Quick Start Guide

PTX1000

IN THIS GUIDE

Step 1: Begin | 1

Step 2: Up and Running | 4

Step 3: Keep Going | 6

Step 1: Begin

IN THIS SECTION

Mount the PTX1000 | 2

Connect Power to the PTX1000 | 3

To install and configure a Juniper Networks PTX1000 Router, you need:

•Either a mechanical lift or two people to lift the PTX1000 into place and another person to secure it to the rack

•An electrostatic discharge (ESD) grounding strap (not provided)

•A pair of front-mounting rails (provided)

•A pair of rear-mounting blades (provided)

•Flat-head M4x6-mm Phillips mounting screws to secure the mounting rails to the chassis (24 screws are provided—11

for each side and 2 extra screws)

•Sixteen screws to secure the chassis and mounting blades to the rack (not provided)

•Screwdriver appropriate for the rack mounting screws (not provided)

•Four power cords with plugs appropriate for your geographical location (provided)

•RJ-45 cable and RJ-45 to DB-9 serial port adapter (provided)

•Management host, such as a PC laptop, with a serial port (not provided)

•(Optional) Grounding cable with lug, screws, and washers (not provided)

Mount the PTX1000

NOTE: If you are mounting multiple units in the rack, mount the heaviest unit at the bottom and mount the

others from bottom to top in order of decreasing weight. The PTX1000 weighs 68.6 lb (31.1 kg). Installing the

router in a rack requires either a mechanical lift or two people to lift the device and another person to secure it

to the rack.

The PTX1000 can be mounted in a four-post rack configuration. To mount the device in a standard 19-inch rack:

1. Attach the ESD grounding strap to your bare wrist and to a site ESD point.

2. Place the rack in its permanent location, allowing adequate clearance for airflow and maintenance, and secure it to the

building structure.

3. Decide whether the field-replaceable unit (FRU) end of the PTX1000 or the port end is to be placed at the front of the

rack. Position the PTX1000 in such a manner that the AIR OUT labels on components are next to the hot aisle.

4. Using a Phillips screwdriver, remove the six screws on each side of the chassis that hold the cover to the chassis (see

the illustration below for screw locations). These screws will be replaced with the mounting screws included in the

box.

5. Align one of the front-mounting rails with the screw holes on the side of the chassis.

6. Attach the mounting rail to the PTX1000 by using 11 flat-head M4x6-mm Phillips mounting screws. Tighten the screws.

7. Repeat Step 5 and Step 6 on the opposite side of the PTX1000.

8. Either use a mechanical lift or have two people grasp both sides of the PTX1000, lift it, and position it in the rack so

that the front bracket is aligned with the rack holes.

9. Have another person secure the front of the PTX1000 to the rack by using eight mounting screws (and cage nuts and

washers if your rack requires them). Tighten the screws.

10. Continue to support the PTX1000 while sliding the rear-mounting blades into the channel of the side-mounting rails

and securing the blades to the rack (see the illustration below). Use eight mounting screws (and cage nuts and washers

if your rack requires them) to attach to the blade to the rack. Tighten the screws.

11. Ensure that the PTX1000 chassis is level by verifying that all the screws on the front of the rack are aligned with the

screws at the back of the rack.

12. (Optional) Attach a grounding cable to earth ground and then attach it to the chassis grounding point.

Connect Power to the PTX1000

The PTX1000 is supplied with four factory-installed power supplies. For instructions on connecting DC power, see the

installation instructions in the PTX1000 documentation.

To connect power to a PTX1000 with AC power supplies:

1. If the AC power source outlet has a power switch, set it to the OFF (0) position.

2. Insert the coupler end of the power cord into the AC power cord inlet on the AC power supply faceplate.

3. Push the power cord retainer onto the power cord.

4. Insert the power cord plug into the power source outlet.

5. If the AC power source outlet has a power switch, set it to the ON (|) position.

6. Verify that the status LED for each power supply is lit green and on steadily.

Step 2: Up and Running

IN THIS SECTION

Set Parameter Values | 4

Perform the Initial Configuration | 4

Set Parameter Values

You must perform the initial configuration of the PTX1000 through the console port. Before you begin, set the following

parameter values from the console server or PC:

•Baud Rate—9600

•Flow Control—None

•Data—8

•Parity—None

•Stop Bits—1

•DCD State—Disregard

Perform the Initial Configuration

To connect and configure the PTX1000 from the console:

1. Connect the console port to a laptop or PC using the provided RJ-45 cable and RJ-45 to DB-9 serial port adapter. The

console (CON) port is located on the port panel of the router.

2. Log in as root. There is no password. If the software booted before you connect to the console port, you might need

to press the Enter key for the prompt to appear.

3. Start the command-line interface (CLI).

root@% cli

4. Enter configuration mode.

root> configure

5. Add a password to the root administration user account. Enter a plain-text password

[edit]

root@# set system root-authentication plain-text-password

New password: password

Retype new password: password

6. (Optional) Configure the name of the PTX1000. If the name includes spaces, enclose the name in quotation marks (“

”).

[edit]

root@# set system host-name host-name

7. Configure the default gateway.

[edit]

root@# set routing-options static route default next-hop address

8. Configure the IP address and prefix length for the router management interface.

[edit]

root@# set interfaces em0 unit 0 family inet address address/prefix-length

NOTE: The RJ-45 management port, em0, and SFP management port, em1, are found on the management

panel of the PTX1000. They are both labeled MGMT.

9. (Optional) Configure the static routes to remote prefixes with access to the management port.

[edit]

root@# set routing-options static route remote-prefix next-hop destination-IP retain no-readvertise

10. Enable Telnet service.

[edit]

root@# set system services telnet

11. Enable SSH service.

[edit]

root@# commit

Step 3: Keep Going

IN THIS SECTION

Safety Warnings Summary | 6

Power Cable Warning (Japanese) | 7

Contacting Juniper Networks | 7

See the complete PTX1000 documentation at https://www.juniper.net/documentation/product/en_US/ptx1000.

Safety Warnings Summary

This is a summary of safety warnings. For a complete list of warnings, including translations, see the PTX1000 documentation

at https://www.juniper.net/documentation/product/en_US/ptx1000.

WARNING: Failure to observe these safety warnings can result in personal injury or death.

•Permit only trained and qualified personnel to install or replace PTX1000 components.

•Perform only the procedures described in this quick start and the PTX1000 documentation. Other services must be

performed only by authorized service personnel.

•Before installing the PTX1000, read the planning instructions in the PTX1000 documentation to make sure that the site

meets power, environmental, and clearance requirements for the router.

•Before connecting the router to a power source, read the installation instructions in the PTX1000 documentation.

•The PTX1000 weighs 68.6 lb (31.1 kg). Installing the router in a rack or cabinet requires either a mechanical lift or two

people to lift the device and another person to secure it to the rack. To prevent injury, keep your back straight and lift

with your legs, not your back.

•If the rack or cabinet has stabilizing devices, install them in the rack before mounting or servicing the PTX1000 in the

rack or cabinet.

•Before installing or after removing an electrical component, always place it component-side up on a flat antistatic mat

or in an antistatic bag.

•Do not work on the PTX1000 or connect or disconnect cables during electrical storms.

•Before working on equipment that is connected to power lines, remove jewelry, including rings, necklaces, and watches.

Metal objects heat up when connected to power and ground and can cause serious burns or become welded to the

terminals.

Power Cable Warning (Japanese)

The attached power cable is only for this product. Do not use this cable for another product.

g040300

Contacting Juniper Networks

For technical support, see:

http://www.juniper.net/support/requesting-support.html

Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc. in the

United States and other countries. All other trademarks, service marks, registered marks, or registered service marks are the

property of their respective owners. Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper
