KitchenAid KBLS36FKB01 Manuel utilisateur

CABINET PARTS

For Models: KBLS36FKB01, KBLS36FKT01, KBLS36FKW01, KBLS36FKX01

(Black) (Biscuit) (White) (Etched Aluminum)

6−03 Litho In U.S.A. (tpm) Part No. 8198081

36" BOTTOM MOUNT

BUILT IN REFRIGERATOR

CABINET PARTS

For Models: KBLS36FKB01, KBLS36FKT01, KBLS36FKW01, KBLS36FKX01

(Black) (Biscuit) (White) (Etched Aluminum)

8198081

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Literature Parts

LIT2254715

Use & Care Guide

LIT2221286

Energy Label

LIT2254723

Service & Wiring

Sheet

LIT628370

Modular Icemaker

Service Sheet

LIT2215852

Installation

Instructions

2 Cabinet (Not A

Serviceable Part)

3 2005004 Grommet, Tube

Crossover

4 1112023 Roller, Front &

Rear (4)

5 Support, Leveler

Assembly

2004506 Refrigerator Side

2004505 Freezer Side

6 2005006 Grommet, Wiring

7 2005007 Grommet,

Flexible

8 489399 Screw

9 2006442 Mounting Bracket,

Grill

10 2005921 Screw

11 1112849 Cap, Grommet

13 2204516 Tube, Drain

Condensate

14 2207470 Shim−Hinge, Door

15 2221070 Clip, Tube

16 488946 Tube, Clamp

17 2001295 Screw, Door Stop

18 2221134 Hinge, Door

Refrigerator Top

19 2005783 Cam−Closer,

Door

21 2006617 Bracket, Support

22 2002903 Bushing

23 2209022 Housing, Water

Filter

24 2004517 Spring, Door

Closure

25 486194 Screw

26 2203221 Filter, Water

27 2006960 Bushing−Arm,

Extension

28 2006388 Gap, Cover

(Bottom)

29 2005101 Hinge, Bottom

Refrigerator

30 489464 Screw, 8−18 x 1/2

31 489282 Screw

32 Skirt, Grille−

Bottom

2209024B Black

2209024T Biscuit

2209024W White

33 2006346 Washer

34 Grille Base,

Front

2215889B Black

2215889T Biscuit

2215889W White

35 3400878 Screw

36 2209133 Cover, Rear

38 2221094 Arm, Extension

39 2221096 Bracket, Switch

40 2215938 Cover, Switch

41 1163283 Screw

42 Cap, Water Filter

2186494B Black

2186494T Biscuit

2186494W White

43 2001415 Screw (4)

44 487415 Screw, 8−18 x 3/8

45 1118894 Switch, Rocker Arm

46 9791833 Clip

47 2207578 Clip, Snap−In (2)

CABINET AND BREAKER TRIM PARTS

For Models: KBLS36FKB01, KBLS36FKT01, KBLS36FKW01, KBLS36FKX01

(Black) (Biscuit) (White) (Etched Aluminum)

8198081

Illus. Part

No. No. DESCRIPTION

1 Cabinet, Trim

Right Side

2215919B Black

2215919T Biscuit

2215919W White

8201535 Etched Aluminum

3 1163283 Screw

4 2254724 Cabinet, Trim

(Bottom)

5 486194 Screw

6 2003645 Cabinet, Trim Top

7 Breaker Trim

(Not Serviced)

8 2005782 Cover, Hinge

9 2005925 Seal−Trim,Side

10 Cabinet Trim,

Left Side

2215936B Black

2215936T Biscuit

2215936W White

2215936 Etched Aluminum

11 489464 Screw, 8−18 x 1/2

TOP GRILLE AND UNIT COVER PARTS

For Models: KBLS36FKB01, KBLS36FKT01, KBLS36FKW01, KBLS36FKX01

(Black) (Biscuit) (White) (Etched Aluminum)

8198081

Illus. Part

No. No. DESCRIPTION

1 Top Grille

Assembly

2215973W White

2215973B Black

2215973T Biscuit

2215973 Etched Aluminum

2 2209490 Cover, Unit

4 2215830 Back Panel

5 2209492 Guard, Wiring

6 487415 Screw

7 2187423 Wire Assembly

8 2215678 Baffle−Air,

Condenser

9 489348 Clamp

10 488908 Screw, 10−12 x 1/2

LINER PARTS

For Models: KBLS36FKB01, KBLS36FKT01, KBLS36FKW01, KBLS36FKX01

(Black) (Biscuit) (White) (Etched Aluminum)

8198081

LINER PARTS

For Models: KBLS36FKB01, KBLS36FKT01, KBLS36FKW01, KBLS36FKX01

(Black) (Biscuit) (White) (Etched Aluminum)

8198081

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Liner,

Refrigerator

(Not Servicable)

2 Liner,Freezer

(Not Servicable)

3 2215610 Cover, Heat

Exchanger

4 2215827 Diffuser Cap,

Left Side

5 2005931 Diffuser Cap,

Right Side

6 2171846 Release Valve

7 487539 Screw, 8−15 x 1/2

8 486194 Screw

9 2208968 Motor, Grommet

10 2006148 Wiring Channel,

Freezer Rear

11 2215844 Foam, Fan Shroud

12 2215910 Grommet, Flexible

13 2215606 Shroud, Evaporator

Fan

14 2169142 Blade, Fan

15 2208939 Motor, Fan

16 2155590 Retainer,

Fan Motor

17 2221296 Air Baffle

Assembly

18 2215503 Bracket

19 8201595 Wiring Channel

20 2221261 Wiring Harness,

Freezer

21 2215833 Cover, Evaporator

Assembly

22 1116793 Cover, Thermistor

23 2213442 Thermistor

24 2209208 Drain Tube,

Condensate

25 2215530 Insulation, Baffle

26 2215531 Cover, Air

Diffuser

27 2204595 Heater−Tube,

Drain

28 2204538 Insulation, Tube

Drain

29 2204537 Cover, Tube

Drain

31 2215835 Housing, Switch

32 1157158 Screw, 8−18 x 3/8

33 2187377 Wire, Jumper

35 2209204 Clip, Thermistor

36 2215612 Cover, Air Duct

37 2215816 Control Panel

38 2221064 Overlay, Control

Panel

39 2209159 Circuit Board

(User Interface)

40 2215670 Insert, Control

Box

41 489464 Screw

42 2162085 Socket, Light

43 2160708 Light Bulb

44 2187424 Harness, Control

Box

45 8201534 Channel, Wiring

Freezer Light

46 1115375 Clip, Wiring

47 1115373 Switch, Rocker

48 2005792 Wiring Cover,

Icemaker

49 2187378 Defrost Bi−Metal

50 2215829 Diffuser Assembly

51 2221121 Support, Control

Box

52 489006 Screw

REFRIGERATOR SHELF PARTS

For Models: KBLS36FKB01, KBLS36FKT01, KBLS36FKW01, KBLS36FKX01

(Black) (Biscuit) (White) (Etched Aluminum)

8198081

REFRIGERATOR SHELF PARTS

For Models: KBLS36FKB01, KBLS36FKT01, KBLS36FKW01, KBLS36FKX01

(Black) (Biscuit) (White) (Etched Aluminum)

8198081

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Slide, Freezer

Basket

2221278 Right Side

2221279 Left Side

2 9751808 Screw, 8−15 x 1.00

3 8281158 Screw,

8−18 x 1.375

4 Spacer, Crisper

2005138 Right Side

2005139 Left Side

5 2179404 Rack, Wine

6 2216625 Egg Bin

7 2188212 Roller

8 Bracket, Spacer

2221280 Right

2221281 Left

9 2174478 Eyelet, Roller

10 489211 Screw,

10−16 x .750

11 489261 Screw

12 2169935 Cover

13 1113169 Roller Stop

14 486194 Screw

15 2005987 Support, Crisper

Shelf (2)

16 2006454 Rail, Deli

Center

17 2207549 Washer

18 2005571 Shelf (4)

19 2005429 Air Damper, Deli

20 2005151 Rail−Rear, Deli

21 2005152 Glass Shelf, Deli

22 2220883 Rail−Front, Deli

23 2005415 Control Knob, Deli

24 2006235 Screw,

10−16 x .375

25 2006252 Washer

26 2005165 Connector, Deli

Pan

27 2222655 Lid, Deli Pan

28 2005923 Hinge Rod, Deli

Pan

29 2005157 Cripser Pan

30 2005480 Handle, Crisper

Pan

31 2006253 Screw,

8−32 x .340

32 2005986 Overlay, Crisper

Pan

33 2220885 Rail−Front,

Crisper Shelf

34 2005425 Vent, Crisper

Shelf

35 2005413 Slide−Humidity,

Crisper Shelf

36 2006254 Screw,

6−19 x .250

37 2005477 Glass, Crisper

Shelf

38 2005478 Rail−Rear,

Crisper Shelf

39 2005479 Seal−Front,

Crisper Shelf

40 2005984 Insulation,

Crisper Rail

41 2005985 Baffle−Center,

Crisper Shelf

42 2005794 Center Support,

Left Half

43 2005795 Center Support,

Right Half

44 2005796 Bracket, Center

Support

45 2003478 Screw,

10−16 x .625

46 2006235 Screw,

10−16 x .375

47 2222741 Deli Pan

48 2005410 Ladder, Shelf (4)

49 2006475 Screw,

50 2005797 Ladder, Crisper

Support

51 2196483 Shelf Stud

(Includes Item 3)

52 2221260 Roller

53 2207522 Bumper

54 2207415 Nut

55 2207569 Shim

FREEZER DOOR AND BASKET PARTS

For Models: KBLS36FKB01, KBLS36FKT01, KBLS36FKW01, KBLS36FKX01

(Black) (Biscuit) (White) (Etched Aluminum)

8198081

FREEZER DOOR AND BASKET PARTS

For Models: KBLS36FKB01, KBLS36FKT01, KBLS36FKW01, KBLS36FKX01

(Black) (Biscuit) (White) (Etched Aluminum)

8198081

Illus. Part

No. No. DESCRIPTION

1 2188601 Freezer Door

Panel (Includes

Item 9)

2 2204525 Divider, Basket

3 2207429 Clamp, Divider

4 2207415 Nut, Crimp

5 488649 Screw

6 Cover−Trim,

Handle

2006331 Black

2006330 Biscuit

2006328 White

2006327 Etched Aluminum

7 Trim−Door, Side

2006304 Black

2006303 Biscuit

2005869 White

2005868 Etched Aluminum

8 Trim−Door, Bottom

2006282 Black

2006281 Biscuit

2006279 White

2006278 Etched Aluminum

9 2188533 Door Gasket,

Magnetic

10 Cover−Trim, Side

2006326 Black

2006325 Biscuit

2006323 White

2006322 Etched Aluminum

11 Handle, Door

2006292 Black

2006291 Biscuit

2005392 White

2005188 Etched Aluminum

12 2204542 Roller

13 Trim, Corner

2006273 Black

2006272 Biscuit

2006270 White

2207457 Chrome

14 Screw, 8−15 x 1/2

8281252 Black

8281253 Biscuit

8281251 White

8281250 Stainless Steel

15 2207533 Bracket, Assembly

Freezer Basket

17 2005376 Basket, Upper

18 2174124 Pan, Ice Cube

19 2207454 Nut, Hex

20 2207471 Bushing

21 3400507 Screw

22 2006244 Basket, Freezer

Lower

24 2207576 Spacer

25 2207415 Nut

26 2207550 Roller

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels KitchenAid Réfrigérateur

KitchenAid

KitchenAid KTRC22KMBL03 Manuel utilisateur

KitchenAid

KitchenAid KSSC48QVS00 Manuel utilisateur

KitchenAid

KitchenAid KRMF706ESS Manuel utilisateur

KitchenAid

KitchenAid Classic KSSS42QTB Manuel utilisateur

KitchenAid

KitchenAid KRFC400ESS Manuel utilisateur

KitchenAid

KitchenAid Side-by-Side Referigerator Manuel utilisateur

KitchenAid

KitchenAid KFCP22EXMP Manuel de la liste des pièces

KitchenAid

KitchenAid KBFS20ETSS - Architect Series II: 19.7 cu.... Manuel utilisateur

KitchenAid

KitchenAid KBRS20ETBL11 Manuel utilisateur

KitchenAid

KitchenAid KTLA22EMSS00 Manuel utilisateur

KitchenAid

KitchenAid KBRS22KVBL00 Manuel utilisateur

KitchenAid

KitchenAid KSSC42FKB00 Manuel utilisateur

KitchenAid

KitchenAid KBFS22EW Manuel de la liste des pièces

KitchenAid

KitchenAid KFIS20XV Series Manuel de la liste des pièces

KitchenAid

KitchenAid KSSO36FTX02 Manuel utilisateur

KitchenAid

KitchenAid KBRO36FTX00 Manuel utilisateur

KitchenAid

KitchenAid KBFN502ESS Manuel utilisateur

KitchenAid

KitchenAid KBLS19KTMS Instructions de montage

KitchenAid

KitchenAid KSSS48M Manuel utilisateur

KitchenAid

KitchenAid KSSS42QDW04 Guide de dépannage

KitchenAid

KitchenAid FOR THE WAY IT'S MADE KSSS36QDX00 Manuel utilisateur

KitchenAid

KitchenAid FOR THE WAY IT'S MADE KSSS36MDX00 Manuel utilisateur

KitchenAid

KitchenAid KSCS23FVBL02 Manuel utilisateur

KitchenAid

KitchenAid KRSC500ESS Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur

Teledyne

Teledyne 6712FR and Mode d'emploi
