Kärcher B 60 W Bp Manuel utilisateur

QUICKSTART

5.964-036.0 02/11

Warning

These are only brief instructions! Please read and comply with these instructions prior to using or servicing your

appliance.

The non-compliance of the operating and safety instructions may lead to damages of the appliance and to dangers

for the operator and other persons.

Start up

1A B A Unplug the charger from the mains.

B Place the mains cable into the storage com-

partment.

2AA Open the cover of the fresh water reservoir.

Fill in fresh water (maximum 60 °C).

Close the cover of the dirt water reservoir.

3AModel with dosing equipment "Dose"

A Place the bottle with the detergent in the hold-

er behind the operator console.

Close the bottle lid.

Insert the suction hose of the dosaging equip-

ment into the bottle.

Model without dosing equipment

"Dose"

A Add the detergent to the fresh water

reservoir.

Operation

1A B Starting the machine

A Release emergency-stop button by turning.

B Set main switch to “1”.

2A B Drive forward

A Press the driving lever to the front.

Stop the machine: Release driving lever.

B You can use the info button to set the working

speed.

B 60 W Bp

QUICKSTART

5.964-036.0 02/11

3A B Reverse drive

A Press the driving lever to the rear.

Stop the machine: Release driving lever.

B You can use the info button to set the working

speed.

4ASetting the water quantity

A Adjust the water quantity using the regulating

button according to the dirt on the floor

covering.

5ASwitching on the cleaning head

A Press the pedal downwards; move it to the

left and release it upward. The cleaning head

is lowered and the brush motor starts auto-

matically.

6AContact pressure adjustment

A The desired brush contact pressure is

adjusted by means of the lever.

7ALower the vacuum bar

A Turn the lever downwards; the vacuum bar is

lowered and the suction turbine is switched

on.

Operation

QUICKSTART

5.964-036.0 02/11

Finish operation

Turn off the appliance

A Close the regulatory button for setting the

water quantity.

B Release driving lever.

C Lift the cleaning head.

D Briefly drive forward and suck of the

remaining water.

E Raise the vacuum bar.

The suction turbine will continue to run for 5

more seconds to suck off residual water from

the vacuum bar and the vacuum hose.

F Set the key switch at the operator console to

"0" and remove the key.

2A B Emptying the Dirt Water Reservoir

몇Warning

Please observe the local provisions regarding the

wastewater treatment.

A Take the water discharge hose from the

support and lower above a suited collection

device.

B Then rinse the dirt water tank with clear

water.

3AEmptying the Fresh Water Tank

몇Warning

Please observe the local provisions regarding the

wastewater treatment.

A Loosen the lid for emptying the fresh

water - do not remove it fully. Drain water.

Remove the lid with washer fully to rinse off

the fresh water tank.

4ACharging battery

A Charge battery, if required.

Insert the plug of the connecting cable into

the socket.

QUICKSTART

5.964-036.0 02/11

Maintenance and care

daily

monthly

Kärcher Customer Service

몇Warning

Please observe the local provisions

regarding the wastewater treatment.

A Take the water discharge hose

from the support and lower above a

suited collection device.

B Then rinse the dirt water tank with

clear water.

2A몇Warning

Please observe the local provisions

regarding the wastewater treatment.

A Loosen the lid for emptying the

fresh water - do not remove it fully.

Drain water.

Remove the lid with washer fully to

rinse off the fresh water tank.

3AA Check fresh water filter; clean if

required.

4AA Check brush for wear and tear and

clean it.

Check the brushes for wear (bristle

length at least 10 mm), replace if

required.

5A B A Clean the vacuum lips on the vacu-

um bar, turn or replace if required

B Clean the suction channel.

QUICKSTART

5.964-036.0 02/11

6AA Clean the outside of the appliance

with a damp cloth which has been

soaked in mild detergent.

7AA Clean the seals between dirt water

reservoir and cover and check for

tightness, replace if required.

8AA annual

Maintenance and care

daily

monthly

Kärcher Customer Service

QUICKSTART

5.964-036.0 02/11

Troubleshooting

BAppliance cannot be started

A Stand-by, turn key switch to "0", then set it

back to "1".

B Release emergency-stop button by turning.

C Battery depleted.

Charge battery.

2ABCNo or inadequate suction power

A Clean the seals between dirt water reservoir

and cover and check for tightness, replace if

required.

B Clean the vacuum lips on the vacuum bar,

turn or replace if required

C Check suction hose for blockages; clean if

required.

Check connection between suction hose and

suction bar and suction hose and wastewater

tank.

3A B Insufficient cleaning result

A Set/ adjust contact pressure.

B Check brush for wear and tear and clean it.

Check the brushes for wear (bristle length at

least 10 mm), replace if required.

4A b Brushes do not turn

A Set/ adjust contact pressure.

B If over-current switch in the electronics

system has been triggered, turn key switch

to "0", then set it back to "1".

C Check the brushes for blockage due to for-

eign particles, remove them if found.

5A B No or very little detergent solution gets added

A Increase the water volume to activate the

dosing pump.

B Check level of detergent solution in the fresh

water tank; refill, if required.
