Keysight E4991B

Impedance Analyzer

1 MHz to 500 M/1 G/3 GHz

Conguration Guide

02 | Keysight | E4991B Impedance Analyzer - Conguration Guide

Ordering Guide

The following steps will guide you through conguring your E4991B.

Standard furnished item

Description Additional Information

Installation guide Contains the information necessary to start up with the E4991B.

CD ROM IO libraries

7-mm calibration kit with torque wrench Contains Open, Short, 50 ΩLoad and Low-loss Capacitor terminations and torque wrench.

Power Cable

Certicate of Calibration

Note: The following are not furnished: Printed copy of Operation and Service Manual, Test Fixture, Keyboard and Mouse. Refer to Accessory Option, Documentation Option

and Available Accessories for the selection of these items.

Note: The test head is furnished with the E4991B main unit.

Step 1. Choose hardware option - frequency (mandatory)

Description Option No. Requires Not Compatible Additional Information

1 MHz to 3 GHz E4991B-300 None None

1 MHz to 1 GHz E4991B-100 None None

1 MHz to 500 MHz E4991B-050 None None

Step 2. Choose hardware option – frequency reference if not required, go to Step 3)

Description Option No. Requires Not Compatible Additional Information

High Stability

Frequency Reference

E4991B-1E5 None None Adds High Stability

Frequency Reference

Note: Refer to Hardware Upgrade for retrot information on the above options.

Step 3. Choose hardware option – DC bias (If not required, go to Step 4)

Description Option No. Requires Not Compatible Additional Information

DC Bias Source E4991B-001 None None Adds DC Bias Source.

Note: Refer to Hardware Upgrade for retrot information on the above options.

Step 4. Choose software option (If not required, go to Step 5)

Description Option No. Requires Not Compatible Additional Information

Material Measurement

Firmware

E4991B-002 None None Adds Material Measurement Firmware for permittivity and

permeability measurements. This option is required to use the

16453A and 16454A.

Note: Refer to Software Upgrade for retrot information on the above options.

03 | Keysight | E4991B Impedance Analyzer - Conguration Guide

Step 5. Choose accessory option – test kit (If not required, go to step 6)

Description Option No. Requires Not Compatible Additional Information

Temperature

Characteristic Test Kit

E4991B-007 None

(The 16194A

and 82357B are

recommended)

None Adds Temperature Characteristic Test Kit. The kit contains

heat-resistant coaxial cable, RF extension cable, heat-resistant

coaxial termination set, test head stand, xture stand, and

terminal adapters. Sample program for temperature character-

istics measurement is installed on SSD.

Probe Station

Connection Kit

E4991B-010 None None Adds Probe Station Connection Kit. The kit contains test head

with 1 m extension cable and terminal adapters, which are

required to interconnect the E4991B and semiconductor probe

station.

Note: Refer to Hardware Upgrade for retrot information on the above options.

Step 6. Choose accessory option - general/miscellaneous accessories (If not required, go to step 7)

Description Option No. Requires Not Compatible Additional Information

Keyboard E4991B-810 None None USB Keyboard for simplifying word inputs.

Mouse E4991B-820 None None USB Mouse for simplifying measurement operation.

Rackmount Kit E4991B-1CM None None Not installable simultaneously with E4991B-1CP.

Front Handle Kit E4991B-1CN None None Not installable simultaneously with E4991B-1CP.

Handle/Rack Mount Kit E4991B-1CP None None Not installable simultaneously with E4991B-1CM or 1CN.

Note: Refer to Hardware Upgrade for retrot information on the above options.

Step 7. Choose calibration certicate option (If not required, go to step 8)

Description Option No. Requires Not Compatible Additional Information

ISO 17025 Compliant

Calibration

E4991B-1A7 ISO 17025 compliant calibration with test data.

ANSI Z540 Compliant

Calibration

E4991B-A6J ANSI Z540 compliant calibration.

Step 8. Choose warranty Plan

3 year Return-to-Keysight warranty and service plan are standard. For extended warranty options and additional information, contact your local Keysight

Technologies, Inc. sales ofce or visit the Keysight home website.

04 | Keysight | E4991B Impedance Analyzer - Conguration Guide

Hardware Upgrade

Option No. Description Upgrade

Model No. or

Equivalent Part

Number

Customer

Installable

Requires

(Instrument

must already

include the

following)

Not

Compatible

Additional Information

E4991B-100 Upgrade from 500 MHz to 1 GHz E4991BU-100 No E4991B-050 None Installable at service center only

E4991B-300 Upgrade from 1 GHz to 3 GHz E4991BU-300 No E4991B-100 None Installable at service center only

E4991B-300 Upgrade from 500 MHz to 3 GHz E4991BU-301 No E4991B-050 None Installable at service center only

E4991B-1E5 High Stability

Frequency Reference

E4991BU-1E5 No None None Installable at service center only

E4991B-001 DC Bias Source E4991BU-001 No None None Installable at service center only

E4991B-007 Temperature

Characteristic Test Kit

E4991BU-007 No None None Installable at service center only

E4991B-010 Probe Station

Connection Kit

E4991BU-010 No None None Installable at service center only

E4991B-1CM Rackmount Kit 5063-9216 Yes None None

E4991B-1CN Front Handle Kit 5063-9229 Yes None None

E4991B-1CP Handle/Rack Mount Kit 5188-4430 Yes None None

Note: For details of the upgrade information, refer to product homepage on the Keysight home website.

Software Upgrade

Option No. Description Upgrade

Model No. or

Equivalent Part

Number

Customer

Installable

Requires

(Instrument

must already

include the

following)

Not

Compatible

Additional Information

E4991B-002 Material Measurement Firmware E4991BU-002 Yes None

(The 16453A

or 16454A is

required for

measurement)

None

Note: For rmware update and upgrade information, refer to product homepage on the Keysight home website.

05 | Keysight | E4991B Impedance Analyzer - Conguration Guide

Available Accessories - Measurement Accessories

Description Model

Number

Requires (Instrument must

already include the following)

Additional Information

Parallel Electrode

SMD Test Fixture

16196A — For 1608 (mm) / 0603 (inch) SMD up to 3 GHz

16196A-710 — Add Magnifying lens and tweezers

16196A-ABA — U.S. - English localization

16196A-ABJ —Japan - Japanese localization

Parallel Electrode

SMD Test Fixture

16196B — For 1005 (mm) / 0402 (inch) SMD up to 3 GHz

16196B-710 — Add Magnifying lens and tweezers

16196B-ABA — U.S. - English localization

16196B-ABJ —Japan - Japanese localization

Parallel Electrode

SMD Test Fixture

16196C — For 0603 (mm) / 0201 (inch) SMD up to 3 GHz

16196C-710 — Add Magnifying lens and tweezers

16196C-ABA — U.S. - English localization

16196C-ABJ —Japan - Japanese localization

Parallel Electrode

SMD Test Fixture

16196D — For 0402 (mm) / 01005 (inch) SMD up to 3 GHz

16196D-710 — Add Magnifying lens and tweezers

16196D-ABA — U.S. - English localization

16196D-ABJ —Japan - Japanese localization

Bottom Electrode

SMD Test Fixture

16197A — For SMD from 1005 (mm) / 0402 (inch) to 3225 (mm) / 1210 (inch); up to 3 GHz.

Device guides, EIA/EIAJ size shorting bar set, tweezers, wrench, magnifying

lens, carrying case and Operation and Service Manual are furnished.

16197A-001 — Add 0603 (mm) / 0201 (inch) device guide

16197A-ABA — U.S. - English localization

16197A-ABJ —Japan - Japanese localization

High Temperature

Test Fixture

16194A — For SMD and leaded device up to 2 GHz, temperature range: –55 °C to +200 °C.

50 Ω working standard resistors, wrench, tweezers and Operation and Service

Manual are furnished.

16194A-010 — Add EIA/EIAJ size shorting bar set

16194A-701 —Add Shorting bar set; (1 x 1 x 2.4, 1.6 x 2.4 x 2, 3.2 x 2.4 x 2.4, 4.5 x 2.4 x 2.4) mm

SMD Test Fixture 16092A — For SMD and leaded device up to 500 MHz. Operation Note is furnished.

Parallel Electrode

SMD Test Fixture

16192A — For SMD up to 2 GHz. Operation and Service Manual is furnished.

16192A-010 — Add EIA/EIAJ size shorting bar set

16192A-701 —Add Shorting bar set; (1 x 1 x 2.4, 1.6 x 2.4 x 2, 3.2 x 2.4 x 2.4, 4.5 x 2.4 x 2.4) mm

16192A-710 — Add Magnifying lens and tweezers

DC Bias Adapter 16200B — External DC bias adapter; 5A max or 40V max, 1 MHz to 1 GHz. Operation and

Service Manual is furnished.

16200B-001 — Add shorting bars and 51 Ωworking standard resistors set; from 0603 (mm) /

0201 (inch) to 3216 (mm) / 1206 (inch)

Dielectric Material

Test Fixture

16453A E4991B-002 For permittivity measurement of dielectric materials up to 1 GHz

Magnetic Material

Test Fixture

16454A E4991B-002 For permeability measurement of magnetic materials up to 1 GHz

USB/GPIB Inter-

face for Windows

82357B E4991B-007 USB / GPIB interface required for controlling E4991B and ESPEC bench-top

temperature chamber by an external PC.

Note: For more detailed information, refer to Accessories Selection Guide for Impedance Measurements.

06 | Keysight | E4991B Impedance Analyzer - Conguration Guide

Available Accessories – for Performance Test and Maintenance

Description Model

Number

Requires (Instrument must

already include the following)

Additional Information

Performance Test Kit 16190B — 7 mm performance test kit; includes Open, Short, 50 ΩLoad, Air-line, calibra-

tion data, wrench and carrying case.

Note: For details of the performance test kit, refer to product page on the Keysight home website.

Literature Resource

Title Publication Number

E4991B Data Sheet 5991-3893EN

E4991B Brochure 5991-3892EN

LCR Meters, Impedance Analyzers and Test Fixtures Selection Guide 5952-1430E

Accessories Selection Guide For Impedance Measurements 5965-4792E

Impedance Measurement Handbook 5950-3000

Note: More literature is available on the Keysight home website.

Web Resource

Have Access to the following website to acquire the latest news, product and support informa-

tion, application literature and more.

www.keysight.com/find/impedance

07 | Keysight | E4991B Impedance Analyzer - Conguration Guide

myKeysight

www.keysight.com/find/mykeysight

A personalized view into the information most relevant to you.

Three-Year Warranty

www.keysight.com/find/ThreeYearWarranty

Keysight’s commitment to superior product quality and lower total cost

of ownership. The only test and measurement company with three-year

warranty standard on all instruments, worldwide.

www.keysight.com/go/quality

Keysight Technologies, Inc.

DEKRA Certified ISO 9001:2008

Quality Management System

Keysight Channel Partners

www.keysight.com/find/channelpartners

Get the best of both worlds: Keysight’s measurement expertise and product

breadth, combined with channel partner convenience.

This information is subject to change without notice.

Published in USA, August 14, 2015

5991-3894EN

www.keysight.com

For more information on Keysight

Technologies’ products, applications or

services, please contact your local Keysight

office. The complete list is available at:

www.keysight.com/find/contactus

Americas

Canada (877) 894 4414

Brazil 55 11 3351 7010

Mexico 001 800 254 2440

United States (800) 829 4444

Asia Pacic

Australia 1 800 629 485

China 800 810 0189

Hong Kong 800 938 693

India 1 800 112 929

Japan 0120 (421) 345

Korea 080 769 0800

Malaysia 1 800 888 848

Singapore 1 800 375 8100

Taiwan 0800 047 866

Other AP Countries (65) 6375 8100

Europe & Middle East

Austria 0800 001122

Belgium 0800 58580

Finland 0800 523252

France 0805 980333

Germany 0800 6270999

Ireland 1800 832700

Israel 1 809 343051

Italy 800 599100

Luxembourg +32 800 58580

Netherlands 0800 0233200

Russia 8800 5009286

Spain 800 000154

Sweden 0200 882255

Switzerland 0800 805353

Opt. 1 (DE)

Opt. 2 (FR)

Opt. 3 (IT)

United Kingdom 0800 0260637

For other unlisted countries:

www.keysight.com/find/contactus

(BP-09-23-14)

Autres manuels pour E4991B

Table des matières

Autres manuels Keysight Instrument de mesure

Keysight

Keysight N2818 Manuel utilisateur

Keysight

Keysight N2791A Manuel utilisateur

Keysight

Keysight U1211A Manuel utilisateur

Keysight

Keysight N9030B Manuel d'installation et d'exploitation

Keysight

Keysight N9030A Manuel d'installation et d'exploitation

Keysight

Keysight N9068A Manuel utilisateur

Keysight

Keysight N5227BU-420 Manuel utilisateur

Keysight

Keysight PXA X Series Manuel d'installation et d'exploitation

Keysight

Keysight N2820A Manuel utilisateur

Keysight

Keysight U1281A Manuel utilisateur

Keysight

Keysight N5221A Manuel utilisateur

Keysight

Keysight N5244/45AS Option H85 Manuel

Keysight

Keysight FieldFox Manuel utilisateur

Keysight

Keysight PD1000A Manuel utilisateur

Keysight

Keysight Streamline Series Guide de l'utilisateur

Keysight

Keysight x series Guide de démarrage rapide

Keysight

Keysight 4284A Guide d'installation

Keysight

Keysight E5052B Manuel utilisateur

Keysight

Keysight N5241AU- 927 Manuel d'installation et d'exploitation

Keysight

Keysight PNA-L N5231A Manuel d'installation et d'exploitation

Keysight

Keysight N1911A Manuel utilisateur

Keysight

Keysight U1401B Manuel

Keysight

Keysight U1190A Series Manuel utilisateur

Keysight

Keysight U1731C Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

ADTEK

ADTEK MW-5 Manuel utilisateur

Acterna

Acterna MS1400 Manuel utilisateur
