Küenle KFU 2 Series Manuel de programmation
Quick Start
Instructions
Frequency Inverter
Series KFU 2- / 4-
0,55 to 3,0 kW – 230 V – KFU 2-
0,55 to 132 kW – 400 V – KFU 4-
KN 621.1401
e
KFU 2-/4-
1
This documentation describes the first steps for an easy commissioning of the frequency inverters KFU 2-/4-…
The labels on the housing and behind the upper cover helps to identify the devices of the KFU series.
Warning!
The safety instructions and information on use contained in this documentation and in the
operating instructions manual on the attached CD must be complied with strictly during
installation and commissioning of the frequency inverter.
According to the application and optional components refer to additional manuals on CD.
Non-compliance with the precaution described will result in death, serious injury or material
damage.
The present documentation is applicative for qualified staff who is familiar with the installation,
assembly, commissioning and operation of the frequency inverter and has the proper
qualification for the job.
Persons who are not familiar with the operation of the frequency inverter and children may not
have access to the device.
Commissioning and start of operation is not allowed until it has been verified that the machine
meets the requirements of the EC Machinery Directive 98/37/EEC and EN 60204.
When working at the frequency inverter, comply with the applicable standards BGV A2 (VBG 4),
VDE 0100, standards for equipment of heavy current installations such as EN 50178 and other
national directives.
Before commissioning and the start of the operation fix all covers and check the terminals.
Check the additional monitoring and protective devices according to EN 60204 and applicable
the safety directives (e.g. Working Machines Act, Accident Prevention Directives etc.). No
connection work may be performed, while the system is in operation.
KFU 2-/4-
2
KFU 2-/4-
3
TABLE OF CONTENTS
1Safety instructions for “Safe torque off” function (STO)............................................... 5
1Mechanical Installation.................................................................................................. 7
2Electrical Installation................................................................................................... 11
2.1................................................................................................................................................EMC Information
........................................................................................................................................................... 11
2.2...........................................................................................KFU 2- (up to 3.0 kW) and 401 (up to 4.0 kW)
........................................................................................................................................................... 11
2.3.......................................................................................KFU 2- (4.0 to 9.2 kW) and 401 (5.5 to 15.0 kW)
........................................................................................................................................................... 12
2.4.................................................................................................................................KFU 4- (18.5 to 30.0 kW)
........................................................................................................................................................... 12
2.5.................................................................................................................................KFU 4- (37.0 to 65.0 kW)
........................................................................................................................................................... 13
2.6........................................................................................................................KFU 4- (75.0 kW to 132.0 kW)
........................................................................................................................................................... 14
2.7..............................................................................................................................................Control Terminals
........................................................................................................................................................... 15
2.7.1External 24 VDC voltage supply................................................................................................. 16
3Commissioning via the control unit KP500.................................................................. 17
3.1...............................................................................................................................................Functions of keys
........................................................................................................................................................... 17
1.1.....................................................................................................................................Guided Commissioning
........................................................................................................................................................... 18
4Parameter settings....................................................................................................... 21
5Actual values................................................................................................................23
6Control Unit messages ................................................................................................. 25
6.1...........................................................................................Warning and error messages during operation
........................................................................................................................................................... 26
6.2...................................................................Warning and error messages during Guided commissioning
........................................................................................................................................................... 27
KFU 2-/4-
4
KFU 2-/4-
5
1Safety instructions for “Safe torque off” function (STO)
The function “Safe torque off” (STO) is a function-safeguard which protects persons and avoids material damage
in professional engineering and installation conditions as well as intended use. The function does not switch the
machine to a de-energized state.
Install an emergency-stop device according to EN 60204 to de-energize the machine, for example for
maintenance work.
For personal safety and to prevent material damage comply with the following instructions.
Warning!
Improper installation of the safety technique can cause an uncontrolled starting of the drive. This
can result in death, serious injury or material damage.
Only qualified staff may install and commission the safety functions.
The STO (Safe torque off) function does not allow emergency switch-off according to standard
EN 60204. Emergency switch-off can be realized by a mains contactor installation.
Emergency switch-off according to EN 60204 must be functioning in all operation modes of the
frequency inverter. The reset of emergency switch-off may not cause an uncontrolled starting of
the drive.
The drive restarts if the function STO is not requested any more. According to EN 60204 the drive
may only start after an acknowledgement.
Without a mechanical brake the drive might not stop immediately; but coast down. Risk of injury or
material damage has to be prevented by providing additional safety devices.
If risk of injury is possible after the motor power supply is switched off by the STO function the
access to the danger area must be locked. The access to the danger area must be locked until the
drive is come to a standstill.
Check the safety function in periodic maintenance according to your risk assessment. We
recommend an inspection latest after one year.
The STO function is one-fail-safe. No single fault or component failure can cause a disabled drive
to produce motor shaft torque. Only in extremely unlike combinations of component faults the
motor shaft could move jerky with sudden acceleration (maximum 180°/number of pole pairs, for
example jerky movement of 90° for 4-pole motor, 180°/2) and produce torque. It must be
checked, if this behaviour can cause a dangerous machine movement.
If the safety function STO is applied comply with the special safety-, installation- and operating
instructions.
Warning! Dangerous voltage!
The safety function „Safe torque off“ is practical only for mechanical work on driven machines, but not
for work on live-line voltage-carrying components.
Before working (maintenance) on live-line voltage-carrying components electrical isolation from
mains supply is necessary by a main switch.
When the 24VDC power supply is switched off the mains voltage is still alive at the DC link circuit.
Although the motor is de-energized, in standstill or coasts down the motor terminals live with high
voltage.
The motor is not electrically isolated from the DC link circuit of the frequency inverter if the „Safe
torque off“-function is activated and the motor is de-energized. High voltage may live at the motor
terminals.
Do not touch voltage-carrying contacts.
Note:
According to the EU Machinery Directive 98/37/EG the machine must be subjected to a risk
assessment, carried out by the manufacturer. In this assessment the effect of the safety features in
the control system will be taken into account when looking at the overall risk of each possible
hazardous event. Standard EN 1050 – Principles for risk assessment – describes the information,
which is necessary for risk assessment.
KFU 2-/4-
6
KFU 2-/4-
7
1Mechanical Installation
Warning!
During installation the following installation and safety instructions as well as the instructions in the
additional manuals on CD must be complied with.
During assembly, make sure that no foreign particles (e.g. filings, dust, wires, screws, tools) can
get inside the frequency inverter.
Mount the devices with sufficient clearance to other components so that the cooling air can
circulate freely. Avoid soiling by grease and air pollution by dust, aggressive gases, etc.
KFU 2- (up to 3.0 kW) and KFU 4- (up to 4.0 KW)
b
b1
a1
aa2
c
c1
x
x
b1
x 100 mm
Insert the long side of the fixing plate in
the heat sink.
Screw the fixing plate to the mounting
plate.
KFU 2- (4.0 to 9.2 kW) and KFU 4- (5.5 to 15.0 kW)
b
b1
a
a1 a2
c
x
x
c1
x 100 mm
top M4x20
bottom M4x60
Screw the fixing brackets to the heat sink
of the frequency inverter and the assembly
panel.
KFU 2-/4-
8
KFU 4- (18.5 to 30.0 kW)
c
c1
a
a1 a2
x
b
b1
x
x 100 mm
top M4x20 bottom M4x70
Screw the fixing brackets to the heat sink
of the frequency inverter and the assembly
panel.
KFU 4- (37.0 to 65.0 kW)
a
a1
a2
x
b
b1
x
c
c1
x 100 mm
top M5x20 bottom M5x20
Screw the fixing brackets to the heat sink
of the frequency inverter and the assembly
panel.
Dimensions without optional components:
Dimensions in mm Installation dimensions in mm
kW a b c a1 a2 b1 c1
KFU 2-
0.55...1.1 190 60 178 210...230 260 30 133
1.5...3.0 250 60 178 270...290 315 30 133
4.0…5.5 250 100 200 270...290 315 12 133
7.5…9.2 250 125 200 270...290 315 17.5 133
KFU 4-
0.55...1.5 190 60 178 210...230 260 30 133
1.85...4.0 250 60 178 270...290 315 30 133
5.5...9.2 250 100 200 270...290 315 12 133
11.0...15.0 250 125 200 270...290 315 17.5 133
18.5...30.0 250 200 260 270…290 315 20 160
37.0…65.0 400 275 260 425…445 470 20 160
KFU 2-/4-
9
KFU 4- (75.0 to 132.0 kW)
a
b
c
c1
c2
c3
b1
b2
b3
a1
x
x
x300 mm
x300 mm
The diameter of the mounting holes is 9 mm.
Screw the heat sink back panel of the frequency inverter to the assembly panel.
Dimensions without optional components:
Dimensions in mm Installation dimensions in mm
ACTIVE
Cube 401
kW a b c a1 b1 b2 b3 c1 c2 c3
75.0…132.0 510 412 351 480 392 382 342 338 305 110
