VA9300

Non Spring Return Actuators for Ball Valves

Product Bulletin

■Automatic Signal Input Detection model On/Off, Floating and Proportional

Increase availability at distributors. Simplify retrofit.

■High speed actuator model

Allow applications in loop that require a quick response time.

■Optional Auxiliary Switch & potentiometer feedback

Provides line voltage capable single Pole Double-Throw (SPDT) switch and 140Ω, 1KΩ, 2KΩ or 10KΩ feedback

potentiometric.

■Direct-Coupled Design

Requires no separate linkage because the VA9300 Series Actuators are ready for direct attachment to Johnson

Controls VG1000 Series valves by driving one captive screw.

■Rugged IP54 Rated Enclosure

Provides a high degree of protection from dust, splashing water and rough handling.

■Electronic Stall Detection

Protects from overload at all angles of rotation. The actuator may be stalled anywhere in its rotation range without the

need for mechanical end switches.

■Microprocessor-controlled Brushless DC Motor

Provides constant runtime independent of torque and increases life cycle by reducing wear.

The VA9300 Series Electric Non Spring Return

Actuators are used to provide accurate positioning

on Johnson Controls®VG1000 Series DN15

up to DN150 ball valves in Heating, Ventilating

and Air Conditioning (HVAC) applications from 8

to 35 Nm rated torque.

PB_VA9300_05 2020

Installation

Install the ball valve with the actuator at or above the center line of the horizontal piping.

WARNING: In steam applications, install the valve with

the stem horizontal to the piping.

Failure to follow this precaution may shorten the life of the

actuator.

WARNING: Do not install or use this actuator in or near

environments where corrosive substances or vapors

could be present.

Exposure of the actuator to corrosive environments may

damage the device's internal components, and will void

the warranty.

Mounting the actuator Inline to the Valve

1. Make sure the valve stem is inline to the valve Openings.

A C

2. Verify that the actuator handle is inline to the actuator.

100

3. Place the actuator inline into the valve.

4. Tighten the actuator handle to the valve.

PB_VA9300_05 2020

1. Loosen but do not remove the screw that holds the

actuator to the valve.

2. Remove the actuator from the valve.

3. Press and hold the gear release.

The actuator should be against the internal CCW stop.

4. Lift the handle out of the actuator and rotate 90°

counterclockwise.

90°

5. Reinsert the handle perpendicular into the actuator and

tighten the handle screw.

Mounting the Actuator Perpendicular to the Valve

PB_VA9300_05 2020

M9000-561 Thermal Barrier

The Thermal barrier optional kit extends the application of the VA9310 actuators in combination with VG1000 ball valves.

Linking together valve and actuator using the M9000-561 you can include applications with low pressure steam up to

123°C at 103kPa (250°F at 15 psig) and hot water up to 140°C (284°F).

PB_VA9300_05 2020

DA Not

used

Not

used

LED

DA 0-10

RA 2-10

Enter/

Autocal

Span Adj.

Offset Adj.

INC. DA 0-10

RA 2-10

Enter/

Autocal

LED

Accessing the DIP Switches

Locate the oval cover on the front of the unit and pull the cover outward. See installation sheet for further information, DIP

switches and LEDs meaning.

Automatic Signal Input Detection model

VA9310-HGA-1, VA9320-HGA-1 and VA9335-HGA-1 Actuator operate with 24 VAC/DC to provide 10, 20 and 35 Nm rated

torque. The actuators can be used with on/off, floating, or proportional controllers in HVAC systems that are controlled by

an electronic controller or positioner.

When the Actuators work in proportional mode, the actuator responds to 0 to 10 VDC or 2 to 10 VDC control signals. With

the addition of a 500 ohm resistor, the actuator responds to a 0 to 20 mA or 4 to 20 mA signal. A 0 to 10 VDC or 2 to 10

VDC feedback signal indicates position.

DIP Switches Settings

Command Signal Feedback Signal Setting User Interface

0 to 10 VDC

Direct

0 to 10 VDC

DA 0-10

RA 2-10

100%

10V

0V 5V 12V

Flow

Set Point

24 VAC

Floating or ON/OFF

0 to 10 VDC

Reverse

0 to 10 VDC

DA 0-10

RA 2-10

10V

0V 5V 12V

100%

Flow

Set Point

24 VAC

Floating or ON/OFF

2 to 10 VDC

Direct

2 to 10 VDC

DA 0-10

RA 2-10

10V

0V 2V 5V 12V

100%

Flow

Set Point

24 VAC

Floating or ON/OFF

2 to 10 VDC

Reverse

2 to 10 VDC

DA 0-10

RA 2-10

10V

0V 2V 5V 12V

100%

Flow

Set Point

24 VAC

Floating or ON/OFF

Auto Calibration Mode

The actuator enters auto calibration mode and positions the coupler to the maximum and minimum end stops to identify

the range of travel. To complete the auto calibration process, press Enter/Autocal until all three LEDs are on.

Remove

the oval cover

VA93xx-HGA-1

DIP Switches

and LEDs Placement

VA93xx-GUA-1

DIP Switches

and LEDs Placement

VA93xx-AxA-1

DIP Switches

and LEDs Placement

PB_VA9300_05 2020

Setting the SPAN and OFFSET Proportional Command Signal to Other Values

The actuator has the possibility to adjust the input signal changing the working range and the starting point of the signal.

The valid Offset values are 0 to 10 VDC and the valid Span values are 2 to 10 VDC. Adjusting span and offset the

feedback voltage of the actuator is automatically set as 2-10 VDC.

10V

0V 5V

Offset Span

12V

Set Point

100%

Flow

1. Connect a digital multimeter between the orange (feedback) and black (common) wires. See Wiring for more wiring

information.

2. Press Enter/Autocal.

Note: To adjust the span and oset, press but not hold Enter/Autocal.

Holding Enter/Autocal for longer than three seconds triggers an autocal.

The Oset Adj. LED turns on, and the multimeter displays the current oset value.

3. Press INC.

The Offset Adj. LED flashes. The voltage reading on the multimeter increases 0.5 VDC each time you press the button.

Press INC. until you reach the desired voltage.

Once you press INC., if no further action is required, the Offset Adj. LED stops flashing after 10 seconds. The actuator

exits the program mode and the original offset value remains unchanged.

4. Press Enter/Autocal.

The Offset Adj. LED turns off indicating that the desired Offset Adj. value was recorded. The Span Adj. turns on, and the

multimeter displays the present SPAN value.

5. Press INC.

The Span Adj. LED flashes. The voltage reading on the multimeter increases by 0.5 VDC each time you press the

button. Press INC. until you reach the desired voltage.

Once you press INC., if no further action is required, the Offset and Adj. LED stops flashing after 10 seconds. The

actuator exits the program mode and the original offset value remains unchanged.

6. Press Enter/Autocal.

The Span Adj. LED turns off indicating that the desired Span Adj. setting is recored, and the actuator exits the program

mode.

Reading the SPAN and OFFSET Proportional Command Signal Voltage Settings

1. Connect a digital multimeter between the orange (feedback) and black (common) wires. See Wiring for more wiring

information.

2. Press Enter/Autocal.

The Offset Adj. LED turns on, and the multimeter displays the current offset value.

IMPORTANT: Do not press INC. Otherwise your observed offset voltage setting will change.

3. Press Enter/Autocal.

The Offset Adj. LED turns off, the Span Adj. LED turns on, and the multimeter displays the present SPAN value.

IMPORTANT: Do not press INC. Otherwise your observed SPAN voltage setting will change.

4. Press Enter/Autocal.

The Span Adj. LED turns off.

Clearing the SPAN and OFFSET Proportional Command Signal Voltage Setting

Cycle DIP switch two between 2 to 10 and 0 to 10. The active setting is the final state of DIP switch two.

Example

Command

Signal

Feedback

Signal

Setting User Interface

Offset = 5

Span = 7

Active

2 - 10 VDC

DA 0-10

RA 2-10

PB_VA9300_05 2020

Line voltage models and High Speed models (ON/OFF and Floating)

The VA93xx-AUA-x operates with AC 100 to 240 V (AC 85 to 264 V). The actuator is design to be used with ON/OFF or

Floating controls in HVAC systems.

The VA9308-AGA-1Z and VA9316-AGA-1Z operate with 24 V DC/AC.

DIP Switch Settings

Command Signal Setting User Interface

Reverse

DA Not

used

Not

used

LED

Direct

DA Not

used

LED

Not

used

Ordering Informations

Code Torque

(Nm)

Running

Time (s) Controls Signal Supply Voltage

VA9308-AGA-1Z 8 8 ON/OFF and Floating 24V AC/DC

VA9308-AUA-1Z 8 8 ON/OFF and Floating 100 to 240 VAC

VA9310-AUA-1 10 35 ON/OFF and Floating 100 to 240 VAC

VA9310-GUA-1 10 35 Proportional 100 to 240 VAC

VA9310-HGA-1 10 35 ON/OFF, Floating and Proportional 24V AC/DC

VA9316-AGA-1Z*16 16 ON/OFF and Floating 24V AC/DC

VA9316-AUA-1Z*16 16 ON/OFF and Floating 100 to 240 VAC

VA9320-AUA-1 20 90 ON/OFF and Floating 100 to 240 VAC

VA9320-GUA-1 20 90 Proportional 100 to 240 VAC

VA9320-HGA-1 20 90 ON/OFF, Floating and Proportional 24V AC/DC

VA9335-AUA-1 35 150 ON/OFF and Floating 100 to 240 VAC

VA9335-GUA-1 35 150 Proportional 100 to 240 VAC

VA9335-HGA-1 35 150 ON/OFF, Floating and Proportional 24V AC/DC

*: Excluded from use along with VG1000 Ball Valve Series

PB_VA9300_05 2020

Technical Specications

M9308

Product Code VA9308-AGA-1Z VA9308-AUA-1Z

Control Type On/Off, Floating

Power AC 24 V ±20%, 50/60 Hz: 12.7 VA

DC 24 V ±10%: 6.5 W

Nominal AC

230 V,

50/60 Hz:0.08 A

Transformer ≥13 VA ---

Input 24 VAC ±20%, 24 VDC ±10% 100...240 VAC (AC 85...264 V) at 50/60 Hz

Impedance 100k ohm 315k ohm

Feedback ---

Torque 8 Nm

Rotation Range Mechanically Limited 35° to 95° ±3° in 5° increments

Rotation Time 8s

Cycles 60,000 full stroke cycles; 1,500,000 repositions

Audible Noise <52 dBA at 0 to 8 Nm load, at a distance of 1 m

Electrical

Connections

120 in. (3.05 m) UL 444 type CMP plenum rated cable

with 19 AWG (0.75 mm2) conductors

and 0.25 in.(6 mm) ferrule ends

1.2 m (48 in.) Halogen Free Cable with 0.82 mm2 (18

AWG) conductors and 6 mm (0.25 in.)

ferrule ends

Ambient

Conditions

Operating: -30 to 60°C, 95% RH, noncondensing

Storage: -40 to 85°C, 95% RH, noncondensing

Enclosure IP54

Shipping Weight 0.9 kg

M9310

Product Code VA9310-AUA-1 VA9310-GUA-1 VA9310-HGA-1

Control Type On/Off, Floating Proportional On/Off, Floating Proportional

Power Nominal AC 230 V,

50/60 Hz: 0.03 A

Nominal AC 230 V,

50/60 Hz: 0.05 A 24 V ±20%, 50/60 Hz. 6.2 VA 24 VDC ±10%, 1.9 W

Transformer --- ≥6.5 VA

Input 100...240 VAC (AC

85...264 V) at 50/60 Hz

0(2)...10 VDC,

0(4)...20 mA with field

furnished 500 ohm resistor,

Offset: 0...10 VDC,

Span: 2...10 VDC

24 VAC ±20%, 24 VDC

±10%

0(2)...10 VDC,

0(4)...20 mA with field

furnished 500 ohm resistor,

Offset: 0...10 VDC,

Span: 2...10 VDC

Impedance 315k ohm Voltage control: 100 kΩ

Current control: 0.5 kΩ 100k ohm Voltage Control: 100 kΩ

Current Control: 0.5 kΩ

Feedback --- 0(2)...10 VDC --- 0(2)...10 VDC

Torque 10 Nm

Rotation Range Mechanically Limited 35° to 95° ±3° in 5° increments

Rotation Time 35s

Cycles 100,000 full stroke cycles; 2,500,000 repositions

Audible Noise <35 dBA at 0 to 10 Nm load, at a distance of 1 m

Electrincal

Connections 1.2 m (48 in.) Halogen Free Cable with 0.82 mm2 (18 AWG) conductors and 6 mm (0.25 in.) ferrule ends

Ambient

Conditions

Operating: -30 to 60°C, 95% RH, noncondensing

Storage: -40 to 85°C, 95% RH, noncondensing

Enclosure IP54

Shipping Weight 0.9 kg

PB_VA9300_05 2020

Technical Specications

M9316

Product Code VA9316-AGA-1Z VA9316-AUA-1Z

Control Type On/Off, Floating

Power AC 24 V ±20%, 50/60 Hz: 11.6 VA

DC 24 V ±10%: 5.4 W

Nominal AC 230 V,

50/60 Hz: 0.07 A

Transformer ≥13 VA --

Input 24 VAC ±20%, 24 VDC ±10% 100...240 VAC (AC 85...264 V) at 50/60 Hz

Impedance 100k ohm 315k ohm

Feedback --

Torque 16 Nm

Rotation Range Mechanically Limited 35° to 95° ±3° in 5° increments

Rotation Time 16s

Cycles 60,000 full stroke cycles; 1,500,000 repositions

Audible Noise <52 dBA at 0 to 16 Nm load, at a distance of 1 m

Electrical

Connections

120 in. (3.05 m) UL 444 type CMP plenum rated cable

with 19 AWG (0.75 mm2) conductors and 0.25 in.

(6 mm) ferrule ends

1.2 m (48 in.) Halogen Free Cable with 0.82 mm2

(18 AWG) conductors and 6 mm (0.25 in.) ferrule ends

Ambient

Conditions

Operating: -30 to 60°C, 95% RH, noncondensing

Storage: -40 to 85°C, 95% RH, noncondensing

Enclosure IP54

Shipping Weight 0.9 kg

M9320

Product Code VA9320-AUA-1 VA9320-GUA-1 VA9320-HGA-1

Control Type On/Off, Floating Proportional On/Off, Floating Proportional

Power Nominal AC 230 V,

50/60 Hz: 0.04 A

Nominal AC 230 V,

50/60 Hz: 0.04 A 24 V ±20%, 50/60 Hz. 6.2 VA 24 VDC ±10%, 1.9 W

Transformer --- ≥6.5 VA

Input

100...240 VAC

(AC 85...264 V)

at 50/60 Hz

0(2)...10 VDC,

0(4)...20 mA with field

furnished 500 ohm resistor,

Offset: 0...10 VDC,

Span: 2...10 VDC

24 VAC ±20%,

24 VDC ±10%

0(2)...10 VDC,

0(4)...20 mA with field

furnished 500 ohm resistor,

Offset: 0...10 VDC,

Span: 2...10 VDC

Impedance 315k ohm Voltage Control: 100 kΩ

Current Control: 0.5 kΩ 100k ohm Voltage Control: 100 kΩ

Current Control: 0.5 kΩ

Feedback -- 0(2)…10 VDC -- 0(2)...10 VDC

Torque 20 Nm

Rotation Range Mechanically Limited 35° to 95° ±3° in 5° increments

Rotation Time 90s

Cycles 100,000 full stroke cycles; 2,500,000 repositions

Audible Noise <45 dBA at 0 to 20 Nm load, at a distance of 1 m

Electrincal

Connections 1.2 m (48 in.) Halogen Free Cable with 0.82 mm2 (18 AWG) conductors and 6 mm (0.25 in.) ferrule ends

Ambient

Conditions

Operating: -30 to 60°C, 95% RH, noncondensing

Storage: -40 to 85°C, 95% RH, noncondensing

Enclosure IP54

Shipping Weight 0.9 kg

PB_VA9300_05 2020

Technical Specications

M9335

Product Code VA9335-AUA-1 VA9335-GUA-1 VA9335-HGA-1

Control Type On/Off, Floating Proportional On/Off, Floating Proportional

Power Nominal AC 230 V,

50/60 Hz: 0.04 A

Nominal AC 230 V,

50/60 Hz: 0.04 A 24 V ±20%, 50/60 Hz. 6.2 VA 24 VDC ±10%, 1.9 W

Transformer --- ≥6.5 VA

Input

100...240 VAC

(AC 85...264 V)

at 50/60 Hz

0(2)...10 VDC,

0(4)...20 mA with field

furnished 500 ohm resistor,

Offset: 0...10 VDC,

Span: 2...10 VDC

24 VAC ±20%,

24 VDC ±10%

0(2)...10 VDC,

0(4)...20 mA with field

furnished 500 ohm resistor,

Offset: 0...10 VDC,

Span: 2...10 VDC

Impedance 315k ohm Voltage Control: 100 kΩ

Current Control: 0.5 kΩ 100k ohm Voltage Control: 100 kΩ

Current Control: 0.5 kΩ

Feedback -- 0(2)…10 VDC -- 0(2)...10 VDC

Torque 35 Nm

Rotation Range Mechanically Limited 35° to 95° ±3° in 5° increments

Rotation Time 150s

Cycles 30,000 full stroke cycles; 750,000 repositions

Audible Noise <45 dBA at 0 to 35 Nm load, at a distance of 1 m

Electrincal

Connections 1.2 m (48 in.) Halogen Free Cable with 0.82 mm2 (18 AWG) conductors and 6 mm (0.25 in.) ferrule ends

Ambient

Conditions

Operating: -30 to 60°C, 95% RH, noncondensing

Storage: -40 to 85°C, 95% RH, noncondensing

Enclosure IP54

Shipping Weight 0.9 kg

Compliance

United States:

UL Listed, CCN XAPX, File E27734; to UL 60730-1: Automatic Electrical Controls for Household and Similar Use, Part 1; and

UL 60730-2-14: Part 2, Particular Requirements for Electric Actuators. Plenum Rated (UL 2043). Suitable for use in Other

Environmental Air Space (Plenum) in accordance with section 300.22 (c) of the National Electrical Code.

Canada:

UL Listed, CCN XAPX7, File E27734; to CAN/CSA E60730-1:02: Automatic Electrical Controls for Household and Similar Use,

Part 1; and CAN/CSA-E60730-2-14, Particular Requirements for Electric Actuators.

Europe:

CE Mark – Johnson Controls declares that this product is in compliance with the essential requirements and other relevant

provisions of the EMC Directive and Low Voltage Directive.

Australia and New Zealand:

RCM, Australia/NZ Emissions Compliant

Table des matières

Autres manuels Johnson Controls Contrôleurs

Johnson Controls

Johnson Controls G77 Series Manuel utilisateur

Johnson Controls

Johnson Controls T9800 Series Manuel de service

Johnson Controls

Johnson Controls M9203-B Series Manuel utilisateur

Johnson Controls

Johnson Controls M9116-GG-1N4 Series Manuel utilisateur

Johnson Controls

Johnson Controls VA7820-GG-1 Series Manuel utilisateur

Johnson Controls

Johnson Controls CK721-A Instructions de montage

Johnson Controls

Johnson Controls P77 Series Manuel utilisateur

Johnson Controls

Johnson Controls M9220-GGx-3 series Manuel utilisateur

Johnson Controls

Johnson Controls ATC1510 Manuel utilisateur

Johnson Controls

Johnson Controls FEC26 Series Manuel utilisateur

Johnson Controls

Johnson Controls M9204-B 2Z Series Manuel utilisateur

Johnson Controls

Johnson Controls Metasys MS-FEU1610-0U Manuel utilisateur

Johnson Controls

Johnson Controls FEC16 Series Manuel utilisateur

Johnson Controls

Johnson Controls M9108-A-1N Series Manuel utilisateur

Johnson Controls

Johnson Controls Metasys DX-9100 Manuel de service

Johnson Controls

Johnson Controls LP-FXVMA Series Manuel utilisateur

Johnson Controls

Johnson Controls VG1600 Series Manuel utilisateur

Johnson Controls

Johnson Controls M9308-AGA-xZ series Manuel utilisateur

Johnson Controls

Johnson Controls M9206-DN Series Manuel utilisateur

Johnson Controls

Johnson Controls RRS Economizer Controller Manuel utilisateur

Johnson Controls

Johnson Controls tyco iSTAR Ultra Manuel de l'opérateur

Johnson Controls

Johnson Controls EDA-8102 Instructions de montage

Johnson Controls

Johnson Controls PENN P70AB-2 Manuel utilisateur

Johnson Controls

Johnson Controls SNC Series Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
