Kent Euroclean 20 Manuel utilisateur
RazorTM 20 / 20T
PARTS LIST
Kent models: 9087200020
9087201020
9097064000(2)2007-09
2007-06
RAZORTM 20 - 20T 1
9097064000(2)2007-09
DESCRIPTION
PLAN
GENERAL VIEW 2 - 3
SOLUTION TANK 4 - 5
RECOVERY TANK 6 - 7
CHASSIS SYSTEM 8 - 9
WHEEL SYSTEMS 10 - 11
HANDLE ASSEMBLY 12 - 13
SOLUTION SYSTEM 14 - 15
SQUEEGEE SYSTEM 16 - 17
BRUSH SYSTEM RAZOR TM 20 18 - 19
BRUSH SYSTEM RAZOR TM 20T 20 - 21
ACCESSORIES 22 - 23
CONTROL PANEL SYSTEM RAZOR TM 20 24 - 25
CONTROL PANEL SYSTEM RAZOR TM 20T 26 - 27
ELECTRICAL COMPONENTS RAZOR TM 20 28 - 29
ELECTRICAL COMPONENTS RAZOR TM 20T 30 - 31
WIRING DIAGRAMS 32 - 33
RECOMMENDED SPARE PARTS 34 - 35
WHEN ORDERING PARTS
* Use the 8, 9 or 10 digit numbers from the “Ref. No.” columns in this parts list.
* Specify the model and serial number of the machine.
* Use the space below to record the model and serial number for future reference.
Model ___________________ Serial No. ___________________
* = Optional
# = Modied item No. or New item No.
[] = Not shown
xxxxxx= Contained in a Kit
TABLE OF CONTENTS
2007-06
2RAZORTM 20 - 20T
9097064000(2)2007-09
GENERAL VIEW GENERAL VIEW
1
2
3
4
5
6
7
8
9
10
13
1112
2007-06
RAZORTM 20 - 20T 3
9097064000(2)2007-09
GENERAL VIEW GENERAL VIEW
1 1 SOLUTION TANK
2 1 RECOVERY TANK
3 1 CHASSIS SYSTEM
4 1 WHEELS TRACTION SYSTEM
5 1 WHEELS SYSTEM
6 1 HANDLE SYSTEM
7 1 SOLUTION SYSTEM
8 1 SQUEEGEE SYSTEM
9 1 BRUSH SYSTEM RAZOR TM 20
10 1 BRUSH SYSTEM RAZOR TM 20T
11 1 ELECTRICAL COMPONENTS
12 1 BATTERY CHARGER ASSEMBLY
13 1 CONTROL PANEL SYSTEM
Item
No.
Ref. No. Qty Description
2007-06
4RAZORTM 20 - 20T
9097064000(2)2007-09
SOLUTION TANK SOLUTION TANK
6
10
30
13
2
7
15
25
12
22
26
19
5
23
36
40
4
28 35 18 16 14 15 1 42 45 44 33
9
27
41
24
8
29
17
39
31
32
34
21
37
38
3
3
46
49
50
48
43
20
11
DECAL CHECKED BY
NAME PLATE
14
47
2007-06
RAZORTM 20 - 20T 5
9097064000(2)2007-09
SOLUTION TANK SOLUTION TANK
1 909 6493 000 1 SUPPORT, PEDAL
2 909 6621 000 1 KNOB
3 9097019000 1 HANDLE BAR
4 9097020000 1 TANK SOLUTION 35 LT
5 9097105000 2 DECAL KENT
6 909 6596 000 1 GASKET
7 909 6597 000 1 GASKET
8# L08603916 1 CLAMP 12/ 16-27
9 xxxxxxxxxx 1 WASHER 10X30X2,5 UNI6593 (SEE SOLUTION TANK HARDWARE KIT)
10 909 6892 000 1 GASKET MM 960
11# L08812457 2 CAP, TANK LOCKING
12 56264442 1 FITTING PIPE
13 909 6633 000 1 LEVER, SQUEEGEE LIFTING
14 xxxxxxxxxx 3 WASHER M6 UNI1751B (SEE SOLUTION TANK HARDWARE KIT)
15 xxxxxxxxxx 3 WASHER 6X18 UNI6592 (SEE SOLUTION TANK HARDWARE KIT)
16 xxxxxxxxxx 2 SCREW M6X16 UNI5739 (SEE SOLUTION TANK HARDWARE KIT)
17 xxxxxxxxxx 1 CABLE, STOP-LID (SEE CABLE TANK KIT)
18 909 6649 000 1 BRACKET CONNECTOR SUPPORT
19 909 6662 000 1 CABLE, SQUEEGEE LIFTING
20 909 6236 000 1 CAP BLACK
21 909 6673 000 1 CAP BLACK BP6
22 145 8479 000 1 DOWEL M6
23 909 6680 000 1 BUSH FLANGED
24 909 6521 000 1 HOSE CLEAN WATER
25 xxxxxxxxxx 1 SCREW M5X16 UNI7687 (SEE SOLUTION TANK HARDWARE KIT)
26 33005502 1 NUT HEX M6 UNI5588
27 xxxxxxxxxx 3 WASHER M10 UNI1751B (SEE SOLUTION TANK HARDWARE KIT)
28 xxxxxxxxxx 2 NUT SELF L. M5 UNI7474 (SEE SOLUTION TANK HARDWARE KIT)
29# L08603805 1 DECAL WARNING
30 9097211000 1 SCREW M10X30 ISO7380
31 33004345 8 SCREW M6X16 UNI5931
32 33009531 2 HINGE
33 145 0524 000 4 CLAMP
34 145 0541 000 1 CLAMP
35 33003964 2 SCREW M5X25 UNI5739
36 xxxxxxxxxx 1 WASHER M8 UNI1751B (SEE SOLUTION TANK HARDWARE KIT)
37 xxxxxxxxxx 1 SCREW M10X90 UNI5931 (SEE SOLUTION TANK HARDWARE KIT)
38 xxxxxxxxxx 1 WASHER M10 UNI6592 (SEE SOLUTION TANK HARDWARE KIT)
39 xxxxxxxxxx 1 SCREW M5X12 UNI7688 (SEE CABLE TANK KIT)
40 xxxxxxxxxx 1 SCREW M8X60 UNI5931 (SEE SOLUTION TANK HARDWARE KIT)
41 xxxxxxxxxx 2 SCREW HEX HD M10X20 SS (SEE SOLUTION TANK HARDWARE KIT)
42 xxxxxxxxxx 1 NUT SELF L. M10 UNI7473 (SEE SOLUTION TANK HARDWARE KIT)
43 9097108000 1 DECAL KENT
44 909 6337 000 6 SCREW M5X12 UNI7687
45 909 6595 000 6 HOLDER,FLAT TIE
46 33005445 4 SCREW HEX THD TO HD M8X25
47 909 6874 000 1 CABLE TANK KIT (17,39)
48# L08300000 6 WASHER FLAT XL
49 145 8412 000 2 SCREW GRUB M8X30 UNI5929
50 146 1567 000 2 NUT HEX M8
[51] 909 6875 000 1 SOLUTION TANK HARDWARE KIT (9,14,15,16,25,27,28,36,37,38,40,41,42)
Item
No.
Ref. No. Qty Description
2007-09
2007-06
6RAZORTM 20 - 20T
9097064000(2)2007-09
RECOVERY TANK RECOVERY TANK
22
21
27
23
26
30
29
25
31
24
28
32
33
34
8
17
15
10
4
5
1
12
7
16
3
2
18
6
14
11
9
21
13
19
20
2007-06
RAZORTM 20 - 20T 7
9097064000(2)2007-09
RECOVERY TANK RECOVERY TANK
1 9097016000 1 TANK RECOVERY 35 LT
2 909 6528 000 1 HOSE DRAIN
3 909 6230 000 1 HOSE SQUEEGEE VACUUM
4 909 6643 000 2 PLATE TANK COVER
5 909 6679 000 1 BUSH FLANGED
6# L08239900 1 CLAMP GREY
7 xxxxxxxxxx 6 WASHER 6X18X1,5 UNI6593 (SEE HARDWARE TANK SYSTEM KIT)
8# L08812259 2 CAGE,FLOAT CPL
9# L08812373 1 BALL FLOATING
10# L08603668 2 SCREW CYL HD SELFL 4X14
11# L08812968 1 GASKET
12 145 0543 000 2 CLAMP
13 xxxxxxxxxx 2 NUT HEX M6 UNI5721 (SEE HARDWARE TANK SYSTEM KIT)
14 33005124 1 SCREW M5X12 UNI7688
15 xxxxxxxxxx 2 NUT HEX M6 SS (SEE HARDWARE TANK SYSTEM KIT)
16 xxxxxxxxxx 2 SCREW M6X40 UNI5739 (SEE HARDWARE TANK SYSTEM KIT)
17 909 6199 000 1 CAGE FLOAT
18 909 6337 000 1 SCREW M5X12 UNI7687
19 909 6268 000 1 GASKET L=1370
20 9097017000 1 COVER TANK 35 LT BLUE
21 909 6876 000 1 HARDWARE TANK SYSTEM KIT (7,13,15,16)
22 9096918000 1 GASKET, VACUUM MOTOR
23 909 6490 000 1 GASKET, VACUUM MOTOR
24 909 6491 000 1 PANEL,ACOUSTIC INSULATION
25 xxxxxxxxxx 3 PLATE VACUUM COVER (SEE HARDWARE MOTOR FIXING KIT)
26 909 6672 000 1 FILTER
27 909 6802 000 1 MOTOR VACUUM W/CONNEC.KIT
28 xxxxxxxxxx 3 SCREW M6X30 UNI5739 (SEE HARDWARE MOTOR FIXING KIT)
29 xxxxxxxxxx 3 WASHER 6X18 UNI6592 (SEE HARDWARE MOTOR FIXING KIT)
30 909 6051 000 1 COVER,VACUUM MOTOR
31 909 6442 000 1 PIPE,ACOUSTIC INSULATION
32 909 5371 000 2 CARBON BRUSH
33 909 6877 000 1 HARDWARE MOTOR FIXING KIT (25,28,29)
34 9097169000 1 GASKET VACUUM MOTOR
[35] 909 6840 000 1 HARNESS VACUUM MOTOR
Item
No.
Ref. No. Qty Description
2007-09
2007-06
8RAZORTM 20 - 20T
9097064000(2)2007-09
CHASSIS SYSTEM CHASSIS SYSTEM
7 6 17
8
3
13
24
24
18
15
21 12 14 11 19 16
25
22 23
5 9 2 20 1
4 10
