LC SERIES

MODELS LCLX, LCMX

OPERATING INSTRUCTIONS

The following instructions cover lock operations for LC Series locks. The lock models are

battery powered (PowerSaverTM technology). See back page for Battery Replacement

instructions.

SUPER MASTER CONTROL

The Super Master Combination is a six-digit combination used to reset the lock to the

factory default combination (50 25 50) in the event the user combination(s) are lost. See

the Super Master Operations sheet (P/N 394.101).

LOCK MODES

A maximum of two users can exist in a lock. A lock can operate in either Single Mode or

Dual Custody Mode.

• Single Mode E

Single Mode defaults to having only a Manager User (User 1) in the lock. A second

user (User 2) can then be added by the Manager User (User 1). (See section on

Manager User Operations.)

In Single Mode only one valid user combination is required to open the lock - the Manager

User (User 1) combination or the User 2 combination.

Note: Default lock status from the factory is Single Mode with an opening

combination of “50 25 50” for the Manager User (User 1).

•Dual Custody Mode EE

Dual Custody Mode defaults to two users in the lock - User 1 and User 2.

Both user combinations are required to open the lock - the User 1 combination and the

User 2 combination.

Note: Manager User Operations are not available in Dual Custody Mode.

LOCK OPERATION & RESPONSES

• Each keystroke generates a green flash

with a beep 88

• To cancel entry, press .

• The completion of a step within an operation is indicated by a green flash

with a beep 88

• The successful completion of an operation is indicated by two green flashes

with beeps.

• An error is indicated by five green flashes with beeps.

• A low battery is indicated by 5 series of three green flashes with beeps

8after a lock opening.

(See Battery Replacement on back page.)

OPEN/CLOSE THE CONTAINER

1. • For Single Mode EE

E(Factory combination is “50 25 50”.)

Enter Manager User (User 1) or User 2 combination.

• For Dual Custody Mode EE

EEE

Enter User 1 or User 2 combination.

Enter the second combination.

Wrong Try Penalty: 5 wrong tries =

3 min. lockout

Each additional wrong try = 3 min. lockout

Green flashes with beeps

8will occur during the lockout.

2. Immediately rotate the container handle to retract bolt works before green

lights flash with beeps 88

8. Open the container door. To close and lock the

container, close the door and rotate the container handle back to locked position.

CHANGE COMBINATION

WARNING: Super Master Control will be permanently lost if you do not change

the default Super Master Combination prior to changing any User combinations.

See Super Master Operations sheet (P/N 388.105).

Caution: Before changing combination, open the container door to allow testing

with the new combination. Record new combination and store it in a secure

place.

1. • For User 1 (Manager User in Single Mode)

Press . Press .

• For User 2

Press . Press .

2. Enter current combination. (Factory combination is “50 25 50”.)

3. Enter new six-digit combination.

4. Enter new combination again for verification.

5. Open the lock with the new combination before closing container.

CHANGE LOCK MODE (SINGLE / DUAL CUSTODY)

Note: Changing the lock mode will reset the combination(s) to “50 25 50”.

1. Press . Press .

2. • If changing from Single to Dual Custody Mode

Enter Manager User (User 1) combination.

• If changing from Dual Custody to Single Mode

Enter User 1 or User 2 combination.

Enter the second combination.

Manager User Operations

These operations are only available in Single Mode and can only be performed by the

Manager User (User 1). All Manager User Operations involve management of User 2.

User 2 can have a lock access status of “Enabled” or “Disabled”. If “Enabled”, User 2

can open the lock. When User 2 is added to the lock, the default lock access status is

“Enabled”. The Manager User (User 1) has the authority to change the lock access

status for User 2 and can temporarily “Disable” lock access for the user.

ADD USER 2

1. Press . Press .

2. Enter Manager User (User 1) combination.

Note: User 2 is added to the lock as “Enabled” with a factory combination of “50 25 50”.

User 2 can change the User 2 combination while Enabled, but only the Manager User

(User 1) can change the lock access status.

DELETE USER 2

1. Press . Press .

2. Enter Manager User (User 1) combination.

ENABLE USER 2

1. Press . Press .

2. Enter Manager User (User 1) combination.

Note: If you try to enable User 2 when already enabled, you will get an error indication.

DISABLE USER 2

1. Press . Press .

2. Enter Manager User (User 1) combination.

Note: If you try to disable User 2 when already disabled, you will get an error indication.

Document Number 384.120 Rev. C2 - 01/02

www.kaba-mas.com

749 W. Short Street, Lexington, KY 40508

Phone (800) 950-4744 or (859) 253-4744 FAX (859) 253-4748

Battery Replacement

Read all instructions before attempting to replace the battery in an LC Series

lock.

To replace the battery, you must

first remove the keypad

assembly. To do so, insert the

blade of a flat head screwdriver

under the keypad housing at a

point about 15 degrees to the

right of 6 o’clock on the face of

the keypad (below the Enter

key). (See Figure 1.) There is a

small indentation on the back

edge of the keypad housing that

will allow the screwdriver to

easily be inserted at this point.

Pry the keypad assembly from

the face of the safe being

careful not to damage the cable

connection from the safe to the

keypad assembly. (See Figure

2.)

Remove the old battery and

replace with a new 9-Volt

battery. (See Figure 2.) Reattach

the keypad being careful not to

pinch the battery cable

between the keypad housing

and the mounting bracket.

Test the operation of the lock

before closing the container. If

the combination is entered

successfully, one green flash

displays to indicate the lock is

ready to open. Then rotate the

container handle to retract the

bolt. If the test is successful, the

lock and container are now

ready for use.

Note: If the lock does not operate successfully, carefully remove the keypad, check

the cable connection, and verify that all mounting screws are securely tightened.

Insert Blade of

Screwdriver

Under Keypad

Housing

Figure 1

Battery Clip

Cable

Connection

Figure 2

Battery
