EW Weighing Series
User Manual
User Manual
EW Series
Portable Weighing Scale
EW Weighing Series
User Manual
Cautions
When LCD is blank, it means OVERLOAD (the
measured weight is heavier than the max
capacity). Please immediately remove the
measured objects away from the platter.
Do not keep the weight placed on the platter for a
long period.
Keep the scale away from the environment with
high temperature、high humidity、heavy press、
heavy bump.
Make sure the scale is located in a flat and plane
surface.
Dimensions
Indicator: 140mm x 92mm x 25mm (L x W x H)
Platform: 300mm x 300mm x 70mm (L x W x H)
Symbols on LCD
Zero Indication ():
cursor appears on the right-bottom corner of
LCD (above of ZERO printed on the display-
overlay), and indicates the scale is at zero-point.
1
EW Weighing Series
User Manual
Net Weight Indication ():
cursor appears on the bottom edge of LCD (above
of NET printed on the display-overlay), and indicates
the tare weight has been deducted.
Battery Indication :
When LCD shows , it means that the battery is
running in low-voltage status. This is to remind the
user to change the battery. LCD will show
continuously until the battery has been replaced.
Indication of kg or lb Weighing Mode () :
cursor will flash on the bottom edge of LCD
(above of kg or lb printed on the display-overlay),
and indicates the present weighing mode.
Operation Instructions
OFF
key
:
To power off the scale.
ON/UNIT
key
:
(1) To power on the scale.
(2) To select the weighing mode: kg or lb
-
-
2
EW Weighing Series
User Manual
TARE/ZERO
key
:
1. Pressing this key to zero the weight that is lighter
than the division. LCD will show cursor on the
above of ZERO (printed on the display-overlay).
2. While the measured weight is heavier than the
division, pressing this key could get a net weight.
Place a package or container on the platter and
press this key to deduct the tare weight, LCD will
show 0.00 and cursors on the above of ZERO
and NET (printed on the display-overlay).
NET/GROSS
key
:
1. Put the container or package on the platter, and
then press [TARE/ZERO] key. LCD will show 0.00
and cursors above of ZERO and NET (printed on
the display-overlay).At this moment, pressing
[NET/GROSS] key once could recall the deducted
tare weight of container or package. Pressing
[NET/GROSS] key once again, LCD will indicate
0.000 and cursors on the above of ZERO and
NET (printed on the display-overlay).
2. Put the container or package on the platter and
then press [TARE/ZERO] key. LCD will show 0.00
and cursors on the above of ZERO and NET
(printed on the display-overlay). And then put the
3
EW Weighing Series
User Manual
measured subject into the container or package.
LCD will indicate the Net Weight Value. At this
moment, pressing [NET/GROSS] key once can
obtain the total Gross Weight Value. Pressing
[NET/GROSS] key again, LCD will go back to the
Net Weight Value again.
Power Requirements
AC: 100-240V,60Hz
(For optional AC/DC Adaptor)
DC: 9V ALKALINE BATTERY
4
EW Weighing Series
User Manual
We do more than you expect
Portable Weighing Scale
