Keychron Q5 Max Manuel utilisateur
Q5 Max Wireless Mechanical Keyboard
2
Keyboard
1x Fully Assembled Keyboard
Including
1x Aluminum Case
1x PCB
1x PC Plate
1x Sound Absorbing Foam
1x IXPE Foam
1x PET Foam
1x Latex Boom Pad
1x Boom Case Acousc Foam
1x Boom Case PET Foam
14x Gaskets (12 Installed and 2 in the Box)
7 sets x Stabilizers
1 set x Keycaps (PBT Double-shot)
1 set x Switches
Cable
1x Type-C to Type-C Cable
1x Type-A to Type-C Adapter
1x Extension Adapter for Receiver
Receiver
1x Type-A 2.4 GHz Receiver
Tools
1x Keycap & Switch Puller
1x Screwdriver
1x Hex Key
Fully Assembled Version
3
Keyboard Kit
1x Keyboard Kit (Without Keycaps & Switches)
Including
1x Aluminum Case
1x PCB
1x PC Plate
1x Sound Absorbing Foam
1x IXPE Foam
1x PET Foam
1x Latex Boom Pad
1x Boom Case Acousc Foam
1x Boom Case PET Foam
14x Gaskets (12 Installed and 2 in the Box)
7 sets x Stabilizers
Cable
1x Type-C to Type-C Cable
1x Type-A to Type-C Adapter
1x Extension Adapter for Receiver
Receiver
1x Type-A 2.4 GHz Receiver
Tools
1x Keycap & Switch Puller
1x Screwdriver
1x Hex Key
Barebone Version
Quick Start Guide
If you are a Windows user, please find the appropriate keycaps in the box, then follow
theinstructions below to find and replace the following keycaps.
Mac / Windows
4
5
Switch To The Right System
1
Please make sure the system toggle on
the top left corner has been switched
to the same system as your computer's
operating system.
G = 2.4 GHz
G / Cable / BT
2Connect 2.4 GHz Receiver
Switch toggle to 2.4 GHz mode
Connect the 2.4 GHz receiver to
the device USB port.
Type-C
Cable Extension Adapter
For Receiver
2.4 GHz
Receiver
Note: For the best wireless experience, we recommend using the
extension adapter for receiver and putting the 2.4 GHz receiver
somewhere on your desk close to your keyboard for a low rate
of latency and fewer signal interferences.
6
3Connect Bluetooth
Switch toggle to Bluetooth
Press fn + 1 (for 4 seconds) and pair with
device named Keychron Q5 Max
fn + 1
Switch toggle to Bluetooth
G / Cable / BT
4Connect Cable
Switch toggle to Cable
G / Cable / BT
7
6The Layers
There are four layers of key settings on the
keyboard. The layer 0 and layer 1 are for the
Mac system. The layer 2 and layer 3 are for
the Windows system.
If your system toggle is switched
to Mac, then the layer 0 will be
activated.
If your system toggle is switched to Windows, then
the layer 2 will be activated. Remember that if you
are using it in Windows mode, please make changes
to the layer 2 instead of the top layer (the layer 0).
This is a common mistake people are making.
Your keyboard’s best friend
5The VIA Key Remapping Software
Please visit usevia.app to use the online
VIA software to remap the keys.
If the VIA cannot recognize your keyboard,
please reach our support to get the instruction.
*The online VIA software can only run on the latest version of Chrome, Edge, and Opera browsers yet.
*VIA only works when the keyboard is connected by wire to the computer.
8
Press fn + Q to change the lighting effect Press fn + tab to turn the backlight on/off
7The Backlight
Adjust The Backlight Brightness
8
Press fn + W to increase the backlight brightness Press fn + S to decrease the backlight brightness
fn + Q
fn + W fn + S
fn + tab
9
Adjust The Backlight Speed
9
Press fn + T to increase the light effect speed Press fn + G to decrease the light effect speed
Factory Reset
10
1. Download the right firmware and QMK Toolbox from our website.
2. Unplug the power cable and switch the keyboard to Cable mode.
3. Remove the space bar keycap to find the reset button on the PCB.
4. Hold the reset key first, then plug the power cable into the keyboard.
Release the reset key after 2 seconds, and the keyboard will now enter
DFU mode.
5. Flash the firmware with the QMK Toolbox.
6. Factory reset the keyboard by pressing fn + J + Z (for 4 seconds).
Troubleshooting? Don’t know what’s going on with the keyboard?
*Step by step guide can be found on our website.
fn + T fn + G
Warranty
11
The keyboard is highly customizable and easy to be rebuilt.
If anything goes wrong with any of the keyboard components
of keyboard during the warranty period, we will only replace
the defective parts of the keyboard, not the whole keyboard.
