KEF Ci 400 Manuel

Information Sheet

KEF Audio (UK), Eccleston Road,T

ovil, Maidstone, Kent, ME15 6QP U.K. Telephone: + 44 (0) 1622 672261. Fax: + 44 (0) 1622 750653 www.kef.com

KEF America, 10 Timber Lane, Marlboro, New Jersey, 07746 USA. Telephone: + 1 732 683 2356. Fax: + 1 732 683 2358 www.kefamerica.com

GP Acoustics GmbH, Heinrichstraße 51, D-44536 Lünen, Deutschland. Telephone: +49 (0) 231 9860-320. Fax: +49 (0) 231 9860-330. www.kefaudio.de

KEF has taken a new style direction in

custom installation with the Ci400 and

the Ci400T.

Developed from the proven multi-award

winning KHT2005, the innovative and

stylish cast aluminium loudspeakers offer

manyadvantages and benefits to the

professional installer.

Using high-grade crossover components in

conjunction with the Uni-Q®array

contributes to hi-fi sound quality across

the full frequency range, making the

product ideal for both foreground and

background music.

Choose the Ci400 with its adjustable ball

joint and you have flexibility in positioning.

Use it on its own base, mounted

horizontally or vertically on walls, on

ceilings or, using the heavy duty mounting

bracket, attached to poles.

Decide on the Ci400T and you have the

additional transformer mounted within the

base, providing an option for use with

70/100v line systems.

Commercial installations requiring hi-fi

performance will benefit from these

stylish speakers.

Features and Benefits:

The 2-way Ci400 combines 50W power

handling and 88dB sensitivity, for a

maximum output of 104dB.

Astylish cast aluminium reflex ported

enclosure with 100mm (4”) polypropylene

bass/mid cone and coincident mounted,

twin neodymium magnet, 19mm (3⁄4”)

aluminium dome, high-frequency unit.

Achoice of silver, soft black or pearl white

finishes to suit architectural requirements.

Installation

500Hz 1kHz

2kHz 4kHz

8kHz 16kHz

1Ci400 / Ci400T

2Ci400 / Ci400T

5Ci400 / Ci400T

1Ci400 / Ci400T

2Ci400 / Ci400T

6Ci400T

Specifications

Frequency / Power response, Input impedance

Directivity Index / Beamwidth

Polar graphs

(Wall Mount)

(Tube Mount)

Architectural specifications:

The Ci Series Ci400 and Ci400T comprise

a19mm aluminium dome tweeter and

100mm white polypropylene bass/mid unit

with double neo compound magnet

system. Performance should meet or

exceed the following criteria: frequency

response 1 metreon-axis with swept

sinewave shall be 80Hz to 27 kHz,

sensitivity shall be at least 88dB for

2.83V@1m. The impedance and maximum

power shall be 50W at 4 ohms. The Ci

Series Ci400 and Ci400T is best suited

where high quality music and speech

reinforcement applications require hi-fi

performance such as:

·Multi Room systems.

·Home Theatresystems.

·Lounges, Bars, Boutiques.

·Boardrooms & Offices.

·Airports, Convention Centres, Hotels.

·Live Theatre/Concert Hall fill-in.

·Houses of Worship.

·Sports Arenas.

Frequency range 80Hz - 27kHz

Sensitivity (2.83v @ 1m, 2π)88dB

Rec. amplifier power 10 - 50W

Nominal Impedance 4Ω(min. 3.2Ω)

Crossover Frequency 2.8kHz

Enclosure material aluminium alloy

T

erminals binding posts up to Ø5mm (0.2”)

conductor

Dimensions (H x WxD) 198 x 130 x 150 mm, 7.8 x 5.2 x 6 in.

Net weight 2.0kg (4.4lbs)
