Knick Protos 3400 Instructions originales

Safety information

and short description

ENG

Protos 3400(X)

SHW_ENG.qxd 14.04.2004 14:44 Uhr Seite 1 gro DAISY.DATA01:NETDATA:MAC2ALL:BA_in_Arbeit:3400_SHW2:

Instruction manuals and parameter sets for copy are provided

as download at:

www.knick.de

Warranty

Defects occurring within 3 years from delivery date shall be remedied free of

charge at our plant (carriage and insurance paid by sender).

Sensors, fittings, and accessories: 1 year.

TS-201.011-KNX0320140321

Document 4 14.04.2004 17:00 Uhr Seite 1 gro Gronem:Programme Office:QuarkXPress Passport 4.1 Ordner:

ENG-3

Safety information

Information on installation

Be sure to read and observe the following instructions!

The device has been designed in accordance with the state of the art and

complying with the applicable safety regulations.

When operating the device, certain conditions may nevertheless lead to dan-

ger for the operator or damage to the device.

Caution!

Before commissioning it must be proved that the device may be

connected with other equipment. Commissioning may only be

carried out by trained experts!

Whenever it is likely that protection has been impaired, the device shall be

made inoperative and secured against unintended operation. The protection is

likely to be impaired if, for example:

•the device shows visible damage

•the device fails to perform the intended measurements

•after prolonged storage at temperatures above 70 °C

•after severe transport stresses

Before recommissioning the device, a professional routine test in accordance

with EN 61010-1 must be performed. This test should be carried out by the

manufacturer.

Before opening the device, be sure to observe the following:

• Switch off power supply before replacing the front door (FRONT module).

•Switch off power supply before replacing or inserting a module.

• Protect the signal inputs of the modules and the SmartMedia card against

electrostatic discharge.

•Only operate signal outputs and inputs within the specified limits. Provide

the relay outputs with protective wiring.

Warning!

Do not touch the terminal compartment, there may be

dangerous contact voltages!

SHW_ENG.qxd 14.04.2004 14:44 Uhr Seite ENG-3 gro DAISY.DATA01:NETDATA:MAC2ALL:BA_in_Arbeit:3400_SHW2:

ENG-4 Protos 3400(X)

Caution!

Never expose the display to direct sun light! Only operate the display within

the temperature range of 0 °C up to 50 °C max.

Important note concerning SmartMedia card

The SmartMedia card may be inserted or replaced with the power supply

switched on.

Warning!

Do not touch the terminal compartment, there may be dange-

rous contact voltages!

Intended use

Protos is a flexible measuring system for continuous measurements in the

field of liquid analysis. Thanks to its modular design, the Protos can easily be

adapted to your measuring task. Flexible use of plug-in modules allows com-

bined measurements as well as later expansions or modifications.

The measured variables depend on the measuring modules installed.

Communication modules are available for further processing of the output

signals.

The rugged enclosure (IP 65) can be wall or pipe mounted or fixed into a

control panel.

The Protos version with hygienic, polished stainless steel enclosure allows

application in the field of biotechnology, food processing, and in the phar-

maceutical industry.

The Protos version with coated steel enclosure – extremely corrosion resistant –

has been developed for application in the chemical industry, environmental

engineering, water and waste-water treatment, and for application in power

plants .

Safety information

Display. Use of SmartMedia card. Intended use.

SHW_ENG.qxd 14.04.2004 14:44 Uhr Seite ENG-4 gro DAISY.DATA01:NETDATA:MAC2ALL:BA_in_Arbeit:3400_SHW2:

ENG-5

–––––––––––––––––––––

–––––––––––––––––––––––––––––––––––––––––––––––––

Display* LC graphic display, white backlighting

Resolution 240 x 160 pixels

Languages German, English, French, Italian, Spanish, Swedish

––––––––––––––––––––––

–––––––––––––––––––––––––––––––––––––––––––––––––

Keypad NAMUR keypad, individual keys, no double assignments

[meas] [menu] [‚] [ƒ] [„] [‘] [enter] [softkey 1] [softkey 2],

NAMUR LEDs red and green.

––––––––––––––––––––––

–––––––––––––––––––––––––––––––––––––––––––––––––

Power supply 24 (–15 %) to 230 (+15 %) V AC/DC <18 VA/<10 W

Overvoltage category II

Protection class I

Pollution degree 2 (EN 61010-1)

Wire cross-section 2.5 mm2

––––––––––––––––––––––

–––––––––––––––––––––––––––––––––––––––––––––––––

Protection against Protective separation of all extra-low-voltage circuits

electrical shock against mains as per EN 61010-1

––––––––––––––––––––––

–––––––––––––––––––––––––––––––––––––––––––––––––

EMC NAMUR NE 21 and

EN 61326-1

EN 61326-2-3

Emitted interference Class B

Immunity to interference Industry

––––––––––––––––––––––

–––––––––––––––––––––––––––––––––––––––––––––––––

Lightning protection EN 61000-4-5, Installation Class 2

––––––––––––––––––––––

–––––––––––––––––––––––––––––––––––––––––––––––––

Nominal operating Ambient temperature –20 to +55 °C

conditions Relative humidity 10 ... 95 % not condensing

Power supply 24 (–15 %) to 230 (+15%) V AC/DC

Frequency AC 48... 62Hz

––––––––––––––––––––––

–––––––––––––––––––––––––––––––––––––––––––––––––

Transport/ –20 to +70 °C

Storage temperature

––––––––––––––––––––––

–––––––––––––––––––––––––––––––––––––––––––––––––

Ingress protection IP 65 / NEMA 4 X

Terminals Single wires and flexible leads up to 2.5 mm2(AWG 14)

*Caution!

Never expose the display to direct sun light! Only operate the display within the temperature

range of 0 °C up to 50 °C max.

SHW_ENG.qxd 14.04.2004 14:44 Uhr Seite ENG-5 gro DAISY.DATA01:NETDATA:MAC2ALL:BA_in_Arbeit:3400_SHW2:

ModuleFRONT, ModuleBASE 3400-0

Extract from general technical specifications

>>> see "Certificates" for IECEx, ATEX, FM & CSA

ENG-6 Protos 3400(X)

Connection of power supply

Contact assignment of BASE module

Information on installation

Caution!

•Installation may only be carried out by trained experts in accordance with

this instruction manual and as per applicable local and national codes.

•Be sure to observe the technical specifications and input ratings.

•Be sure not to notch the conductor when stripping the insulation.

•All parameters must be set by a system administrator prior to

commissioning.

The terminals are suitable for single wires and flexible leads up to 2.5 mm2

(AWG 14).

SHW_ENG.qxd 14.04.2004 14:44 Uhr Seite ENG-6 gro DAISY.DATA01:NETDATA:MAC2ALL:BA_in_Arbeit:3400_SHW2:

ENG-7

Connection of power supply

Warning! Beware of dangerous contact voltages!

BASE module 3400X-025/VPW

100 (-15 %) ... 230 (+10 %) V AC (EEx em IIC)

BASE module 3400X-026/24V

24 V AC (-15 %, + 10 %)

24 V DC (-15 %, +20 %)

SHW_ENG.qxd 14.04.2004 14:44 Uhr Seite ENG-7 gro DAISY.DATA01:NETDATA:MAC2ALL:BA_in_Arbeit:3400_SHW2:

BASE module 3400-029,terminal plate

Connection of power supply

With the VariPower broad-range power supply unit, the Protos

can be operated with a power supply of 24 (-15 %) to 230 (+15 %) V AC/DC

making it suitable for all public mains supplies in the world.

ENG-8 Protos 3400(X)

Short description: FRONT module

Protos 3400

Modular hardware and software system for liquid analysis.

Transflective LC graphic display

(240 x 160 pixels)

white backlighting, high resolution

and high contrast.

Red LED

signals failure (On) or

maintenance request/function check

(flashing) corresponding to NE 44.

4 captive scews

for opening the Protos

(Caution! Make sure that the gasket

between FRONT and BASE is properly seated and clean!)

Green LED

Voltage supply okay

5 self-sealing cable glands

M20 x 1.5

for entry of voltage supply and signal lines

2 softkeys

with context-sensitive functions.

User interface

with plaintext menus as recommen-

ded by NAMUR.

Menu texts can be switched to:

German, English, French, Italian,

Swedish, and Spanish.

Intuitively acquirable menu logic,

based on Windows standards.

Control panel

3 function keys

(menu, meas, enter)

and 4 arrow keys for menu selection

and data entries

Measurement display

Secondary displays

SHW_ENG.qxd 14.04.2004 14:44 Uhr Seite ENG-8 gro DAISY.DATA01:NETDATA:MAC2ALL:BA_in_Arbeit:3400_SHW2:

ENG-9

Measuring

Short description: Menu structure

Basic functions: Calibration, maintenance, parameter setting, diagnostics

Calibration Maintenance Parameter setting Diagnostics

Menu groups

1147 2958 1246

Operator level

1989

Admin. level

Passcode:

Selection of

further

menu items:

Module 1

Module 2

Module 3

BASE

Module 1

Module 2

Module 3

SYSTEM

FRONT

BASE

Module 1

Module 2

Module 3

Legend:

(1) Pressing the menu key accesses menu selection

(2) Pressing the meas key returns to measurement

(3) Menu groups are selected using the arrow keys

(4) Press enter to confirm, enter passcode

(5) Further menu items are displayed

(6) Selected functions of the Diagnostics menu can be

recalled via softkey even when in measuring mode

Message list

Logbook

Device description

FRONT

BASE

Module 1

Module 2

Module 3

SHW_ENG.qxd 14.04.2004 14:44 Uhr Seite ENG-9 gro DAISY.DATA01:NETDATA:MAC2ALL:BA_in_Arbeit:3400_SHW2:

ENG-10 Protos 3400(X)

Short description: FRONT module

Protos 3400

View into the open device (FRONT module)

Terminal plates

of “hidden” modules

Each module comes with an adhesive

label containing the contact assignments.

This label should be sticked to the inner

side of the front (as shown).

Then, the terminal assignments remain

visible even if further modules are

inserted.

Slot for SmartMedia card

• Data recording

The SmartMedia card expands the

measurement recorder capacity to

> 50000 records.

•Exchange of parameter sets

5 parameter sets can be stored

on the SmartMedia card,

2 of them can be loaded to the

Protos and switched

by remote control.

Parameter sets can be transmitted

from one Protos to the other

(same hard- and software

configuration required).

•Function expansions

are possible with additional software

modules which are released

using transaction numbers (TAN)

•Software updates

(also at different devices)

The circumferential sealing

guarantees IP 65protection and allows spray

cleaning / disinfection.

Caution! Keep clean!

Replacing the front module

Pull off power cord and ground wire.

To separate the FRONT module from

the BASE module, turn the retaining

screws of the pivot hinge by 90°.

SHW_ENG.qxd 14.04.2004 14:44 Uhr Seite ENG-10 gro DAISY.DATA01:NETDATA:MAC2ALL:BA_in_Arbeit:3400_SHW2:

Autres manuels pour Protos 3400

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Knick Instrument de mesure

Knick

Knick Portavo 902 PH Manuel utilisateur

Knick

Knick Stratos Pro A201CONDI Manuel utilisateur

Knick

Knick Stratos Pro A401B PH Manuel utilisateur

Knick

Knick Protos 3400X Manuel utilisateur

Knick

Knick 830 R Manuel utilisateur

Knick

Knick Protos CONDI 3400(X)-051 Manuel utilisateur

Knick

Knick Stratos Eco 2405 pH Manuel utilisateur

Knick

Knick Stratos Evo A402 Manuel utilisateur

Knick

Knick Stratos Eco 2405 CondI Manuel utilisateur

Knick

Knick Protos 3400X Manuel utilisateur

Knick

Knick Stratos Eco 2405 Cond Manuel utilisateur

Knick

Knick Stratos Pro A2 COND Series Manuel utilisateur

Knick

Knick PORTAVO 904 PH Manuel utilisateur

Knick

Knick Stratos Pro A2 COND Series Manuel utilisateur

Knick

Knick Protos II 4400 Manuel utilisateur

Knick

Knick Stratos Pro A2 COND Series Manuel utilisateur

Knick

Knick Stratos Pro A201MSCONDI Manuel utilisateur

Knick

Knick Protos 3400 Manuel utilisateur

Knick

Knick Portavo 908 MULTI Manuel utilisateur

Knick

Knick Protos II 4400(X) Manuel utilisateur

Knick

Knick Stratos Evo A402 Manuel utilisateur

Knick

Knick Protos II 4400 Manuel utilisateur

Knick

Knick Stratos Pro A201 PH Manuel utilisateur

Knick

Knick PORTAVO 904X PH Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
