KEF Ci 200.2QT Manuel

Sometimes custom installation needs

something extra special and KEF’s

Ci200.2QT is just that. Easily configured

for infrared remote control an integral DC

motor allows you to position the speaker

at the optimum angle with the press of a

button. When fully retracted it can be

operated as a conventional ceiling flush

mounted speaker.

Providing the perfect sound stage is KEF’s

patented Uni-Q®driver array producing

audiophile quality sound with an expansive

soundscape and excellent bass extension.

When partnering with others in the range

such as the Ci130DS it is the perfect

companion for creating a high

performance built-in home theatre.

Features and Benefits:

The 2-way Ci200.2QT combines 100W

power handling and 88dB sensitivity, for a

maximum output of 108dB. A 200mm (8”)

polypropylene cone bass/mid unit with a

coincident mounted 25mm (1”) soft dome,

ferrofluid cooled high-frequency unit gives

superb off-axis dispersion characteristics.

Five pre-set tilt positions with music

sensing mode provides a unique touch of

sophistication for the discerning client.

The bezel and grill can be painted to match

the interior décor.

KEF Audio (UK), Eccleston Road,T

ovil, Maidstone, Kent, ME15 6QP U.K. Telephone: + 44 (0) 1622 672261. Fax: + 44 (0) 1622 750653 www.kef.com

KEF America, 10

Timber Lane,Marlboro,New Jersey, 07746 USA. Telephone: + 1 732 683 2356. Fax: + 1 732 683 2358 www.kefamerica.com

GP Acoustics GmbH, Heinrichstraße 51, D-44536 Lünen, Deutschland. Telephone: +49 (0) 231 9860-320. Fax: +49 (0) 231 9860-330. www.kefaudio.de

Information Sheet

Polar graphs

Directivity Index / Beamwidth

Frequency / Power response, Input impedance

Specifications

Installation

Architectural specifications:

The Ci Series Ci200.2QT comprise a

coincident mounted 25mm soft dome

ferrofluid cooled tweeter with a 200mm

polypropylene cone bass/mid unit.

Performance should meet or exceed the

following criteria: frequency response

1 metre on-axis with swept sinewave

shall be 43Hz to 20 kHz, sensitivity shall

be at least 88dB for 2.83V@1m.

The impedance and maximum power

shall be 100W at 8 ohms. The Ci Series

Ci200.2QT is best suited where high

quality music and speech reinforcement

applications require hi-fi performance

such as:

· Multi Room systems.

· Home Theatre systems.

· Lounges, Bars, Boutiques.

· Boardrooms & Offices.

· Airports, Convention Centres, Hotels.

· Live Theatre/Concert Hall fill-in.

· Houses of Worship.

· Sports Arenas.

Frequency range 43Hz - 20kHz

Sensitivity (2.83v @ 1m) 88dB

Rec. amplifier power 10 - 100W

Nominal Impedance 8Ω(min. 4.8Ω)

Crossover Frequency 2.5kHz

Enclosure material N/A

Terminals terminal blocks up to Ø2.5mm (0.1”)

conductor

Dimensions (H x W x D) 381 x 279 x 215 mm, 15 x 11 x 8.5 in.

Net weight 5.52kg (12.1lbs)

500Hz 1kHz

2kHz 4kHz

8kHz 16kHz

PL1601EN

1

2

3

4

5

6
