Kenwood TK-2260EX Manuel utilisateur

TK-2260EX VHF FM Transceiver

TK-3260EX UHF FM Transceiver

ATEX certified Transceivers, the TK-2260EX (VHF) and the TK-3260EX

(UHF).

．．

SCHEDULE

Launch:

TK-2260EX (136-174MHz)

TK-3260EX (440-470MHz)

．．

MAIN FEATURES

ATEX Certified Radio

The TK-2260EX/3260EX are products designed for use in potentially explosive

atmospheres. They meet European Union Directive 94/9/EC, commonly called the

ATEX Directive. The products are designed to ensure the safe functioning of

equipment and protective systems with respect to the risks of explosion, as covered

by the scope of this Directive.

The certified classes are as follow, providing comprehensive protection for

professional radio users:

¾II2G Ex ib IIC T4 for Gas protection

Group “IIC” is suitable for use in most of types of gas atmospheres including

Hydrogen. “T4” temperature class covers most gases and vapours

¾II 2D Ex tD ibD A21 IP6X T110°C for Dust protection

¾IM2 Ex ib I for Mining protection

1.2W Output power

The TK-2260EX/3260EX strike a successful balance between a high protection class,

excellent performance and effective output power.

Ready for Various Emergency Scene (STAFF SAFE Functions)

These functions provide security and safety for users who work remotely as well as

for those who work in hazardous areas. If the operator is in an emergency situation,

the transceiver automatically sends a help signal to a pre-determined person or

system.

¾Standard Man-down

Standard Man-down function is available as a factory setting.

If the operator (and the radio) are horizontal (or slanted)* for a pre-set period,

an alert signal is transmitted.

Can be activated as the default option

* The angle value can be pre-set

¾Advanced Motion Detection (Software License Option*)

* Need activation file

Stationary mode

When the operator (and the radio) do not move for a pre-set period, an

alert signal is transmitted.

Motion mode (Panic)

When the operator (and the radio) moves a lot for certain period, an alert

signal is transmitted.

¾Lone Worker Function

This ingenious feature provides an extra layer of security and safety for

individuals. As long as the buttons are pressed regularly, the radio operates

normally; however, if there is a long lapse (programmable), it will sound an

alert.

In the absence of further response from the user, the TK-2260EX/3260EX

will place an emergency call to a pre-determined person or group of people..

Lone Worker function can be used in combination with other Emergency

functions.

¾Emergency Key (Orange Key)

A clearly identified Orange key can be used exclusively for emergency

signalling to send a help signal to a pre-determined person or group of

people.

16 Channels

The TK-2260EX/3260EX provides plenty of capacity for multiple channels or radio

systems.

Variety of Signalling

¾5-Tone Signalling

Built-in 5-tone encoder/decoder provides 6-different formats, ZVEI, ZVEI2,

CCIR, EIA, EEA and the Kenwood format. It is also possible to set not only

5-Tone but up to 8-Tone, 2-flames 5-Tone and the 3-flames 5-tone signalling.

¾QT/DQT/DTMF

The Encoder/Decoder function uses QT/DQT to segregate talk groups, so

users only hear calls from their own group.

DTMF PTT ID is included for dispatch operations or for a simple remote

control application. The DTMF decode capabilities include a selective call

ID, transpond with ID, “wild card” group calling and radio stun.

¾FleetSync®PTT ID, SelCall & Emergency

Utilizing Kenwood’s FleetSync®digital signalling protocol, the TK-

2260EX/3260EX have PTT ID (ANI: automatic number identification) and

Selective Calling capabilities for managed dispatch operations. For

hazardous/hostile duty environments, a PF key can also be programmed for

Emergency status to alert the dispatcher and/or operator to a user in

distress.

Enhanced Kenwood Audio

The TK-2260EX/3260EX provide loud clear audio even in noisy environments.

Kenwood has utilized its longstanding audio heritage to optimize voice frequency

components so that the audio output cuts through typical ambient noise. This

enhancement and the companded noise reduction provide clarity and low distortion

especially on narrow bandwidth systems.

Priority Scan

Scanning is a simple way to monitor multiple channels. There are both standard and

priority scan modes available to the TK-2260EX/3260EX. In addition, Talk Back

allows you to respond immediately to a call regardless of the pre-programmed or

selected scan revert channel.

Programmable Function Keys

3 x PF Keys (including Orange key) are programmable for any features allowing the

transceiver to be customized to fit users’ specific requirements.

Voting

In addition to the Priority Scan function, the TK-2260EX/3260EX supports Voting

function, which will look for and lock on to the best repeater signals automatically in

multi site system. This feature enables users to communicate without compromise.

Built-In Voice Inversion Scrambler

Built into the TK-2260EX/3260EX is a scrambler that offers convenient confidentiality.

The audio will be indecipherable to any third party picking up your signal, although

all group members will receive you loud and clear.

VOX Ready

The TK-2260EX/3260EX offer convenient hands-free operation with the KMC-46EX.

The TK-2260EX/3260EX internal VOX (voice-operated transmission) circuitry

provides automatic PTT and a 10-level sensitivity adjustment for different ambient

noise levels.

．．

OTHER FEATURES

Wide/ Semi Wide/Narrow per channel

Companded Audio per Channel

Talk Around

B.C.L. (Busy Channel Lockout)

Key Lock

3-colours LED (Red, Orange, Green)

Scan Del/Add function

KENWOOD ESN (Electronic Serial Number)

Adjustable Microphone Gain by FPU only: High or Normal

Microsoft Windows® PC Programming & Tuning

Windows® is a registered trademark of Microsoft Corporation in the United States and

other countries.

．．

QUALITY CONTROL

Made in Japan with ISO 9001 Quality Management

The TK-2260EX/3260EX are manufactured in Kenwood’s factory in Japan, which has

been certified to ISO9001 international quality management standard.

High-level quality system produces excellent quality product.

Kenwood Original Quality Test Standards for Products

Each transceiver has passed Kenwood’s original quality tests, which simulate years

of sustained, demanding use in harsh operating conditions. These tests have higher

thresholds than any other accepted industry standards in the market.

EU-Directives RoHS / WEEE compliance

Kenwood is committed to design and manufacturer of products that are

environmentally friendly. Kenwood factories have been assessed and registered as

ISO 14001 compliant, the international standard for Environment Protection

Management. The TK-2260EX/3260EX are designed and produced without using

hazardous substances. They will comply with the EU-directives of RoHS and WEEE.

MIL-STD 810 C/D/E/F

The TK-2260EX/3260EX are fully compliant with U.S. Department of Defence

environmental standards for US MIL-STD 810 C/D/E/F for;

Low Pressure, High Temperature, Low Temperature, Temperature Shock, Solar

Radiation, Rain (incl. Blowing Rain), Humidity, Salt Fog, Dust, Vibration, Shock

．．

Applicable Standards

Standard Detail ID

Low Voltage Directive EN 60065, EN 60950-1, EN

60215

R&TTE Directive

EN 300 086-2, EN 300 113-

2, EN 300 219-2, EN 301

489-5, EN 301 489-1

CE0168!

ATEX Directive

Gas: II 2G Ex ib IIC T4

Dust: II 2D Ex tD ibD A21 IP6X

T110°C

Mining: I M2 Ex ib I

EN 60079- 0, EN 60079-11,

EN 61241- 0, EN 61241- 1,

EN 61241-11

TÜV 09

ATEX

7759 X

IECEx Scheme

Gas: Ex ib IIC T4 Gb

Dust: Ex ib tb III C T110°C Db IP6X

Mining: Ex ib I Mb

IEC 60079- 0, IEC 60079-

11, IEC 61241- 0, IEC

61241- 1, IEC 61241-11

IECEx

TUR

09.0004X

International Protection Standard

Dust & Water Protection: IP 64

．．

OPTIONAL ACCESSORIES

KBH-16EX Belt-Clip

KNB-58LEX Li-Ion Battery (1,880 mAh)

KRA-22 VHF short Antenna

KRA-23 UHF short Antenna

KRA-26 VHF Antenna

KRA-27 UHF Antenna

KSC-32 Rapid Charger for the KNB-58LEX

KSC-326 6 Pocket Multiple Charger for the KNB-58LEX

KMC-46EX Heavy-duty Speaker-Microphone (Future available)

KLH-168EX Leather Case

KSL-3SF Enhanced Staff Safe Software License

Programming Accessories for Dealers;

KPG-36A Programming Interface cable

KPG-123D Programming Software

．．

SUPPLIED ACCESSORIES

Li-Ion Battery (KNB-58LEX)

Users Manual

Safety Manual

Belt-Clip (KBH-16EX)

．．

SPECIFICATIONS : TK-2260EX/TK-3260EX

Specifications shown are typical.

General TK-2260EX TK-3260EX

Frequency Range

136-174 MHz 440-470 MHz

Number of Channel Max. 16ch

Channel Spacing

25 / 20 / 12.5 kHz

Antenna Impedance 50 ohm

Operating Voltage 7.5V DC±20%

Battery Life (5-5-90) Bat. Save ON 23 hours

with KNB-58LEX Bat. Save OFF 18 hours

Operating Temperature Range -20°C to +50°C

Frequency Stability ± 2.5 ppm (-20°C to +50°C )

Dimensions (W x H x D)

with KNB-58LEX 61.8 x 128.3 x 49.5 mm

Weight Main body: 279g

(with KNB-58LEX : 484 g)

Applicable Standards IP64

Receiver

EIA 12dB SINAD

25 / 20 / 12.5 kHz

-6 dB μV (0.25 μV) / -6 dB μV (0.25 μV)

/ -4 dB μV (0.32 μV)

Sensitivity EN 20 dB SINAD:

25 / 20 / 12.5 kHz

-4 dB μV (0.32 μV) / -4 dB μV (0.32 μV)

/ -3 dB μV (0.36 μV)

Adjacent Channel Selectivity

25 / 20 / 12.5 kHz 70 dB / 70 dB / 62 dB

Intermodulation 65dB

Spurious Response Rejection 70 dB

Audio Output (16 ohm impedance) 400 mW

Transmitter

RF Power output 1.2W

Modulation Limiting

±5.0 kHz at 25 kHz

±4.0 kHz at 20 kHz

±2.5 kHz at 12.5 kHz

Spurious Emission -36 dBm≦1 GHz , -30 dBm>1 GHz

FM Noise (EIA)

25 / 20 / 12.5 kHz 45 dB / 43 dB / 43 dB

Audio Distortion 3% typical

Kenwood follows a policy of continuous advancement in development.

For this reasons, specifications may be changed without notice.
