DIGITAL VIDEO CAMERA

GR-DVX709ED

GR-DVX509ED

GR-DVX400ED

GR-DVX709SH

GR-DVX509SH

ENGLISH

Automatic Demonstration 8

GETTING STARTED 9

VIDEO RECORDING &

PLAYBACK 18

DIGITAL STILL CAMERA

(D.S.C.) RECORDING &

PLAYBACK

ADVANCED FEATURES 37

REFERENCES 80

TERMS 102

Please visit our Homepage on the World Wide

Web and answer our Consumer Survey (in

English only):

For Accessories:

http://www.jvc-victor.co.jp/english/index-e.html

http://www.jvc-victor.co.jp/english/accessory

INSTRUCTIONS

The D.S.C. (Digital Still Camera) features are available on

GR-DVX709 and GR-DVX509.

The camcorder

illustrations appearing in

this instruction manual are

of the GR-DVX709.

GR-DVX709SH_00-Cover.fm Page 2 Wednesday, February 27, 2002 1:41 PM

2EN

Master Page: Left-Safety

GR-DVX709SH_02-08.fmPage 2

Using This Instruction Manual

●All major sections are listed in the Table Of Contents on the cover page.

●Notes appear after most subsections. Be sure to read these as well.

●Basic and advanced features/operation are separated for easier reference.

It is recommended that you…

…refer to the Index (墌pg. 94 – 101) and familiarise yourself with button locations, etc. before use.

…read thoroughly the Safety Precautions and Safety Instructions that follow. They contain extremely

important information regarding the safe use of this product.

SAFETY PRECAUTIONS

Dear Customer,

Thank you for purchasing this digital video camera. Before use, please read the safety information and

precautions contained in the following pages to ensure safe use of this product.

You are recommended to carefully read the cautions on pages 88 through 90 before use.

WARNING:

TO PREVENT FIRE OR SHOCK

HAZARD, DO NOT EXPOSE THIS

UNIT TO RAIN OR MOISTURE.

CAUTIONS:

●If you notice smoke or a peculiar smell coming

from the camcorder or AC Adapter, shut it down

and unplug it immediately. Continue using the

camcorder or AC Adapter under these

conditions could lead to fire or electric shock.

Contact your JVC dealer. Do not attempt to

repair the malfunction yourself.

●To prevent shock, do not open the cabinet. No

user serviceable parts inside. Refer servicing to

qualified personnel.

●When you are not using the AC Adapter for a

long period of time, it is recommended that you

disconnect the power cord from AC outlet.

NOTES:

●The rating plate (serial number plate) and safety

caution are on the bottom and/or the back of

the main unit.

●The rating information and safety caution of the

AC Adapter are on its upper and lower sides.

CAUTION:

To avoid electric

shock or damage to

the unit, first firmly

insert the small end

of the power cord

into the AC Adapter

until it is no longer

wobbly, and then plug the larger end of the power

cord into an AC outlet.

GR-DVX709SH_02-08.fm Page 2 Saturday, February 23, 2002 5:42 PM

EN 3

Master Page: Right-Safety

GR-DVX709SH_02-08.fmPage 3

CAUTIONS:

●This camcorder is designed to be used with PAL-type colour television signals. It cannot be used for

playback with a television of a different standard. However, live recording and LCD monitor/viewfinder

playback are possible anywhere.

●Use the JVC BN-V306U/V312U battery packs and, to recharge them or to supply power to the camcorder

from an AC outlet, use the provided multi-voltage AC Adapter and Power Cord. (An appropriate

conversion adapter may be necessary to accommodate different designs of AC outlets in different

countries.)

When the equipment is installed in a cabinet or on a shelf, make sure that it has sufficient space on all sides

to allow for ventilation (10 cm or more on both sides, on top and at the rear).

Do not block the ventilation holes.

(If the ventilation holes are blocked by a newspaper, or cloth etc. the heat may not be able to get out.)

No naked flame sources, such as lighted candles, should be placed on the apparatus.

When discarding batteries, environmental problems must be considered and the local rules or laws

governing the disposal of these batteries must be followed strictly.

The apparatus shall not be exposed to dripping or splashing.

Do not use this equipment in a bathroom or places with water.

Also do not place any containers filled with water or liquids (such as cosmetics or medicines, flower vases,

potted plants, cups etc.) on top of this unit.

(If water or liquid is allowed to enter this equipment, fire or electric shock may be caused.)

GR-DVX709SH_02-08.fm Page 3 Saturday, February 23, 2002 5:42 PM

4EN

Master Page: Left-Safety

GR-DVX709SH_02-08.fmPage 4

SAFETY PRECAUTIONS

Do not point the lens or the viewfinder directly into the sun. This can cause eye injuries, as well as lead to the

malfunctioning of internal circuitry. There is also a risk of fire or electric shock.

CAUTION!

The following notes concern possible physical damage to the camcorder and to the user.

When carrying, be sure to hold the camcorder firmly in your hand, with the grip strap securely around your

wrist. Carrying or holding the camcorder by the viewfinder and/or the LCD monitor can result in dropping the

unit, or in a malfunction.

Take care not to get your finger caught in the cassette holder cover. Do not let children operate the

camcorder, as they are particularly susceptible to this type of injury.

Do not use a tripod on unsteady or unlevel surfaces. It could tip over, causing serious damage to the

camcorder.

CAUTION!

Connecting cables (Audio/Video, S-Video, etc.) to the camcorder and leaving it on top of the TV is not

recommended, as tripping on the cables will cause the camcorder to fall, resulting in damage.

䡲This camcorder is designed exclusively for the digital video cassette, SD Memory Card and

MultiMediaCard. Only cassettes marked “ ” and memory cards* marked “ ” or

“ ” can be used with this unit.

Before recording an important scene…

… make sure you only use cassettes with the Mini DV mark .

… make sure you only use memory cards* with the mark or .

… remember that this camcorder is not compatible with other digital video formats.

… remember that this camcorder is intended for private consumer use only. Any commercial use without

proper permission is prohibited. (Even if you record an event such as a show, performance or exhibition for

personal enjoyment, it is strongly recommended that you obtain permission beforehand.)

* Memory cards can be used with GR-DVX709/509 only.

GR-DVX709SH_02-08.fm Page 4 Saturday, February 23, 2002 5:42 PM

EN 5

Master Page: Right-Safety

GR-DVX709SH_02-08.fmPage 5

* Attach the battery mount cover to protect the battery connector when the battery pack is removed. For the

attachment/detachment, refer to “Charging The Battery Pack” (墌pg. 10).

NOTE:

In order to maintain optimum performance of the camcorder, provided cables may be equipped with one or

more core filter. If a cable has only one core filter, the end that is closest to the filter should be connected to

the camcorder.

Provided Accessories

●AC Adapter

GR-DVX709/509/400ED:

AP-V10ED or AP-V12ED

GR-DVX709/509SH:

AP-V10EG or AP-V12EG

●Power Cord ●Battery Pack

BN-V306U

●Battery Mount Cover*

(Already attached on

the camcorder)

●Remote Control Unit

RM-V717U

●CD-ROM ●AAA (R03) Battery x 2

(for remote control unit)

●USB Cable

(GR-DVX709/509

only)

●PC Connection

Cable

(GR-DVX400 only)

●Memory Card 8 MB

(GR-DVX709/509 only)

(Already inserted in the

camcorder)

●Lens Cap

(墌pg. 7 for

attachment)

●Audio/Video Cable

(ø3.5 mini-plug to

RCA plug)

●Editing Cable

GR-DVX709/509:

Both plugs have 1 ring

around the pin.

GR-DVX400:

One plug has 3 rings

around the pin and

the other has 1 ring

around the pin.

●Grip Belt

(墌pg. 6 for

attachment)

●Finger Support

(墌pg. 6 for

attachment)

GR-DVX709SH_02-08.fm Page 5 Saturday, February 23, 2002 5:42 PM

6EN

Master Page: Left

GR-DVX709SH_02-08.fmPage 6

How To Attach The Grip Belt

NOTES:

●It is recommended to use the finger support so that

the tally lamp or the flash (GR-DVX709/509 only)

is unobstructed with your fingers.

●The grip belt can be attached to the camcorder

even if the finger support is not used. Be careful

not to cover the tally lamp or the flash

(GR-DVX709/509 only) when holding camcorder

without finger support.

1) Thread the finger support with the end of the strap

2) Thread the loop end gthrough the eyelet a, then

pass the other end of the strap hand the pad

through the loop end h.

3) Thread the end of the strap hthrough the eyelet

4) Thread the end of the strap through the buckle c.

Open the pad and fold the end of the strap hin

the pad. Then fold the pad.

5) Adjust the grip. (墌pg. 12)

GR-DVX709SH_02-08.fm Page 6 Saturday, February 23, 2002 5:42 PM

EN 7

Master Page: Right

GR-DVX709SH_02-08.fmPage 7

How To Attach The Lens Cap

To protect the lens, attach the provided lens cap to

the camcorder as shown in the illustration.

NOTE:

To confirm the lens cap is on correctly make sure the

cap is flush to the camcorder.

3) Attach the lens cap with the cut downward.

●During shooting

GR-DVX709SH_02-08.fm Page 7 Saturday, February 23, 2002 5:42 PM

8EN

Master Page: Left

GR-DVX709SH_02-08.fmPage 8

Automatic Demonstration

Automatic Demonstration takes place when “DEMO

MODE” is set to “ON” (factory-preset).

䡲Automatic Demonstration starts when there is no

operation for about 3 minutes after the Power Switch is

set to “A” or “M” and no cassette is in the camcorder.

䡲Performing any operation during the demonstration

stops the demonstration temporarily. If no operation is

performed for more than 3 minute after that, the

demonstration will resume.

䡲“DEMO MODE” remains “ON” even if the camcorder

power is turned off.

䡲To cancel Automatic Demonstration:

1) Set the Power Switch to “M” while pressing down the

Lock Button located on the switch.

2) Open the LCD monitor fully, or pull out the viewfinder

fully.

3) Press the MENU Wheel in. The Menu Screen appears.

4) Rotate the MENU Wheel to select “sSYSTEM”, and

press it. The SYSTEM Menu appears.

5) Rotate the MENU Wheel to select “DEMO MODE”,

and press it. The Sub Menu appears.

6) Rotate the MENU Wheel to select “OFF”, and press it.

7) Rotate the MENU Wheel to select “BRETURN”, and

press it twice. The normal screen appears.

NOTE:

Detach the lens cap to see the actual changes of the

Automatic Demonstration activated on the LCD monitor

or viewfinder.

MOD EDEMO

OFF

PLA

Power Switch

Lock Button

MENU Wheel

Sub Menu

GR-DVX709/

509 only

GR-DVX709SH_02-08.fm Page 8 Saturday, February 23, 2002 5:42 PM

Master Page: Right-SecCover

GR-DVX709SH_09-17.fm Page 9

EN 9

GETTING STARTED

Power ..................................................................................................10

Grip Adjustment .....................................................................................12

Viewfinder Adjustment ...........................................................................12

Tripod Mounting .....................................................................................13

LCD Monitor And Viewfinder ...................................................................13

Brightness Adjustment Of The Display ......................................................13

Operation Mode .....................................................................................14

Date/Time Settings ................................................................................15

Loading A Cassette/Unloading A Cassette .................................................16

Loading A Memory Card/Unloading A Memory Card

(GR-DVX709/509 only) .........................................................................17

CONTENTS

GR-DVX709SH_09-17.fm Page 9 Saturday, February 23, 2002 5:48 PM

10 EN

Master Page: Left

GR-DVX709SH_09-17.fm Page 10

This camcorder’s 2-way power supply system lets

you choose the most appropriate source of power.

Do not use provided power supply units with other

equipment.

Charging The Battery Pack

1With the arrow on the battery pack pointing to

the lens side, push the battery pack slightly

against the battery pack mount a, then slide the

battery pack until it locks in place b.

2Set the Power Switch to “OFF” while pressing

down the Lock Button located on the switch.

3Connect the AC Adapter to the camcorder c,

then connect the Power Cord to the AC Adapter

4Plug the Power Cord into an AC outlet e.

5The CHARGE Lamp on the camcorder blinks to

indicate charging has started.

6When the CHARGE Lamp stops blinking but

stays lit, charging is finished.

7Unplug the Power Cord from the AC outlet.

8Disconnect the AC Adapter from the camcorder.

To detach the battery pack...

While sliding and holding the BATT.RELEASE tab to

the right, remove it.

NOTES:

●

During charging, the camcorder cannot be operated.

●

If the protective cap is attached to the battery pack,

remove it first.

●

When charging the battery pack for the first time or

after a long storage period, the CHARGE Lamp may

not light. In this case, remove the battery pack from

the camcorder, then try charging again.

●

If the battery operation time remains extremely short

even after having been fully charged, the battery is

worn out and needs to be replaced. Please purchase

a new one.

●

For other notes,

墌

pg. 81.

Using The Battery Pack

Perform step 1 of “Charging The Battery Pack” in the

left column.

Approximate recording time

For GR-DVX709:

For GR-DVX509/400:

*Provided

NOTES:

●Recording time is reduced significantly under the

following conditions:

• Zoom or Record-Standby mode is engaged

repeatedly.

• The LCD monitor is used repeatedly.

• The playback mode is engaged repeatedly.

●Before extended use, it is recommended that you

prepare enough battery packs to cover 3 times the

planned shooting time.

Power

BATT.RELEASE

Tab

To AC outlet

To DC connector

Power Cord

Open the cover.

AC Adapter

Power Switch

CHARGE Lamp

Lock Button

Battery pack Charging time

BN-V306U Approx. 1 hr. 30 min.

BN-V312U

(optional)

Approx. 2 hr. 40 min.

Battery pack LCD monitor on Viewfinder on

BN-V306U* 45 min. 55 min.

BN-V312U 1 hr. 40 min. 2 hr.

BN-V840U 4 hr. 50 min. 5 hr. 40 min.

BN-V856U 7 hr. 20 min. 8 hr. 35 min.

Battery pack LCD monitor on Viewfinder on

BN-V306U* 50 min. 1 hr. 05 min.

BN-V312U 1 hr. 50 min. 2 hr. 15 min.

BN-V840U 5 hr. 20 min. 6 hr. 40 min.

BN-V856U 8 hr. 10 min. 10 hr. 10 min.

GETTING STARTED

GR-DVX709SH_09-17.fm Page 10 Saturday, February 23, 2002 5:48 PM

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels JVC caméscope

JVC

JVC GR-D33US Manuel utilisateur

JVC

JVC Everio GZ-HM30U Manuel d'utilisation et d'entretien

JVC

JVC ProHD GY-HM650 Manuel utilisateur

JVC

JVC GZ HD5 - Everio Camcorder - 1080i Manuel utilisateur

JVC

JVC GR-D270 Manuel utilisateur

JVC

JVC GR-AX710 Manuel utilisateur

JVC

JVC Everio GZ-MC500AA Manuel utilisateur

JVC

JVC Everio GZ-HD620BEK Manuel d'utilisation et d'entretien

JVC

JVC GZ-HD10E Manuel

JVC

JVC GZ-MG70E Manuel utilisateur

JVC

JVC GR-DV3000 Manuel utilisateur

JVC

JVC EVERIO GZ-HM650BUS Manuel utilisateur

JVC

JVC GZ-HM330SEK Manuel d'utilisation et d'entretien

JVC

JVC GR-D50EK Manuel utilisateur

JVC

JVC GZMG330AUS - Everio Camcorder - 680 KP Manuel utilisateur

JVC

JVC GR-SXM590AG Manuel utilisateur

JVC

JVC Everio GZ-MC200US Guide de l'administrateur

JVC

JVC TK-S250U - Ccd B/w Video Camera Manuel utilisateur

JVC

JVC GZ-RY980HE Manuel d'utilisation et d'entretien

JVC

JVC GZ-VX700BUS Manuel d'utilisation et d'entretien

JVC

JVC GR-AXM341 Manuel utilisateur

JVC

JVC GR-AX760 Manuel utilisateur

JVC

JVC GZ HD10 - Everio Camcorder - 1080p Manuel

JVC

JVC GZ-EX210 Everio Manuel utilisateur

Manuels caméscope populaires d'autres marques

Toshiba

Toshiba CAMILEO Z100 Manuel utilisateur

Panasonic

Panasonic NV-VS40B Manuel utilisateur

Canon

Canon RC 260 Manuel utilisateur

Sony

Sony Handycam DCR-DVD7E Manuel utilisateur

Brinno

Brinno TimeLapse TLC200 Manuel utilisateur

Panasonic

Panasonic AG-HMC152EN Manuel utilisateur

Insignia

Insignia NS-DCC5HB09 - Camcorder - 720p Manuel utilisateur

MYDLINK

MYDLINK DCS-6100LH Manuel utilisateur

Sony

Sony video Hi8 Handycam CCD-TR555 Manuel utilisateur

SECURECOM

SECURECOM V-5014B Manuel utilisateur

Panasonic

Panasonic HDC-SD100 Manuel utilisateur

Sharper Image

Sharper Image U-VIDEO Manuel utilisateur

Canon

Canon LEGRIA HV40 Manuel utilisateur

Sony

Sony Handycam DCR-VX2000 Manuel utilisateur

RCA

RCA CC616 Manuel utilisateur

Panasonic

Panasonic NVM40 Manuel utilisateur

ATIK Cameras

ATIK Cameras Horizon Manuel utilisateur

Sony

Sony Handycam HDR-CX580V Manuel utilisateur
