Kenwood TK-3601D-E Manuel utilisateur

USER GUIDE

GUIDE DE L'UTILISATEUR

GUÍA DEL USUARIO

GUIDA PER L'UTENTE

BENUTZERHANDBUCH

GEBRUIKERSHANDLEIDING

KULLANICI REHBERI

ΟΔΗΓΟΣ ΧΡΗΣΤΗ

GUIA DO UTILIZADOR

TK-3601D

B5A-2555-10/01 (E)

The AMBE+2TM voice coding Technology embodied in this

product is protected by intellectual property rights including

patent rights, copyrights and trade secrets of Digital Voice

Systems, Inc. This voice coding Technology is licensed

solely for use within this Communications Equipment.

The user of this Technology is explicitly prohibited from

attempting to extract, remove, decompile, reverse engineer,

or disassemble the Object Code, or in any other way convert

the Object Code into a human-readable form. U.S. Patent

Nos. #8,315,860, #8,595,002, #6,912,495, #8,200,497,

#7,970,606, and #8,359,197.

USER GUIDE

UHF DIGITAL TRANSCEIVER

TK-3601D

THANK YOU

We are grateful you have chosen KENWOOD for your dPMR446

applications.

CONTENTS

PRECAUTIONS............................................................ 4

UNPACKING AND CHECKING EQUIPMENT............................ 7

PREPARATION ............................................................ 8

ORIENTATION ............................................................12

BASIC OPERATION ......................................................14

CHANNEL LIST...........................................................15

Firmware Copyrights

The title to and ownership of copyrights for ﬁrmware embedded in

KENWOOD product memories are reserved for JVCKENWOOD

Corporation.

OPERATING CONDITIONS

Open locations (no obstructions) : Up to 9.0 km

Residential areas (near buildings) : Up to 2.7 km

Note:

◆The above range is based on ﬁeld testing and may vary with your operating

conditions.

NOTICES TO THE USER

Refer service to qualiﬁed technicians only.

Safety: It is important that the operator is aware of, and understands,

hazards common to the operation of any transceiver.

This equipment complies with the essential requirements of directive

2014/53/EU.

Information on disposal of old Electrical and electronic equipment and

batteries (applicable for countries that have adopted separate waste

collection systems)

Products and batteries with the symbol (crossed-out wheeled bin)

cannot be disposed as household waste.

Old electrical and electronic equipment and batteries should be

recycled at a facility capable of handling these items and their waste

byproducts.

Contact your local authority for details in locating a recycle facility

nearest to you.

Proper recycling and waste disposal will help conserve resources

whilst preventing detrimental effects on our health and the

environment.

Notice: The sign “Pb” below the symbol for batteries indicates that

this battery contains lead.

PRECAUTIONS

Observe the following precautions to prevent ﬁre, personal injury, and

transceiver damage.

• Do not charge the transceiver and battery pack when they are wet.

• Ensure that there are no metallic items located between the transceiver and

the battery pack.

• Do not use options not speciﬁed by KENWOOD.

• If the chassis or other transceiver part is damaged, do not touch the

damaged parts.

• If a headset or earphone is connected to the transceiver, reduce the

transceiver volume.

• Do not place the optional speaker/ microphone, clip mic. with earphone, or

headset around your neck while near machinery that may catch the cable.

• Do not place the transceiver on unstable surfaces.

• Ensure that the end of the antenna does not touch your eyes.

•

When the transceiver is used for transmission for many hours, the radiator

and chassis will become hot. Do not touch these locations when replacing the

battery pack.

• Always switch the transceiver power off before installing optional

accessories.

• The charger is the device that disconnects the unit from the AC mains line.

The AC plug should be readily accessible.

• To dispose of batteries, be sure to comply with the laws and regulations in

your country or region.

WARNING

Turn the transceiver power off before entering the following

locations:

• Near explosives or blasting sites.

• In aircraft. (Any use of the transceiver must follow the instructions and

regulations provided by the airline crew.)

• Where restrictions or warnings are posted regarding the use of radio

devices, including but not limited to medical facilities.

• Near persons wearing pacemakers.

• In explosive atmospheres (inﬂammable gas, dust particles, metallic

powders, grain powders, etc.).

• While pumping fuel or while parked at gasoline service stations.

CAUTION

• Do not disassemble or modify the transceiver for any reason.

• Do not place the transceiver on or near airbag equipment while the vehicle

is running. When the airbag inﬂates, the transceiver may be ejected and

strike the driver or passengers.

• If an abnormal odor or smoke is detected coming from the transceiver,

switch the transceiver power off immediately, remove the battery pack from

the transceiver, and contact your KENWOOD dealer.

• Use of the transceiver while you are driving may be against trafﬁc laws.

Please check and observe the vehicle regulations in your area.

• Do not expose the transceiver to extremely hot or cold conditions.

• Do not carry the battery pack (or battery case) with metal objects, as they

may short the battery terminals.

• Danger of explosion if the battery is incorrectly replaced; replace only with

the same type

• When attaching a commercial strap to the transceiver, ensure that the

strap is durable. In addition, do not swing the transceiver around by the

strap; you may inadvertently strike and injure another person with the

transceiver.

• If a commercially available neck strap is used, take care not to let the strap

get caught on nearby machine.

• When operating the transceiver in areas where the air is dry, it is easy to

build up an electric charge (static electricity). When using an earphone

accessory in such conditions, it is possible for the transceiver to send

an electric shock through the earphone and to your ear. We recommend

you use only a speaker/microphone in these conditions, to avoid electric

shocks.

• Do not expose the transceiver to long periods of direct sunlight, nor place

it near heating appliances.

INFORMATION CONCERNING THE BATTERY PACK

The battery pack includes ﬂammable objects such as organic solvent.

Mishandling may cause the battery to rupture producing ﬂames or

extreme heat, deteriorate, or cause other forms of damage to the

battery. Please observe the following prohibitive matters.

DANGER

• Do not disassemble or reconstruct battery.

• Do not short-circuit the battery.

• Do not incinerate or apply heat to the battery.

• Do not leave the battery near ﬁres, stoves, or other heat generators

(areas reaching over 80°C).

• Do not immerse the battery in water or get it wet by other means.

• Do not charge the battery near ﬁres or under direct sunlight.

• Use only the speciﬁed charger and observe charging requirements.

• Do not pierce the battery with any object, strike it with an instrument,

or step on it.

• Do not jar or throw the battery.

• Do not use the battery pack if it is damaged in any way.

• Do not solder directly onto the battery.

• Do not reverse the battery polarity (and terminals).

• Do not reverse-charge or reverse-connect the battery.

• Do not touch a ruptured and leaking battery.

If the electrolyte liquid from the battery gets into your eyes, wash your eyes

out with fresh water as soon as possible, without rubbing your eyes. Go to

the hospital immediately. If left untreated, it may cause eye-problems.

WARNING

• Do not charge the battery for longer than the speciﬁed time.

• Do not place the battery pack into a microwave or high pressure

container.

• Keep ruptured and leaking battery packs away from ﬁre.

• Do not use an abnormal battery.

• Do not change or charge the battery in hazardous locations.

UNPACKING AND CHECKING EQUIPMENT

Carefully unpack the transceiver. If any of the items listed below are

missing or damaged, ﬁle a claim with the carrier immediately.

SUPPLIED ACCESSORIES

• Battery charger (KSC-50CR)..................................................1

• AC adapter ............................................................................1

• Li-ion Battery pack (KNB-81L) ...............................................1

• Belt clip ..................................................................................1

• Screw (M3 x 6 mm) ................................................................2

• Battery cover .........................................................................1

• User guide .............................................................................1

Note:

◆Refer to “PREPARATION” for accessory installation instructions.

PREPARATION

INSTALLING THE BATTERY PACK

The battery pack is not charged enough at the factory. Be sure to fully

charge the battery pack when ﬁrst inserting it to the transceiver.

CAUTION

•

Be sure to remove the battery pack when it will not be used for a long time.

•

Do not short the battery terminals or dispose of the battery by ﬁre.

• Never attempt to remove the casing from the battery pack.

WWYYR

Battery cover

Battery pack

Label

1Insert the battery pack into the battery

cover.

• Pay attention to the position of notch of

the battery pack.

• Insert the battery pack with the model

name label facing up.

• Be careful not to drop the battery pack.

2Align the battery cover with the groove

on the back of the transceiver.

Lock lever

Slide the lock lever (both side) to lock it.

• There will be feedback in the form of a

click.

REMOVING THE BATTERY PACK

1Slide the lock lever (both side) to

unlock.

2Release the lock on the battery cover,

then remove the battery cover with a

coin or the like.

• Be careful not to drop the battery pack.
