M

HD177 Throw Distance

Thank you for choosing Knöll projectors! There are two versions of the HD177, those

shipped after November 1, 2004 and before. Please note that the lens assembl is

different and therefore the throw distances are different.

The HD177 is a state of the art projector with a high resolution 16:9 igital light processing

chips to give bright clear images an isplay movies in a format similar to the one they were

filme in. Its Carl Zeiss lens allows for a wi e level amount of zooming (1:1.25).

The HD177 projector is esigne only for use with 16:9 aspect ratio screens. 4:3 images can

safely be isplaye on the 16:9 screens. Some screens have moveable screen wi th curtains

that can be controlle by the HD177 ual trigger outputs.

The Knöll CM25 ceiling mount kit is easy to install an swivels for exact placement. It rops

the projector about 3" an the projector lens is about 6" from the ceiling. If more of a rop

is nee e , the CM20+6 exten er a s an extra 6" rop. As many CM20+6 can be a e as

nee e .

The most frequently aske questions concerning DLP projectors are:

How much can the projector be tilte own (when ceiling mounting) or up (when floor

mounte )?

About 20 egrees. The HD177 has a igital a justable keystone but for best overall image

the HD177 projector shoul i eally be level if the screen is vertical (which is usually the

case).

Is the wi th of the 4:3 image the same as the 16:9 image?

No. The HD177 has 16:9 imager an isplays 16:9 or wi escreen images using its full wi th of

1024 pixels by 576 pixels high. When isplaying 4:3 images it still uses all of its 576 pixels in

height but the image wi th is re uce to 768 pixels. Black bars are a e on the si es of the

image.

Projection throw istances are the maximum an minimum horizontal

istances from the projector lens to the screen. If the projector is mounte

level (this is strongly recommen e ) the image will rop (ceiling mounte

projector) or rise (floor mounte projector).

knöll systems - advanced home products http://www.knollsystems.com/dlp177.htm

2 of 3 1/21/2005 1:15 M

HD177 Projection Throw Distance 16:9 Video Screen (shipped after November 1, 2004)

Screen Diagonal 92" 103" 106" 110" 122.5" 146.75"

Minimum

Distance 166.4" 186.7" 191.4" 199.7" 222.5" 266.3"

Maximum

Distance 208" 233.3" 239.2" 249.6" 278.2" 332.8"

Image rise or

rop 14.3" 16.7" 17.1" 17.8" 23.8" 26.7"

Viewing Area 45"x80" 50.5"x89.75" 52"x92" 54"x96" 60"x107" 72"x128"

MAXIMUM DISTANCE TO SCREEN (16:9) = 2.268 x SCREEN DIAGONAL SIZE

MINIMUM DISTANCE TO SCREEN (16:9) = 1.815 x SCREEN DIAGONAL SIZE

IMAGE DROP OR RISE (16:9) = 0.162 x SCREEN DIAGONAL SIZE

HD177 Projection Throw Distance 16:9 Video Screen (shipped before November 1, 2004)

Screen Diagonal 92" 103" 106" 110" 122.5" 146.75"

knöll systems - advanced home products http://www.knollsystems.com/dlp177.htm

3 of 3 1/21/2005 1:15 M

Minimum

Distance 151.5" 169.7" 174.5" 181.2" 201.8" 241.7"

Maximum

Distance 210.8" 236.1" 243" 252.1" 280.8" 336.4"

Image rise or

rop 14.3" 16.7" 17.1" 17.8" 23.8" 26.7"

Viewing Area 45"x80" 50.5"x89.75" 52"x92" 54"x96" 60"x107" 72"x128"

MAXIMUM DISTANCE TO SCREEN (16:9) = 2.292 x SCREEN DIAGONAL SIZE

MINIMUM DISTANCE TO SCREEN (16:9) = 1.647 x SCREEN DIAGONAL SIZE

IMAGE DROP OR RISE (16:9) = 0.162 x SCREEN DIAGONAL SIZE
