Plum Audio - DSO 150 EuroScope v2.0 - Build Guide!

Deign by Shay Shezifi

10.02.19

Jye Tech DSO 150

Eurorack Conversion Kit MKII

Build Guide

DSO 150 Is a cheap mini oscilloscope from JYE TECH.

This conversion kit lets you the ability to convert it to Eruorack module and contains

two parts:!

- 14 Hp Panel

- Conversion Board

- Optional: Expander 2Hp PCB+Panel

This is an easy DIY project, just follow this instructions guide.!

Assembling Video Playlist: https://www.youtube.com/watch?

v=Akz4jSZyOQc&list=PL2KBIbSMnGOh_Mu7Z_c3bYFIhDCGHZpcL

Plum Audio - DSO 150 EuroScope v2.0 - Build Guide!

Deign by Shay Shezifi

10.02.19

Bill Of Materials

Part/Value

Ref

Source

Notes

DSO150 Eurorack

panel mk2

Pusherman

DSO150 Conversion

Board mk2

Pusherman

Original Dso150

(15001K) DIY KIT

Banggood

There’s other places to buy this

kit, but you need pay attention

to:!

1. buy only the original kit of jye

tech version 2017.!

I’ve checked this source and it is

the original kit.

2. buy the DIY Kit and not the

assembled one.

L7809CV – 9v Voltage

Regulator (SMD)

IC1

Mouser

Mouser Part: 511-L78M09ABDT-TR!

(or AliExpress/eBay)

TL072 SMD - SOIC8

IC2

Mouser!

Tayda

Diode 1N5819HW

D1,D2

Mouser!

AliExpress

Plum Audio - DSO 150 EuroScope v2.0 - Build Guide!

Deign by Shay Shezifi

10.02.19

0.33uF – Tantalum

Capacitor (SMD 0805)

Mouser

Mouser Part: 581-TAJR334K020R

0.1uF – Ceramic

Capacitor <25v (SMD

0603/0805)

C2,C3,

Tayda!

Mouser!

AliExpress

10uF Electrolytic

Capacitor (SMD 4mm

dia) <25v

Mouser

Resistor 4.7R (SMD

1206)

R1, R3

Mouser

Resistor 51R (SMD

0603/0805)

Mouser

Tayda

Resistor 10M (SMD

0603/0805)

Mouser

Tayda

3X1 Male Pin Headers

Tayda

Cut from row of 40 pins

Jumper

Tayda

10 Pin Eurorack

Power Socket

Tayda

Box Header Type

3M - 6mm Standoffs

(Spacers) + 2 3M

Screws

AliExpress

The Nylon/Plastic Type are

better.!

To mount the conversion board

to dso150 main board.

3M – 12mm-16mm

Black Screws

AliExpress

To mount the panel to DSO150

mainboard and fix the screen

position.

PEC11L Encoder

SW6

(Main

Board)

Mouser

Mouser Part:652-PEC11L4215FS0015

* 30 Detent / 15 PPR

* SLIM Body!

SW6 on DSO150 Main Board.

PJ301M-12

“Thonkiconn”

Thonk

DPDT (ON-ON) Sub

Miniature Toggle

Switch

SW2,

SW3

Thonk

Encoder Knob

Thonk

Recommended - Sifam Large Soft

Encoder Knob – 12mm (D-Shaft)

10cm Wrapping Wires

Plum Audio - DSO 150 EuroScope v2.0 - Build Guide!

Deign by Shay Shezifi

10.02.19

Phase 1:

Assembling DSO 150 KIT

Basically, you need to follow the instructions in the user manual that come with your

DSO150 DIY Kit BUT you need to do only the steps below (and skip the others):

1. In the mainboard (Marked as “Step 1”) You need to solder only the Tact

Switches (Step 6) and desolder (or cut) the power socket.!

solder encoder in place (SW6).!

* DON’T REMOVE R30!!

Assembling Video Part 1: https://youtu.be/Akz4jSZyOQc!

2. In the Analog Board (Marked as “Step 2”) You need to solder only the

Resistors (Step 1), Capacitors (Steps 2 & 4) and the Pin-Header (Step 6).!

Assembling Video Part 2: https://youtu.be/BhblcA2ikeY

Plum Audio - DSO 150 EuroScope v2.0 - Build Guide!

Deign by Shay Shezifi

10.02.19

Phase 2:

Assembling Conversion Board!

Assembling Video Part 3: https://youtu.be/UtAiYVECAHI!

1. Solder all conversion board components (Regulator, Capacitors, Resistors,

Opamp, Diodes, Power Header, 3 Pin headers), Short with jumper 2 top pins.!

Plum Audio - DSO 150 EuroScope v2.0 - Build Guide!

Deign by Shay Shezifi

10.02.19

2. Put in place interface parts (do not solder them yet)!

- Thonkiconns!

- Toggle Switches (SW2, SW3)!

3. Connect the board to power source and check for 9v (+/- 10%) at J2!

Plum Audio - DSO 150 EuroScope v2.0 - Build Guide!

Deign by Shay Shezifi

10.02.19

Phase 3:

Assembling all together!

Assembling Video Part 4: https://youtu.be/F8vCOfcVhDU

1. Wiring!!

W1 – 6 Wires to SW1 @ DSO 150 analog board, from left to right: !

- 2 wires of AC !

- 2 Wires of DC !

- 2 Wires for switches signal output, You do not need to wire the GND.!

W2 – The square pad need to be wired to the signal input, It’s the lower hole of J1

(BNC Connector).!

The round pad Need to be wired to test signal tone (J8 @ DSO 150 Main Board).!

2. Mount the conversion board to the DSO150 mainboard with 2 3M 6mm

Standoffs spacers, Do Not forget to put in place the pin headers (J2), If

you need to expand the holes in the DSO150 mainboard you can rotate in

them a sharp knife or scissors.!

Plum Audio - DSO 150 EuroScope v2.0 - Build Guide!

Deign by Shay Shezifi

10.02.19

3. Solder J2 pin headers on both boards!

4. Before you mount the panel It’s good time to adjust trimmers C3 and C5 (Step

5 @ DSO 150 user manual). !

The test signal tone is normalised to the input jack if the jumper set to “Test

Tone”, so you don’t need to plug anything to the audio input for calibration,

just connect your module to a power supply and follow the DSO 150 manual

calibrations instructions (after calibration you can move the jumper to bottom

position).

Plum Audio - DSO 150 EuroScope v2.0 - Build Guide!

Deign by Shay Shezifi

10.02.19

5. Mount the panel to DSO150’s Mainboard with two 3M 12mm-16mm!

6. Solder The Interface parts:!

- Thonkiconn (J3)!

- Toggle Switches (SW2, SW3)!

Plum Audio - DSO 150 EuroScope v2.0 - Build Guide!

Deign by Shay Shezifi

10.02.19

Enjoy Your New DSO 150 EuroScope v2.0!!

www.plum-audio.com
