UHF DIGITAL TRANSCEIVER

USER MANUAL

TK-3401D

B5A-0037-30 (E, T)

THANK YOU

We are grateful you have chosen KENWOOD for your

dPMR446 applications.

OPERATING CONDITIONS

Open locations (no obstructions) : Up to 9.0 km

Note:

◆The above range is based on ﬁeld testing and may vary with your

operating conditions and individual transceiver.

◆

Digital technology provides superior clarity in extended coverage.

As RF signal strength weakens with distance, analog reception

becomes increasingly noisy and intermittent. dPMR's low BER

improves reception in fringe areas, thereby “effectively” increasing

coverage as much as twenty percent over analog.

NOTICES TO THE USER

Refer service to qualiﬁed technicians only.

Safety: It is important that the operator is aware of, and

understands, hazards common to the operation of any

transceiver.

Firmware Copyrights

The title to and ownership of copyrights for ﬁrmware embedded in

KENWOOD product memories are reserved for JVC KENWOOD

Corporation.

Turn the transceiver power off in the following locations:

• In explosive atmospheres (inﬂammable gas, dust particles, metallic

powders, grain powders, etc.).

• While taking on fuel or while parked at gasoline service stations.

• Near explosives or blasting sites.

• In aircraft. (Any use of the transceiver must follow the instructions

and regulations provided by the airline crew.)

• Where restrictions or warnings are posted regarding the use of

radio devices, including but not limited to medical facilities.

• Near persons using pacemakers.

PRECAUTIONS

• Do not charge the transceiver and battery pack when they are

wet.

• Ensure that there are no metallic items located between the

transceiver and the battery pack.

• Do not use options not speciﬁed by KENWOOD.

• If the die-cast chassis or other transceiver part is damaged, do

not touch the damaged parts.

• If a headset or headphone is connected to the transceiver,

reduce the transceiver volume. Pay attention to the volume level

when turning the squelch off.

• Do not place the microphone cable around your neck while near

machinery that may catch the cable.

• Do not place the transceiver on unstable surfaces.

• Ensure that the end of the antenna does not touch your eyes.

• When the transceiver is used for transmission for many hours,

the radiator and chassis will become hot. Do not touch these

locations when replacing the battery pack.

• Do not immerse the transceiver in water.

• Always switch the transceiver power off before installing optional

accessories.

• The charger is the device that disconnects the unit from the AC

mains line. The AC plug should be readily accessible.

iii

• Do not disassemble or modify the transceiver for any reason.

• Do not place the transceiver on or near airbag equipment while the

vehicle is running. When the airbag inﬂates, the transceiver may be

ejected and strike the driver or passengers.

• Do not transmit while touching the antenna terminal or if any

metallic parts are exposed from the antenna covering. Transmitting

at such a time may result in a high-frequency burn.

• If an abnormal odor or smoke is detected coming from the

transceiver, switch the transceiver power off immediately,

remove the battery pack from the transceiver, and contact your

KENWOOD dealer.

•

Use of the transceiver while you are driving may be against trafﬁc

laws. Please check and observe the vehicle regulations in your area.

• Do not expose the transceiver to extremely hot or cold conditions.

• Do not carry the battery pack (or battery case) with metal objects,

as they may short the battery terminals.

• Danger of explosion if the battery is incorrectly replaced; replace

only with the same type.

• When attaching a commercial strap to the transceiver, ensure

that the strap is durable. In addition, do not swing the transceiver

around by the strap; you may inadvertently strike and injure

another person with the transceiver.

• If a commercially available neck strap is used, take care not to let

the strap get caught on nearby machine.

• When operating the transceiver in areas where the air is dry, it is

easy to build up an electric charge (static electricity). When using

an earphone accessory in such conditions, it is possible for the

transceiver to send an electric shock through the earphone and to

your ear. We recommend you use only a speaker/microphone in

these conditions, to avoid electric shocks.

Information concerning the battery pack:

The battery pack includes ﬂammable objects such as organic

solvent. Mishandling may cause the battery to rupture

producing ﬂames or extreme heat, deteriorate, or cause other

forms of damage to the battery. Please observe the following

prohibitive matters.

• Do not disassemble or reconstruct battery!

The battery pack has a safety function and protection circuit to

avoid danger. If they suffer serious damage, the battery may

generate heat or smoke, rupture, or burst into ﬂame.

• Do not short-circuit the battery!

Do not join the + and – terminals using any form of metal (such

as a paper clip or wire). Do not carry or store the battery pack in

containers holding metal objects (such as wires, chain-necklaces or

hairpins). If the battery pack is short-circuited, excessive current will

ﬂow and the battery may generate heat or smoke, rupture, or burst

into ﬂame. It will also cause metal objects to heat up.

• Do not incinerate or apply heat to the battery!

If the insulator is melted, the gas release vent or safety function is

damaged, or the electrolyte is ignited, the battery may generate

heat or smoke, rupture, or burst into ﬂame.

• Do not leave the battery near ﬁre, stoves, or other heat

generators (areas reaching over 80°C/ 176°F)!

If the polymer separator is melted due to high temperature, an

internal short-circuit may occur in the individual cells and the

battery may generate heat or smoke, rupture, or burst into ﬂame.

• Avoid immerse the battery in water or get it wet by other

means!

If the battery’s protection circuit is damaged, the battery may

charge at extreme current (or voltage) and an abnormal chemical

reaction may occur. The battery may generate heat or smoke,

rupture, or burst into ﬂame.

• Do not charge the battery near ﬁre or under direct sunlight!

If the battery’s protection circuit is damaged, the battery may

charge at extreme current (or voltage) and an abnormal chemical

reaction may occur. The battery may generate heat or smoke,

rupture, or burst into ﬂame.

• Use only the speciﬁed charger and observe charging

requirements!

If the battery is charged in unspeciﬁed conditions (under high

temperature over the regulated value, excessive high voltage or

current over regulated value, or with a remodeled charger), it may

overcharge or an abnormal chemical reaction may occur. The

battery may generate heat or smoke, rupture, or burst into ﬂame.

• Do not pierce the battery with any object, strike it with an

instrument, or step on it!

This may break or deform the battery, causing a short-circuit. The

battery may generate heat or smoke, rupture, or burst into ﬂame.

• Do not jar or throw the battery!

An impact may cause the battery to leak, generate heat or smoke,

rupture, and/or burst into ﬂame. If the battery’s protection circuit

is damaged, the battery may charge at an abnormal current (or

voltage), and an abnormal chemical reaction may occur. The

battery may generate heat or smoke, rupture, or burst into ﬂame.

• Do not use the battery pack if it is damaged in any way!

The battery may generate heat or smoke, rupture, or burst into

ﬂame.

• Do not solder directly onto the battery!

If the insulator is melted or the gas release vent or safety function

is damaged, the battery may generate heat or smoke, rupture, or

burst into ﬂame.

• Do not reverse the battery polarity (and terminals)!

When charging a reversed battery, an abnormal chemical reaction

may occur. In some cases, an unexpected large amount of current

may ﬂow upon discharging. The battery may generate heat or

smoke, rupture, or burst into ﬂame.

• Do not reverse-charge or reverse-connect the battery!

The battery pack has positive and negative poles. If the battery

pack does not smoothly connect with a charger or operating

equipment, do not force it; check the polarity of the battery. If the

battery pack is reverse-connected to the charger, it will be reverse-

charged and an abnormal chemical reaction may occur. The

battery may generate heat or smoke, rupture, or burst into ﬂame.

• Do not touch a ruptured and leaking battery!

If the electrolyte liquid from the battery gets into your eyes, wash

your eyes with fresh water as soon as possible, without rubbing

your eyes. Go to the hospital immediately. If left untreated, it may

cause eye-problems.

• Do not charge the battery for longer than the speciﬁed time!

If the battery pack has not ﬁnished charging even after the

regulated time has passed, stop it. The battery may generate heat

or smoke, rupture, or burst into ﬂame.

• Do not place the battery pack into a microwave or high

pressure container!

The battery may generate heat or smoke, rupture, or burst into

ﬂame.

• Keep ruptured and leaking battery packs away from ﬁre!

If the battery pack is leaking (or the battery emits a bad odor),

immediately remove it from ﬂammable areas. Electrolyte leaking

from battery can easily catch on ﬁre and may cause the battery to

generate smoke or burst into ﬂame.

• Do not use an abnormal battery!

If the battery pack emits a bad odor, appears to have different

coloring, is deformed, or seems abnormal for any other reason,

remove it from the charger or operating equipment and do not use

it. The battery may generate heat or smoke, rupture, or burst into

ﬂame.

CONTENTS

UNPACKING AND CHECKING EQUIPMENT ......................................1

PREPARATION .....................................................................................2

ORIENTATION.......................................................................................8

BASIC OPERATIONS .........................................................................10

CHANNEL SETUP MODE...................................................................11

KEY ASSIGNMENT MODE.................................................................20

BACKGROUND OPERATIONS ..........................................................24

VOICE OPERATED TRANSMISSION (VOX) ......................................25

ALL RESET MODE .............................................................................26

TROUBLESHOOTING GUIDE ............................................................27

UNPACKING AND CHECKING EQUIPMENT

Carefully unpack the transceiver. If any of the items listed

below are missing or damaged, ﬁle a claim with the carrier

immediately.

SUPPLIED ACCESSORIES

• Battery charger/ AC adapter (KSC-35S) ................................1

• Li-ion Battery pack (KNB-45L)................................................ 1

• Cap.........................................................................................1

• Locking bracket.......................................................................1

• Belt clip (KBH-10)...................................................................1

• Screw (M3 x 8 mm) ................................................................2

• User guide ..............................................................................1

Note:

◆Refer to “PREPARATION” {page 2} for accessory installation

instructions.

PREPARATION

INSTALLING/ REMOVING THE BATTERY PACK

◆

Do not short the battery terminals or dispose of the battery by ﬁre.

◆Never attempt to remove the casing from the battery pack.

◆Install the battery pack after cleaning the battery pack contacts

and the transceiver terminals.

1Align the battery pack with the back

of the transceiver, then press the

battery pack and transceiver ﬁrmly

together until the release latch on

the base of the transceiver locks.

2To remove the battery pack, lift the

safety catch on the base of the

transceiver, then press the release

latch underneath the safety catch.

3While pressing the release latch,

pull the battery pack away from the

transceiver.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Kenwood Émetteur-récepteur

Kenwood

Kenwood ProTalk tk-3501 Manuel utilisateur

Kenwood

Kenwood TH-21A Manuel utilisateur

Kenwood

Kenwood TM-221A Manuel utilisateur

Kenwood

Kenwood TK 3230 - FreeTalk XLS UHF Instructions d'installation et d'utilisation

Kenwood

Kenwood TM-241A Manuel utilisateur

Kenwood

Kenwood TK-7100-1 Manuel utilisateur

Kenwood

Kenwood ProTalk TK-3301 Manuel utilisateur

Kenwood

Kenwood TS-870S Manuel utilisateur

Kenwood

Kenwood NX-3720HG Manuel utilisateur

Kenwood

Kenwood TK-390 Manuel utilisateur

Kenwood

Kenwood TK-480 Manuel utilisateur

Kenwood

Kenwood TM-V7A Manuel utilisateur

Kenwood

Kenwood TK-7360H Manuel utilisateur

Kenwood

Kenwood TK-270G Manuel utilisateur

Kenwood

Kenwood TS-130S Manuel utilisateur

Kenwood

Kenwood NEXEDGE NX-200 Manuel utilisateur

Kenwood

Kenwood TH-D7A Manuel utilisateur

Kenwood

Kenwood TK-D240 Manuel utilisateur

Kenwood

Kenwood TK-3000 K Manuel utilisateur

Kenwood

Kenwood TK-3148 Manuel utilisateur

Kenwood

Kenwood TK-2312 Manuel utilisateur

Kenwood

Kenwood TK-980 Manuel utilisateur

Kenwood

Kenwood TS-570D, TS-570S Manuel utilisateur

Kenwood

Kenwood TS-570D, TS-570S Manuel utilisateur

Manuels Émetteur-récepteur populaires d'autres marques

Yaesu

Yaesu FT-7B Manuel utilisateur

Texas Instruments

Texas Instruments TLK10232 Manuel utilisateur

Mizuho

Mizuho MX-2 Guide produit

Blitz

Blitz MJ-398U Manuel utilisateur

Utilicom

Utilicom LongRanger 2050 Manuel utilisateur

Standart

Standart HX290UKA Manuel utilisateur

Altronix

Altronix Pace1PTM Manuel utilisateur

Kirisun

Kirisun PT2208 Manuel utilisateur

ELECRAFT

ELECRAFT KX2 Manuel utilisateur

Zodiac

Zodiac K3 Manuel utilisateur

Assa Abloy

Assa Abloy SecureComm HKC GSM-WIFI U Manuel utilisateur

Siemens

Siemens PSO 4000 Manuel utilisateur

Midland

Midland G8E-BT Manuel

ComNav

ComNav Mariner X2 Manuel utilisateur

Uniden

Uniden UH820 Series Manuel utilisateur

Standard Horizon

Standard Horizon HX320E Manuel utilisateur

Em-Trak

Em-Trak A100 Manuel utilisateur

HPE

HPE Aruba QSFP28 Manuel utilisateur
