User’s Guide

• In this manual, we refer only to the model KAODCPPRO.

• Be sure to read the 'Safety Precautions' in this document, and make sure you use this product

correctly.

• Keep this manual in a safe place for future reference.

1. Introduction

• The contents of this user guide is subject to change without notice.

• Copying of this manual, either in part or its entirety is forbidden. You are allowed to use

this manual for your personal use only.

• The images and sample screens shown in this manual are for illustrative purposes only,

and may not be exactly the same as screens actually produced by this product.

Thank you for purchasing the KickAss Outdoor Cinema Projector. We designed this

projector alongside our optional DC-DC vehicle adapter (sold separately) to oﬀer you the

ﬂexibility of being able to use it at home or while you're on an adventure away from home.

Please ensure you read through the following information before use for the best

entertainment experience.

• Microsoft, Windows and Windows Vista are registered trade marks or trade marks of

Microsoft Corporation in the United States and other countries.

• iOS, Mac Os and App Store are registered trade marks or trade marks of Apple, Inc. in

the United States, and other countries.

• Google Home and Android are registered trade marks or trade marks of Google LLC in

the United States, and other countries.

• EZCast is a registered trade mark or trade mark of Actios Microelectronics Co., Ltd. in

China, and other countries.

• HDMI, the HDMI Logo and High-Deﬁnition Multimedia Interface are trade marks or

registered trade marks of HDMI Licensing, LLC.

2

3. What’s Included

Do not look directly at or into the lens while the device is in use.

To avoid overheating do not block or obstruct the ventilation panels on the device.

Avoid using chemicals to clean the device. Wipe clean with a dry cloth.

Please keep out of reach of children.

Store the device is a well ventilated and dry area. Between 5-30°C

Do not place heavy objects on top of the device.

Handle the device with care, avoid shaking, throwing and dropping.

Do not attempt to disassemble or repair the device. Please contact Customer

Support for assistance with any technical or operational enquiries.

If the device is in use for more than 8 hours, it is recommended that the device

should be turned oﬀ for 30 minutes.

(1)

(2)

(3)

(4)

(5)

(6)

(7)

(8)

(9)

2. Precautions

OUTDOOR CINEMA

PROJECTOR

USER GUIDE

KAODCPPRO

Projector Unit

Power Adapter 19V 3.42A with

Australian Regulations Cable

Infrared Remote Control

(batteries not included)

User Manual

WiFi Adapter Audio Cable

How to use the device correctly:

3

4. Optional Accessories

DC-DC Vehicle Adapter

(KAODCPPROPS)

The optional DC-DC Vehicle adapter can be

used to power your KickAss Outdoor Cinema

Projector from any power source with a 12V

Cigarette socket. A great addition to power the

unit from a battery box, vehicle or caravan.

CASE FOR OUTDOOR CINEMA

PROJECTOR

(KAODCPPROCASE)

Perfect for carrying and protecting your

KickAss Projector.

Portable Travel Projector & Camera Tripod

(KAPTRIPOD)

This tripod can help achieve great quality shots

in or outdoors. With its durable design and heavy

duty materials proven to be outback ready. You

can also attach a projector and create your very

own cinema out in the bush.

12 Volt Outdoor Cinema Inﬂatable Screen

(KAODCINFSCREEN)

Enjoy your favorite ﬁlms on the big screen

anytime and anywhere.

4

5. Projector and Remote Control

Mounting point

Important

• Batteries not included

• Use only alkaline batteries

• Risk of explosion if incorrect battery type is used

• Dispose of used batteries according to the instructions

5

For Best Results

• Use the projector in a dark room or at night.

• Make sure the projector is on a ﬂat, level surface.

• Do not place the projector in direct sunlight or near any source of direct heat.

• Handle the projector with care.

Connect the power plug to the projector.

Insert the wireless adapter UWA5 into the Wi-Fi interface (USB2 port of the

projector).

To turn on the projector, hold the power button for 3 seconds until the device beeps.

Adjust focus ring until image is clear and focused.

Adjust the keystone correction wheel manually to correct the vertical edges of the

image.

(1)

(2)

(3)

(4)

Getting Started

7. Adjustments

6. Operating Instructions

Adjusting Height and Angle

Simply unscrew the height adjustment piece on the bottom of

the projector until it has reached the desired height or angle.

Mounting Your Projector

Simply unscrew the screw on the bottom of the projector.

Screw your projector directly onto our specially designed

Portable Projector and Camera Tripod.

(1)

(2)

6

Settings

Language settings: Press the left and right arrow keys to select and change the

language.

Firmware Update: To update the ﬁrmware using WIFI ensure the projector is

connected to the internet and select the 'Update' option.

Advanced Settings: Colour adjustment.

Reset Menu: To reset the projector back to factory settings and delete all data,

select 'yes' in the reset menu.

(1)

(2)

(3)

(4)

Shutting Down The Projector:

To turn oﬀ the projector, hold the power button for 3 seconds until the device beeps.

8. Start Up and Connecting to Wi-Fi

Select the start-up language.

WiFi setting: connect the projector to your

router and enter the password. Connect the

projector to your WiFi.

After connecting to wiﬁ you can now

navigate through the main menu using the

arrow keys on the remote controller.

Android, iOS, MacOS, Windows, EZCast,

Multimedia, HDMI, and Setting, as shown

on the right;

(1)

(2)

(3)

7

Open the Google Play Store

and download the app EZCast

on your Android device.

On the main menu of the

projector select 'Plug and Play'

and press OK.

Connect your Android device

to the projector via the USB

charging cable and enable

'USB Tethering' on your

device.

Open the EZCast App and

select 'Beam-XXXX' to play

media.

(1)

(2)

(3)

(4)

1. Android

Open the App Store and

download the EZCast app on

your iOS device.

On the main menu of the

projector select 'Plug and Play'

and press OK.

Connect your iOS device to

the projector via the USB

charging cable.

Select 'Trust This Computer' to

view the media.

(1)

(2)

(3)

(4)

2. iOS

9. Projecting an Image

Multimedia Playback

Insert a USB ﬂash drive into the USB1 port or insert SD Card into the SD Card

port.

Select 'Multimedia > USB or SD Card > Video, Music or Photo to view the media

Using the arrow keys, select the media ﬁle and press 'OK'.

To view the menu again press 'OK' and select the next ﬁle by using the arrow

keys.

(1)

(2)

(3)

(4)

Supported Formats

8

Visit https://www.ezcast.com/app and download the EZCast App onto your

desktop.

On the main menu of the projector select 'Plug and Play' and press OK.

Connect your PC to the projector via USB A-to-A Cable.

Open the EZCast App and select 'Beam-XXXX' to play media.

(1)

(2)

(3)

(4)

3. Windows 10

Visit https://www.ezcast.com/app and download the EZCast App onto your

desktop.

On the main menu of the projector select 'Plug and Play' and press OK.

Connect your PC to the projector via USB A-to-A Cable.

Open the EZCast App and select 'Beam-XXXX' to play media.

(1)

(2)

(3)

(4)

4. Mac OS
