K1600 MANUAL
TABLE OF CONTENTS
I. SYSTEM OVERVIEW PAGE
A. INTRODUCTION 1
B. FUNCTION PUSHBUTTONS 2
C. MULTIPLE TANK DISPLAY 3
D. SINGLE TANK DISPLAY 4
II. DESCRIPTIONS
A. CHANNEL NUMBER 5
B. TANK NAMES 5
C. UNITS OF MEASURE 5
D. PRODUCT NAMES 6
E. SPECIFIC GRAVITY 6
F. PERCENT FULL 6
G. GENERAL ALARM STATUS LINE 6
H. LEVEL ALARM STATUS 7
I. ANALOG TO DIGITAL COUNTS 7
J. TRANSMITTER ZERO OFFSET-MANUAL/ AUTO
ZERO FUNCTION
III. VIEWING DATA
A. UNITS 9
B. PRODUCT IN TANKS 9
C. ALARM SETPOINTS HI-MID-LOW 1 0
D. ZERO OFFSET VALUES 1 1
E. TIME/DATE 1 1
F. INVENTORY SCREENS 1 1
8500
Installation/Start-up/Operation
Lit # 8500 OP
2
IV. PROGRAMMING AND CHANGING DATA PAGE
GENERAL AND ACCESS CODES 12
TIME/DATE 1 3
PRODUCT NAME AND SPECIFIC GRAVITY 1 5
ALARM SETPOINTS 1 9
TRANSMITTER ZERO OFFSETS 2 2
UNITS OF MEASURE SETTING 2 6
V. INSTALLATION AND START UP
INSTALLATION OF INVENTORY CABINETS 2 8
4-20 MA TRANSMITTERS 2 9
4-20 MA SIGNAL LINES 2 9
PNEUMATIC TANK SENSORS 3 0
PNEUMATIC SIGNAL LINES 3 0
LEVEL ALARM OUTPUTS 3 1
RS232 COMMUNICATIONS 3 1
OPERATION AND START UP 3 1
INSTALLATION AND START UP SUMMARY 3 3
SENSOR & MISC. INSTALLATION DOCUMENTS
3
I. SYSTEM OVERVIEW
INTRODUCTION
The K SYSTEMS K1600 Tank Inventory system is a micro-processor based inventory
control system designed for high accuracy measurements of liquid contents of up to 16 storage
tanks. The inventory and alarm status of each tank can be viewed on a large 4x20 LCD display.
Tank inventory is continuously run in the background even while the operator has control of the
system through the LCD display and the front panel key pad.
The K1600 can be configured to accept up to 16 pneumatic or 4-20 milliamp input
signals from the sensors in the tank. This signal is converted from analog to digital (ATOD)
counts which, in conjunction with the entered specific gravity and programmed tank profile
tables, are utilized in determining the correct inventory value. The K1600 can manually or
automatically compensate for zero shift of input signals directly from the display without
4
having to adjust at the sensors.
Alarm setpoints, Product names and Specific gravities, Transmitter zero values and
Time/date can easily be changed by authorized personell through use of multi-level access
codes and the functionally labeled keypad on the front panel.
Inventory for individual or multiple tanks can be viewed on the display by pressing the
RUN/PAGE button. Once on the desired display page additional tanks can be viewed by pressing
the up/down arrow keys. In addition inventory can be read in POUNDS or GALLONS (LITERS or
KILOGRAMS) by selecting the UNITS button.
Optional field programmable alarm outputs, an RS232 communication port, and
Printout capability allow accurate inventory information to be brought out to a host of
peripheral devices for reporting and control.
Although the K1600 Tank Inventory System is micro-processor based, it is functionally
driven and requires little knowledge and understanding of computers. All functional displays
and operations can be accessed from either the single or multiple tank display screen by
selecting the button which corresponds to the desired operation.
5
FUNCTION PUSHBUTTONS
RUN - toggles between the multi-tank and the single tank readout.
PAGE Depressing this button from any other sub-level viewing or programming
screen will return to the active inventory screen last viewed.
PROG - turns on/off the system programming feature allowing for alterations of tank,
product and sensor parameters when required.
UNIT - toggles between pre-programmed units of measure (pounds and gallons or liters
and kilograms)
ALARM - changes screen to view alarm setpoint values in gallons. The multi-tank
screen will indicate all the HI- level values inditcated by an asterisk ( * )
and by pressing the up and down keys to the left of the readout the screen will
change to view MID (M) and LO (L) level values. The single tank screen will
display the HIGH - MID - LO for the tank selected. Press RUN/PAGE to return
to normal inventory display.
PROD - changes screen to view product names for all tanks from the multi-tank screen.
Product names are normally displayed on the single tank screen.
TIME - changes Multi-tank screen to view the zero offset values in ATOD counts of the
ZERO transmitter output for all tanks. From the single tank screen the bottom
line will display the ATOD values of the offset as well as the current output.
PRINT - accesses optional line printer.
ALARM - acknowledges an alarm condition and silences optional
ACK audible alarm
ENTER - records the existing entry in a data field in memory and either moves to the
next programmable data field on the page or moves to the next screen and
terminates the programming mode.
DELETE - erases an entry in an active field during programming
6
MULTIPLE TANK DISPLAY
The K1600 Multi-tank display is a two page display where tanks are arranged in 2
columns per page as defined by channel numbers 1-4, 5-8, 9-12, 13-16. Page 1 shows the
inventory levels of channels 1 through 8 (tanks 1-8) and Page 2 displays channels 9 - 16
(tanks 9-16). Each tank has a status mark which becomes active when an alarm condition
exists (see TANK LEVEL STATUS below). While all tank inventories are continuously updated,
the operator can easily toggle from Page 1 to Page 2 by using the scroll keys. The <PAGE> key
can be used to toggle from the Multi-tank display to the Individual tank display where more
complete tank information can be viewed.
1 *40345 G
5 M 789
2 L 567 6 3705
3 456 7 *26536
4 E 67 8 1789
TANK LEVEL STATUS
OUTPUT
E=@ SENSOR NONE
L = @ OR BELOW LO SETPOINT ON
= ABOVE LO & BELOW MID NONE
M = @ OR ABOVE MID SETPOINT NONE
* = @ OR ABOVE HI SETPOINT ON
UNITS
SELECTED
G= GALLONS
#= POUNDS
INVENTORY
VALUES IN
UNITS SELECTED
CHANNEL
NUMBER
CHANNEL
NUMBER
INVENTORY
VALUES IN
UNITS SELECTED
MULTIPLE TANK DISPLAY
7
SINGLE TANK DISPLAY
This display lists inventory on a tank by tank basis. The operator may view all
individual tank information by using the scroll keys to increment or decrement the channel
number. Again, the <PAGE> key can be used to toggle between the multiple and individual tank
screens.
PAST 1 13732 GAL.
CH: 2 **Hi** LEVEL
CREAM 0.998 SPGR
97% FULL
PERCENT FULL OF
TANK VOLUME BASED
ON EMPTY TO HI
LEVEL SETPOINT
PRODUCT NAME
AS SELECTED FROM
PRODUCT LIST
PRODUCT SPECIFIC
GRAVITY AS SELECTED
OR ENTERED FROM
PRODUCT LIST
TANK NAME AS
PROGRAMMED
INVENTORY VALUE
IN UNITS SELECTED
UNITS
SELECTED
LEVEL ALARM
STATUS
(HI-MID-LO)
CHANNEL
NUMBER
SINGLE TANK DISPLAY
8
II. DESCRIPTIONS
CHANNEL NUMBER
During the initial set-up of the system each tank is linked in software to an input
channel number as defined by hardware on the analog input board (See System Set-up and
Installation). The channel number also defines the Multi-tank display location of a tank and is
used throughout the system to identify a particular tank's data shown on display screens where
actual tank names cannot be written. Channel numbers are displayed on the Multi-tank
displays prior to the particular information requested. On the Single tank dislpays the channel
number is usually preceded by the characters "CH" as in CH:12. There are 16 available
channels, one for each tank. The actual number of channels used and displayed is typically
determined by the number of tanks on the system. When in the appropriate mode, channel
number can be incremented or decremented using the scroll keys.
TANK NAMES
Tank names or designations which define a particular tank appear in the upper left-
hand corner of the single tank display and consist of up to six characters. Names such as RT 1,
PT 6, or TANK 3 help the operator identify a tank. Tank Names are supplied by the customer
and are entered into the system prior to shipment as part of the initial factory set-up. These
names are stored in E-prom memory and will not be lost during a power outage. Tank names
cannot be altered in the field through use of the keyboard entry system.
UNITS
The K1600 will readout in English or metric units as either Pounds and Gallons or
Liters and Kilograms. Units define the units of measure in which the inventory value is shown
and appears on the Single tank screen in the upper right-hand corner following the actual
inventory value displayed. On the Multi-tank screen units are indicated in the center of the
display on the 1st line. Pressing the <UNITS> button toggles the display and inventory values
between the units of measure programmed.
9
PRODUCT NAMES
Product names on the Single tank screen appear on the 3rd row , left-hand side of the
display. These names identify the product selected by the operator for the tank shown. Up to 18
product names consisting of a maximum of six characters are supplied by the customer and are
pre-programmed at the factory during initial set-up prior to shipment. Similar to Tank
Names, Product Names are stored in E-Prom memory and will not be lost during a power outage
nor can they be altered through the keyboard entry system. On the Multi-tank screen product
names can be viewed by pressing the <PROD> button on the front panel. The product names
will be preceded by the appropriate channel number.
(See Viewing Data - Multi-Tank)
SPECIFIC GRAVITY
Product specific gravity is indicated on the Single tank screen only on the 3rd row
directly to the right of the product name. Specific gravity refers to the weight of the product in
the tank which directly effects the head pressure being measured. The specific gravity of the
product displayed has a direct effect on the accuracy of the inventory value and as such care
should be taken to insure that the proper "SPGR" is shown. Even though the product name is
correct, incorrect SPGR can adversely effect the inventory value indicated. The correct
specific gravity for a product is entered and linked to the product name during operator
programming so thereafter, a product name selected from the Product list simultaneously
selects the correct specific gravity. (See User Programming- Product Name)
PERCENT FULL
Line 4 of the Single tank display indicates how full the tank is in percentage of volume.
GENERAL ALARM STATUS LINE
When an alarm is encountered during normal operation or in the programming mode,
line 1 or 4 of any display is replaced by the general alarm status line. This will alert the
operator of an alarm condition in a tank. The operator will be cued to silence the audible alarm
(optional) and acknowledge, <ACK>, the alarm. After acknowledgement is complete, normal
operation will resume. Multiple alarms will be processed on a first in - first out basis.
10
LEVEL ALARM STATUS
There are three level setpoints per tank (HI - MID - LO) which are programmed by the
user. When the level in the tank reaches a setpoint line 1 or 4 on the screen is relpaced by the
General Alarm Status Line . After all alarms have been acknowledged the display returns to its
normal appearance. However, the level status indicator is now activated for the alarms
acknowledged. Level alarm status indication appears on both the Single and the Multi-tank
screen in various forms. The Multi-tank screen displays an astericks ( *) for high level, the
letter "M" for mid level and the letter "L" for low level. These characters appear immediately
following the channel number. If there is no indication in the level status column for a
particular tank then the actual product level in the tank is between the lo level and the mid
level setpoint.
The letter "E" appearing in the level status column indicates that the product level is
at or below the level sensor in the tank.
The Single tank screen displays the tank level status on the 2nd line after the channel
number and preceding the word "LEVEL". When the tank product level is at or above the Hi-
level setpoint the characters "HI" appear. Similarly when the product level is at or above the
Mid-level setpoint and below the Hi-level setpoint the characters "Md" appear. The characters
"OK" are displayed when the product level is betweem the lo-level and the mid-level setpoints.
"LO" appears when the level is at or below the lo-level setpoint. When the product level is at
or below the tank sensor the characters "EMPTY" appear on the screen.
(CAUTION: Even though the screen reads "empty" product may remain in the
tank below the level sensor)
ANALOG TO DIGITAL COUNTS
The K1600 uses a 12-Bit Analog to Digital converter which normally converts a 4-
20 Ma current input signal to 0-4096 digital counts. The K1600 utilizes a "LIVE" zero and
condensed span adjustment so that a 4.00 milliamp input produces 50 AtoD counts and a 20
milliamp input produces 4050 counts. The system micro-processor then utilizes these digital
counts in determining the product level in the tank. The current ATOD count for each tank can
be viewed individually from the Single tank screen by pressing the <TIME/ZERO> button. These
values can be used as a reference to view and/or adjust the transmitter zero offset when a tank
is empty.
Table des matières
Autres manuels K-Systems Système de contrôle
