JVA Z11 Manuel utilisateur

JVA TECHNOLOGIES

www.jva-fence.com

User ManUal

Page 2 © JVA Technologies www.jva-fence.com

1 Quick Start Guide

1.1 THE FULL USER MANUAL

The compete user manuals can be downloaded here:

www.jva-fence.com/z11

www.jva-fence.com/z13

www.jva-fence.com/z14

www.jva-fence.com/z18

1.2 LOW VOLTAGE WIRING

Label Type Descripon

IN1 2 Way Energizer control input 1 (dry contact) internally wired

in parallel with the key switch. Arm energizer when

closed

GATE 2 Way Energizer control input 2 (dry contact). Default func-

on is gate input, normally closed. When the unit is

armed and the gate is opened, it will trigger the gate

alarm.

KEYPAD 3 Way Supplies power and data line for an external keypad.

The +12 source on these terminals is protected with

1A self reseng fuse.

SIREN 2 Way Switched 12V output. 30W max, shared between Si-

ren and Strobe. Low side switched

STROBE 2 Way Switched 12V output. 30W max, shared between Si-

ren and Strobe. Low side switched

Page 3

Label Type Descripon

16Vac 3 Way 16Vac 1.5A power input plus earth. Connecon of

the earth is only required where local safety or wir-

ing codes demand it. This should be connected to the

cabinet or mains earth NOT the fence earth.

Ba Battery

leads

12V dc or baery connecon via F1

(4 Amp slow blow fuse).

Relay 3 3 Way “Form C” relay with dry contacts. Default operaon

Fence Alarm

Relay 4 3 Way “Form C” relay with dry contacts. Default operaon

Zone Armed

Relay 5 3 Way “Form C” relay with dry contacts. Default operaon

General Alarm

1.3 JUMPERS

Jumpers allow you to turn on and o dierent features, or reset the device

to defaults.

JUMPER FUNCTION

J3 Inhibit AC fail error.

J3(Z14R) Tamper disable.

J4 Factory default jumper - on for normal operaon.

O to return programmable opons to factory defaults on

power up.

J8 Disable on board beeper

J5, J6 & J7 Supplies +12V to the Common terminal of Relay 3, 4, 5.

Jumpers located on the top right hand side of the board

Page 4 © JVA Technologies www.jva-fence.com

1.4 QUICK TEST OF CONFIGURED UNIT

It is a good idea to test the energizer before connecng the it to a fence.

This will give you condence that the unit is operang as expected and it

also isolates potenal fence issues.

To do this, connect your energizer with a “test fence” as shown.

Power the energizer and then Arm it. The unit should begin pulsing and

not show any alarms. Disarm the energizer and remove the fence cable as

shown.

Arm the energizer once again, aer 3 pulses (unless you congured it oth-

erwise) the unit should go into alarm as the fence will appear to be cut.

Check that any sirens, strobes or relays acvate as expected.

Page 5

1.5 CONNECTING TO THE FENCE

A convenonal fence installaon including earth loop monitoring.

Page 6 © JVA Technologies.

Z-Series Quick Start Manual

1.6 CHANGING THE PROGRAMMING OPTIONS

Default Installer PIN 012345

Default User PIN 1234

First you have to enter Programming mode.

Command Key1 Key2 Key3 Key4 Key5 Key6 Key7 Key8 Key9

Enter Programming Mode Installer Pin * 0 #

When you have entered Programming mode you can begin to enter the following opons to congure your Security

Energizer. Default Values are highlighted in grey.

Command Key1 Key2 Keys 3 and 4 Key5

Change The Installer PIN

6 Digits

0 0 Enter the new 6 digit Installer PIN #

High Power Mode Power

Level

0 1 0 0 0 1 0 2 0 3 0 4 0 5 0 6 0 7 0 8 0 9 #

Output Voltage (kV) Conventional

5.0 5.5 6.0 6.5 7. 0 7. 5 8.0 8.5 9.0 9.5

Output Voltage (kV) Bi-Polar

2.5 2.8 3.0 3.3 3.5 3.8 4.0 4.3 4.5 4.5

Z-Series Quick Start Manual Page 7

Command Key1 Key2 Keys 3 and 4 Key5

Low Power Mode Power

Level

0 2 00 01 02 03 04 05 06 07 08 09 #

Percentage of High Power Mode Power Level

0.5% 1.0% 1.5% 2.0% 2.5% 3.0% 3.5% 4.0% 4.5% 5.0%

Return Fence Alarm

Voltage For High Power

Mode

0 3 00 01 02 03 04 05 06 07 08 09 #

Fence Alarm Voltage (kV) Conventional

1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0

Fence Alarm Voltage (kV) Bi-Polar

1.5 1.8 2.1 2.4 2.7 3.0 3.3 3.6 3.9 4.2

Return Fence Alarm Volt-

age For Low Power Mode

0 5 00 01 02 03 04 #

300 Volts 500 Volts 700 Volts 900 Volts 110 0 Vo lt s

Bad/Missed Pulse Count

Before Alarm Triggers

0 6 00 01 02 03 04 05 06 07 08 09 #

0123456789

Battery Alarm

Voltage(volts). Alarm

Value Shown, Reduced

Power is 1V less

0 7 00 01 02 03 04 05 06 07 08 09 #

9.0 9.5 10.0 10.5 11.0 11. 5 12.0 12.5 13.0 13.5

Siren On Time

(S=Seconds, M=Minutes)

0 8 00 01 02 03 04 05 06 07 08 09 #

10S 30S 1M 2M 3M 4M 5M 20M 45M 130M

Siren O Time

(S=Seconds, M=Minutes)

0 9 00 01 02 03 04 05 06 07 08 09 #

10S 1M 2M 5M 10M 20M 30M 40M 50M 60M

Page 8 © JVA Technologies.

Z-Series Quick Start Manual

Command Key1 Key2 Keys 3 and 4 Key5

Siren Cycles 1 0 00 01 02 03 04 05 06 07 08 09 #

0123456789

Input Type 1 1 00 01 #

Normally Open (NO) Normally Closed (NC)

Input 2 Function 1 2 00 01 #

Gate Low Power

Gate Entry/Exit Delay

(S=Seconds, M=Minutes)

1 3 00 01 02 03 04 05 06 07 08 09 #

0S 30S 1M 2M 3M 4M 5M 6M 7M 8M

Chime Mode 1 4 01 02 03 04 05 #

None Door Chime Siren Fence Alarm Gate Beeps

Plus Siren

Combined Options 1

(add up the options you

want. e.g. for Max Power

and Limit output:

2 + 4 = 6 Therefore enter

06 for keys 3 and 4

1 6 +2 +4 +8 +16 +32 #

Maximum

Power at all

times

Limits out-

put to 2.5J

per Zone

Enables IR

Tamper.

Stop slaves

on comms

fail

Stop Ener-

giser send-

ing alarm

memory

Anti Bridging threshold 1 7 Enter in the percentage dierence required to trigger the Anti-Bridging

alarm. e.g. if you require a 10% change in return voltage to trigger the

alarm, enter 10 for keys 3 and 4

Z-Series Quick Start Manual Page 9

Command Key1 Key2 Keys 3 and 4 Key5

Combined Options 2

(like Combined Options 1)

1 8 +1 +2 +4 +8 #

Siren Codes

(Chirps 1 for

armed, twice for

disarmed)

Gate Delay Type 4800 baud 9600 baud

Auto Re-arm Time

(S=Seconds, M = Minutes,

D=Disabled

2 0 00 01 02 03 04 05 06 07 08 09 #

0S 30S 1M 2M 3M 4M 5M 6M 7M D

Relay 1 2 1 Options Explained under “1.1.1 Relay Functions” Default is 08 #

Relay 2 2 2 Options Explained under “1.1.1 Relay Functions” Default is 09 #

Relay 3 (if Fitted) 2 3 Options Explained under “1.1.1 Relay Functions” Default is 00 #

Relay 4 (if Fitted) 2 4 Options Explained under “1.1.1 Relay Functions” Default is 02 #

Relay 5 (if Fitted) 2 5 Options Explained under “1.1.1 Relay Functions” Default is 07 #

Group Mode 2 6 00 01 02 etc 15 #

No Group Master Slave 1 Slave 14

Exit Programming Mode * #

Z-Series Quick Start Manual

1.6.1 Relay Funcons

The table below is for use for the relay programming opons menoned in the table on the previous page.

Keys 3

and 4

Funcon Descripon

00 Fence Triggers when Zone 1 is Armed and Return Voltage is below the Threshold Voltage

01 Fence or O Triggers when Zone 1 is Disarmed or Return Voltage is below the Threshold Voltage

02 Armed Zone 1 is Armed

06 Fence Bi-Polar Triggers when energizer is Armed and the fence Return Voltage on either Bi-Polar re-

turn line has fallen below the Threshold Voltage

07 General Triggers on AC Fail, Tamper, Low Baery/Bad Baery, Gate Alarm or Internal error.

Latched (internal errors only)

08 Siren Triggers on Fence Alarm, Gate or Tamper. Will me out aer the Siren Time Out me.

Latched

09 Strobe Triggers on Fence alarm, Gate or Tamper. Only turns o on Energizer Disarm. Latched

10 AC Fail Triggers on AC Fail

11 Low/Bad Battery Triggers on Low or Bad Battery

12 Tamper Triggers when the case has been opened and J3 has been tted (Z14R only)

14 Gate Triggers on Gate Alarm

15 Siren Caused by

Gate

Behaves like siren, only for Gate Alarms

16 Armed - Low

Power Mode

Triggers when Armed in Low Power mode
