Keysight N5224AU-217 Manuel d'installation et d'exploitation

Keysight Add Source and

Receiver Attenuators Upgrade

Kit

Installation Note

To Upgrade PNA N5224A or N5225A Option 201 to

Option 217

Upgrade Kit Order Numbers: N5224AU-217 or

N5225AU-217

Keysight Kit Number: N5225-60103

2 Installation Note N5225-90103

WARRANTY STATEMENT

THE MATERIAL CONTAINED IN THIS DOCUMENT IS PROVIDED “AS IS,” AND IS SUBJECT TO BEING

CHANGED, WITHOUT NOTICE, IN FUTURE EDITIONS. FURTHER, TO THE MAXIMUM EXTENT PERMITTED BY

APPLICABLE LAW, KEYSIGHT DISCLAIMS ALL WARRANTIES, EITHER EXPRESS OR IMPLIED WITH REGARD

TO THIS MANUAL AND ANY INFORMATION CONTAINED HEREIN, INCLUDING BUT NOT LIMITED TO THE

IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. KEYSIGHT

SHALL NOT BE LIABLE FOR ERRORS OR FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES IN CONNECTION

WITH THE FURNISHING, USE, OR PERFORMANCE OF THIS DOCUMENT OR ANY INFORMATION CONTAINED

HEREIN. SHOULD KEYSIGHT AND THE USER HAVE A SEPARATE WRITTEN AGREEMENT WITH WARRANTY

TERMS COVERING THE MATERIAL IN THIS DOCUMENT THAT CONFLICT WITH THESE TERMS, THE

WARRANTY TERMS IN THE SEPARATE AGREEMENT WILL CONTROL.

DFARS/Restricted Rights Notice

If software is for use in the performance of a U.S. Government prime contract or subcontract, Software is

delivered and licensed as “Commercial computer software” as defined in DFAR 252.227-7014 (June 1995), or

as a “commercial item” as defined in FAR 2.101(a) or as “Restricted computer software” as defined in FAR

52.227-19 (June 1987) or any equivalent agency regulation or contract clause. Use, duplication or disclosure of

Software is subject to Keysight Technologies’ standard commercial license terms, and non-DOD Departments

and Agencies of the U.S. Government will receive no greater than Restricted Rights as defined in FAR 52.227-

19(c)(1-2) (June 1987). U.S. Government users will receive no greater than Limited Rights as defined in FAR

52.227-14 (June 1987) or DFAR 252.227-7015 (b)(2) (November 1995), as applicable in any technical data.

Safety Notes

The following safety notes are used throughout this document. Familiarize yourself with each of these notes

and its meaning before performing any of the procedures in this document.

WARNING Warning denotes a hazard. It calls attention to a procedure which, if not correctly performed

or adhered to, could result in injury or loss of life. Do not proceed beyond a warning note

until the indicated conditions are fully understood and met.

CAUTION Caution denotes a hazard. It calls attention to a procedure that, if not correctly performed or

adhered to, could result in damage to or destruction of the instrument. Do not proceed beyond

a caution note until the indicated conditions are fully understood and met.

Installation Note N5225-90103 3

Description of the Upgrade

This upgrade adds the following items to your N5224A Option 201 or N5225A Option 201 network analyzer:

• a 60-dB source attenuator in each source port channel

• a 35-dB receiver attenuator in each receiver channel

• front panel overlay replacement

•newcables

After installation of this upgrade, your analyzer will be an N5224A Option 217 or N5225A Option 217.

Getting Assistance from Keysight

By internet, phone, or fax, get assistance with all your test and measurement needs.

Contacting Keysight

Assistance with test and measurements needs and information on finding a local Keysight office are available

on the Web at:

http://www.keysight.com/find/assist

If you do not have access to the Internet, please contact your Keysight field engineer.

NOTE In any correspondence or telephone conversation, refer to the Keysight product by its model

number and full serial number. With this information, the Keysight representative can

determine whether your product is still within its warranty period.

4 Installation Note N5225-90103

Getting Prepared

CAUTION The PNA contains extremely sensitive components that can be ruined if mishandled. Follow

instructions carefully when making cable connections, especially wire harness connections.

The person performing the work accepts responsibility for the full cost of the repair or

replacement of damaged components.

To successfully install this upgrade kit, you will need the following:

• A license key - refer to “License Key Redemption” below.

• A PDF copy or a paper copy of the PNA Service Guide - refer to “Downloading the Online PNA Service

Guide” below.

• An ESD-safe work area - refer to “Protecting Your Workspace from Electrostatic Discharge” below.

• Correct tools - refer to “Tools Required for the Installation” on page 6.

• Enough time - refer to “About Installing the Upgrade” on page 6.

• Test equipment for the post-upgrade adjustments and full instrument calibration. To view the equipment

list, click the Chapter 3 bookmark “Tests and Adjustments” in the PDF Service Guide1.

License Key Redemption

NOTE The enclosed Option Entitlement Certificate is a receipt, verifying that you have purchased a

licensed option for the PNA of your choice. You must now use a Keysight Web page to request

a license key for the instrument that will receive the option.

To enable the option product, you must request a license key from: http://www.keysight.com/find/

softwarelicense. To complete the request, you will need to gather the following information:

• From the certificate

❏Order number

❏Certificate number

• From your instrument

❏Model number

❏Serial number

❏Host ID

The instrument information is available on the network analyzer – on the analyzer’s Help menu, click About

Network Analyzer.

If you provide an email address, Keysight will promptly email your license key. Otherwise, you will your receive

your license key via postal mail.

1. See “Downloading the Online PNA Service Guide” on page 5.

Installation Note N5225-90103 5

Downloading the Online PNA Service Guide

To view the online Service Guide for your PNA model number, use the following steps:

1. Go to www.keysight.com.

2. In the Search box, enter the model number of the analyzer (Ex: N5242A) and click Search.

3. Click Technical Support > Manuals.

4. Click Service Manual.

5. Click the service guide title to download the PDF file.

6. When the PDF of the Service Guide is displayed, scroll through the Contents section bookmarks to locate

the information needed.

Protecting Your Workspace from Electrostatic Discharge

For information, click on the Chapter 1 bookmark, “Electrostatic Discharge Protection” in the PDF Service

Guide1.

ESD Equipment Required for the Installation

1. See “Downloading the Online PNA Service Guide” on page 5.

Description Keysight Part Number

ESD grounding wrist strap 9300-1367

5-ft grounding cord for wrist strap 9300-0980

2 x 4 ft conductive table mat and 15-ft grounding wire 9300-0797

ESD heel strap (for use with conductive floors) 9300-1308

6 Installation Note N5225-90103

Tools Required for the Installation

CAUTION Use a 5/16-in torque wrench set to 10 in-lbs on all cable connections.

About Installing the Upgrade

Description Qty Part Number

T-10 TORX driver - set to 9 in-lbs (1.02 N.m) 1 N/A

T-20 TORX driver - set to 21 in-lbs (2.38 N.m) 1 N/A

5/16-in (8 mm) nutsetter or open end torque wrench - set to 10 in-lbs (1.13 N.m) 1 N/A

Products affected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . N5224A and N5225A Option 201

Installation to be performed by . . . . . . . . . . . . . . . . . . . . . . Keysight service center or personnel qualified by

Keysight

Estimated installation time . . . . . . . . . . . . . . . . . . . . . . . . . 2 hours

Estimated adjustment time . . . . . . . . . . . . . . . . . . . . . . . . . 0.5 hour

Estimated full instrument calibration time . . . . . . . . . . . . . 4.5 hours

Installation Note N5225-90103 7

Items Included in the Upgrade Kit1

Check the contents of your kit against the following list. If any part is missing or damaged, contact Keysight

Technologies. Refer to “Getting Assistance from Keysight” on page 3.

1. In addition to the upgrade kit, the shipment includes an Option Entitlement Certificate. Refer to “License Key Redemption”

on page 4 for important information about this certificate.

Table 1 Contents of Upgrade Kit N5225-60103

Ref

Desig. Description Qty Part Number

-- Installation note (this document) 1 N5225-90103

A38,

A41 0–60 dB source step attenuator 2 33325-60016

A46,

A49 0-35 dB receiver step attenuator 2 33325-60017

-- Attenuator bracket (For source attenuators.) 2 N5245-00015

-- Attenuator bracket (For receiver attenuators.) 2 N5225-00001

-- Cable clamp 8 1400-1334

-- Cable tie 5 1400-0249

-- Front panel overlay 1 N5225-80002

-- Machine screw, M3 x 8, pan head (to attach brackets to attenuators; to attach

receiver attenuators to deck) 17 0515-0372

-- Machine screw, M3 x 6, pan head (to attach source attenuators to deck) 4 0515-0430

W12 A29 port 1 receiver coupler to W11 1 N5245-20050

W18 A32 port 2 receiver coupler to W17 1 N5245-20049

W21 A29 port 1 receiver coupler to A37 reference mixer switch 1 N5245-20118

W33 RF cable, A32 port 2 receiver coupler to front-panel REF 2 SOURCE OUT 1 N5245-20010

W47 REF 2 RCVR R2 IN to A27 mixer brick (R2) 1 N5245-20119

W81 RF cable, A29 test port 1 receiver coupler to A38 test port 1 source attenuator 1 N5245-20029

W82 RF cable, A38 test port 1 source attenuator to front-panel Port 1 SOURCE OUT 1 N5245-20077

W93 RF cable, A32 test port 2 receiver coupler to A41 test port 2 source attenuator 1 N5245-20029

W94 RF cable, A41 test port 2 source attenuator to front-panel Port 2 SOURCE OUT 1 N5245-20031

W97 RF cable, front-panel Port 1 RCVR A IN to A46 port 1 receiver attenuator 1 N5245-20054

W98 RF cable, A46 port 1 receiver attenuator to A27 mixer brick (A) 1 N5245-20056

W103 RF cable, Port 2 RCVR B IN to A49 port 2 receiver attenuator 1 N5245-20055

W104 RF cable, A49 port 2 receiver attenuator to A27 mixer brick (B) 1 N5245-20057

-- Ribbon cable, A23 test set motherboard J205 to A46 port 1 receiver attenuator

2N5245-60026

Was 8121-0982

-- Ribbon cable, A23 test set motherboard J208 to A49 port 2 receiver attenuator

8 Installation Note N5225-90103

NOTE Extra quantities of items such as protective plastic caps, screws, cable ties, and cable clamps

may be included in this upgrade kit. It is normal for some of these items to remain unused after

the upgrade is completed.

-- Ribbon cable, A23 test set motherboard J549 to A38 test port 1 source attenuator

2 N5245-60006

-- Ribbon cable, A23 test set motherboard J546 to A41 test port 2 source attenuator

Table 1 Contents of Upgrade Kit N5225-60103

Ref

Desig. Description Qty Part Number

Installation Note N5225-90103 9

Installation Procedure for the Upgrade

The network analyzer must be in proper working condition prior to installing this option. Any necessary repairs

must be made before proceeding with this installation.

WARNING This installation requires the removal of the analyzer’s protective outer covers. The analyzer

must be powered down and disconnected from the mains supply before performing this

procedure.

Overview of the Installation Procedure

Step 1. Obtain a Keyword and Verify the Information.

Step 2. Remove the Outer Cover.

Step 3. Remove Some Bottom-Side (Test Set) Cables.

Step 4. Assemble the A46 and A49 Receiver Attenuator Assemblies.

Step 5. Install the A46 and A49 Receiver Attenuator Assemblies.

Step 6. Assemble the A38 and A41 Source Attenuator Assemblies.

Step 7. Install the A38 and A41 Source Attenuator Assemblies.

Step 8. Install Some Bottom-Side (Test Set) Cables.

Step 9. Remove the Old Lower Front Panel Overlay.

Step 10. Reinstall Front Panel Assembly.

Step 11. Install the New Lower Front Panel Overlay.

Step 12. Reinstall Front Panel Jumpers.

Step 13. Position the Cables and Wires to Prevent Pinching.

Step 14. Reinstall the Outer Cover.

Step 15. Enable Option 217.

Step 16. Perform Post-Upgrade Adjustments and Calibration.

Step 17. Prepare the PNA for the User.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Keysight Instrument de mesure

Keysight

Keysight N437 Series Manuel

Keysight

Keysight NFA Series Manuel d'utilisation et d'entretien

Keysight

Keysight AE6941A Manuel utilisateur

Keysight

Keysight MXA Series Manuel d'installation et d'exploitation

Keysight

Keysight N2140A Manuel utilisateur

Keysight

Keysight M9614A Guide de l'utilisateur

Keysight

Keysight x-series Manuel utilisateur

Keysight

Keysight N5227BU-420 Manuel utilisateur

Keysight

Keysight B2980A Series Guide d'installation

Keysight

Keysight N4376E Manuel utilisateur

Keysight

Keysight N5222-60118 Manuel d'installation et d'exploitation

Keysight

Keysight Truevolt Series Manuel de service

Keysight

Keysight M9203A Guide de l'utilisateur

Keysight

Keysight N2791A Manuel utilisateur

Keysight

Keysight U8903A Manuel utilisateur

Keysight

Keysight PD1000A Guide de l'utilisateur

Keysight

Keysight M9370A Guide de l'utilisateur

Keysight

Keysight N5227A Manuel utilisateur

Keysight

Keysight EXA X-Series N9010A Manuel utilisateur

Keysight

Keysight U8903A Manuel utilisateur

Keysight

Keysight M31 A Series Manuel utilisateur

Keysight

Keysight E8362-60109 Manuel d'installation et d'exploitation

Keysight

Keysight u2722a Manuel utilisateur

Keysight

Keysight PNA-X N5241A Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

ADTEK

ADTEK MW-5 Manuel utilisateur

Acterna

Acterna MS1400 Manuel utilisateur
