Connecting Serial Controllers to the P2000 Comark

Server Running Software Version 3.11

This document describes how to connect supported serial controllers to the P2000 Comark

server running software Version 3.11. P2000 supports the following serial controllers:

•S321-DIN

•D620

•D600-AP (Version PS 155B or higher)

•D620-TIU

•S320

•P900

If installing serial controllers, you may need the following equipment:

•Digi® AccelePort® serial adapter board (installed at the P2000 server)

•PC232 converter (S321-DIN and P900 controllers excluded)

•B&B Electronics RS-232 to RS-485 converter (model 485OT9L) (S321-DIN controllers

using serial communications only)

Note: The S321-DIN can use serial communications with the RS-232 to RS-485 converter,

or it can communicate via IP using the Digi One® SP converter. This document covers both

scenarios.

P2000 supports a controller loop configuration in which most serial controllers connect to the

server using a PC232 converter and an AccelePort connector box. See Figure 1 for an

illustration of a P2000 system component configuration with serial controllers.

Connecting Serial Controllers to the P2000 Comark Server Running Software Version 3.11

Preliminary – This information may change.

Figure 1: P2000 System with Serial Controllers

Connecting Serial Controllers

The following sections describe the hardware components needed to support serial

controllers (D620, D620-TIU, D600-AP, S320, and P900), including how to connect the

controllers to the system and establish communications. These components are not supplied

and must be purchased separately.

Note: This section does not include instructions for installing S321-DIN controllers. For

information on connecting these controllers, see Connecting S321-DIN Controllers on

page 13.

Note: The sections on the current loop converter do not apply to the P900 controller. For

more information on the P900 controller, refer to the P900 Installation Manual (Part No.

09-9133-01).

Connecting Serial Controllers to the P2000 Comark Server Running Software Version 3.11

Preliminary – This information may change.

For detailed information about configuring controller loop communication, refer to the

installation documentation of the serial controller.

Installing the AccelePort Serial Adapter

The AccelePort board is an expandable serial communication adapter that provides each

server with additional connections to serial controllers (S321-DIN controllers excluded).

Install the AccelePort board in one of the available PCI slots. After installing the AccelePort

board, connect the cable to the board’s interface. Follow the manufacturer’s documentation

for detailed instructions on installing the board.

Note: When configuring the AccelePort, name your devices as COM1, COM2, and so on.

The AccelePort does not support other names.

AccelePort to PC232 Installation

The AccelePort module provides additional RS-232 serial ports. The module is connected to

the AccelePort PCI board in the server by a DB44 RS-232 cable. Connect one end of the

DB44 cable to the AccelePort COM port, and the other DB44 end to the CPU port on the

module. See Figure 2.

Digi PORTS/16m

Xem PCI Adapter

Installed in PCI Slot 2

DB-44 Cable

Front Side

Back Side

PC-232

Converter

Legacy

Controller

(S321/P900

Excluded)

DB-25 Female Connector

RJ-45

Connector

EBI OUT

EBI IN

Side

Panel

Connect to EBI IN

DB-25 Male Connector

Acceleport to

PC-232

To next legacy

controller

Each channel supports 16

legacy controllers

P900

Controller

To next P900 controller

Figure 2: AccelePort Connection (16 port model shown)

Connecting Serial Controllers to the P2000 Comark Server Running Software Version 3.11

Preliminary – This information may change.

Current Loop Converter

The D620, D620-TIU, D600-AP (Version PS 155B or higher), and S320 controllers

communicate with the system via the Johnson Controls® proprietary Nodal Protocol B. The

current loop converter converts standard serial communication to Nodal Protocol B to allow

the P2000 Database Server to communicate with these controllers.

Current loop converters are available in two models:

•Model PC232-S4-1 Accommodates 4 loops and operates on 120 VAC

•Model PC232-S4-2 Accommodates 4 loops and operates on 240 VAC

Both models use the same type of enclosure for mounting. If installing only one 4-loop

converter, communication can be established with up to 64 controllers. If installing two

4-loop converters, communication can be established with up to 128 controllers. The

enclosure contains a tamper switch, transformer, EMI line filter, and current loop converter

Printed Circuit Board (PCB).

Specifications

The environmental specifications for the Field Panel Interface board are the same as for the

computers. The specifications of the current loop converter are listed in Table 1.

Table 1: Current Loop Converter Specifications

Item Specification

Number of Channels per PCBA 4

Input/Output RS-232 to current loop and current loop to RS-232

Number of Serial Controllers per Channel 16

Ambient Temperature 32° to 122°F (0° to 50°C)

Relative Humidity 0 to 95%

Ventilation Free flow of air over all exposed surfaces

Power Requirements:

PC232-S4-1

PC232-S4-2

120 VAC, 125 milliamps

240 VAC, 70 milliamps

PC232-S4-X Converter Installation

Install the PC232-S4-X enclosure on a wall or other mounting surface in a restricted-access

area with an ambient temperature between 32° and 122°F (0° and 50°C) and a relative

humidity between 0 and 95 percent.

Note: High heat and humidity can be harmful to electronic equipment and contributes to

early component failure. Long life and reliable operation can best be obtained by installing

the converter in an environment which is comfortable to a person.

Suggested installation locations include a locking utility closet, a crawl space, or inside a

suspended ceiling (if necessary). Install the unit so the door can swing fully open to the right.

The location must allow free flow of air over all exposed surfaces.

Connecting Serial Controllers to the P2000 Comark Server Running Software Version 3.11

Preliminary – This information may change.

The converter can function in any position, but we recommend mounting it flat against a wall

with the hinge to the right.

To be UL-compliant, the Current Loop Converter must be located in the same room and

within 20 feet (6.1 m) of the Proprietary Station.

Installing the Enclosure

To meet UL requirements, the PC232-S4-X board must be installed in the enclosure supplied

for the PC232-S4-X. This enclosure has four corner holes for mounting (see Figure 3). The

diameter of these holes is 0.196 inches (4.98 mm).

The enclosure has knockout holes for cable entry. You can bring cables to the mounting

location and terminate them before or after the enclosure installation, as dictated by the

requirements of the installation.

To install the enclosure:

1. Remove the PC232-S4-X board from the enclosure by disconnecting the power cable

from J6 and the tamper switch cable from J1. Then, remove the four screws securing the

PC232-S4-X board to the enclosure.

2. Set aside the screws in a safe place, so you can use them to replace the board into the

enclosure.

3. Hold the enclosure in the desired location on the mounting surface and use as a template

to mark the location of the four mounting holes that correspond to the holes shown in

Figure 3.

4. Bore holes in the mounting surface at the four marks. If necessary, install hollow-wall

anchors.

5. Mount the enclosure on the wall using appropriate hardware.

6. Bring the cables to the mounting location, allowing enough excess cable for a service

loop.

7. Determine the point of entry for each cable and remove the appropriate knockout(s).

8. When using conduit, attach appropriate conduit fasteners to the conduit in the enclosure.

9. Install the PC232-S4-X board removed in Step 1.

10. Reconnect the power cable to J6 and the tamper switch cable to J1. You have completed

the enclosure installation.

Connecting Serial Controllers to the P2000 Comark Server Running Software Version 3.11

Preliminary – This information may change.

Figure 3: PC232 4X Mounting Holes Location

Cabling from PC232-S4-X

All cabling must be in conformance with the National Electric Code, NFPA 70*. Observe all

local codes for specific wiring and conduit requirements. Construct cabling using good

wiring practices. All cables should be long enough to allow for service loops at their

terminations within the terminal enclosure. This allows the installer to conveniently wire the

cable connectors and plug them into the mating connectors.

* For Canadian installations, refer to the Canadian Electric Code, C22.1.

Take into account the following requirements for cable routing:

•Route power lines separately from data lines. These lines can be a standard

3-wire stranded #16 AWG UL listed/CSA approved line cord used with UL listed/CSA

approved strain relief.

•All low-level input cables (system data, alarm cables, etc.) must be shielded types and

should be in grounded conduit or at least two feet from AC power, fluorescent lights, or

other high-energy sources.

Table 2 lists the connectors in the kit supplied with one PC232-S4-X current loop converter,

and Table 3 lists the connectors supplied with two PC232-S4-X converters. Use these

connectors to construct the cables.

Connecting Serial Controllers to the P2000 Comark Server Running Software Version 3.11

Preliminary – This information may change.

One PC232-S4-X Unit

This kit is used for the installation of one PC232-S4-X board. The cable connections of the

kit complete the interface of the serial controllers to the server.

Table 2: Connector Kit (supplied with one PC232-S4-X unit)

Type Quantity Mating Connector/Function

Conn., 25-pin, MTA-100 4 Ports 1, 2, 3, and 4 on connector box

DB-25 Backshell 4 Covers for DB-25 connectors

Conn., 2-pin, MTA-100 1 J1 to tamper switch connector on current loop converter board

Conn., 4-pin, MTA-100 3 J3, J4, J5 on first or only current loop converter board

Conn., 5-pin, MTA-100 1 J2 on first current loop converter board

Conn., 8-pin, MTA-100 4 J7, J8, J9, J10 on first or only current loop converter board. (The

other sides of the cables made with these connectors plug into

the serial controllers.)

Screw, 6-32x7/8 inch 4 Used to mount current loop converter board to enclosure wall

Screw, 6-32x1/2 inch 6 Used to ground wire shields to enclosure wall

Two PC232-S4-X Units

This kit is used for the installation of two PC232-S4-X boards. The cable connections of the

kit complete the interface of the serial controllers to the server.

Table 3: Connector Kit (supplied with two PC232-S4-X units)

Type Quantity Mating Connector/Function

Conn., 25-pin, MTA-100 8 Ports 1 through 8 on connector box

DB-25 Backshell 8 Covers for DB-25 connectors

Conn., 2-pin, MTA-100 2 J1 to tamper switch connector on current loop converter board

Conn., 4-pin, MTA-100 6 J3, J4, J5 on both current loop converter boards

Conn., 5-pin, MTA-100 2 J2 on both current loop converter boards

Conn., 8-pin, MTA-100 8 J7, J8, J9, J10 on both current loop converter boards (The other

sides of the cables made with these connectors plug into the

serial controllers.)

Screw, 6-32x7/8 inch 8 Used to mount current loop converter board to enclosure

Screw, 6-32x1/2 inch 12 Used to ground wire shields to enclosure wall

The connectors supplied are mass termination type; attaching the cable wires to the

connectors requires special tools. The recommended tools are listed in Table 4.

Connecting Serial Controllers to the P2000 Comark Server Running Software Version 3.11

Preliminary – This information may change.

Table 4: Tools Required to Install Wires in MTA Connectors

Johnson Controls

Part Number

AMP Part

Number

Tool Description

96-0014 58074-1 Pistol-grip Handle Assembly

96-0015 58246-1 MTA-100 Modular Head (used in pistol-grip tool)

96-0010-01 59803-1 MTA-100 Maintenance Hand Tool (inserts one wire at a time)

Cabling between PC232-S4-X Converter Board and Connector Box

Create the cables to connect the connector box and the PC232-S4-X converter board using

#22, 4- and 5-conductor shielded cabling. We recommend Belden® 9940 and 9941,

respectively. The cable length must not exceed 25 feet (7.6 m).

For systems with one PC232-S4-X converter board, use 4-conductor cable to connect ports 2,

3, and 4 of the FPI connector box to the PC232-S4-X PCB connectors J3, J4, and J5,

respectively. Use the 25-pin connectors supplied with the kit on ports 2, 3, and 4 of the

connector box. Use the red 4-pin connectors supplied with the kit on the PC232-S4-X PCB

end. A 5-conductor cable connects port 1 of the connector box to connector J2 on the PC232-

S4-X PCB. Use the remaining 25-pin connector for port 1 of the connector box and the only

red 5-pin connector for J2 of the PC232-S4-X PCB. (See Figure 4 for the wiring diagram.)

For systems with two PC232-S4-X converter boards, use 4-conductor cable to connect ports

2 through 8 of the FPI connector box to both PC232-S4-X PCB connectors J3, J4, and J5,

respectively. Use the 25-pin connectors supplied with the kit on ports 2 through 8 of the

connector box. Use the red 4-pin connectors supplied with the kit on both PC232-S4-X PCB

ends. Use a red 5-pin connector for connector J2 on the second PC232-S4-X PCB. Only four

wires connect to the 5-pin connector attaching to J2 of the second PC232-S4-X PCB. A

5-conductor cable connects port 1 of the connector box to connector J2 on the first PC232-

S4-X PCB. Use the remaining 25-pin connector for port 1 of the connector box and

remaining red 5-pin connector for J2 of the first PC232-S4-X PCB. (See Figure 4 for the

wiring diagram.)

Cabling between PC232-S4-X and the Serial Controllers

Construct the cables to connect the PC232-S4-X and the serial controllers using #22, two

twisted pair cabling (Belden 8723 recommended). See Figure 4 for the wiring diagram. The

diagram shows the pin-to-pin connections for the serial controllers. The maximum cable

length is 4,000 feet (1,219 m) total loop distance.

Install a Lightning Transient Suppressor at each end of every cable between the PC232-S4-X

and the serial controller that is exposed to an area where lightning may strike directly or

nearby. This includes any above-ground cable runs between buildings. We recommend the

Johnson Controls Model TS10/TS11 Transient Suppressor for this purpose.

Connecting Serial Controllers to the P2000 Comark Server Running Software Version 3.11

Preliminary – This information may change.

Tamper Switch

Install the wires in the cable from the tamper switch into the two-pin connector provided in

the connector kit, and plug the connector into J1 of the first or only PC232-S4-X converter

board. If using two PC232-S4-X units, only a single tamper switch connection is needed.

Fuses

The fuse located in the PC232-S4-X PCBs is 1 A, 3AG, SloBlo (Littelfuse® PN 313001).

Current Loop Converter, Routine Maintenance

•Vacuum the current loop converter every six months, or more often if the unit is located

in a dusty environment.

•Check the continuity of the grounding circuit periodically.

Testing Communications

This test assumes that all hardware and software is installed. (Refer to the P2000

Server/Workstation Software Installation Manual [Part No. 24-10618-120] for instructions.)

Monitor the status of loops, controllers, and terminals by using the P2000 System Status

window (located in the System menu). Refer to the P2000 Software User Manual (Part No.

24-10618-147) for more information.

Use visual checks to help verify that the system is working properly. Use the two wiring

diagrams, in Figure 4 and Figure 5, as troubleshooting aids.

•LED2 through LED9 on the PC232 PCB flicker when operating correctly.

•If the LEDs on the PC232 PCB do not flicker, verify that all cables are constructed

correctly and securely attached.

•If LED1 is lit, the board is receiving power. If not, verify power is flowing from the main

source to the PC232.

Connecting Serial Controllers to the P2000 Comark Server Running Software Version 3.11

Preliminary – This information may change.

Figure 4: Interconnect: I/O Converter to Current Loop Converter

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Johnson Controls Contrôleurs

Johnson Controls

Johnson Controls S1-33103010000 Manuel utilisateur

Johnson Controls

Johnson Controls LN-IO -1 Series Manuel utilisateur

Johnson Controls

Johnson Controls LP-NRM653-000C Manuel utilisateur

Johnson Controls

Johnson Controls M9102-AGA-2S Series Manuel utilisateur

Johnson Controls

Johnson Controls VA9310 Series Manuel utilisateur

Johnson Controls

Johnson Controls A350E Manuel

Johnson Controls

Johnson Controls Metasys NCE25 series Manuel utilisateur

Johnson Controls

Johnson Controls tyco Kantech IP LINK Manuel utilisateur

Johnson Controls

Johnson Controls LN Series Manuel utilisateur

Johnson Controls

Johnson Controls Metasys FAC4911 Manuel utilisateur

Johnson Controls

Johnson Controls York YKN2Open board Manuel

Johnson Controls

Johnson Controls M9108 Series Manuel utilisateur

Johnson Controls

Johnson Controls VCC-64 Manuel utilisateur

Johnson Controls

Johnson Controls FEC26 Series Manuel utilisateur

Johnson Controls

Johnson Controls SE-SPU101 Series Manuel utilisateur

Johnson Controls

Johnson Controls FX-PCA3611 Manuel utilisateur

Johnson Controls

Johnson Controls VA-77 Series Manuel utilisateur

Johnson Controls

Johnson Controls FEC16 Series Manuel utilisateur

Johnson Controls

Johnson Controls Tyco KT-1 Manuel utilisateur

Johnson Controls

Johnson Controls M9200 Series Manuel utilisateur

Johnson Controls

Johnson Controls VA-7010 Series Manuel

Johnson Controls

Johnson Controls LC-AVMHTC1-0 Manuel utilisateur

Johnson Controls

Johnson Controls M9316-A Z Series Manuel utilisateur

Johnson Controls

Johnson Controls M4-CVM03050 Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
