7
FORM NO. 56042374
SelectGloss™20B
99-7 CONTROL HANDLE
Item Ref. No. Qty Description
56393501 1 Handle Assembly
156448677 1 Battery Meter
256389434 1 Green Indicator Light (before February 1998)
56392858 1 Green Indicator Light (after January 1998)
356389433 1 Red Indicator Light (before February 1998)
56393863 1 Red Indicator Light (after January 1998)
456389527 1 Amp Meter
556015676 1 Decal, Control Handle
656393568 1 Connector with Wires
756393653 1 Handle
856009019 2 Scr, Hex Thd Form 1/4-20 x .38
956015422 1 Decal, Switch
10 56025264 1 Decal, Cable Routing
11 56002058 1 Scr, Hex Hd 3/8-16 x 2.25
12 56002606 1 Scr, Hex Hd 5/16-18 x 3.25
13 56002834 3 Scr, Hex Hd #10-24 x .38
14 56301636 1 Main Switch
15 56001861 2 Scr, Hex Cap 1/4-20 x .38
16 56009033 4 Scr, Hex Thd Form 1/4-20 x .50
17 56234079 1 Screw
*56001905 2 Wsh, Int Shprf 5/16
18 56002809 4 Scr, Hex Loc #6-32 x .88
19 56393530 1 Lever
20 56375334 1 Bushing
21 56388019 1 Pad Up Switch
22 56376015 2 Nut Plate
23 56388184 1 Pedal
24 56003262 2 Retaining Ring
25 56009034 2 Scr, Hex #8-32 x .88
26 56200115 1 Wsh, Flt
27 56001954 2 Wsh, Flt SAE #10
28 56009087 4 Nut, Hex Jam 1/4-20
29 56386314 1 Leveler
31 56009142 2 Nut, Hex 1/4-20
32 56365002 1 Pad
33 56002192 2 Scr, Pan Phil #10-24 x .75
34 56393654 1 Tube
35 56388545 2 Grip
36 56002021 1 Scr, Soc Set Loc 5/16-18 x .38
37 56367354 1 Collar
38 56372129 2 Spring
39 56393522 1 Rod
Item Ref. No. Qty Description
40 56393723 1 Panel
41 56016068 1 Decal, Wiring
42 56015119 1 Decal, Caution
43 56393725 1 Handle
44 56344621 1 Grommet
45 56469858 1 Insulated Stand-Off
46 56009020 1 Stud, 1/4-20 x .88
47 56009064 1 Wsh, Int Shprf 1/4
48 56001894 1 Nut, Hex Serrated 3/8-16
49 56328790 1 Spring
51 56002832 4 Nut, Hex Nyl Loc-Thin 10-24
50 56395450 1 Contactor
52 56393696 1 Bearing Block Assembly
53 56200123 2 Bushing
54 56009039 2 #10-24 x 1/2 Hex Screw
55 56393520 1 Pivot
56 56002826 1 Nut, Hex Nyl Loc-Thin 5/16-18
57 56393534 1 Support
58 56002769 1 Nut, Hex Nyl Loc 3/8-16
59 56002063 2 Wsh, Flt SAE 3/8
60 56171177 1 Spring
61 56440760 2 Washer
62 56367184 2 Thrust Bearing
63 56471193 1 Grip
64 56393528 1 Lever
65 56386793 1 Shunt
66 56393569 1 Mercury Switch
67 56385615 1 Switch
68 56015122 1 Decal, Circuit Breaker
69 56387316 1 Circuit Breaker
70 56393722 1 Circuit Breaker
71 56002231 1 Scr, Pan Phil #10-24 x 1.50
72 56393325 1 Bracket, Keylock
73 56001833 1 Scr, Hex Hd 1/4-20 x 1.50
74 56002098 3 Wsh, Flt SAE 1/4
75 56207489 1 Bushing
76 56244859 1 Bushing
77 56002840 1 Nut, Hex Nyl Loc-Thin 1/4-20
78 56002271 1 Scr, Hex Hd 3/8-16 x .88
* = Not Shown
01-12
