1 Safety instructions ............................................................................................................ 3
2 Device components .......................................................................................................... 4
3 Intended use..................................................................................................................... 5
4 Operation.......................................................................................................................... 5
5 Information for electrically skilled persons........................................................................ 8
6 Technical data ................................................................................................................ 10
2 / 11
82406413 20.07.2023
J0082406413
Heating actuator 6-gang with controller
1 Safety instructions
Electrical devices may be mounted and connected only by electrically skilled
persons.
Serious injuries, fire or property damage are possible. Please read and follow the
manual fully.
Danger of electric shock. Always disconnect before carrying out work on the device
or load. In so doing, take all the circuit breakers into account, which support danger-
ous voltages to the device and or load.
Danger of electric shock. Device is not suitable for disconnection from supply voltage
because mains potential even is applied on the load when the device is switched off.
Before carrying out work on the device or load, switch off all corresponding circuit
breakers.
This manual is an integral part of the product, and must remain with the customer.
Heating actuator 6-gang with controller
3 / 11
82406413 20.07.2023
J0082406413
2 Device components
Image1: Front view
(1) Supply of electrothermal valve drives
(2) Connection of electrothermal valve drives (A1 to A6)
(3) Status LEDs for outputs
(4) Button field for manual operation
(5) Programming button and LED
(6) Bus connection
If all of the status LEDs (3) are flashing (2 Hz), the device is indicating that
there is no power supply to the electrothermal valve drives (1).
Heating actuator 6-gang with controller
4 / 11
82406413 20.07.2023
J0082406413
3 Intended use
– Switching of electrothermal valve drives for heaters or cooling ceilings
– Operation in KNX system
– Installation in sub-distribution units on DIN rail according to DIN EN 60715
4 Operation
(3) Status LEDs for outputs
(7) ǃ button – Manual operation
LED - On: permanent manual operation mode active
(8) Open button – Open valve
LED – On: valve opened, manual operation mode
(9) Close button – Close valve
LED – On: valve closed, manual operation mode
(10) ALL OP / CL button – Central operating function for all outputs in case of
permanent manual operation: Open and close all valves alternately
Status display and output behaviour
The status LEDs A1...A6 (3) show whether the current flow is switched on or
switched off at the appropriate output. The connected heating or cooling valves open
and close according to their characteristics.
Valve drive Status LED on Status LED off
Deenergised closed Heating/cooling
Valve opened
Valve closed
Deenergised opened Valve closed Heating/cooling
Valve opened
– Status LED flashes slowly: output in manual operation mode
– Status LED flashes quickly: output disabled via permanent manual operation
mode
Operating modes
– Bus operation: operation via push-button sensors, for example
– Temporary manual operation mode: manual operation on device with button
field, automatic return to bus mode
– Permanent manual operation mode: exclusively manual operation on the
device
No bus operation is possible in manual mode.
All controlled valve outputs switch off after bus voltage failure.
Switching on temporary manual operation mode
Operation is not disabled.
Heating actuator 6-gang with controller
5 / 11
82406413 20.07.2023
J0082406413
￭ Press the ǃ button briefly.
Status LED A1 flashes, LED ǃ flashes.
After 5 seconds without button actuation, the actuator returns automatically to
bus mode.
Switching off temporary manual operation mode
The device is in short-term manual mode.
￭ No button has been actuated for 5 seconds.
- or -
￭ Press the ǃ button briefly as many times as necessary until the actuator exits
temporary manual operation mode.
Status LEDs A1...A6 no longer flash, but indicate the status.
Switching on permanent manual operation mode
Operation is not disabled.
￭ Press the ǃ button for at least 5 seconds.
LED ǃ is illuminated, status LED A1 flashes, permanent manual operation
mode is switched on.
Switching off permanent manual operation mode
The device is in permanent manual operation mode.
￭ Press the ǃ button for at least 5 seconds.
LED ǃ is off, status LEDs A1...A6 no longer flash, bus mode is switched on.
Operating the outputs
In manual operation mode the outputs can be operated instantly.
The device is in permanent or temporary manual operation mode.
￭ Press the ǃ button briefly, < 1 s, as many times as necessary until the de-
sired output is selected.
The status LED of the selected output A1...A6 flashes.
The LEDs Open and Close indicate the status.
￭ Press the Open button.
Valve opens.
￭ Press the Close button.
Valve closes.
The LEDs Open and Close indicate the valve status.
Heating actuator 6-gang with controller
6 / 11
82406413 20.07.2023
J0082406413
Short-term manual mode: After running through all of the outputs the device
exits manual mode after another brief actuation.
Operating all outputs simultaneously
The device is in permanent manual operation mode.
￭ Press the ALL OP / CL button.
All the valves open and close alternately.
In contrast to the operating function using the OPEN or CLOSE buttons, the actuator
always activates the valve outputs with a constant signal (0% or 100%), when they
are activated simultaneously. This causes the valves to close or open completely. No
pulse width modulation is executed.
Disabling individual outputs
The device is in permanent manual operation mode.
￭ Press the button ǃ briefly as many times as necessary until the desired out-
put is selected.
The status LED of the selected output flashes.
￭ Press buttons Open and Close simultaneously for at least 5 seconds.
Selected output is disabled.
The status LED of the disabled output flashes quickly.
￭ Deactivate permanent manual operation mode(see chapter "Operation" }
Page 6).
A disabled output can be operated in manual mode.
Re-enabling outputs
The device is in permanent manual operation mode.
￭ Press the button ǃ briefly as many times as necessary until the desired out-
put is selected.
￭ Press buttons Open and Close simultaneously for at least 5 seconds.
Selected output is enabled.
Status LED of the enabled output flashes slowly.
￭ Deactivate permanent manual operation mode (see chapter "Operation" }
Page 6).
Heating actuator 6-gang with controller
7 / 11
82406413 20.07.2023
J0082406413
5 Information for electrically skilled persons
DANGER!
Electric shock when live parts are touched.
Electric shocks can be fatal.
Always disconnect before carrying out work on the device or load. For this, switch off
all the corresponding circuit breakers, secure against being switched on again, and
check that there is no voltage. Cover up adjacent live parts.
Mount device
– Enter or scan the device certificate and add it to the project. A high resolution
camera should be used to scan the QR code.
– The device certificate should be removed from the device during mounting.
– Document all passwords and keep them safe.
Observe ambient temperature. Ensure adequate cooling.
￭ Mount device on DIN rail.
Connect device
Connect either AC 230 V or AC 24 V valve drives to all the outputs.
Only connect valve drives with the same characteristics to each output (deenergised
closed/opened).
Do not connect any other loads.
Connect valve drives for frost-sensitive rooms to outputs A1 and A4. These are
switched off last in the event of overload.
Do not exceed maximum number of valve drives per output.
Observe the technical data of the valve drives used.
Do not connect the neutral conductor from the output terminals through to additional
devices.
￭ Connect AC 230 V valve drives according to the connection diagram
(see figure 2).
Heating actuator 6-gang with controller
8 / 11
82406413 20.07.2023
J0082406413
Image2: Connection of actuators 230 V
￭ Connect AC 24 V valve drives according to the connection diagram
(see figure 3).
Image3: Connection of actuators 24 V
￭ Connect the supply for the valve drives to the terminals 8(L) and 8(N) (1).
￭ Connect bus line with device connection terminal observing the correct polar-
ity.
￭ Attach the cover cap to the bus connection as protection against hazardous
voltages.
Commissioning
The device is commissioned with the ETS from version 5.7.7 or 6.0.3.
Heating actuator 6-gang with controller
9 / 11
82406413 20.07.2023
J0082406413
6 Technical data
KNX
KNX medium TP256
Commissioning mode S mode
Rated voltage KNX DC 21 ... 32 V SELV
Current consumption KNX 4.5 ... 10 mA
Heating outputs
Contact type Semi-conductor (Triac), ε
Switching voltage AC 24 / 230 V ~
Mains frequency 50 / 60 Hz
Switching current 5 ... 160 mA
Switch-on current max. 1.5 A (2 s)
Switch-on current max. 0.3 A (2 min)
Number of drives per output
230 V drives max. 4
24 V drives max. 2
Housing
Installation width 72 mm / 4 HP
Clampable cable cross-sections (see figure 4)
Ambient conditions
Ambient temperature -5 ... +45°C
Storage/transport temperature -25 ... +70°C
Connection torque, screw terminals max. 0.8 Nm
Image4: Clampable conductor cross-section
