Johnson Controls PENN ACT2 Manuel de service

Refrigeration Systems Technical Manual 804

I/O Parameters Section

Issue Date 0699

Code No. LIT-804350

TECHNICAL BULLETIN

Programming ACT2 Generic I/O Parameters

Viewing the Status of Generic Inputs and Outputs ...........................7

Introduction......................................................................................................... 7

Key Concepts...................................................................................................... 8

Generic Inputs .................................................................................................................8

Input Status Screen.........................................................................................................8

Generic Outputs ..............................................................................................................8

Generic Output Status Screen.........................................................................................9

Analog Output Status Screen ..........................................................................................9

Procedure Overview......................................................................................... 10

Detailed Procedures......................................................................................... 11

Viewing the Status of a Generic Input............................................................................11

Viewing the Status of a Generic Output.........................................................................12

Viewing the Analog Output Status .................................................................................13

Viewing Input Logs ............................................................................15

Introduction....................................................................................................... 15

Key Concepts.................................................................................................... 16

Input Log Screen ...........................................................................................................16

Procedure Overview......................................................................................... 17

Detailed Procedures......................................................................................... 18

Viewing the Input Logs ..................................................................................................18

I/O Parameters

Viewing Usage Information ...............................................................19

Introduction....................................................................................................... 19

Key Concepts.................................................................................................... 20

Usage Parameters ........................................................................................................20

Daily Usage Parameters................................................................................................20

Monthly Usage Parameters ...........................................................................................20

Peak Usage Since Last Reset .......................................................................................21

Daily Usage Logs ..........................................................................................................22

Monthly Usage Logs......................................................................................................22

Procedure Overview......................................................................................... 23

Detailed Procedures......................................................................................... 25

Viewing Usage Data for Today ......................................................................................25

Viewing Usage Data for Month ......................................................................................26

Viewing Peak Usage Since Last Reset..........................................................................27

Viewing Usage Daily Logs.............................................................................................28

Viewing the Usage Monthly Logs...................................................................................29

Viewing Schedules.............................................................................31

Introduction....................................................................................................... 31

Key Concepts.................................................................................................... 32

Schedule Status ............................................................................................................32

Procedure Overview......................................................................................... 33

Detailed Procedures......................................................................................... 34

Viewing the Status of a Schedule ..................................................................................34

Viewing Holiday Dates...................................................................................................35

Programming ACT2 Generic I/O Parameters 3

Logging In...........................................................................................37

Introduction....................................................................................................... 37

Key Concepts.................................................................................................... 38

Passwords.....................................................................................................................38

Procedure Overview......................................................................................... 39

Detailed Procedure........................................................................................... 40

Logging In .....................................................................................................................40

Overriding an Output .........................................................................41

Introduction....................................................................................................... 41

Key Concepts.................................................................................................... 42

Output Override Options................................................................................................42

Procedure Overview......................................................................................... 43

Detailed Procedures......................................................................................... 44

Overriding an Output .....................................................................................................44

Setting Up Generic Inputs and Usage Sensor Inputs......................47

Introduction....................................................................................................... 47

Key Concepts.................................................................................................... 48

Input Alarm Settings ......................................................................................................48

Logging Interval.............................................................................................................49

Input Addressing ...........................................................................................................49

Input Math .....................................................................................................................50

Sensor Identification......................................................................................................51

Usage Sensor Attributes................................................................................................51

I/O Parameters

Procedure Overview......................................................................................... 52

Detailed Procedures......................................................................................... 56

Setting the Input Alarm Settings ....................................................................................56

Setting the Alarm Reset Function and the Logging Interval ...........................................57

Setting the Input Board/Point Location and Related Sensor Information........................58

Setting the Input Sensor Type and Name ......................................................................60

Setting the Pulse Setup Values .....................................................................................61

Setting Up the Usage Parameters .................................................................................63

Resetting the Usage Statistics.......................................................................................65

Setting Up Generic Outputs ..............................................................67

Introduction....................................................................................................... 67

Key Concepts.................................................................................................... 68

Normal and Alternate Setpoints.....................................................................................68

Phase Protection ...........................................................................................................68

Defining What Controls the Output ................................................................................69

Output Name and Location............................................................................................69

Procedure Overview......................................................................................... 70

Detailed Procedures......................................................................................... 73

Setting the Normal Setpoints for the Output ..................................................................73

Setting the Output's Alternate Setpoints ........................................................................74

Setting the Output Phase Protection..............................................................................75

Defining what Controls the Output .................................................................................76

Setting the Output Name and Location..........................................................................77

Programming ACT2 Generic I/O Parameters 5

Setting Up Generic Analog Outputs .................................................79

Introduction....................................................................................................... 79

Key Concepts.................................................................................................... 80

Analog Output Parameters ............................................................................................80

Analog Output Maximum and Minimum Output .............................................................80

Defining What Controls the Analog Output ....................................................................80

Procedure Overview......................................................................................... 81

Detailed Procedures......................................................................................... 83

Setting the Analog Output Target, Deadband, and Gain................................................83

Setting the Analog Output Operating Limit Setpoints.....................................................84

Defining How the Analog Output is Controlled...............................................................85

Setting Up Schedules ........................................................................87

Introduction....................................................................................................... 87

Key Concepts.................................................................................................... 88

Schedules .....................................................................................................................88

Schedule Types.............................................................................................................89

Schedule Events ...........................................................................................................89

Holidays ........................................................................................................................90

Procedure Overview......................................................................................... 91

Detailed Procedures......................................................................................... 92

Setting a Schedule ........................................................................................................92

Setting the Holiday Dates ..............................................................................................93

I/O Parameters

Programming ACT2 Generic I/O Parameters 7

Viewing the Status of Generic

Inputs and Outputs

Introduction

This section covers the steps needed to view the status of generic

inputs and outputs.

Generic inputs are be used to provide additional information to control

a generic output, or to use for logging or usage tracking.

Generic outputs are used to control items that are not included in the

refrigeration and HVAC control schemes such as lighting, exhaust

fans, etc. Two types of generic output are available: ON/OFF relay

outputs or analog outputs (4-20 mA or 0-10 VDC output).

I/O Parameters

Key Concepts

Generic Inputs

Generic inputs are used to collect information about the controlled

system above and beyond the information collected for HVAC and

Refrigeration control. Typical examples of generic inputs include:

additional temperature sensors, light level sensors, water or electrical

usage sensors, door switches, etc.

Input Status Screen

INPUT STATUS

LOT1 LTG 15

ELECTRIC 250

MENU UP DOWN SELECT

Sensor Name

As assigned during

parameter setup.

Current Sensor

Reading

Figure 1: Input Status Screen

The Input Status screen is identified by the title in the first line of the

ACT2 controller screen. Sensors are identified by the name given them

during setup. The value in the right hand column is the current sensor

reading for the sensor to the left - units are determined by the type of

sensor used.

Generic Outputs

Generic outputs are used to control equipment above and beyond what

can be controlled with the HVAC and Refrigeration control schemes.

Typical examples of items controlled by generic outputs include:

parking lot lighting, outdoor sprinkler systems, exhaust fans over

cooktops, anti-sweat heaters on freezer doors, etc.

Programming ACT2 Generic I/O Parameters 9

Generic Output Status Screen

Output Name

As assigned during

parameter setup.

Output Relay

Status

Associated

Sensor

Status

Schedule

Status for Output

OUT1 OUTPUT STATUS

LIGHTS1 ON

SCHED OFF SENS 15

MENU UP DOWN SELECT

Figure 2: Output Status Screen

The Output Status screen is identified by the output number and title in

the first line of the display. The status screen shows the current relay

status of that output, which may be one of the following:

•On: The output is active/used.

•Off: The output is inactive/not used.

•Open: The relay contact for this output is open.

•Closed: The relay contact for this output is closed.

•-On-: The output is overridden and will remain On until either the

override is cancelled or, if the output is set to On Timed, the

override time delay elapses.

•-Off-: The output is overridden and will remain Off until either the

override is cancelled or, if the output is set to Off Timed, the

override time delay elapses.

Associated schedules and sensors are also shown for the output

displayed.

Analog Output Status Screen

ANALOG OUTPUT STATUS

A01 0% SENSOR 0

A02 0% SENSOR 0

BACK SELECT

Current Output

As a percent of total.

Associated

Sensor

Status

Figure 3: Analog Output Status Screen

The Analog Output Status screen is identified by the title in the first

line of the display. The status screen shows the percent of total output

and the associated sensor reading.

I/O Parameters

Procedure Overview

Table 1: Viewing the Status of Generic Inputs and Outputs

To Do This Follow These Steps:

View the Status of a Generic

Input

For a definition of generic inputs,

see the Key Concepts section

Generic Inputs, and for an

explanation of the generic input

status screen, see the Input

Status Screen section.

1. From the Main menu, press the I/O

button.

2. Press the SELECT button so that

OUTPUTS flashes.

3. Use the NEXT button to select INPUTS.

4. Press the PICK button.

5. Press the UP or DOWN button until the

desired input is shown.

6. Press the

MENU button to return to the

Generic I/O menu selections.

View the Status of a Generic

Output

For a definition of generic

outputs, see the Key Concepts

section Generic Outputs, and for

an explanation of the generic

output status screen, see the

Key Concepts section Generic

Output Status Screen.

1. From the Main menu, press the I/O

button.

2. Press the SELECT button so that

OUTPUTS flashes.

3. Press the PICK button.

4. Press the UP or DOWN buttons until the

desired output is shown.

5. Press the

MENU button to return to the

Generic I/O menu selections.

View the Analog Output Status

For an explanation of the analog

output status screen, see the

Key Concepts section Analog

Output Status Screen.

1. From the Main menu, press the I/O

button.

2. Press the

SELECT button so that

OUTPUTS flashes.

3. Use the NEXT button to select AN_OUT.

4. Press the PICK button.

5. Press the BACK button to return to the

Generic I/O menu when finished.

Autres manuels pour PENN ACT2

Table des matières

Autres manuels Johnson Controls Contrôleurs

Johnson Controls

Johnson Controls FX-PCV1615 Manuel utilisateur

Johnson Controls

Johnson Controls M9132-AG -1N Series Manuel utilisateur

Johnson Controls

Johnson Controls M9220-GG-3 Series Manuel utilisateur

Johnson Controls

Johnson Controls JCRL120PW Manuel utilisateur

Johnson Controls

Johnson Controls VA7820-HG*-2 Series Manuel utilisateur

Johnson Controls

Johnson Controls M9116-GG-1N4 Series Manuel utilisateur

Johnson Controls

Johnson Controls FX-PCA2611-0 Manuel utilisateur

Johnson Controls

Johnson Controls TRUE RH HC-67x3 Manuel utilisateur

Johnson Controls

Johnson Controls SE-ZEC510-1 Manuel utilisateur

Johnson Controls

Johnson Controls PENN P70 Series Manuel utilisateur

Johnson Controls

Johnson Controls FW-08 Manuel utilisateur

Johnson Controls

Johnson Controls FEC26 Series Manuel utilisateur

Johnson Controls

Johnson Controls PCA2513 Manuel utilisateur

Johnson Controls

Johnson Controls VA9104-AGA-1S Manuel utilisateur

Johnson Controls

Johnson Controls VFD66 Series Manuel

Johnson Controls

Johnson Controls VA7820-GG-1 Series Manuel utilisateur

Johnson Controls

Johnson Controls T-5800 Series Manuel d'utilisation et d'entretien

Johnson Controls

Johnson Controls FMS-2000C Manuel utilisateur

Johnson Controls

Johnson Controls EDA-8100 Instructions de montage

Johnson Controls

Johnson Controls FX Supervisory Controller RS-485 Card Manuel utilisateur

Johnson Controls

Johnson Controls York 366-70488 Mode d’emploi

Johnson Controls

Johnson Controls M9320-AUA-4 Manuel utilisateur

Johnson Controls

Johnson Controls A25CN Series Mode d’emploi

Johnson Controls

Johnson Controls VMA1930 Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
