Johnson Controls TEC3000 Series Manuel utilisateur

TEC3000 Series Networked and Wireless Proportional Fan Coil and

Individual Zone Thermostat Controllers with Dehumidification Capability

Quick Start Guide

Refer to the QuickLIT website for the most up-to-date version of this document.

North American emissions compliance

United States

Canada

Installation

Parts included

• One TEC3000 Series Thermostat Controller with integral mounting base

• One installation instructions sheet

Location considerations

For networked models, locate the TEC3000 Series Thermostat Controller:

• On a partitioning wall, approximately 5 ft (1.5 m) above the floor in a location of average temperature, allowing

for vertical air circulation to the TEC

• Away from direct sunlight, radiant heat, outside walls, outside doors, air discharge grills, stairwells, and from

behind doors

• Away from steam or water pipes, warm air stacks, unconditioned areas (not heated or cooled), or sources of

electrical interference

• In a clear path between the integrated passive infrared (PIR) occupancy sensor (if equipped) and the space

being monitored

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part

15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This Class (B) digital apparatus meets all the requirements of the Canadian Interference-Causing Equipment

Regulations.

Cet appareil numérique de la Classe (B) respecte toutes les exigences du Règlement sur le matériel brouilleur

du Canada.

TEC3000 Series Networked and Wireless Proportional Fan

Coil and Individual Zone Thermostat Controllers with

Dehumidification Capability

Quick Start Guide

TEC3322-1x-xxx, TEC3323-1x-xxx, TEC3622-1x-xxx, TEC3623-1x-xxx, TEC3022-1x-xxx, TEC3023-1x-xxx

Part No. 24-11353-00028, Rev.

Issued May 2019

(barcode for factory use only)

24-11353-00028, Rev. C

*241135300028C*

TEC3000 Series Networked and Wireless Proportional Fan Coil and Individual Zone Thermostat Controllers with

Dehumidification Capability Quick Start Guide

For wireless models, also locate the thermostat controller:

• Outside of a recessed area, metal enclosure, or shelving unit

• On the same building level as the other wireless devices on the same personal area network (PAN)

• At least 2 in. (51 mm) away from any metal obstruction

• In the direct line of sight to other wireless devices on the same PAN. Signal transmission is best if the path

between the TEC3000 and other wireless devices is direct as possible. Line of sight is desirable but not

required. See Table 1 for recommended and maximum distances.

• Away from metal and large solid obstructions (including equipment rooms and elevator shafts and concrete or

brick walls) between the TEC3000 and the ZFR Pro Router/Repeater or ZFR Pro Coordinator Radio

• Within range of two or more wireless devices on the same PAN. Redundancy in the layout provides the best

reliability in wireless installations

• At least 20 ft (6 m) from a microwave oven

For integrated passive infrared (PIR) models, be sure that the thermostat controller is located centrally, where

occupant movement is frequent. Ensure that the unit is not blocked by a plastic tamper resistant enclosure (such

as the GRD10A-608). The plastic enclosure blocks the occupancy sensing capability.

The use of insulating foam pads is required for installations where wiring passes through the wall to the thermostat.

For wireless models, the effective transmission range and distance for indoor applications vary because of wireless

signal absorption and reflection due to metal obstructions, walls or floors, and furniture found in typical building

interiors.

Notes:

• Allow for sufficient clearance to insert a USB drive into the USB port

• For more details on using ZFR Pro Series communication devices, refer to the WNC1800/ZFR182x Pro

Series Wireless Field Bus System Technical Bulletin (LIT-12012356).

Table 1: Indoor line-of-sight transmission ranges

Range type Transmission distance

WNC Coordinator Radio,

ZFR Pro Repeater TEC3000 Wireless Thermostat

Controller

Recommended 50 ft (15.2 m) 50 ft (15.2 m)

Line of sight, maximum 250 ft (76.2 m) 100 ft (30 m)

IMPORTANT: Only connect memory devices to the USB port. Do not use it for charging external devices.

TEC3000 Series Networked and Wireless Proportional Fan Coil and Individual Zone Thermostat Controllers with

Dehumidification Capability Quick Start Guide

Installing the thermostat controller

1. Use a 1/16 in. (1.5 mm)Allen wrench or Johnson Controls® T-4000-119 Allen-Head Adjustment Tool (order

separately) to remove the security screw if it is installed on the top of the thermostat controller cover as

illustrated in Figure 2.

2. Pull the top edge of the cover and open the thermostat controller as illustrated in Figure 2.

IMPORTANT: The cover is not secured on the bottom. Be careful not to drop the cover.

IMPORTANT: If you are installing more than one thermostat controller, keep track of which cover attaches to

which base. The controller version ans the base version must match to ensure proper operation.

IMPORTANT: Use proper Electrostatic Discharge (ESD) precautions during installation and servicing to avoid

damage to the electronic circuits of the thermostat controller.

Figure 1: Thermostat controller

shown without occupancy sensor,

dimensions, in. (mm)

TEC3000 Series Networked and Wireless Proportional Fan Coil and Individual Zone Thermostat Controllers with

Dehumidification Capability Quick Start Guide

Figure 2: Removing the security screw from the thermostat controller cover

(shown without occupancy sensor) (left) and removing the thermostat controller cover (right)

3. Align the thermostat controller mounting base on the wall with the security screw on the top and use the base

as a template to mark the two mounting hole locations. See Figure 3.

Notes:

• If you need to install the thermostat controller on an electrical junction box, use

2-1/2 x 4 in. (63 x 101 mm) square boxes with mud ring covers and avoid smaller 1-1/2 x 4 in.

(38 x 101 mm) square or 3 x 2 in. (76 x 51 mm) boxes. This procedure ensures that you have enough

space for cabling, if needed.

• For surface-mounted applications, use durable mounting hardware, such as wall anchors, that cannot be

easily pulled out of the mounting surface.

4. Pull approximately 6 in. (152 mm) of wire from the wall and insert the wire through the center hole in the

thermostat controller mounting base. See Figure 3.

5. Secure the mounting base to the wall surface using two mounting screws (user supplied) as illustrated in

Figure 3.

Note: Be careful not to overtighten the mounting screws.

TEC3000 Series Networked and Wireless Proportional Fan Coil and Individual Zone Thermostat Controllers with

Dehumidification Capability Quick Start Guide

Figure 3: Mounting hole locations, dimensions, in. (mm) (left) and

securing the thermostat controller mounting base to the wall (right)

Note: When the unit is mounted on the wall, you can hang the front cover on the end of the back cover as

illustrated in Figure 4.

Figure 4: Hanging the thermostat controller front cover

TEC3000 Series Networked and Wireless Proportional Fan Coil and Individual Zone Thermostat Controllers with

Dehumidification Capability Quick Start Guide

Wiring

Whenanexistingthermostatcontrollerisreplaced,removeandlabelthewirestoidentifytheterminalfunctions.

To wire the thermostat controller:

1. Strip the ends of each wire 1/4 in. (6 mm) and connect them to the appropriate screw terminals as indicated in

Table 2.

Note: For more details on wiring the MS/TP Communications Bus, refer to the MS/TP Communications Bus

Technical Bulletin (LIT-12011034).

2. Attach the communication wires to the terminal block.

Note: If multiple wires are inserted into the terminals, be sure to properly twist the wires together before

inserting them into the terminal connectors.

3. Carefully push any excess wire back into the wall.

Note: Seal the hole in the wall with fireproof material to prevent drafts from affecting the ambient temperature

readings.

4. For networked models, set the bus end-of-line (EOL) termination switch to the desired location.

Risk of Electric Shock.

Disconnect the power supply before making electrical connections to avoid electric shock.

Risque de décharge électrique.

Débrancher l'alimentation avant de réaliser tout raccordement électrique afin d'éviter tout risque de décharge

électrique.

Risk of Property Damage.

Do not apply power to the system before checking all wiring connections. Short circuited or improperly connected

wires may result in permanent damage to the equipment.

Risque de dégâts matériels.

Ne pas mettre le système sous tension avant d'avoir vérifié tous les raccords de câblage. Des fils formant un

court-circuit ou connectés de façon incorrecte risquent d'endommager irrémédiablement l'équipement.

IMPORTANT: Make all wiring connections in accordance with local, national, and regional regulations. Do not

exceed the electrical ratings of the TEC3000 Series Thermostat Controller.

IMPORTANT: Use proper ESD precautions during installation and servicing to avoid damage to the electronic

circuits of the thermostat controller.

TEC3000 Series Networked and Wireless Proportional Fan Coil and Individual Zone Thermostat Controllers with

Dehumidification Capability Quick Start Guide

The bus EOL termination switch allows you to designate the thermostat controller as the end of the Field

Controller (FC) Bus and N2 Bus. The default position is OFF. If the thermostat controller is at the end of a daisy

chain of devices on the FC Bus and N2 Bus, set the EOL switch to the ON position. See Figure 3.

5. Reattach the thermostat controller cover to the mounting base (bottom side first).

6. Use a 1/16 in. (1.5 mm)Allen wrench or Johnson Controls T-4000-119 Allen-Head Adjustment Tool (order

separately) to reinstall the security screw on the top of the thermostat controller cover. See Figure 2 for security

screw placement.

7. Remove the protective plastic cover sheet from the display.

Notes:

• For VAV and two-pipe systems, connect the valve to the heating output.

• Only one transformer is required for each TEC.

• Power to the AUX contact comes from the reheat coil.

IMPORTANT: Make sure you reattach the cover that corresponds to its correct base. The CPU board number

needs to match the base board number. Otherwise, an operation error occurs after you reattach a cover and

base that do not belong together.

IMPORTANT: If the display is dirty, gently wipe it clean with isopropyl alcohol or ethyl alcohol. Do not scrub

hard as to avoid damaging the surface. Do not use other cleaners such as water, ketones, and aromatic

solvents, since they may damage the polarizer.

TEC3000 Series Networked and Wireless Proportional Fan Coil and Individual Zone Thermostat Controllers with

Dehumidification Capability Quick Start Guide

Table 2: Terminal identification (See Figure 5 for wiring diagrams)

Terminal label Function

TEC3022, TEC3023,

Proportional FC/VAV TEC3322, TEC3323, Proportional

FC/VAV TEC3622, TEC3623

Proportional FC/VAV

24 V 24 VAC hot from transformer

FAN H Fan high

FAN M Fan medium

FAN L Fan low and fan on

AUX Auxiliary binary output

AUX Auxiliary power

COM1

1. For the networked models, the common terminals, which do not include NET COM, are internally connected and can be

used for all inputs and outputs. For the wireless models, the common terminals are connected and can be used for all

inputs, outputs, and 24 VAC power.

24 VAC common from transformer

CLG Cooling command (configurable 0 to 10 V range)

NC No connection

HTG Heating command (configurable 0 to 10 V range)

RSEN Configurable analog input 1

COS Configurable analog input 2/Changeover binary switch

COM1Common

VSF Variable speed fan command (configurable 0 to 10 V range)

BI-2 Configurable binary input 2

BI-1 Configurable binary input 1

NET+ N/A Not connected Field bus+/N2+

NET- N/A Not connected Field bus-/N2-

NET COM N/A Not connected Isolated common for field bus

TEC3000 Series Networked and Wireless Proportional Fan Coil and Individual Zone Thermostat Controllers with

Dehumidification Capability Quick Start Guide

Figure 5: Proportional wiring diagram (See Table 2 for terminal identification)

TEC3000 Series Networked and Wireless Proportional Fan Coil and Individual Zone Thermostat Controllers with

Dehumidification Capability Quick Start Guide

Figure 6: Proportional 0 to 10 VDC control (pressure-dependent VAV)

Figure 7: Proportional 0 to 10 VDC control (pressure-dependent VAV with changeover sensor/switch)

Figure 8: Proportional 0 to 10 VDC control

(pressure-dependent VAV with changeover sensor/switch and reheat)

Autres manuels pour TEC3000 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Johnson Controls Contrôleurs

Johnson Controls

Johnson Controls VMA1615 Manuel utilisateur

Johnson Controls

Johnson Controls M9102 GA-1S Series Manuel utilisateur

Johnson Controls

Johnson Controls VA9204-B-2 Series Manuel utilisateur

Johnson Controls

Johnson Controls RRS Economizer Controller Manuel utilisateur

Johnson Controls

Johnson Controls PENN P28 Manuel utilisateur

Johnson Controls

Johnson Controls M9206-DN Series Manuel utilisateur

Johnson Controls

Johnson Controls System 350 P352AB Series Manuel utilisateur

Johnson Controls

Johnson Controls Facility Explorer FX20 Manuel utilisateur

Johnson Controls

Johnson Controls PEAK OEM 18 Manuel utilisateur

Johnson Controls

Johnson Controls LP-FX2211T-0 Manuel utilisateur

Johnson Controls

Johnson Controls tyco iSTAR Ultra Manuel de l'opérateur

Johnson Controls

Johnson Controls MS-FEC1611-1U Manuel utilisateur

Johnson Controls

Johnson Controls EDA-8000 Manuel

Johnson Controls

Johnson Controls EDA-8000 Instructions de montage

Johnson Controls

Johnson Controls IQ Keypad-PG Manuel utilisateur

Johnson Controls

Johnson Controls FEC25 Manuel utilisateur

Johnson Controls

Johnson Controls FX-PCG1621 Series Manuel utilisateur

Johnson Controls

Johnson Controls M4-CGM Series Manuel utilisateur

Johnson Controls

Johnson Controls METASYS VAV110 Manuel utilisateur

Johnson Controls

Johnson Controls A25 Series Manuel de service

Johnson Controls

Johnson Controls M9200 Series Manuel utilisateur

Johnson Controls

Johnson Controls G670 Instructions de montage

Johnson Controls

Johnson Controls EDA-8100 Instructions de montage

Johnson Controls

Johnson Controls FA-33-741 Series Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
