Kapro 883G Manuel utilisateur
Prolaser 3D All-Lines GREEN
Model No. 883G
Li-ion
165'/50m RECHARGEABLE
Up to 70m/230'
4 AA
INCLUDED
User Manual
Manual del usuario
Manuel d'utilisation
Руководство по эксплуатации
2
Thank you for purchasing Kapro’s 883G Prolaser®3D All- Lines
GREEN. You now own one of the most advanced laser tools
available. This manual will show you how to get the most out of
your laser tool.
APPLICATIONS
The 883G Prolaser®3D All- Lines GREEN is a laser level with 3
green diodes, that emits 3 circular lines. The laser is innovatively
designed for a very broad range of professional and DIY jobs,
including:
• Hanging cabinets and shelves.
• Setting oor and wall tiles
• Drywall installation and hanging acoustic ceilings
• Framing and aligning windows and doors
• Leveling electrical outlets, plumbing and studs
• Accurately laying out right angles for ooring, fences, gates,
decks, pergolas and gazebos.
• Leveling slopes for stairs, rails, roofs and more. (manual mode)
NOTE
Keep this user manual for future reference.
EN
Li-ion
165'/50m RECHARGEABLE
Up to 70m/230'
4 AA
INCLUDED
3
CONTENTS
• Features 4
• Safety instructions 5-6
• Battery installation & Safety 7-8
• Overview 9
• Operating instructions 10-12
• Maintenance 13
• Field calibration test 14-23
• Specifications 24
• Warranty 25
4
FEATURES
• This laser tool automatically determines the horizontal
and vertical plans.
• This laser emits 1 horizontal 360° and 2 orthogonal 360°
vertical green beams, that intersect on 4 walls, oor and
ceiling.
• Self-leveling in automatic mode when the laser is
positioned within its self-leveling range which is ±2.5º
• Visual warning when the laser level is out of leveling
range.
• Pulse mode emits pulses that can be detected by a detector.
• Max. indoor working range - 30 m (100’) with green goggles.
• The max. detectable range of the laser in pulse mode is
70m (230’).
• Manual mode allows angular layout/marking.
• IP65 Rated for water and dust protection.
• Locking mechanism to protect the pendulum during
transportation.
• 1/4" and 5/8" tripod threads.
• Shock resistant rubber over molded casing.
• Multi-purpose magnetic mount.
• Battery compartment for optional use with 4 AA Alkaline
batteries.
• Charger.
NOTE
This device contains precision components
sensitive to external shock, impact or falls
that may compromise its functionality. Handle
with care to maintain its accuracy.
5
SAFETY INSTRUCTIONS
WARNING
This product emits radiation classified as Class II
according to EN 60825 -1
The laser radiation can cause serious eye injury
• Do not stare into the laser beam
• Do not position the laser beam so that it unintentionally
blinds you or others.
• Do not operate the laser level near children or let children
operate the laser level.
• Do not look into a laser beam using magnifying optical
devices such as binoculars or a telescope,since it will
increase the level of eye injury.
WARNING: This product contains lead in soldered joints
and certain Electrical parts contain chemicals which are
known to the State of California to cause cancer, birth
defects or other reproductive harm.
(California Health & Safety Code Section 25249.6- Proposition 65)
NOTE
The green goggles are intended to enhance
the visibility of the laser beam. They will not
protect your eyes against laser radiation.
6
• Do not remove or deface warning labels on the laser level.
• Do not disassemble the laser level, laser radiation can
cause serious eye injury.
• Do not drop the unit.
• Do not use solvents to clean the laser unit.
• Do not use in temperatures below -10°C or above 50°C
(14°F to 122°F)
• Do not operate the laser in explosive atmospheres such
as ammable liquids, gases or dust. Sparks can cause
ignition.
• When not in use remove the battery, engage the
pendulum lock and place the laser in the carrying pouch.
• Make sure the pendulum lock mechanism is engaged
before transporting the laser.
NOTE
If the Pendulum lock mechanism is not
engaged before transportation, internal
mechanical damage may occur.
7
The 883G Prolaser®3D All-Lines GREEN offers 2 power supply
options: a rechargeable Li-Ion battery pack or 4 AA Alkaline
batteries (battery compartment included).
Installation
1. Press down the latch of the battery cover.
2. Insert the Li-Ion battery pack or the battery compartment with
the 4 AA Alkaline batteries, with the terminal contacts forward,
according to the shape of the battery compartment.
3. Close the battery cover.
BATTERY INSTALLATION & SAFETY
Li- Ion batteryAlkaline batteries
Battery
compartment
8
Charge the Li- Ion battery or use new AA Alkaline batteries if
the beam/ battery indicator (b) starts to ash instead of emitting
a steady light.
NOTE: Connecting the charger with the charging adaptor to
the power (without the battery) will show a steady green LED
indicator with a small blinking dot. During the charging the LED
indicator (on the charging adaptor)
will be red and then green,
once fully charged.
1. Charger
2. Charging adaptor
3. LED indicator
4. Rechargeable battery
WARNING: Battery can deteriorate, leak or explode and
can cause injury or re.
1. Do not shorten the battery terminals.
2. Do not dispose of battery into household waste.
3. Do not dispose of battery in re.
4. Defective or dead batteries must be disposed according to
local regulations.
5. Keep the batteries out of children's reach.
1
2
3
4
9
OVERVIEW
78
6
1
2
a
db
c
3
45
1. On/Off Locking Switch
2. Keypad
a. Beam Selector/Manual mode button
b. Beam / Battery indicator
c. Pulse Mode button
d. Pulse Mode indicator
3. Horizontal laser beam window
4. Forward vertical laser beam window
5. Side vertical laser beam window
6. Battery cover
7. 1/4” tripod mount
8. 5/8” tripod mount
10
OPERATING INSTRUCTIONS
Working in Automatic mode (self-leveling):
In automatic mode the laser level will level itself in a ± 2.5°
range and will project 1 horizontal 360° or/and 2 vertical
360° green beams.
1. Remove the laser level from the case and place it on a
solid, at, vibration free surface or on a tripod.
2. Push the locking switch #1 to the ON position. The laser
level will project a 360° horizontal beam. The beam
indicator (b) will turn on.
3. Press the beam selector button (a) - it will turn on a 360°
vertical side beam instead of the horizontal beam.
4. An additional click on the beam selector button will turn
on a 360° vertical front beam in addition to the side vertical
beam.
5. One more click on the beam selector button (a) will switch
on the horizontal beam in addition to the vertical beams.
6. An additional click on the beam selector button (a) will
switch off the two vertical beams.
7. If the initial inclination of the laser level is beyond ± 2.5°
and the automatic mode is activated, the laser beams will
ash. In this case reposition the laser level on a more level
surface.
8. Before moving the laser level turn the locking switch
#1 to the OFF position, this will lock the pendulum and
protect your laser level.
