Keychron K2 Manuel utilisateur

K2 Bluetooth Mechanical Keyboard

2

Keychron K2 Bluetooth Mechanical Keyboard x 1

Type-C Cable * 1

Manual * 1

Quick Start Guide * 1

Extra Keycaps Set * 1

IN THE BOX:

Quick Start Guide

If you are a Windows user, please find the appropriate keycaps in the box,

then follow the instructions below to find and replace the following keycaps.

Mac / Windows

3

4

4

5

4

4

6

6

5

6.5

For Mac - Karabiner For Windows - SharpKeys

Karabiner SharpKeys

Remap keys Linux’s Setting

We have a Linux user group on facebook. Please search

“Keychron Linux Group” on facebook. So you can

better experience with our keyboard.

We don’t have an oicial software to remap the keys yet.

But you can use these two software to get the job done.

(Except the light eect key)

Disable Auto Sleep Mode

The keyboard goes to Auto Sleep Mode in 10 minutes

of sitting idle to save battery

Press fn + S + O (for 4 seconds) to disable the Auto Sleep Mode.

(If you want to go back to the Auto Sleep mode, press fn + S + O for 4 seconds again)

7

Factory Reset

8

JZ

Trouble shooting? Don’t know what’s going on with the keyboard?

Try factory reset by pressing fn +J +Z（for 4 seconds)

8

K2 BLUETOOTH MECHANICAL KEYBOARD SPECIFICATIONS

Number of keys: 84

Switch type: Mechanical / Optical Switch

Battery: 4000mAh

Working time: Around 70 hours with the backlight on.

Charging time: Around 3 hours

Charging port: USB Type-C

Mode: Bluetooth/Wired

Bluetooth operating distance: Within 10 meters (open space)

Name of Bluetooth device: Keychron K2

Operating Environment: -10 to 50°c

Technical specifications can be subjected to change without notice we apologize for any

inconvenience caused

9

K2 BLUETOOTH MECHANICAL KEYBOARD OVERVIEW

Windows

Mac

1

1

2

3

4

5

Bluetooth indicator

Charging port

Battery indicator

Win/Android Mac/iOS (OS Toggle Swit

ch)

BT OFF Cable (Mode Toggle Switch)

2

4

3

5

10

LED STATUS OVERVIEW

LED Location

Battery indicator

Bluetooth indicator

Function

Charging

Bluetooth

Status

Low battery - Blinking Red

Charging - Static Red

Fully charged - Static Green

Pairing - Fast Blinking

Paired - Light Off

Switching - Slow Blinking

*The Keychron keyboard is compatible with all USB ports. Please use a 5V 2A adapter or USB 3.0 for

the best performance. The Keychron K2 can be charged in Bluetooth/on/off mode.

** This product supports up to 5V charging voltage and 2A charging current. We are not responsible

for any problems caused by improper charging.

3
