Johnson Controls EasyIO FS Series Manuel utilisateur

EasyIO FS Series

BACnet User Guide

LIT-12013777

Disclaimer

Confidentiality Notice

The information contained in this document is confidential information of Johnson Controls (S) Pte Ltd. Such

information and the software described herein, is furnished under a license agreement and may be used

only in accordance with that agreement.

The information contained in this document is provided solely for use by Johnson Controls (S) Pte Ltd employees,

licensees, and system owners; and, except as permitted under the below copyright notice, is not to be released to, or

reproduced for, anyone else.

While every effort has been made to assure the accuracy of this document, Johnson Controls (S) Pte Ltd is not

responsible for damages of any kind, including without limitation consequential damages, arising from the application of

the information contained herein. Information and specifications published here are current as of the date of this

publication and are subject to change without notice. The latest product specifications can be found by contacting our

corporate headquarters or support channel.

Trademark Notice

EasyIO logos are registered trademarks of Johnson Controls (S) Pte Ltd.

BACnet and ASHRAE are registered trademarks of American Society of Heating, Refrigerating and Air-

Conditioning Engineers. All other product names and services, mentioned in this publication, that are

known to be trademarks, registered trademarks, or service marks are the property of their respective

owners.

Freeboard is an open source real time Dashboard builder.

This document may not, in whole or in part, be copied, photocopied, reproduced, translated, or reduced

to any electronic medium or machine-readable form without prior written consent from Johnson Controls (S) Pte Ltd

Disclaimer

The material in this manual is for information purposes only. The contents and the product it

describes are subject to change without notice. Johnson Controls (S) Pte Ltd makes no

representations or warranties with respect to this manual. In no event shall Johnson Controls (S) Pte Ltd be liable for any

damages, direct or incidental, arising out of or related to the use of this manual.

Johnson Controls (S) Pte Ltd

31, International Business Park,

#03-02, Singapore 609921

Singapore 609921

Worldwide and Asia Pacific Support: [email protected]

Americas Support: [email protected]

Europe Support: [email protected]

United States

Canada

This Class (B) digital apparatus meets all the requirements of the Canadian Interference-Causing Equipment Regulations.

Cet appareil numérique de la Classe (B) respecte toutes les exigences du Règlement sur le matériel brouilleur du

Canada.

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two

conditions:

This device may not cause interference, and

This device must accept any interference, including interference that may cause undesired operation of the

device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.

L'exploitation est autorisée aux deux conditions suivantes :

L'appareil ne doit pas produire de brouillage, et

L'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en

compromettre le fonctionnement.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions,maycause harmful interference toradio communications. However, there is no guarantee

that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from that to which the receiver isconnected.

•

Consult the dealer or an experienced radio/TV technician for help.

Warning (Part 15.21)

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to

operate the equipment.

Table of Contents

Introduction ................................................................................................................................................................... 5

Prerequisites .................................................................................................................................................................. 5

BACnet server configuration limitations........................................................................................................................ 5

BACnet server configuration.......................................................................................................................................... 6

BACnet schedule...................................................................................................................................................... 11

BACnet calendar ...................................................................................................................................................... 11

BACnet trend ........................................................................................................................................................... 12

BACnet client configuration limitations....................................................................................................................... 12

Device and points limitation.................................................................................................................................... 12

BACnet client configuration......................................................................................................................................... 13

SA bus devices ......................................................................................................................................................... 19

Tech tips....................................................................................................................................................................... 21

BACnet MSTP best practice (EIA-485).......................................................................................................................... 21

Technical support......................................................................................................................................................... 22

Introduction

The EasyIO® FS series operates as a BACnet device and BACnet client. The series handles the following BACnet

protocols:

•BACnet IP server

•BACnet MSTP server

•BACnet IP Client

•BACnet MSTP Client

Prerequisites

A prerequisite for the FS series is the latest version of CPT Tools. The firmware must also be V3.0b51b or later.

BACnet server configuration limitations

The FS series controller does not provide power on the SA bus. You must use an external power source.

Objects supported

Properties supported

Optional properties

supported

Total objects

( FS series )

Device

Object Identifier

Object Name

APDU Timeout

Number Of APDU Retries

Max Master

Max Info Frames

Description

Binary value (BV)

Object Identifier

Object Name

Present Value

Relinquish Default

Description

Priority Array

Relinquish Default

512

(BV 0 ~ BV 511)

Analog value (AV)

Object Identifier

Object Name

Present Value

Relinquish Default

Description

Priority Array

Relinquish Default

512

(AV 0 ~ AV 511)

Multistate value (MV)

Object Identifier

Object Name

Present Value

Relinquish Default

Description

Priority Array

Relinquish Default

State Text (32)

512

(MV 0 ~ MV 511)

Binary

schedule

Object Identifier

Object Name

Effective Period

Schedule Default

Priority for Writing

Weekly Schedule

Exception Schedule

Description

Present Value

Reliability

Schedule 0 ~ Schedule 31

Analog schedule

Object Identifier

Object Name

Effective Period

Schedule Default

Priority for Writing

Weekly Schedule

Exception Schedule

Description

Present Value

Reliability

Schedule 32 ~ Schedule 64

Calendar

Object Identifier

Description

BACnet server configuration

You can deploy the architecture of the driver, as per the below procedure. You can drop the network object

anywhere in the Sedona app tree. It is best practice to create a separate folder for each network.

Bacnet Service

Bacnet Server Network (IP and MSTP)

Points (BACnet server objects)

The BACnet driver kit, easyioFGBACnet,is dependent on the installation of the easyioFGDriver. To install both kits

to enable configuration of the BACnet network in an FS series device, complete the following steps:

1. Connect to the controller with Sedona Workbench or CPT Tools with the following default logon

credentials:

•IP address: 192.168.10.12

•Username: admin

•Password: <no password>

2. To add the kits to the controller, navigate to the kit management and install easyioFGBACnet and

easyioFGDriver on your controller.

3. Select easyioFGBACnet from the kit library, drag the BACService object into the EasyIO folder on your app.

Alternatively, you can create a new folder for the Service Object. In the following example, the object is in

a new folder with a BACnet label.

Object Name

Date List

Present Value

(Calendar 0 ~ Calendar 15)

Trend logs

(Support boolean,

float and integer)

Object Identifier

Object Name

Object Type

Enable

Stop When Full

Buffer Size

Log Buffer

Record Count

Total Record Count

Event State

Logging Type

Status Flag

Log Interval

Description

Trigger

(Trend 0 ~ Trend 31)

4. To view the property on the property sidebar, click the BACnet service object. In the below example, there

is the configuration of the BACnet communication parameters, such as the MSTP MAC address.

5. Select the BACnet communication stack that you want to enable. By default, both the IP stack and MSTP

stack are disabled.

Note: For the MSTP connection, Port 1 is supported. Port 2 does not support BACnet MSTP. EasyIO FS

series is not a BBMD device or BACnet router. The FS BACnet service can register itself to a BBMD device

to receive broadcast messages through the bbmdEnable, bbmdIp, and bbmdTTL properties. If BBMD is not

preset or required in the network, these properties must be blank. If the communications stack is

configured correctly, the status displays OK.

FS Series Baud Rate Supported

9.6k , 19.2K, 38.4K, 76.8K

6. From the easyioFGBACnet object, drag BACnetServerNetwork into the BACnet service object on your app.

Note: The BACnet server and BACnet client object can coexist under the BACnet service object. There can

only be one BACnet service object in a controller. You cannot duplicate the BACnet service object.

7. To view the property on the property sidebar, click the Server Network object and enable the server

network. If the IP service and MSTP service are enabled correctly for the BACnet Service object, the status

displays OK.

8. Drag the BACServerBV, BACServerAV, BACServerMSV, BACServerTrend, or BACSchedule type object under

the Network object. The register object must be a child folder of the network object.

Note: By default, all registers are set to the disabled mode of enable = false. If you want other systems,

such as BACnet client, to discover the register, you must enable each register object in the application. By

default, the registers are named according to the type followed by the address number. To enter a

preferred name for the object, right-click the object and select selObjectName or manually enter the

object name in the property sidebar. The maximum number of characters permitted for objectName is 63.

As shown in the figure, you must also add the instanceNumber object. The instance number limitation is 0

to 512.

9. Use the manual process to link a valid value to the BACnet objects. The BACnet objects do not export any

valid value by themselves. In the following figure, to export a valid temp value as a BACnet object, write

from the temp value to the BACnetAV object.
