Owners’s

Manual

High Performance

Deep Searching

Metal Detector

112

GLOSSARY OF TERMS

Air Test - A sensitivity test performed by

outwardly moving various sized metal

samples under the metal detector search-

coil to measure the distance limit of detec-

tion. This test is not always an accurate

indicator of ground depth penetration ca-

pability. (See Bench Test)

Alkaline - A class of battery characterized

by the ability to sustain longer periods

of current drain and greater storage life

when compared to the standard carbon-

zinc type.

Bench Test - An air test to determine at

what discriminate settings various metal

samples are rejected or accepted. The test

is conducted in a non-metallic area.

Cache - Any intentionally buried or se-

creted hoard of valuables.

Conductivity - The measure of a metal

target's ability to allow eddy current gen-

eration on its surface.

Control Housing - A metal or plastic box

which holds circuit boards, indicators, me-

ter, controls and power supply.

Depth Penetration - The greatest mea-

sure of metal detector ability to transmit an

electromagnetic ﬁeld into the soil matrix

and produce a target signal.

Discrimination - Adjustable circuitry

which ignores or nulls audio responses

from a speciﬁc conductivity range allow-

ing positive responses to be heard from

metals higher in conductivity above the

discriminate control setting. Designed

primarily to eliminate audio response from

trash metals.

Double Blip - A signal characteristic com-

mon to elongated ferrous targets such as

nails detected in the all-metal non-motion

mode.

Faint Signal - A sound characteristic of

targets that are sometimes deeply buried

or very small in size.

False Signal - An erroneous signal cre-

ated by automatic retuning overshoot,

ground voids or highly mineralized hot

rocks.

Ferrous - Descriptive of any iron or iron

bearing material.

Metal - Metallic substances; iron, foil,

nickel, aluminum, gold, brass, lead, cop-

per, silver, etc.

Metal Detectorist - A person operating

a metal detector in the ﬁeld. This name is

preferred by many over Treasure Hunter.

Mineralized Ground - any soil that

contains conductive or non-conductive

components.

Motion Discriminator - A detector type

that requires searchcoil motion to activate

its simultaneous ground balance and dis-

criminate functions.

Non-Ferrous - Not of iron. Metals of the

precious class (i.e. gold, silver, copper,

etc.)

Pinpointing - Finding the exact target

location with respect to a searchcoil's des-

ignated center. Accomplished by interpret-

ing the centers of audio response width in

perpendicular direction or scans.

Searchcoil - A circular (can be other

shapes) plastic housing containing single

or multiple transmit and receive windings

in a speciﬁc orientation or conﬁguration to

emit and receive signals from ground and

targets. (Also called loop or coil).

Searchcoil Cable - An electrostatically

shielded cable of conductors (wires) which

convey signals to/from the searchcoil or

control housing.

Sensitivity - The measure or capacity of

a metal detector to perceive changes in

conductivity within the detection pattern.

Generally, the more sensitivity a detector

can smoothly provide, the more depth it

will achieve.

Signal - An audio response or visual in-

dication alerting the operator that a target

has been detected.

Slow Motion - A description of searchcoil

speed required to operate the motion dis-

criminate mode.

Sweep - the motion one employs in mov-

ing the coil.

DISCRIMINATE VOLUME

ON / OFF

SENSITIVITY

PINPOINT

PRO

High Performance – Deep Searching

456

PRE SET PRE SET

456

PRE SET

Exclusive Features of the MP5 Pro:

• State-of-the-art high reliable circuitry.

• Full automatic tuning.

• Full automatic ground balancing.

• Full range VLF discrimination.

• Target response light for pin-pointing

• Volume control.

• Detection depth control.

• Low battery LED warning.

• 12.5 kHz. VLF operation.

• APC Pin Pointing.

The MP5 Pro is a high powered metal detector that is easy to use.

With a fully automatic circuitry that handles the ground balancing

and tuning for you.

ASSEMBLY —

1. Unpack your metal detector carefully. Slip the lower stem into the

middle stem. Adjust the stem length and coil angle. The stem length is

adjusted by loosening the lower lock nut and allowing the spring clip to

snap into one of the holes in the center stem. The coil angle is adjusted

by loosening the nylon wing nut on top of the search coil. With the stem

length properly adjusted, wrap the coil cable snugly around the lower

stem and the center section. Leave just enough slack near the coil to

allow it to be tilted completely backward and forward.

2. Install (2) 9-Volt batteries and then the detector will be ready for

use.

DISCRIMINATE VOLUME

ON / OFF

SENSITIVITY

PINPOINT

PRO

High Performance – Deep Searching

456

PRE SET PRE SET

456

PRE SET

310

MIND YOUR MANNERS

Filling holes and obeying NO TRESPASSING Signs are but 2 require-

ments of a dedicated metal detector hobbyist. A sincere request that

Kellyco makes to every user of a detector is that each place searched be

left in a better condition that it was found. Thousands of individuals and

organizations have adopted this formal.

Metal Detector Operators Code of Ethics:

• I will respect private and public property, all historical and archaeological

sites and will do no metal detecting on these lands without proper permis-

sion.

• I will keep informed on and obey all laws, regulations and rules governing

federal, state and local public lands.

• I will aid law enforcement officials whenever possible.

• I will cause no willful damage to property of any kind, including fences,

signs and buildings and will always fill holes I dig.

• I will not destroy property, buildings or the remains of ghost towns or other

deserted structures.

• I will not leave litter or uncovered items lying around. I will carry all trash

and dug targets with me when I leave each search area.

• I will observe the golden rule, using good outdoor manners and conduct-

ing myself at all times in a manner which will add to the stature and public

image of all people engages in the field of metal detection.

Warning!

Any metal detector may detect underground power lines, explosives or

other items which when struck could cause personal injury. When search-

ing for treasure with your detector, observe these precautions:

Do not hunt in an area where you believe there may be shallowly buried

underground electric lines or pipes.

Do not hunt in a military zone where bombs or other explosives may be

buried.

Avoid striking any line known to be or suspected to be carrying electrical

power.

Do not disturb any pipeline, particularly if it could be carrying flammable

gas or liquid.

Use reasonable caution in digging toward any target, particularly in areas

where you are uncertain of underground conditions.

CONTROL PANEL —

PINPOINT

BUTTON

POWER

ON/OFF

PIN POINT/

BATTERY

TEST LIGHT

NOTE: A Loose cable near the search coil may cause false signals, but

don't wrap it so tightly that it pulls against the housing or the coil.

VOLUME

CONTROL

• FACTORY

RECOMMEND

STARTING

POINT

(Pre-Set

Position)

• FACTORY RECOMMEND

STARTING POINT

(Pre-Set Position)

UPPER

LOCK NUT

LOWER

LOCK NUT

LOWER

STEM

NYLON

NUT & BOLT

COIL

CABLE

CONTROL UNIT

& PANEL

ARM REST

UPPER

STEM

MIDDLE

STEM

IN THE FIELD TIP FOR USING YOUR MP5 PRO DETECTOR

2. Correct arm position. Adjust the lower stem so that your arm

is hanging in a comfortable position by your side with the coil

about 1 inch off the ground.

1. Always keep the bottom of the coil level with the ground. Try

to maintain coil 1 inch off the ground at all times. You do not need

to scrub the ground with the coil.

INSTALLING THE BATTERIES –

1/4" HEADPHONE JACK

Installing the Batteries: Re-

move the battery compart-

ment cover and install two (2)

9-volt batteries. Make the cor-

rect connections between the

new batteries and ensure the

battery snaps are plugged in.

Replace the battery cover.

Battery Door Cover

DISCRIMINATE VOLUME

ON / OFF

SENSITIVITY

PINPOINT

PRO

High Performance – Deep Searching

456

PRE SET PRE SET

456

PRE SET

Automatic LED (Red Light): The MP5 Pro has built-in automatic LED

battery test light that will start to glow red when the batteries reach a volt-

age point that is too low for maximum performance. At first turn-on the LED

might flicker some, then go out. This is normal. Only when the MP5 Pro is

on and the batteries start to lose their charge will the LED begin to glow

Red. When this happens it is time to replace both batteries. (You may still

be able to use the detector for a short while longer.) Only use fresh high

quality alkaline type.

Note: If using rechargeable types your run time will be somewhat less than

standard alkaline types.

Automatic LED

(Red Light)

USING THE MP5 PRO METAL DETECTOR —

The MP5 Pro is a slow motion type detector, in other words the coil

must be in slow motion to respond to any target. By simply moving

the coil back and forth over the ground this motion will activate the

automatic ground balance and tuning circuits of you detector and keep

it at its optimum tuning levels. When scanning the ground try to keep

the search coil about 1 inch off the ground. DO NOT scrub the ground,

you may get some "False Signals" by doing that. Please refer to the

following drawings for the correct way to sweep and hold your metal

detector.

FEET

PER

SECOND

OPERATION OF CONTROLS —

To operate and turn on the MP5 Pro simply turn the On/Off Vol-

ume Control fully clockwise. Turning this same control counter-

clockwise will lower the volume.

TIP: Adjust the Volume level that is comfortable for your personal

hearing if using an optional headphone. When not using headphones

keep volume at maximum so you will not miss the deeper targets.

After you have turned on the MP5 Pro you should now adjust the

Sensitivity Control and the Discriminate Control to their Pre-set

positions. This is only a starting point and will help you get familiar

with your new MP5 Pro.

POWER ON / OFF

Volume Switch.

• Factory

recommend

starting

point

(Pre-Set

Position)

DISCRIMINATE VOLUME

ON / OFF

SENSITIVITY

PINPOINT

PRO

High Performance – Deep Searching

456

PRE SET PRE SET

456

PRE SET

Simply move the coil back and forth

over the ground.

The Discriminate Control is used to reject or discriminate unwanted trash

targets. When the control is set to '0' your MP5 Pro will be in the All-Metal Mode

and will respond to all targets. When you increase the control to a higher number

the detector will begin to reject small iron targets first then most small foil pieces

and then pull tabs. Study the below chart to get a better understanding of the dif-

ferent levels that trash targets are eliminated.

Note: Most Eliminated Trash Targets will give a broken or chattered sound when discrimi-

nated, this is normal and is a design feature of this detector. It was designed this way so you

can easily identify trash targets. Some trash targets will give NO sounds at all. Practice using

the Discriminate Control by putting some different coins and trash items on the ground in a

straight line about 10 inches apart. Pass each item once and then come back and increase

the discriminate control knob (clockwise) and listen to the changes in the audio response on

the trash targets as you keep increasing the control by one. Remember even good targets

can be eliminated at the maximum discrimination settings.

• FACTORY RECOMMEND STARTING POINT (Pre-Set Position)













-00RO4ARGET2ESPONSE

$ISCRIMINATION,EVEL3ETTING

3-//4(#,%!22%30/.3%

3(/24#,)00%$

2%30/.3%

./2%30/.3%

TIP: Always keep the Discriminate Control at its lowest possible settings

so you will not reject nickels and small gold rings . . .

OPERATION OF THE SENSITIVITY CONTROL –

• FACTORY RECOMMEND STARTING POINT

(Pre-Set Position)

By starting out at the Pre-set

point the MP5 Pro is set at

the normal sensitivity depth

range. The normal range is

good for most soil conditions,

but by increasing this control

clockwise to the maximum po-

sition you will get better depth

on older coins. This control is

extremely helpful in eliminating

false signals caused by high

minerals. If you are experienc-

ing false signals you should

decrease this control until

these signals are minimized.

TIP: Try running the MP5 Pro in the highest Sensitivity Depth Range that you can (with

minimal false signals) so the detector will give you maximum coin depth.

DISCRIMINATE VOLUME

ON / OFF

SENSITIVITY

PINPOINT

PRO

High Performance – Deep Searching

456

PRE SET PRE SET

456

PRE SET

DISCRIMINATE VOLUME

ON / OFF

SENSITIVITY

PINPOINT

PRO

High Performance – Deep Searching

456

PRE SET PRE SET

456

PRE SET

DISCRIMINATE VOLUME

ON / OFF

SENSITIVITY

PINPOINT

PRO

High Performance – Deep Searching

456

PRE SET PRE SET

456

PRE SET

NOTE: The deeper

the target the softer

or lower the sound or

volume will be.

OPERATION OF THE DISCRIMINATE CONTROL –

LOWEST

AUDIO

PITCH

LOWEST

AUDIO

PITCH

HIGHEST AUDIO PITCH

(Dead Center)

Keep the search coil about

1 inch off the ground.

The MP5 Pro incorporates a very precise APC or Audio Centering Pinpointing fea-

ture that will accurately locate any target when you're ready to dig. Once you have

located a buried target and have identified that target in the slow motion mode you

start by moving the coil away from the target area with the coil about 1/2 inch off the

ground. Now you simply push in the round button switch in the lower left corner and

hold while slowly moving the coil over the target area until you get the highest audio

pitch and the loudest sound (volume level). At this point you are centered over the

target. What you are hearing is the new APC technology working to make pinpoint-

ing as effortless as possible. Another feature is the (dual colored LED) above the

pinpoint button will glow green only when in the button is pushed in.

PIN POINTING BUTTON

*Results may vary due to target oxidation and ground mineral conditions.

USING THE PINPOINT BUTTON –

Table des matières

Autres manuels Kellyco Détecteur de métaux

Kellyco

Kellyco Cobra beach magnet Manuel utilisateur

Kellyco

Kellyco Minelab X-Terra 70 Manuel utilisateur

Kellyco

Kellyco SOVEREIGN GT Manuel utilisateur

Kellyco

Kellyco XLT Manuel utilisateur

Kellyco

Kellyco X-TERRA 305 Manuel utilisateur

Kellyco

Kellyco BeachHunter ID Manuel utilisateur

Kellyco

Kellyco DFX Manuel utilisateur

Kellyco

Kellyco Classic ID Manuel utilisateur

Kellyco

Kellyco Titan 2000XD Manuel utilisateur

Kellyco

Kellyco Excalibur II Mode d'emploi

Kellyco

Kellyco Explorer SE Manuel utilisateur

Kellyco

Kellyco Titan 9000 Manuel utilisateur

Kellyco

Kellyco Minelab X-Terra Manuel utilisateur

Kellyco

Kellyco M6 Manuel utilisateur

Kellyco

Kellyco X-TERRA 705 Manuel utilisateur

Kellyco

Kellyco Surf P.I. Pro Manuel utilisateur

Kellyco

Kellyco Mini Master Manuel utilisateur

Kellyco

Kellyco GOLD FINDER Manuel utilisateur

Kellyco

Kellyco PULSE STAR II PRO Manuel utilisateur

Kellyco

Kellyco MPX Digital Manuel utilisateur

Manuels Détecteur de métaux populaires d'autres marques

Garrett

Garrett MAGNASCANNER CS 5000 Manuel utilisateur

Valex

Valex 1800200 Manuel utilisateur

Gauss

Gauss MIL MD Manuel utilisateur

Velleman

Velleman CS130 Manuel utilisateur

Sears

Sears 321.596370 Manuel utilisateur

Eriez

Eriez X8 Manuel utilisateur

Steinberg Systems

Steinberg Systems SBS-MD-22 Manuel utilisateur

Zircon

Zircon MetalliScanner m60c Manuel utilisateur

nalanda

nalanda MD027 Manuel utilisateur

REV Ritter

REV Ritter CB-7005 Manuel utilisateur

Minelab

Minelab F1A4 Manuel utilisateur

Fisher Research Labs

Fisher Research Labs F70 Manuel utilisateur

Steinberg Systems

Steinberg Systems SBS-MD-12 Manuel utilisateur

GOLDEN MASK

GOLDEN MASK 5 Manuel utilisateur

Grizzly

Grizzly YM 203 Manuel utilisateur

Fisher Research Labs

Fisher Research Labs 1280-X Aquanaut Manuel utilisateur

Treasure Cove

Treasure Cove Vibra-Probe 560 Manuel utilisateur

Accurate Locators

Accurate Locators XL16 IMAGER Manuel utilisateur
