CABINET PARTS

6−08 Litho In U.S.A (mat)(bay) Part No. W10208053 Rev.A

REFRIGERATOR

For Models: KFCS22EVWH00, KFCS22EVBL00, KFCS22EVMS00

(White) (Black)(Monochromatic Stainless)

CABINET PARTS

2W10208053

Illus. Part

No. No. DESCRIPTION

For Models: KFCS22EVWH00, KFCS22EVBL00, KFCS22EVMS00

(White) (Black)(Monochromatic Stainless)

1 Literature Parts

W10210867

Use & Care Guide

W10194233

Energy Guide

W10210870

Tech Sheet

2 Cabinet (Not a

Servicable Part)

3 B5759649 Gasket

4 Roller Assembly

W10130460

Left

W10130459

Right

W10141622

Foot, Brake

6 67006521 Screw

7 Cover, Hinge

W10163248

White, Left

W10163247

White, Right

W10153130

Black, Left

W10153131

Black, Right

W10120102

Apollo Grey, Left

W10120103

Apollo Grey, Right

8 67006380 Screw

9 67006400 Screw

10 67003331 Cover, Water Line

11 67006303 Screw (3)

12 Hinge, Center

W10162694

White, Left

W10162695

White, Right

W10119776

Black, Left

W10119778

Black, Right

W10135096

Stainless, Left

W10135097

Stainless, Right

13 Hinge, Top

W10120106

White, RH

W10120105

White, LH

14 Cover, Corner

67003484 White

67003485 Black

W10157973

Clip, Drain

16 67006102 Cover, Unit

17 Grille, Toe

W10131133

White

W10131134

Black

18 M0114003 Clip, Speed

W10164397

Tube, Drain

20 67006425 Screw (10)

21 67003796 Fiber, Acoustic

22 67004098 Cover, Water Valve

23 M0108105 Clamp, Tube

W10137519

Elbow, Fill Tube

25 67006287 Screw

26 67004092 Block, Filter (2)

27 67004101 Sweep, Dual Tube

FREEZER LINER PARTS

For Models: KFCS22EVWH00, KFCS22EVBL00, KFCS22EVMS00

(White) (Black)(Monochromatic Stainless)

W10208053

FREEZER LINER PARTS

4W10208053

Illus. Part

No. No. DESCRIPTION

1 Liner (Not A

Seviceable Part)

2 67001291 Gasket, Foam

3 12002497 Gear (Left)

(Includes Item 7)

4 67003905 Cover, Light

5 67004261 Shaft

Y12570701

Socket, Light

7 12002497 Gear(Right)

(Includes Item 3)

8 67006473 Screw (8)

9 A0282812 Bulb, Light

10 67001035 Housing, Light

W10203139

Cover, Evaporator

12 67006425 Screw (4)

13 Bracket, Door

W10122147

Left

W10122148

Right

W10119832

Module, Freezer

W10167028

Clip, Evap. Motor

16 67005653 Switch, Light

17 67006530 Screw

18 Cradle, Basket

W10119848

Left

W10119849

Right

W10165841

Slide, Drawer

20 67001776 Gasket, Bottom

21 Adapter, Slide

W10163084

Left

W10163087

Right

W10175909

Grille, Fz Air

W10167023

Shroud, Evap.Fan

24 2169142 Blade, Fan

(Evaporator)

W10150583

Grommet

W10199049

Motor, Evaporator

27 D7753903 Funnel, Drain

28 M0500703 Seal

29 B8381501 Gasket

W10203133

Thermistor

31 67003924 Cover, Thermistor

32 67006406 Screw (6)

W10201550

Guide, Fill Tube

34 Adaptor, Shelf

W10203148

Left Hand

W10203149

Right Hand

Following Parts Not Illustrated

W10196195

Harness, Lights

(Freezer)

For Models: KFCS22EVWH00, KFCS22EVBL00, KFCS22EVMS00

(White) (Black)(Monochromatic Stainless)

REFRIGERATOR LINER PARTS

For Models: KFCS22EVWH00, KFCS22EVBL00, KFCS22EVMS00

(White) (Black)(Monochromatic Stainless)

W10208053

REFRIGERATOR LINER PARTS

For Models: KFCS22EVWH00, KFCS22EVBL00, KFCS22EVMS00

(White) (Black)(Monochromatic Stainless)

W10208053

Illus. Part

No. No. DESCRIPTION

1 Liner (Not A

Serviceable Part)

W10203323

Module, Light

W10185585

Module, Control

W10116216

Board, Control

6 12466104 Switch, Light

7 67003897 Cover, Light

8 67003901 Housing, Light

9 A0282812 Bulb, Light (2)

Y12570701

Socket, Light (2)

11 67003900 Insert,

Damper Cover

12 67006602 Screw (2)

13 67003899 Cover, Damper

14 67006604 Insulation

W10127431

Control, Damper

(Includes Harness)

16 12791416 Thermistor

17 67006325 Bracket, Filter

W10204043

Head, Filter

UKF8001AXX

Filter, Water

20 67006331 Lid, Filter

21 67006287 Screw (2)

W10204285

Facade, Disp.

23 12575502 Switch, Limit

W10117324

Waterline,

Dispenser

W10153959

Tank, Water

26 61006182 Union

27 67003146 Plug, Bypass

28 67006400 Screw

29 Slide, Crisper

2302952 Left

2302953 Right

Vent

Following Parts Not Illustrated

W10119821

Harness, Controls

(Refrigerator)

REFRIGERATOR DOOR PARTS

W10208053

For Models: KFCS22EVWH00, KFCS22EVBL00, KFCS22EVMS00

(White) (Black)(Monochromatic Stainless)

REFRIGERATOR DOOR PARTS

8W10208053

Illus. Part

No. No. DESCRIPTION

For Models: KFCS22EVWH00, KFCS22EVBL00, KFCS22EVMS00

(White) (Black)(Monochromatic Stainless)

1 Door, Refrigerator

W10203555

White, LH

W10203552

White, RH

W10210876

Black, LH

W10210874

Black, RH

W10210880

Stainless, LH

W10210879

Stainless, RH

2 67006901 Screw

3 67003819 Door, Dairy

4 67001279 Tray, Dairy

W10184033

Bucket, Medium (3)

7 Plug, Button (2)

10712401 White

67004838 Black

8 Gasket, Door

W10183535

White

W10131327

Black

9 Handle, Door

2319727W White

2319727B Black

2319727S Stainless

10 67006113 Mount, Handle

11 Closure, Door

67003638 White

67003639 Black

W10046670

Nameplate

15 67006287 Screw

16 Bushing (4)

67002732 White

67002731 Black

17 Stop, Door

W10163249

White

W10153126

Black

W10120097

Apollo Grey

W10184034

Bucket, Gallon (2)

UNIT PARTS

W10208053

For Models: KFCS22EVWH00, KFCS22EVBL00, KFCS22EVMS00

(White) (Black)(Monochromatic Stainless)

UNIT PARTS

For Models: KFCS22EVWH00, KFCS22EVBL00, KFCS22EVMS00

(White) (Black)(Monochromatic Stainless)

W10208053

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 67006433 Screw

W10162928

Blade, Fan

3 67005889 Basepan

4 67006425 Screw

5 67005491 Block, Condenser

W10134293

Tube, Discharge

W10196196

Harness, Evap.

Heater

8 67007175 Drain Pan

9 61004743 Grommet (3)

W10203111

Heater, Defrost

W10136415

Clip, Capacitor

W10128791

Start Device

13 67003731 Gasket

W10165425

Thermostat,

Defrost

15 67005680 Grommet (2)

16 67006573 Screw

W10169124

Grommet (4)

18 67006131 Condenser

19 67006432 Screw (3)

20 67002490 Tray, Drip

21 67006737 Screw

W10203111

Evaporator Heater

23 Dam

W10203109

Right Side

W10203108

Left Side

24 67004432 Motor, Fan

25 10428101 Clip, Heater

W10137210

Harness, Unit

with Power Cord

W10143759

Drier

W10134623

Compressor

(Includes items

11,12,17,27,29)

29 2264017 Capacitor

30 67006434 Axle, Roller (2)

W10158508

Shroud

32 67004953 Bracket, Fan Motor

33 67004954 Screw

34 10547003 Clip, Drier

35 67005149 Roller (2)

W10137529

Grommet, Cond. (4)

37 13058002 Clip, Evaporator

W10119790

Box, HV Control

W10203258

Lid, HV Control

W10120821

Control,

Electronic,15W,PS

W10120827

Control,

Electronic,Trilogy

Following Parts Not Illustrated

and Optional Parts Not Included

978025 Valve, Access

(1/4")

978026 Valve, Access

(5/16")

978027 Valve, Access

(3/8")

978028 Valve, Access

(1/2")

978029 Valve, Access

(5/8")

978030 Valve, Access

(3/4")

876764 Valve, Access

(3/16")

REFRIGERANT CHARGE

5.0 Ozs.

(R−134A)
